Power
This DVR select the adaptor is DC12V; please make sure the power supply voltage before use the machine.
If do not use the machine for a long time, please turn off the power of DVR machine, and let the electric plug
away from power socket.
Safety
This DVR only for indoor use, as for prevent short circuit or electric danger, please do not let the DVR in the
raining or humid area.
In case any solid or liquid inside the case of DVR, please turn off the power immediately, and ask the qualified
technician check it before reboot the DVR;
The DVR is the precision machine, there is nothing for repair by customers themselves in it, when it break
down, please ask the qualified technician to check and repair, or contact with the agents of it.
Installation
Please keep the DVR in level for installation.
Pay attention to equipment ground.
For the first time to install the DVR, please make sure if the hard disk drive install or not.
Prevent to open the case and change the hard disk drive in electrified.
Propose to select the performance of hard disk drive will be 7200 rotating speed person second.
Please select the appropriate installation site, so let the air can be free flow inside the DVR, prevent the
machine overheating.
Please do not install the DVR nearby the radiator, air chute etc. heat source,or where the direct sunlight, too
much dust, or mechanical vibration or attack.
Chapter 1 Products Introduce
1.1 Technical Parameter
Compression standard
H.264 baseline profi[email protected]
Video input
Composite 1.0Vp-p/75Ω,BNC×4/ BNC×8
Video output
Composite 1.0Vp-p/75Ω,HDMI×1, VGA×1
Resolution Preview SDI 1080P（PAL）， 1080P（NTSC）
CIF 352×288（PAL）， 320×240（NTSC）
Recording SDI 1080P（PAL）， 1080P（NTSC）
CIF 352
×
288
（
PAL
），
320
×
240
（
NTSC
）
Frate rate Preview/ recording
4ch 100fps(PAL), 120fps(NTSC
8ch 200fps(PAL), 240fps(NTSC)
Audio input
-8dB~22k,RCAx4(4ch)
Audio output
-8dB~92dB,RCAx1
Audio decode
ADPCM
Alarm input Input low level alarm, user setting normal open or normal close, Varies
according to the model
Alarm output 1ch output; Varies according to the model
Recording mode Manual recording, timing recording , motion detection recording and external
alarm recording
Simplex/duplex/ triplex
triplex(recording, playback , LAN transmission)

LAN
RJ45(10M/100M self-adapting)
PTZ control
Yes
Communication
RS485×1
，
USB2.0×2
USB
USB mouse control
Hard disk drive
4x SATA
（
4TB or bellow
）
Remote control unit
Yes
Dimension
Main board size : 230mm x 110mm
Power supply
AC110-230V
1.2 Performance
Real-time
monitoring
Turn-by-turn analog video output and
VGA interface, according to TV monitor
or VGA monitor to live view in 1/4/8/9 or
more video channel to monitoring the
recording streaming and the record file
capacity in Every hours every channel, to
presentation the status of video channel,
recording, dynamic detection, video loss,
monitoring lock-
up. You can view the
system log in local DVR.
Storage
function
Internal 4 SATA interface, MAX
4TB hard disk drive, the file of hard disk
drive include cover mode circulation
recording and none cyclical recording,
the storage data to use the proprietary
format, can not falsify the data, make
sure the data safety.
Compression
format
Video compression format:: H.264
Support 8ch video and audio signal,
video and audio maintaining stability in
synchronous.
Backup
function
Through USB interface to backup. ( for
example USB drive and mobile hard
disk drive etc.) The video file can be
downloaded by Client software through
LAN to laptop hard disk drive.
Recording
and
playback
function
* Multiplex, to achieve real time recording
to be independent at the same time to
single channel playback, research and
backwards, network monitoring, network
search download etc.
* Multiple recording mode: Manual,
normal, alarm, linkage, dynamic
detection recording etc. turn-by-turn
pre-recording function.
* Can playback the record file in DVR
through network, to achieve quick-search
the recording file and recording type,
multiple playback type: SLOW, Fast
Forward, Backwards, step Forward.
Display the exact time of event occurred
while recording file playback.
Network
Operation
function
* through network to real time remote
monitoring;
* PTZ control
* recording research and real time
playback;
* system setting parameter modify and
the system software upgrade;
* remote monitoring alarm process and
view the system log message;
* to use embedded TCP/IP protocol and
Embedded Operation System, can
access the DVR through client software
program bundle in the package;
*Management Model: use enhancement
user management, password mode to
make sure the valid user to login the
system, flexible convenient and fast to
set the different permission user
requirement.

Alarm
linkage
function
4ch alarm input (alarm event mode can
be set normal open or normal close
selection), and turn-by-turn video loss
alarm, dynamic detection alarm, the
alarm device may be smoke detection
censer, temperature
detector, IR
detector. Possess 4ch relay switch
alarm output, flexible convenient and
fast to achieve alarm linkage and
lighting control at site.
They’re possess protective circuit in
Alarm input and alarm output port,
make sure the device not to damaged.
Communication
port
* Possess specific interface, achieve
alarm input and PTZ control;
* possess a standard Ethernet interface,
achieve the ne
twork remote
monitoring.
PTZ
control
* Support PTZ decoder through RS485
communicate
* scalable multiple decoder protocol,
easy to achieve to control the pan
driver and speed dome camera
function.
Intelligent
operation
* mouse operation function;
* In menu for same setting and to
process shortcut copy operation
Chapter 2 Hardware
2.1 H.264 standalone 4CH/8CH/16CH
2.1.1 Hard disk Installation
For the first use, please install the hard disk
○
1E
ARemove the screws on both A○
2E
Aextracted from the next cover up A○
3E
Aconnect hard disk and mother board
sides of shell
A○
4E
Afix the screw of hard disk A○
5E
Aclose cover A○
6E
Ainstall the screws on both sides of shell

2.1.2 Rear panel
4CH
Item
Interface
Description
1
VIDEO-IN
4ch video input
2
AUDIO IN
4ch audio input
3
HD-OUT
HDMI output
4
A/V OUT
AUDIO and VIDEO output
5
VGA
VGA monitor
6
NETWORK
RJ45 for internet
7 USB First USB for backup or upgrade system of DVR; Second
USB for mouse
8
ON/OFF
Power supply switcher
9
DC-12V
Power adaptor port
10
ALARM IN：1 2 3 4 alarm input port
RS-485：A, B
ALARM OUT: N1 alarm output port, every channel connect
GND、OUT、COM;
every two channel OUT, COM port is for GND;
8CH
Item
Interface
Description
1
VIDEO-IN
8ch video input
2
AUDIO IN
8ch audio input
3
HD-OUT
HDMI output
4
VGA
VGA monitor

5
NETWORK
RJ45 for internet
6 USB First USB for backup or upgrade system of DVR; Second
USB for mouse
7 ON/OFF Power supply switcher
8
DC-12V
Power adaptor port
9
ALARM IN：1 2 3 4 alarm input port
RS-485：A, B
ALARM OUT: N1 alarm output port, every channel connect
GND、OUT、COM;
every two channel OUT, COM port is for GND;
16CH
Item
Interface
Description
1
VIDEO-IN
8ch video input
2
AUDIO IN
8ch audio input
3
HD-OUT
HDMI output
4
VGA
VGA monitor
5
NETWORK
RJ45 for internet
6 USB First USB for backup or upgrade system of DVR; Second
USB for mouse
7 ON/OFF Power supply switcher
8
DC-12V
Power adaptor port
9
ALARM IN：1 2 3 4 alarm input port
RS-485：A, B
ALARM OUT: N1 alarm output port, every channel connect
GND、OUT、COM;
every two channel OUT, COM port is for GND;
2.1.3 Alarm input port
4chanel alarm input, the mode of alarm input is no restriction (possible is normal open also normal close);
The GND alarm detector connect to COM under parallel connection (the power of alarm detector supply by
external power supply;
The ground terminal of alarm detector join-up in parallel with DVR;
The NC of alarm detector connect with the input end (alarm) of DVR;
When you want to reset the remote alarm of triggered , the +12V power supply of alarm detector supply by DVR,

for example, smoke detector.
When you select the external power supply, please share the GND with DVR;
Alarm input circuit:
Alarm inlet connection:
2.1.4 Alarm output port
4 way switching value alarm output, selectable in normally open contact, also selectable in
normally closed
contact, the external
alarm device should
be need VCC;

Chapter 3 Operation
3.
１
Operation instruction
3.1.1 Remote control AND Front panel keypad
Table
：
S/
N
Keypad
Name
Operating
instruction
S/
N
Keypad
Name
Operating
instruction
1
【
】Power ON/OFF 13 【ENTER 】
【OK】
This button is used as “ enter ”
and “ ok ” key in most
circumstances
2 【REC】To mode of recording

3
【MENU】
Access main menu
4 【ESC】
Exit operation or enter upper
menu
Close soft keyboard
Close current window
Exit from current control
Return to last menu
Exit from PTZ control under
preview state
14 【PTZ】Access/exit from PTZ control
under preview state
5 【 】 Switching of 1/4/8/9 Preview
mode 15 【+/-】
Volume or number
increase/reduction Select item
of the list
6 【FN】Short cut 16 【ZOOM/ ▲
/▼】 Lens control
7
【】
Slow playback,1/2×, 1/4×,
1/8× and single frame play 17 【FOCUS/
▲/▼】
Aperture control
8
【】
Fast playback, 2×,4× and 8×
playback
18 【0~9 10+】
Digital input Corresponding;
Channel is magnified in full
screen under preview state
19 【】delete
20 【--】Single and double switch
9
【 】 Playback stop 21 【 】 Mute sound
【 】 Play / Pause
22 【Display
】Display setup
【▲.▼.
】
Four-way to move the focal
point in main menu, up and
down to move in the normal
window, to control pan driver
to move in
the PTZ control windows
【 】 Speed normal 23 【Backup】backup
10
【
WIZARD】The wizard menu 24 【SEQ】start/stop SEQ display
11
【
DEV】
Selection of equipment, such
as modify the address of
remote control
25
【ALARM】 Alarm reset
12
【
SEARCH】Search for playback time
choosing
26 【CLEAR】Clear alarm
3.1.2 How to use mouse of DVR (for right hand mouse)
1 Left key single click To any function menu icon click the mouse left key into the menu
To run the control point out operation
