V&D Electric Bikes Scoot E-3 User manual

Scoot E-3 Instructions

Directory
1. Products and accessories································ 01
2. Instrument description··································02
3. Folding steps············································· 02
4. Operating instructions·································· 03
5. Functional features······································ 04
6. Charger connection····································· 05
7. Safety instructions······································· 06
8. Daily maintenance and maintenance··················07
9. Model parameters······································· 08

1. Products and accessories
Operating instructions
The adapter Hexagon wrench
－１－

1. Instrument description
For your better operation, please read the
instructions carefully.
electricity
Headlight
Switch
1. Operation instructions
speed
Gear position
Gear shift
switchboard
1. Push the button on/off.
2. After starting up, press the headlight switch to turn on the headlight.
3. Switch gears, you can get a 1/2/3 slot
4. When braking, there are mechanical brakes and electronic brakes. Press the brake
signal and stop rotating the motor.
5. Add accelerator down and down momentarily. Loosen and release accelerator.
6. Instrument display table, in the absence of speed is displayed as 00.
7. Brake, but also need to give the rear taillights a signal, lit the rear taillights when the
red light flashing. Let go and breathe out.
－２－

2. Functional features
（1） Fold function；
（2） Headlights lighting function, rear taillights；
（3） Adapter charge function；
（4） Electronics display function: speed；
（5） Gear requirements: 3 gear shift at will, 1 gear for low gear, 3 gear for
high grade；
（6） Power display: 5 power display；
（7）Electronic brake function；
（8）
Mechanical brake function；
（9）Free rotation at 130 degrees；
instrument bell
Speed dial
Front lamp
Hand brake
－３－

5. Charger connection
adaptor
Car port Charging port
Insert charging plug into charging port
Note: please aim the adapter socket at the
charging port and insert again
－４－

6. Folding steps
1、folding：
①Hold the clasp in your hand and pull it out
②Push the front tube down（Pay attention to the position of limit
position）
③Finish folding when you hear "click"
Card buckle
2、clasp：
①The tap is pushed upwards and the snap lock is raised
－５－

7 Safety instructions
It must be worn with helmets and protection
No cycling into motor vehicle driveways and car mixed flow of residential district，Do not drive in
water exceeding 2CM。
No more people riding or hugging children。No riding up or down stairs or escalators，Encounter
deceleration belt, elevator threshold, potholes road surface，Please keep low speed (3 ~ 10KMH) or
stop using and get off the cart。
Electric scooter is a sports entertainment tool not transport，But once you drive it into the public area,
it will also have transport properties, so there are all vehicles there may be a security risk. Following
the instructions of the book, it will protect you and others to the fullest extent.
At the same time, you need to understand that once you drive in a public lane or other public places,
even if you completely follow this manual, you may face the risk of improper driving operation caused
by other people or vehicles. Just like walking or riding a bicycle may be hurt by other means of
transportation; Like all vehicles, the faster you drive, the more distance you need to brake, and
slamming on some smooth surfaces can cause the wheels to slip and lose balance, leading to falls. So it's
very important to be vigilant when you're driving to be at the right speed to be at the right distance
from other people and things. When entering an unfamiliar terrain before the alert and lower speed。
Please respect pedestrians' right of way when driving. Avoid frightening pedestrians, especially children.
Remind pedestrians when passing behind and slow down when passing. As far as possible, pass from
the left side of pedestrians. It is applicable to countries and regions where vehicles drive on the right
side。
Please strictly abide by this manual when driving in regions where there are no national standards and
regulations related to electric scooters. The company shall not be directly or severally liable for any loss
of property or personal injury accidents, legal disputes or any other adverse events causing conflicts of
interest caused by the violation of the use behavior indicated in this manual.
Do not lend your car to people who do not use it to avoid injury. Please be responsible for the safety of
your friend. Please teach your friend before giving it to him and tell him that he must wear safety
protective equipment.
Please carry out basic inspection on the vehicle before each driving. If you find obvious parts loose,
battery life significantly reduced or abnormal parts with excessive wear and tear sound, please stop using
immediately and do not force driving.
Please contact our customer service staff for product maintenance.
-6-

8. Daily maintenance and maintenance
Cleaning and storage
If the car body surface stains, use soft cloth dips in water to wipe a little amount; If the stain is
difficult to clean, use toothpaste on a soft cloth and wipe it with a wet cloth.
Tip: do not use alcohol, gasoline, kerosene or other corrosive, volatile chemical solvent
cleaning, otherwise it will seriously damage the appearance and internal structure of the car. It is
forbidden to use pressure water gun to spray and wash. Please make sure that the power is
turned off and the charging cable has been removed and the rubber cover of the charging port
has been tightened. Otherwise, it may cause electric shock or serious failure due to internal
water inflow.
Do not use, as far as possible to store indoor dry, cool storage, as far as possible to avoid long
time in the outdoor storage. Exposure to sunlight, overcooling, and overheating outdoors can
accelerate appearance and tire aging and reduce battery life.
Battery maintenance
Please don't place the battery in more than 50 ℃ high temperature or below 20 ℃ low
temperature environment (for example, do not keep the battery in the summer sun car) prohibit
put battery into the fire, otherwise may cause the battery failure, overheating, or even the risk of
fire, other battery maintenance note, please refer to the battery brand.
To avoid a full battery drain and recharge, it can be used as a way to prolong the battery life.
When used at room temperature, the battery pack can give play to higher range and performance.
In lower than 0 ℃ environment, battery performance. Under special circumstances, at 20 ℃
environment, half range may only when the normal temperature or lower.
Tip: the battery will run out after 20-50 days of standby when the battery is not fully charged.
When fully charged, the battery runs out about 50 to 90 days after standby. If the battery is not
charged in time after running out of power, it may lead to excessive discharge and damage of
the battery. This damage is not recoverable. The damage caused by not charging for a long time
will not be recharged and will not be covered by the free warranty. (note: non-professionals are
not allowed to disassemble the battery pack at will, otherwise it may cause serious safety
accidents due to electric shock or short circuit)
－７－

9. Product parameters
Body color: black Controller: Liquid crystal
Positive octave
controller
Vehicle weight: 12 KG Electric machine: 450W/350W
brushless motor
Vehicle gross
weight:
15.1KG Braking way: Electronic brakes
and mechanical
brakes
Maximum weight: 120KG Battery type: 18650 lithium
batteries
Packing size: 112*20.5*55.5cm Battery capacity: 6AH/8AH/10AH
Tire size: Before and after
the 8.5 inch
vacuum tyre
Voltage: 36V
Maximum
endurance range:
30-40KM Charging time: 3-4h
Top speed: 25KM/H Driving mode: Rear wheel drive
－８－
/13AH
