DV Gas Insert
739JLN/P (Logs) & 739IRN/P (Rocks)
Installation & Owner’s Manual
This manual contains instructions to install the
ENGINE ONLY. A front is also REQUIRED to
complete this installation. A barrier screen is pro-
vided with the front. Refer to the manual sup-
plied with the front for installation.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪Do not try to light any appliance.
▪Do not touch any electrical switch; do
not use any phone in your building.
▪Leave the building immediately.
▪Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
▪If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
Ce guide est disponible en français sur demande.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
!WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
INSTALLER
Leave this manual
with the appliance.
CONSUMER
Retain this manual
for future reference.
Please read this manual
BEFORE installing and
operating this appliance.

Safety Precautions .................................................3
Safety and Your Fireplace......................................4
Owner’s Information...............................................5
Operating Your Fireplace for the First Time...............5
Cleaning Your Fireplace ............................................ 6
Checking pilot and burner flames .............................. 7
Replacing Batteries ................................................... 7
Using Handset Wall Holder........................................8
Locating Lighting, Operation and Rating Information
Plate........................................................................8
Servicing Your Fireplace............................................ 8
Operating Your Fireplace........................................... 8
How to Turn Your Fireplace OFF (including pilot) ..... 8
How to Ensure Your Fireplace Cannot
Be Turned ON Inadvertently ................................... 8
Remote Control Operation.....................................9
Options..................................................................13
Lighting Instructions............................................14
Warranty ................................................................ 35
Specifications .......................................................15
Overview................................................................16
Dimensions ...........................................................17
Cavity.....................................................................17
Clearances ............................................................18
Venting...................................................................19
Existing Fireplace Preparation............................20
Installation Planning ............................................20
Unpack the appliance .............................................. 21
Installation.............................................................21
Remove Window ..................................................... 22
Install Fan (if used) .................................................. 22
Connect Venting ......................................................23
Connect Gas Supply................................................ 24
Install Liner Panels .................................................. 25
Install Ceramic Logs (739JL)................................... 26
Install Ceramic Rocks (739IR)................................. 28
Refit and Check Window ......................................... 30
Synchronize Remote Control................................... 30
Check Operation...................................................... 31
Adjust Aeration (if necessary).................................. 31
Install Front, Trim and Barrier Screen...................... 31
Install Handset Wall Holder ..................................... 32
Wiring Diagram ..................................................... 33
Approved Venting Components..........................34
Warranty ................................................................ 35
Spare Parts............................................................36
