VANQ VQ-GLCP Series User manual

Shenzhen VANQ Technology Co., Ltd.
Supplemental Lighting-
VQ-GLCP Series THCMax Bloom Light
Manufacturer：Shenzhen VANQ Technology Co., Ltd.
Address：3#, BLDG B, Debaoli lndustrial park, NO.312, Jihua Road, Longgang, Shenzhen China
Telephone：[phone] Fax：[phone] Email：[e-mail]
Web：www.vanqled.com
Version：2022.10

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
2
CATALOG
1LAMP INTRODUCTION ......................................................................................................................................................3
2THCMAX BLOOM LIGHT INFORMATION AND SPECIFICATION ............................................................................. 3
3THCMAX BLOOM LIGHT TIME SWITCH INTRODUCTION ........................................................................................5
4SIZE AND PACKAGE: .........................................................................................................................................................6
5LAMP CONNECTION PRINCIPLE ................................................................................................................................... 8
6PRECAUTIONS ....................................................................................................................................................................9
7INSTALLATION ...................................................................................................................................................................10
8OPERATION GUIDES TO TIME SWITCH OF THCMAX BLOOM LIGHT ................................................................16
9THC MAX BLOOM LIGHT -UVB BAND LIGHT RADIATION DISTRIBUTION TEST ............................................. 19
10 USE，STORAGE AND DISPOSAL ................................................................................................................................20
11 WARRANTY SERVICES ...................................................................................................................................................20

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
3
VQ-GLCP Series THCMax Bloom light
1Lamp Introduction
1.1 Brief Introduction
Thank you for purchasing VQ-GLCP series lamps. VQ-GLCP series lamps are specially designed for
horticultural auxiliary lighting, in conjunction with VANQ other series grow lighting , aiming to increase THC
content of industrial hemp flowers for indoor planting.
This manual not only introduces the purpose and parameters of lamps, but also introduces the installation
methods of lamps. Please read this manual carefully before installing the lamps and time switch. If you have
any questions, please feel free to contact us.
1.2 Lamp functions and characteristics.
1、Improving photosynthetic efficiency,shortening the flowering cycle;
2、Improving crop quality,increasing THC content,estimated yield up by 20-25%;
3、Reduce fungi,molds and plant pests and maintain a healthy growing environment;
4、Useful for the formation of plant, flowering, fruit coloring and vitamin C;
5、Full range of models, UV only and UV+Far-red different models for customer choices;
6、Optimized optical design, together with main light source use, the even illumination distribution, make
sure high consistency of plant flower growth;
7、Far-red and UV circuits are designed separately, in combination with THCMax bloom lamp timing switch
(two channels and 16 timers) to meet the lighting needs of crops from growth to flowering.
2THCMax Bloom light information and Specification
2.1 Basic Information
Item name THCMax Bloom light
Manufacturer ShenZhen VANQ Technology Co.,Ltd
Waterproof rate Non-waterproof
Size 445Lx 472Wx42H(mm)
Working Temperature -20°C ~ 40°C | -4°F ~ 104°F
Beam angel 120°
Dimmable function No
Warranty 1 Year
In order to simplify the content, in some chapters, THCMax bloom light are abbreviated as lamps.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
4
2.2 Parameter
Model VQ-GLCP-044UF-L VQ-GLCP-044UF-S
Electric
parameter
Rated input voltage 110VAC 50/60HZ 220VAC 50/60HZ
Total Power 44w±5%
Light
Source
Parameter
Far-red
light
Light Source LED
Specification 3535SMD
LED QTY 28PCS
Power 28*1=28W
UV light
Light Source Fluorescent lamp
Specification T5
lamp QTY 2PCS
Power 2*8=16W
Light Spectrum
Net Weight 1.6kg
Features IR and UV light
Manual attention !Can not be used alone, to be connected with the time switch
of THCMax Bloom light,installed onto the main lamps for
application.
Model VQ-GLCP-016UN-L VQ-GLCP-016UN-S
Electric
parameter
Rated input voltage 110VAC 50/60HZ 220VAC 50/60HZ
Total Power 16w±5%
Light
Source
Parameter
UV light
Light Source Fluorescent lamp
Specification T5
lamp QTY 2PCS
Power 2*8=16W
Light Spectrum
Net Weight 1.6kg
Features Only ultraviolet UV light
Manual attention !Can not be used alone,to be connected with the time
switch,installed onto the main lamps for application.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
5
2.3 Order Coding Rules
Item Series Model Input Voltage
VQ-GLCP -044UF：Power 44W included UV and IR light
-016UN：Power 16W included UV,without IR light
-L：110-120VAC
-S：220-240VAC
For example: VQ-GLCP-044UF-S refers to the VQ-GLCP series THCMax bloom light, total power 44W,
including UV and Far-red, input voltage 220-240VAC.
3THCMax bloom light time switch introduction
!THCMax bloom light needs to be connected with the time switch for using, a separate purchase of
lamps or time switch will be unable to work normally.
3.1 Basic Parameters of Time Switch
Name THCMax bloom light time switch
Model VQ-GLCP-DTS8A
Input voltage 85-265VAC 50/60HZ
Timer function two channels timer separately, each channel has 16 independent timers
Size 193L*118W*98H（mm）
Net weight 850g
Switch capacity Single channel 8A
Time control range 1 Minute-168 Hours
Working temperature
-10
°
C
~
40
°
C
|
14
°
F
~
104
°
F
In order to simplify the content, some chapters of THCMax time switch abbreviation for time switch.
3.2 Time Switch Order Code
Controlled lamp series Model Plug type
VQ-GLCP
-DTS8A：D-Dual，T-Timer，
S-Switch，
That is, two-channel time
switch, 8A-single 8A output.
-US：USA type 120VAC 5-15P
-EU：Europe type 220VAC
-UK：United kingdom type 230VAC
-AUS：Australia type 240VAC
-CHA：China Type 220VAC
-XXX：（Japen、Italy...）,etc country type，
The number of digits in XXX shall
be subject to the client needs.
For example: VQ-GLCP-DTS8A-CHA refers to: THCMax bloom light time switch used to control VQ-GLCP

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
6
series lamps, two channels switches, single 8A output, CHINA plug.
4Size and Package
!THCMax bloom light and THCMax bloom light time switch are separately packaged。
4.1 Lamp
1、Lamp size
2、Package ways
Note: Inner Packing A can be shipped directly as standard packing.
L =445mm
W=472mm
H =42mm
W1=66mm
L1=440mm
Inner packing of lamp A:1pcs/box
Gross weight:2.2kg
Net weight:1.6kg
Size A:615L x 200W x 110H(mm)
Package material :Plastic
bag+Foam+Cartons
Outer Packing of lamp
B:12pcs/box
Gross weight:28kg
Size B:630L x 615W x 460H(mm)
Package material:Plastic
bag+Foam+Cartons

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
7
3、Inner Package (A) packing list
A.M3 Screw B. ST4.0Screw C. Mounting bracket D. Source
4.2 THCMax Bloom light time switch
1、Time switch
NO Item Name Specification QTY
A M3 Screws PWM-M3*6，round head cross screwed with medium thread 8
B ST4.0Screws PA-ST4*8，Self tapping screws with round head and cross point tail 4
CMounting bracket Size：472mm*26mm*3.2mm，Stainless steel material 2
DSource Aluminum alloy 6063 radiator，single Fluorescent lamp (UV)light or
LED Far-red(FR) light +Fluorescent UV light 2
L =193mm
W=118mm
H =98mm
L1=160mm
L2=2M

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
8
2、Time switch package
3、Packing List
B.ST4.0 Screw F.Safety Cap E.Time switch
Please check the products and accessories carefully according to the contents of the list. If you find the actual
product does not match the list, or product damaged, please contact us immediately and provide photos or
videos!
5Lamp connection principle
According to the connection principle, customers determine the way of connection and installation of lamps,
choose the number of THCMax Bloom light time switch.
5.1 Connected Principle Diagram
1. THCMax bloom light and time switch are connected as shown in the following diagram. Each time switch is
NO Name specification Quantities
BST4.0 screw
PA-ST4*8，Self tapping screws with round head
and cross point tail
4
FProtective Cover Plastic material, not waterproof function 1
E Time controlled switch two channels, 16groups time switch constrol 1
Time controlled switch
package:1pcs/box
Gross weight: 1.1kg
Net weight: 0.85kg
Size:220L x 170W x 110H(mm)
Package material:Carton

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
9
connected with a number of lamps N ≤20, 1 set time switch can be connected with different types of
lamps(UV/FR/UV+FR).
2. The internal connection principle of THCMax Bloom light and its time switch is shown in the below photo.
The time switch has two time-controlled outputs to control the Far-red light (FR) and the UV light (UV) of the
lamps respectively. The bloom light and the time switch are connected by a 5-core cord.The same to different
bloom lights.
6Precautions
! Please read the following items carefully before you install the product.
6.1 Installation precautions
1. Only certified professionals are able to install the lights;
2. Make sure the power is switched off before installation;
3. Connect cables according to local safety regulations and electrical codes;
4. Time switch and bloom light can’t touch or close to heating objects;
5. The number of bloom lights connect to a time switch can’t exceed 20 units.
6.2 Requirements of working environment
! Our company does not provide warranty service for damage to lights and time switch caused by
improper working environment.
1. The power supply voltage needs to match the input voltage of the lights, and the lights are 110V or 220V
single-voltage input products;

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
10
2. he working temperature cannot exceed the specified range, the working temperature of lights is -20°C ~
40°C, and the working temperature of time switches is -10°C ~ 40°C;
3. Do not use lights and time switches in environments with serious dust pollution;
4. Do not use lights and time switches near flammable and explosive objects;
5. Do not use lights and time switches outdoors;
6. Do not use lights and time switches in environment with water, lights and time switches are not
waterproof.
7Installation
! Bloom lights must be installed to our series grow lights, it can’t work individually. Bloom lights can
work together with VQ-GLMX series, MG-Octopus640 and MG-Octopus800.
7.1 Installation guides to VQ-GLMX series ligh
1. Installation of mounting bracket(c)
Set the mounting holes on the mounting bracket(c) to the screws of heat sink on VQ-GLMX series lights.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
11
2. Fix the bloom lights
Fix the M3(c) screws on the slots of mounting bracket, and lock it to the nuts of groove on the back of
THCMax bloom light, and then the THCMax bloom light and mounting bracket are fixed together.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
12
3. Installation to time switch of THCMax bloom light
Fix the time switch next to the bloom light, make sure the distance can’t exceed 2 meters.
4. Cords connection
Connect the waterproof connectors of time switch and bloom light, and connect the waterproof connectors of
bloom light and VQ-GLMX series lights, finally tighten the threaded cap.The waterproof cords should be
connected above the VQ-GLMX series lights,avoiding to block the light, especially the cords will accelerate
aging after be explored to UV light.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
13
5. Connection to multi VQ-GLMX series lights
Each time switch can connect to max 20 units VQ-GLMX series lights.The distance of Time switch and main
VQ-GLMX series light can’t exceed 2 meters. The distance of VQ-GLMX series light to next one can’t exceed
0.5 meters.
7.2 Installation guides to MG-Octopus640 and MG-Octopus80

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
14
1. Install the THCMax bloom light.
2. Disassemble the power supply from MG-Octopus640/800.
3. Put the Bloom light on the middle of the MG-Octopus640/800 and fix it tightly by screws.
4. Re-assemble the power supply to MG-Octopus640/800, and fix it tightly by screws.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
15
5. Installation time switch of THCMax bloom light. Same to installation of time switch to VQ-GLMX
series.Please refer to 3rd sector in Item 7.1.
6. Cords connection
Connect the waterproof connectors of time switch and bloom light, and connect the waterproof connectors of
bloom light and MG-Octopus640/800 lights, finally tighten the threaded cap.The waterproof cords should be
connected above the MG-Octopus640/800 lights,avoiding to block the lights, especially the cords will
accelerate aging after be explored to UV light.
7. Connection to multi MG-Octopus640/800 lights
Each time switch can connect to max 20 units MG-Octopus640/800 .The distance of Time switch and
main MG-Octopus640/800 can’t exceed 2 meters. The distance of MG-Octopus640/800 to next one can’t
exceed 0.4 meters.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
16
8Operation guides to time switch of THCMax bloom light
8.1 User manual
1. Chinese & English display and button names comparison
2. Lock and unlock of time switch
Only time switch is under unlock status, it is available to operate.
1) Unlock: There is a “ ” icon displayed on the left bottom of the screen. Short press the “ Cancel”
key four times, “ ” icon disappears, the time switch is unlocked.
2) Lock: short press the “ Cancel ” key four times or no operation in 30 seconds, the time switch will
recover to lock status, there is a “ ” icon displayed on the left bottom of the screen.
8.2 Time adjustment
Please make sure the displayed time on time switch is exact same to current time, please adjust it if the
clock is incorrect.
Short press Cancel Key four times to unlock. Press “Hour”, “Min”and “Sec”keys to adjust time switch to
current time and week.
Chinese
星期
开 自动 关 上午 下午
一 二 三 四 五 六 日
English Mo Tu We Th Fri Sa Su ON Auto OFF AM PM
Chinese 取消/恢复 校时 校分 校秒 校星期 定时（设
定
）
时钟 手动/自动 复位
English Cancel Hour Min Sec Week Prog Clock ON/Auto/OFF Reset

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
17
8.3 Instructions
1、Operating Instructions
Procedure Key Function Note
①Press“Cancel”Key Press the "Cancel" Key four times to unlock
②Press“Prog”Key Enter the Timer 1“ON” setting Note 1
③Press“Hour”、“Min”Key Set the specific ON time [hour, minute]
④Press“Week”Key Set repeat cycle from 15 different “repeat modes” Note 2
⑤Press“ON/Auto/OFF”Key Set the Working Channels ON (CH1 Or CH2 Or Both) Note 3
⑥Press“Prog”Key Enter the Timer 1“OFF” setting
⑦Press“Hour”、“Min”Key Set the specific OFF time [hour, minute]
⑧Press“Week”Key
Set repeat cycle from 15 different “repeat modes” （Should be
same as Set of “ON”）
⑨Press“ON/Auto/OFF”Key Set the Working Channels OFF (CH1 Or CH2 Or Both) Note 3
⑩Repeat Operation ①-⑧Set Timer 2/Timers 3...Timers 16 ON/OFF Time （If No
Need,Disable the Timer by setting ON- -/OFF - -）Note 4
⑪Press“Clock”Key Finish Timers Setting，Back to Start-up Screen
⑫Press“ON/Auto/OFF”Key
Press multiple times to switch working modes (Auto) Timer
Enabled/(ON)Timers Disable With Lamps ON or Timers Disabled
With Lamps OFF
Note 5
Note：Note 1 During the operation of the Timer Setting, the timers not work.
Note 2 Press“Week”Key multiple times，you can change different repeat modes.
Note 3 Press“ON/Auto/OFF”Key，Selet the Working Channels (CH1 Or CH2 Or Both).
Note 4
Press “Cancel” Key To Disable the Timer by setting ON- -/OFF - -(Not 00:00),Press”Cancel”Key
again to enable the Timer.
Inspection：Multiple press “Prog” Keys to confirm all setting are correct.
Modification：If any timer is wrong, by pressing “prog” Key to locate the wrong timer,press
“Cancel” key to clear the setting, reset the timer following the instruction.
If all correct,Press“Clock”Key,back to Start-up Screen.
Note 5 Timers Enabled：Unlock the time switch,press “ON/Auto/OFF”Key multiple times to change
modes, If under “Auto” mode，the timers will work normally as setting, if under “ON”mode,both
UV and FR lamps will be on with all timers disabled, if under “OFF” mode,both UV and FR
lamps will be off with all Timers disabled.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
18
2、Examples
Example 1：THCMax Bloom Light Far red and UV should be ON during 19:00-08:00 everyday.
1） Follow procedure ①~⑤，make sure Timer 1 setting as below figure 1a show.
2） Follow procedure ⑥~⑨，make sure Timer 1 setting as below figure 1b show.
1a 1b
3） Follow procedure⑩，disable Timers2,Timers3....Timers 16.
4） Multiple press “Prog” Keys to confirm all setting are correct.If not correct,please repeat 1)-3).
5） Follow procedure⑪，Finish Timers Setting，Back to Start-up Scree.
6） Follow procedure⑫，Make sue the switch under “AUTO” mode.
Example 2：THCMax Bloom Light Far red should be ON during 19:00-08:00 everyday,and UV should be
ON during 09:30-16:30 everyday.
1） Follow procedure①~⑨，make sure Timer 1 setting as below figure 2a,2b show;Timer 2 setting as
below figure 3a,3b show.
2） Follow procedure⑩，disable Timers 3,Timers 4....Timers 16.
2a 2b
3a 3b
3） Follow procedure⑪，Finish Timers Setting，Back to Start-up Scree
4） Follow procedure⑫，Make sue the switch under “AUTO” mode.

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
19
8.4 Time Switch Internal Circuit
9THC Max Bloom Light -UVB band light radiation distribution test
Unit：μW/cm²

Shenzhen VANQ Technology Co., Ltd.VQ-GLCP Series THCMax Bloom Light
20
10 USE，Storage and Disposal
10.1 Precautions for use
1、This lamp contains UV light, and the human body cannot be exposed to the irradiation range for a long
time;
2、When the lamp is working, do not touch the lamp directly; the temperature of the lamp will be high after
working for a period of time, and touching the lamp directly may cause burns;
3、Regularly check the wires of lamps and time switch, and do not use them if they are damaged;
4、When the lamps or time switch are damaged, do not disassemble and repair by yourself. There is high
voltage inside ; VANQ company will no longer provide warranty services after repairs;
5、Do not modify lamps or time switch by yourself. There is a high voltage inside, VANQ company will no
longer provide warranty services after modification;
6、Do not use wet towels or any chemical reagents to clean lamps and time switch, and gently wipe with a
dry duster.
10.2 Storage, Disposal
1、Store in a dry and clean environment, the ambient temperature is -20~75°C;
2、Products can not be disposed as unsorted municipal waste, must be collected separately for disposal,
recycling and environmental friendly.
11 Warranty Services
1、The warranty period is one year. During the warranty period, VANQ will provide free warranty service for
any product quality problem.Warranty services include replacement of new products, replacement of product
parts, and repair of defective products. The method to be adopted is at the discretion of VANQ. If repair is
required, please send the product and invoice back to VANQ.Even VANQ provide warranty service for the
product, the remaining warranty period is still one year from the date of purchase of the original product
2、Warranty services are not provided in the following cases
1）Product damage caused by more than 20 lamps connected to one time switch.
2）Product damage caused by violation of "6.2 Requirements of working environment".
3）Product damage caused by violating 4, 5, 6three points Of"10.1 Precautions for use" .
