VAT 650 Series Assembly instructions

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 1/86
Pendulum control & isolation valve
with CC-Link interface
with valve cluster functionality
This manual is valid for the valve ordering number(s):
65051-JAWL-0001
configured with firmware 650C.1E.15
The fabrication number is indicated on each product as per the label
below (or similar):
made in Switzerland
Fabrication No.:
650
..
–
....
–
..../....
A
–
. ... ..
Fabrication number
sample picture
Explanation of symbols:
Read declaration carefully before you start any other
action!
Keep body parts and objects away from the valve
opening!
Attention! Hot surfaces; do not touch!
Product is in conformity with EC guidelines,
if applicable!
Loaded springs and/or air cushions are potential
hazards!
Disconnect electrical power and compressed air
lines. Do not touch parts under voltage!
Wear gloves!
Read these «Installation, Operating & Maintenance Instructions» and the enclosed «General
Safety Instructions» carefully before you start any other action!

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 2/86
Imprint
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Manufacturer
Website
www.vatvalve.com
Phone
[phone]
Fax
[phone]
Email
[e-mail]
Publisher VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Editor VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Print VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Copyright © VAT Vakuumventile AG 2010
No part of these Instructions may be reproduced in any way (photocopies, microfilms or any
other reproduction processes) nor may it be manipulated with electronic systems, duplicated or
distributed without written permission from VAT. Offenders are liable to pay damages.
The original VAT firmware and updated state of the art versions of the VAT firmware are
intended for use with VAT products. The VAT firmware contains a limited, time unlimited user
license. The VAT firmware may not be used for purposes other than those intended nor is it
permitted to make copies of the VAT firmware. In particular, it is strictly forbidden to give
copies of the VAT firmware to other people.
The use of trade names, brand names, trademarks, etc. in these Instructions does not entitle
third parties to consider these names to be unprotected and to use them freely. This is in
accordance with the meaning of the laws and acts covering brand names and trademarks.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 3/86
Contents:
1Use of product .......................................................................................................................................................... 5
1.1 Technical data ................................................................................................................................................. 5
2Installation................................................................................................................................................................. 7
2.1 Unpacking........................................................................................................................................................ 7
2.2 Installation into the system .............................................................................................................................. 7
2.3 Tightening torque............................................................................................................................................. 9
2.3.1 Mounting with centering rings............................................................................................................ 10
2.3.2 Mounting with O-ring in grooves........................................................................................................ 10
2.4 Admissible forces........................................................................................................................................... 11
2.5 Requirements to sensor connection.............................................................................................................. 11
2.6 Electrical connection...................................................................................................................................... 12
2.6.1 Ground connection............................................................................................................................ 12
2.6.2 Sensor supply concepts.................................................................................................................... 13
2.6.3 Power and sensor connection (±15 VDC sensors) using SPS module............................................. 14
2.6.4 Power connection for Slave valve only.............................................................................................. 15
2.6.5 CC-Link interface connection ............................................................................................................ 16
2.6.6 LOGIC I/O.......................................................................................................................................... 22
2.6.7 Digital input........................................................................................................................................ 23
2.6.8 Digital output ..................................................................................................................................... 23
2.6.9 Service port connection..................................................................................................................... 23
2.6.10 Valve cluster connection ................................................................................................................... 24
3Operation................................................................................................................................................................ 27
3.1 Introduction.................................................................................................................................................... 27
3.1.1 Individual valve control...................................................................................................................... 28
3.1.2 Individual valve status ....................................................................................................................... 28
3.1.3 Freeze mode ..................................................................................................................................... 28
3.1.4 Position offset.................................................................................................................................... 28
3.1.5 Local operation.................................................................................................................................. 29
3.1.6 Remote operation.............................................................................................................................. 29
3.1.7 Safety mode ...................................................................................................................................... 30
3.1.8 Service indication .............................................................................................................................. 30
3.2 Operation under increased temperature........................................................................................................ 30
3.3 Behavior during power up.............................................................................................................................. 30
3.4 Behavior in case of power failure................................................................................................................... 31
3.5 Display information ........................................................................................................................................ 32
3.5.1 CC-Link LEDs.................................................................................................................................... 34
3.6 Setup procedure ............................................................................................................................................ 35
3.6.1 Cluster address configuration............................................................................................................ 35
3.6.2 CC-Link configuration........................................................................................................................ 39
3.6.3 Valve and sensor configuration......................................................................................................... 44
3.6.4 ZERO................................................................................................................................................. 46
3.6.5 LEARN............................................................................................................................................... 47
3.7 Close valve .................................................................................................................................................... 48
3.8 Open valve..................................................................................................................................................... 48
3.9 Position control .............................................................................................................................................. 49
3.10 Pressure control............................................................................................................................................. 49
3.10.1 Tuning of control performance........................................................................................................... 50
3.11 CC-Link interface connection setup............................................................................................................... 54
3.11.1 CC-Link Handshaking........................................................................................................................ 54
3.11.2 Location of the handshaking bits....................................................................................................... 55
3.11.3 Example of the handshaking by a PLC-program...............................................................................56
3.12 CC-Link interface (Process data – cyclic communication)............................................................................. 57
3.12.1 OUTPUT Buffer (Master PLC)........................................................................................................... 57
3.12.2 INPUT Buffer (Master PLC)............................................................................................................... 62
3.12.3 Communication and timing control between Master (PLC) and Station (Valve)................................ 69
3.12.4 PRESSURE and SENSOR READING allocation .............................................................................. 70

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 4/86
4Trouble shooting..................................................................................................................................................... 71
4.1 Additional CC-Link warning............................................................................................................................ 73
5Maintenance & repairs............................................................................................................................................ 74
5.1 Maintenance procedures ............................................................................................................................... 75
5.2 Option board.................................................................................................................................................. 81
5.2.1 Durability of power fail battery........................................................................................................... 81
5.2.2 Retrofit / replacement procedure....................................................................................................... 82
6Warranty................................................................................................................................................................. 86

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 5/86
1 Use of product
This product is a throttling pendulum valve with isolation functionality. It is intended to use for downstream pressure
control applications.
Use product for clean and dry indoor vacuum applications under the conditions indicated in chapter «Technical data» only!
Other applications are only allowed with the written permission of VAT.
1.1 Technical data
Control and actuating unit
Input voltage 1) +24 VDC (±10%) @ 0.5 V pk-pk max. [connector: POWER]
Power consumption 96 W [connector: POWER]
Sensor power supply output 2) ±15 VDC (±5%) / 1000 mA max. [connector: SENSOR]
Sensor input
Signal input voltage / Input resistance
ADC resolution
Sampling time
0-10 VDC / Ri>100 k(linear to pressure)
0.23 mV
10 ms
[connector: SENSOR]
Digital inputs 3) ±24 VDC max. [connector: INTERFACE]
Digital outputs 3)
Input voltage
Input current
Breaking capacity
70 VDC or 70 V peak max.
0.5 ADC or 0.5 A peak max.
10 W max.
[connector: INTERFACE]
Analog outputs 3) (optional) 0-10 VDC / 1 mA max. [connector: INTERFACE]
PFO4) battery pack
Charging time
Durability
2 minutes max.
up to 10 years @ 25°C ambient
refer to «Durability of power fail battery» for details
Compressed air supply
4 - 7 bar / 55 - 100 psi (above ATM)
Ambient temperature 0 °C to +50 °C max. (<35 °C recommended)
Pressure control accuracy 0.1% of sensor full scale
Position resolution / position control capability 13422 (full stroke)
Closing time throttling only 1.3 s typ.
Opening time throttling only 1.3 s typ.
Closing time throttling & isolation 5 s typ.
Opening time throttling & isolation 6 s typ.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 6/86
1) Internal overcurrent protection by a PTC device.
2) Refer to chapter «Sensor supply concepts» for details.
3) Refer to chapter «Schematics» for details.
4) PFO = Power Failure Option. Refer to «Behavior in case of power failure» for details.
Valve unit
Pressure range at 20°C 1 x 10E-8 mbar to 1.2 bar (abs)
Leak rate to outside at 20°C 1 x 10E-9 mbar l/s
Leak rate valve seat at 20°C 1 x 10E-9 mbar l/s
Cycles until first service
- Isolation cycles (open - closed - open)
- Throttling cycles (open - max. throttle - open)
200’000 (unheated and under clean conditions)
1’000’000(unheated and under clean conditions)
Admissible operating temperature 10°C to +150°C
Mounting position horizontally only (valve seat to face chamber is recommended)
Wetted materials
body Aluminium AA6082 (3.2315)
pendulum plate Aluminium AA6082 (3.2315)
sealing ring Aluminium AA6082 (3.2315) 3.2315 (AA6082), 1.4306 (304L)
Other parts Stainless steel 316L (1.4404 or 1.4435), 1.4122, 301 (1.4310),
304 (1.4303), 1.4571, A2 (304)
Seals body Viton
plate Viton
rotary feedthrough atmosphere side Viton
rotary feedthrough vacuum side Viton
shaft feedthrough atmosphere side Viton
shaft feedthrough vacuum side Viton
bonnet Viton
Max. differential pressure on plate during isolation 1200 mbar in either direction
Max. differential pressure on plate
during opening and throttling
5 mbar
Min. controllable conductance
(N2molecular flow)
25 l/s
Dimensions Refer to dimensional drawing of specific valve ordering number
(available on request)

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 7/86
2 Installation
2.1 Unpacking
As this valve is a heavy component you should lift it with adequate equipment to prevent any injury to
humans.
Valves DN200 (8”) and larger are equipped with attachment points (tapped holes). Add eyebolts to
these attachment points for lifting. The attachment points are indicated on the dimensional drawing of
the specific valve part number (available on request).
Never lay the valve down with control and actuating unit downwards as it may be damaged.
2.2 Installation into the system
Connectors at controller panel:
Connection overview:
Fingers and objects must be kept out of
the valve opening and away from moving
parts.
The valve plate starts to move just after
power is supplied.
Do not connect or disconnect sensor cable
when device is under power.
Do not disconnect air supply when device is
under power.
Compressed air pressure must be in the range
of: 4 - 7 bar / 55 - 100 psi (above ATM).
Use only clean, dry or slightly oiled air.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 8/86
1. Install valves [1] into the vacuum system. Valve seat side should face process chamber. The valve seat side is
indicated by the symbol "∇" on the valve flange.
Caution: Do not tighten the flange screws stronger than indicated under «Tightening torque».
Caution: Do not admit higher forces to the valve than indicated under «Admissible forces».
Note: Make sure that enough space is kept free to do preventive maintenance work. The required space is indicated
on the dimensional drawing.
2. Connect compressed air supply to connection labeled ‘IN’ located at actuator, see Figure 1 below.
Connect compressed air return line connection labeled ‘OUT’ located at actuator, see Figure 1 below.
Caution: Compressed air pressure must be in the range of: 4 - 7 bar / 55 - 100 psi (above ATM).
Note: Use only clean, dry or slightly oiled air. IN / OUT connections are 1/8“ ISO/NPT internal threads.
3. Install the ground connection cable at controller. Refer to «Electrical connection»
4. Install pressure sensor(s) [2] according to the recommendations of the sensor manufacturer and directives given
under
«Requirements to sensor connection».
5. Connect sensor cable [3] to sensor(s) and then to Master valve (connector: SENSOR).
Refer to chapter «Electrical connection» for correct wiring.
Note: 65051-JAWL-0001 supports 1 sensor(s).
6. Connect Master valve to CC-Link [4] (connector: INTERFACE). Refer to «CC-Link schematics» for correct wiring.
7. Enable terminating resistor in link adapter of first and last valve in the system. Refer to «Valve cluster connection» for
details.
8. Connect link cable [6] between Slave valve(s) and Master valve (link adapter). Refer to «Valve cluster connection» for
correct wiring.
9. Connect power supply [5] to each valve (connector: POWER). Refer to chapter «Electrical connection» for correct
wiring.
Note: To provide power to the valve motor pins 4 and 8 must be bridged, otherwise motor interlock is active and the
valve enters the safety mode and is not operative. Refer also to «Safety mode».
MasterSlave
[6] Link cable
[6] Link to next Slave

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 9/86
10. This valve has a double sealed rotary feedthrough and optionally an intermediate pumping port for the actuator shaft.
This port (1/8“ ISO/NPT) could be connected to the vacuum line, see Figure 2 below.
11. These valves may optionally be equipped with a heating device. Connect VAT heating device according to manual of
respective heating device.
12. Perform «Setup procedure» to prepare valve cluster for operation.
Note: Without performing the setup procedure the valve cluster will not be able to do pressure control.
Fig. 1 Fig. 2
2.3 Tightening torque
Note:
The torque values below are dependent on many factors, such as materials involved, surface quality, surface treatment,
and lubrication.
intermediate
pumping port
IN
OUT

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 10/86
The torques below are valid if immersion depth of the mounting screws is at least once the thread diameter (min. 1d), and
the friction coefficient of the screw-flange connection (µtotal = (µscrew thread-helicoil + µunder screw head)/2) is bigger than 0.12. Lower
friction coefficients may damage the valve, as the resulting preload force gets too high. Therefore for other friction
coefficients the torque needs to be adapted. Please review design guidelines for Helicoil-Screw connections and make
sure that screws in use are capable to withstand applied torques, are appropriate for the application and are not too long.
Too long screws may damage the valve, the immersion depth should not exceed (hole depth – 1 mm).
Tighten mounting screws of the flanges uniformly in crosswise order. Observe the maximum torque levels in the following
tables.
2.3.1 Mounting with centering rings
ISO-F ISO-F
max. tightening torque
(Nm) max. tightening torque (lbs . ft)
n/a n/a
hole depth (mm) hole depth (inch)
n/a n/a
Refer to «Spare parts / Accessories» for centering rings ordering numbers.
2.3.2 Mounting with O-ring in grooves
ISO-F JIS ASA-LP
ISO-F JIS ASA-LP
max. tightening torque
(Nm) max. tightening torque (lbs . ft)
n/a 65-70 n/a n/a 48-52 n/a
hole depth (mm) hole depth (inch)
n/a n/a

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 11/86
2.4 Admissible forces
Forces from evacuating the system, from the weight of other components, and from baking can lead to deformation and
malfunctioning of the valve. Stress has to be relieved by suitable means, e.g. bellows sections.
Axial tensile or
compressive force «FA»
Bending moment «M»
N lb. Nm lbf.
3500 770 140 105 F
A
M
For a combination of both forces (FAand M) the values are invalid.
Verify that the depth of the mounting screws is min. 1 x thread diameter.
Please contact VAT for more information.
2.5 Requirements to sensor connection
To achieve fast and accurate pressure control a fast
sensor response is required.
Sensor response time: < 50ms
The sensor is normally connected to the chamber by a
pipe. To maintain that the response time is not degraded
by this connection it needs to meet the following
requirements:
Inner diameter of connection pipe: > = 10 mm
Length of connection pipe: < = 300 mm
These conductance guidelines must include all valves
and limiting orifices that may also be present.
Make also sure that there is no obstruction in front of
sensor connection port inside the chamber.
The sensor should also be mounted free of mechanical
shock and vibration.
Dynamic stray magnetic fields may introduce noise to
sensor output and should be avoided or shielded.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 12/86
2.6 Electrical connection
2.6.1 Ground connection
Recommendation for ground strap between controller and system (chassis)
Material L (Length max.) B1 (min.) B2 (min.) d1 (∅) d2 (∅)
copper tinned 200 mm 25 mm 25 mm 4.5 mm customized
Note: Connection plates of ground strap must be total plane for a good electrical contact!
Note: The connection point at chassis (PE) must be blank metal (not coated).
It is also possible to connect the ground strap at system chamber if it is well connected to PE.
Note: Avoid low chassis cross section to the system PE connection. (Min. same cross section as ground strap)
d1
B1
Controller Master Controller Slave(s)
Recommendation
ground connection
Slave: AWG 12
(3mm2)
System
Chassis (PE)
(Protective Earth)
B2
d2
L
Ground strap PE

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 13/86
2.6.2 Sensor supply concepts
This valve has a built in sensor power supply (SPS). It supplies ±15 VDC. The sensor can be supplied by two different
concepts (see below).
Concepts:
•External + 24 VDC supplied to POWER connector is feed through to SENSOR connector to supply 24 VDC
sensors. Refer to chapter «Power and sensor connection (+24 VDC sensors)» for schematic and correct wiring.
•External + 24 VDC supplied to POWER connector is converted into ±15 VDC by the valve internal SPS and
supplied to SENSOR connector to supply ±15 VDC sensors. Refer to chapter «Power and sensor connection
(±15 VDC sensors) with optional SPS module» for schematic and correct wiring.
Valve versions:
•650 . . - . . V. - . . . . / 650 . . - . . W. - . . . . SPS module included
•650 . . - . . . S- . . . . slave valve, no sensor connection
Note: The SPS module can be retrofitted. Refer to chapter «Retrofit / replacement procedure» for instruction.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 14/86
2.6.3 Power and sensor connection (±15 VDC sensors) using SPS module
[650 . . - . . V. - . . . . / 650 . . - . . W. - . . . . versions only]
Note:
•Use shielded sensor cable(s). Keep cable as short as possible, but locate it away from noise sources.
•Connect the ±15 VDC sensors at DB–15 female sensor connector exactly as shown in the drawing above. Do not
connect other pins that may damage sensor, power supply or controller!
•Connector: Use only screws with 4-40UNC thread for fastening the connectors!
Pins 4 and 8 must be bridged for operation!
An optional switch would allow for motor interlock
to prevent valve from moving.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 15/86
2.6.4 Power connection for Slave valve only
[650 . . - . . . S- . . . . or valves configured as slave]
Note: Do not connect other pins as shown above, that may damage power supply or controller!
Connector: Use only screws with 4-40UNC thread for fastening the connectors!
Pins 4 and 8 must be
bridged for operation!
An optional switch would allow
for motor interlock to prevent
valve from moving.

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 16/86
2.6.5 CC-Link interface connection
2.6.5.1 CC-Link cable installation (example)
PE = Protective Earth
= Connector housing
PE PE
= Internal connection between «SLD and FG»
Note: The valve can be defined as «first station», «…stations…» between first and last, or «last station».
If the valve at first or last station, «TR» must be installed between 1 (DA) and 2 (DB).
Note: The station type for VAT valves are: Version 2 Remote Device Station.
TR = Terminal resister (Must be compatible to used CC-Link cable version!)
first station … stations … last station
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 17/86
2.6.5.2 Preparing CC-Link connector
Description Required tool
1. Remove «COMBICOM» connector (A) at
valve controller
sample picture
2. Prepare all parts of connector for
installation
Note: All parts of connector are
supplemented in a plastic bag (407612),
except «COMBICOM» connector from valve
controller
2.6.5.3 CC-Link connector overview
A COMBICON D Strain-relief screw for shield mesh and cable
B CC-Link wires E Connector housing VAT
C Shield mesh F CC-Link cable
A
B C D
A
E
D
E
F C

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 18/86
2.6.5.4 Install CC-Link cable at valve controller
Description Required tool
3. Remove the cable coat carefully
Cable Pos. A, xabout 30mm
Cable Pos. B, x about 40mm
Note: Pos. see step 8
Knife
4. Cut off the shield wire
Side-cutting pliers
5. Cut off the aluminum shield and remove it Side-cutting pliers
6. Cut off the plastic and remove it
Note:
Take care to the wires. Do not damage the
isolation of wires!
Side-cutting pliers
7. Cut off the shield wires about 15mm
8. Separate the shield wires in two equal
quantum and place them 180° opposite
Side-cutting pliers
15mm
x

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 19/86
Description Required tool
9. Remove the wire coat carefully about 5mm Wire strippers
10. Insert the cable(s) at connector hosing as
shown in the pictures, see also chapter CC-
Link connector
Note:
If valve in CC-Link network is at «first or last
station» install the CC-Link cable at position
A and close B with blind plug C.
If valve in CC-Link network at
«…stations…» install the CC-Link cables at
position A and B.
11. Fasten the strain-relief screw until the cable
can not pulled out by manual force
Screw driver
size 4
5mm
Shield
Pos. A
Pos. B
C

Installation, Operating & Maintenance Instructions
Series 650 DN 350 (I.D. 14”), CC-Link
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel [phone] Fax [phone] [email protected]om www.vatvalve.com 286241EA
2010-10-11 20/86
Description Required tool
12. Install the CC-Link wires, see also
«Connector type» table below
Note:
If cable at pos. A (first or last station) install
«TR» between 1 and 2
1 x blue to 1
1 x white to 2
1 x yellow to 3
If cables at pos. A + B (…stations…) install
2 x blue to 1
2 x white to 2
2x yellow to 3
Screw driver
size 1
13. Close the cover of connector and fasten the
screws a little
Pozidriv screw driver
size 2
14. Connect the connector and fasten it with the
screws at controller (sample picture)
Allen Wrench
2.5 mm
15. Push the cover down to controller and
fasten the cover screws (sample picture)
Pozidriv screw driver
size 2
A
