Operang this equipment:
To place your press into service —
1.) Follow the assembly instrucons on pages 4 through 12.
To operate your press —
1.) Clamp your rst screen into head #1.
2.) Repeat for addional screens, using addional heads.
3.) Place garment in pallet #1.
4.) Lower print head and squeegee ink through screen.
5.) Raise print head. For one-color prinng, load new, blank garment and repeat steps above.
6.) For mul-color prinng, rotate the pallet to print head #2 and repeat steps above unl all colors are printed.
7.) If any adjustments to the print heads need to be made, refer to the instrucons in this manual.
Safe handling, transport, and storage of the press:
Your press is designed to be inherently safe under all normal condions. When handling or transporng your
press, be aware of the weight of your unit and have an appropriate number of people to li the weight safely:
V100-11: 65lb (29.5kg) V100-44: 132lb (59.9kg)
In the event of an accident or breakdown:
In the unlikely event that a part of your press breaks, or if your press does not seem to be operang normally and
the instrucons in this manual do not correct the issue, do not connue using your press. Contact Vastex for as-
sistance in repairing your press.
Safety during maintenance or while making adjustments:
When cleaning or lubricang your press, make sure that nobody in the work area is close enough to cause
any part of the press to move unexpectedly.
Do not remove springs unless under the specic direcon of Vastex customer service.
Observe the general safety cauons on page 2 of this manual.
Placing this equipment into service:
Stability during use, transportaon, assembly, foreseeable breakdowns, etc.:
This equipment is designed and expected to be stable during all normal condions of use.
When assembling your press, do not stand tall parts upright unl you are ready to install them; lay them at
instead.
It is recommended that assembly should be done by two or more people, to facilitate the alignment of parts
that must be bolted together.
If one or more legs of the press will be removed, be certain to adequately support the rest of the press.
