VAT 12150-PA24 ISO-320 Assembly instructions

Installation, Operating &
Maintenance Instructions
600968EA
Edition
2015
-
11
-
16
Vacuum gate valve
with double acting pneumatic actuator
Series 121
DN 63 – 320 mm (I. D. 2½" – 12")
This manual is valid for the following product ordering numbers:
121 .. - .... - ....
Sample picture

Series
121
2
/
27
Edition
2015
-
11
-
16
600968EA
Imprint
Manufacturer
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Website:
Phone:
Fax:
Email:
www.vatvalve.com
[phone]
[phone]
[email protected]
Publisher VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Editor VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Print VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Copyright © VAT Vakuumventile AG 2015
No part of these instructions may be reproduced in any way (photo-
copies, microfilms or any other reproduction processes) nor may it be
manipulated with electronic systems, duplicated or distributed without
written permission from VAT. Offenders are liable to pay damages.
The original VAT firmware and updated state of the art versions of the
VAT firmware are intended for use with VAT products. The VAT firmware
contains a limited, time unlimited user license. The VAT firmware may not
be used for purposes other than those intended nor is it permitted to
make copies of the VAT firmware. In particular, it is strictly forbidden to
give copies of the VAT firmware to other people.
The use of trade names, brand names, trademarks, etc. in these
Instructions does not entitle third parties to consider these names to be
unprotected and to use them freely. This is in accordance with the
meaning of the laws and acts covering brand names and trademarks.

Series 121 DESCRIPTION OF PRODUCT
600968EA
Edition
2015
-
11
-
16
3
/
27
Contents
1 Description of product........................................................................4
1.1 Identification of product.......................................................................................4
1.2 Use of product.....................................................................................................4
1.3 Related documents.............................................................................................4
1.4 Important information..........................................................................................4
1.5 Technical data.....................................................................................................4
2 Safety ...................................................................................................5
2.1 Compulsory reading material..............................................................................5
2.2 Danger levels......................................................................................................5
2.3 Personnel qualifications......................................................................................6
2.4 Safety labels........................................................................................................6
3 Design and Function...........................................................................7
3.1 Design.................................................................................................................7
3.2 Function ..............................................................................................................7
4 Installation...........................................................................................8
4.1 Unpacking ...........................................................................................................8
4.2 Installation into the system..................................................................................8
4.2.1 Admissible forces and bending moments.............................................10
4.3 Compressed air connection ..............................................................................11
4.4 Electrical connection.........................................................................................11
5 Operation...........................................................................................12
5.1 Normal operation...............................................................................................12
5.2 Operation under increased temperature...........................................................12
5.3 Behavior in case of compressed air pressure drop ..........................................12
5.4 Behavior in case of power failure......................................................................12
5.4.1 Manual emergency operation...............................................................13
5.5 Trouble shooting ...............................................................................................14
6 Maintenance ......................................................................................15
6.1 Maintenance intervals.......................................................................................15
6.2 Tightening torque specifications .......................................................................16
6.3 Required tools...................................................................................................16
6.4 Replacement of gate seal and bonnet seal ......................................................16
7 Repairs...............................................................................................20
8 Dismounting and Storage.................................................................21
8.1 Dismounting ......................................................................................................22
8.2 Storage..............................................................................................................22
9 Packaging and Transport.................................................................23
9.1 Packaging .........................................................................................................24
9.2 Transport...........................................................................................................24
10 Disposal.............................................................................................25
11 Spare parts ........................................................................................26

DESCRIPTION OF PRODUCT Series
121
4
/
27
Edition
2015
-
11
-
16
600968EA
1 Description of product
1.1 Identification of product
The fabrication number and order number are fixed on the product directly or by means of
an identification plate.
made in Switzerland
Fabrication No.:
121 . .- . . . .- . . . ./ . . . .
A - . . . . . .


Fabrication number
Order number
1.2 Use of product
Use product for clean and dry vacuum applications only. Other applications are only allowed
with the written permission of VAT.
1.3 Related documents
•Product data sheet
•Dimensional drawing
1.4 Important information
This symbol points to a very important statement that requires particular
attention.
Example
:
VAT disclaims any liability for damages resulting from inappropriate packaging.
1.5 Technical data
See product data sheet and dimensional drawing.

Series 121 SAFETY
600968EA
Edition
2015
-
11
-
16
5
/
27
2 Safety
2.1 Compulsory reading material
Read this chapter prior to performing any work with or on the product. It contains important
information that is significant for your own personal safety. This chapter must have been
read and understood by all persons who perform any kind of work with or on the product
during any stage of its serviceable life.
NOTICE
Lack of knowledge
Failing to read this manual may result in property damage.
Firstly, read manual.
These Installation, Operating & Maintenance Instructions are an integral part
of a comprehensive documentation belonging to a complete technical
system. They must be stored together with the other documentation and
accessible for anybody who is authorized to work with the system at any
time.
2.2 Danger levels
DANGER
High risk
Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
Medium risk
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Low risk
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injury.
NOTICE
Command
Indicates a hazardous situation which, if not avoided, may result in property
damage.

SAFETY Series
121
6
/
27
Edition
2015
-
11
-
16
600968EA
2.3 Personnel qualifications
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
2.4 Safety labels
Label Part No. Location on valve
T-9001-155 (DN 63 – 100) Protective cover
T-9001-156 (DN 160 – 320) Protective cover
N-6289-351 On the actuator
Table 2-1

Series 121 DESIGN AND FUNCTION
600968EA
Edition
2015
-
11
-
16
7
/
27
3 Design and Function
3.1 Design
1 Sealing surface
2 Valve body
3 Actuator
4 Position indicator
5 Solenoid valve
Figure 3-1
3.2 Function
The valve features the VATLOCK sealing technology. This means, the valve is mechani-
cally locked in the closed position. In the open position, the mechanism is not locked. Leaf
springs hold gate and counter plate against the carriage with the ball retainers. The ball
pairs are in the detents. For closing, the mechanism is moved forward into the closing
position. The locking starts after the leaf spring stop touches the body. The ball retainers
move the ball pairs out of the detents. Gate and counter plate are spread apart. The gate
seal is pressed against the sealing surface without scuffing. The arrangement of the ball
pairs ensures an increase of the sealing force with vacuum on either side of the gate.
During opening the movements proceed in the reverse order; see «Figure 3-2».
1 Valve gate
2 Counter-plate
3 Leaf springs
4 Spring stop
5 Ball pairs
6 Ball detents
7 Gate seal
Valve seat side
Figure 3-2

INSTALLATION Series
121
8
/
27
Edition
2015
-
11
-
16
600968EA
4 Installation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Heavy weight
Physical overstraining.
Use a crane to lift the product.
4.1 Unpacking
•
Make sure that the supplied products are in accordance with your order.
•Inspect the quality of the supplied products visually. If it does not meet
your requirements, please contact VAT immediately.
•Store the original packaging material. It may be useful if products must be
returned to VAT.
The valve can be lifted only at the eyebolt threads;
see dimensional drawing.
4.2 Installation into the system
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not connect or supply electrical power and compressed air before the
product is completely mounted in the system.
NOTICE
Contamination
Product may get contaminated.
Always wear cleanroom gloves when handling the product.

Series 121 INSTALLATION
600968EA
Edition
2015
-
11
-
16
9
/
27
NOTICE
Inappropriate tools
Sealing surfaces may get damaged.
Do not use sharp-edged tools.
NOTICE
Wrong tightening torque
Valve body and screws may get damaged.
Use tightening torque according the size of the screws.
NOTICE
Too long screws
Valve body may get deformed and / or malfunctions may occur.
Use only screws recommended by VAT.
1. Remove protective covers from body flanges.
2. Clean sealing surfaces and seals of both flanges;
see (1) and (2) according to «Figure 4-1».
The valve seat side is marked with the symbol «∇» on flange «A».
3. Lift the valve to the mounting position. For the size DN 320 (12150- . .14 / 24 / 34 / 44)
use only the eyebolts threads; see dimensional drawing.
4. Mount the four screws (3) according to «Figure 4-1», evenly in crosswise order until the
seal touches the sealing surface.
5. Tighten all screws with the torques appropriate for their property classes.
1 Flange A
2 Flange B
3 Screws
Figure 4-1

INSTALLATION Series
121
10
/
27
Edition
2015
-
11
-
16
600968EA
4.2.1 Admissible forces and bending moments
Forces from evacuating the system, from the weight of other components or
from baking can lead to deformation of the valve body and to malfunction of
the valve. The stress has to be relieved by suitable means; e.g. bellows
sections.
The following forces or bending moments are admissible:
DN (nom. I. D.) Axial tensile or com-
pressive force «FA» Bending moment «M»
mm inch N lbf Nm lbf ·ft
63 2½ 980 220 39 29
80 3 1025 230 43 32
100 4 1080 242 49 36
160 6 3000 674 150 110
200 8 3000 674 150 110
250 10 3500 787 200 148
320 12 4000 900 300 220
If a combination of both forces («FA» and «M») occurs, the values
mentioned above are invalid. Please contact VAT for more
information.
Table 4-1

Series 121 INSTALLATION
600968EA
Edition
2015
-
11
-
16
11
/
27
4.3 Compressed air connection
WARNING
Valve in open position
Risk of injury when compressed air is connected to the valve.
Connect compressed air only when:
– valve is installed in the vacuum system
– moving parts cannot be touched
Use clean, dry or slightly oiled air only.
Admissible air pressure range, see product data sheet.
1. Connect compressed air according to the product data sheet and dimensional drawing.
4.4 Electrical connection
DANGER
Electric shock
Parts being under voltage will result in serious injury or death.
Do not touch parts being under voltage.
NOTICE
Wrong voltage
Electrical components may get damaged.
Supply electrical components with the correct voltage.
1. Connect solenoid valve according to the product data sheet and dimensional drawing.
2. Connect position indicator according to the product data sheet and dimensional
drawing.
3. Connect heater (option) according to the product data sheet and dimensional drawing.

OPERATION Series
121
12
/
27
Edition
2015
-
11
-
16
600968EA
5 Operation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not operate before product is installed completely into the vacuum system.
WARNING
Hot surfaces
Risk of burning when touching hot surfaces.
Do not touch hot surfaces.
5.1 Normal operation
Valve is opened and closed pneumatically.
5.2 Operation under increased temperature
Maximum allowed temperature, see product data sheet.
5.3 Behavior in case of compressed air pressure drop
See product data sheet.
5.4 Behavior in case of power failure
See product data sheet.

Series 121 OPERATION
600968EA
Edition
2015
-
11
-
16
13
/
27
5.4.1 Manual emergency operation
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Keep human body parts away from movable parts.
Only valid for the ordering number 121..-..
3
4
/
44
(with solenoid valve)
In case of a power failure, the valve can be actuated manually if compressed air is
available.
Standard solenoid valve
Press push-button (1): valve opens
Release push-button (1): valve closes
Solenoid valve with lockable emergency operation (option)
Push and rotate in lockable: valve opens
Push and rotate unlockable: valve closes

OPERATION Series
121
14
/
27
Edition
2015
-
11
-
16
600968EA
Solenoid valve for impulse actuation (option)
Press push-button (1): valve opens
Press push -button (2): valve closes
5.5 Trouble shooting
Failure Check Action See
Valve does not
close / open Air pressure Connect compressed air «4.3 Compressed air connection»
Operating
pressure Adjust operating pressure Product data sheet
Voltage at
solenoid valve Connect voltage «4.4 Electrical connection»
Leak at gate Gate seal all
right? Replace valve gate «6.4 Replacement of gate seal and bonnet seal»
Gate damaged or
contaminated? Replace valve gate «6.4 Replacement of gate seal and bonnet seal»
Operating
pressure Adjust operating pressure Product data sheet
Leak at body Bonnet seal and
sealing surface all
right?
Clean sealing
surface, if
necessary,
replace bonnet
seal
«6.4 Replacement of gate
seal and bonnet seal»
Table 5-1
If you need any further information, please contact one of our service centers. You will find
the addresses on our website www.vatvalve.com.

Series 121 MAINTENANCE
600968EA
Edition
2015
-
11
-
16
15
/
27
6 Maintenance
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Heavy weight
Physical overstraining.
Use a crane to lift the valve insert.
WARNING
Hazardous components
Human body parts may get jammed and severely injured.
Before starting maintenance:
– disconnect compressed air supply
– disconnect electrical power supply
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Keep human body parts away from movable parts.
WARNING
Hot surfaces
Risk of burning when touching hot surfaces.
Touch hot surfaces only if the valve has cooled down.
6.1 Maintenance intervals
Under clean operating conditions the valve does not require any maintenance during the
specified cycles; see product data sheet. After these cycles, VAT recommends replacing
the mechanism unit; see chapter «6.4 Replacement of gate seal and bonnet seal».
For more information or a general overhaul please contact one of our service centers. You
will find the addresses on our website www.vatvalve.com.

MAINTENANCE Series
121
16
/
27
Edition
2015
-
11
-
16
600968EA
6.2 Tightening torque specifications
Item-No. Description Tightening torque [Nm]
DN 160–200 DN 250–320
2
Bonnet screw 14 20
Item-No. Description Tightening torque [Nm]
DN 63–100
2
Bonnet screw 3.5
Table 6-1
6.3 Required tools
•Torque wrench according «Table 6-1»
•Cleanroom wiper soaked with alcohol (2% methyl ethyl ketone)
•O-Ring removal tool; see «Table 11-1» on page 27
Figure 6-1
6.4 Replacement of gate seal and bonnet seal
WARNING
Loaded spring steel sheet
Human body parts may get jammed and severely injured.
Do not put human body parts between valve gate and spring steel sheet.
NOTICE
Contamination
Product may get contaminated.
Always wear cleanroom gloves when handling the product.

Series 121 MAINTENANCE
600968EA
Edition
2015
-
11
-
16
17
/
27
NOTICE
Inappropriate tools
Sealing surfaces may get damaged.
Do not use sharp-edged tools.
The numbers in brackets ( ) refer to «Figure 6-4» on page 19.
1. Vent chambers on either side to atmospheric pressure.
2. Open valve.
3. Disconnect compressed air supply.
4. Disconnect electrical power supply.
5. Loosen both screws (2).
6. Swing the both screws (2) out (only for DN 160 or higher).
Make sure to maintain upper valve body (5) in its position while losing and
swinging out the screws!
7. Lift upper valve body (5) carefully from lower part of body (1) without touching the body
wall and put it on a clean place (seat side symbol «∇» on top).
Do not touch the actuator with the lifting ropes, if you lift the upper valve
body!
8. Apply compressed air (air pressure approx. 1 bar) and move mechanism slowly out of
upper part of body (5).
Provide sufficient free space in order to prevent the mechanism from
touching any objects.
9. Disconnect compressed air.
10. Remove gate seal (1) from groove; see «Figure 6-2»; use O-ring removal tool.
1 Gate seal
2 Valve gate
Figure 6-2

MAINTENANCE Series
121
18
/
27
Edition
2015
-
11
-
16
600968EA
11. Check and clean sealing surface of valve seat; use cleanroom wiper.
12. Install new gate seal (1); see «Figure 6-2».
Press O-ring uniformly in crosswise order (diagonal) into groove.
13. Remove bonnet seal (3) from groove; use O-ring removal tool.
14. Check and clean sealing surface of bonnet seat; use cleanroom wiper.
15. Install new bonnet seal (5).
•Press O-ring into groove on one short side.
•Distribute seal uniformly over long sides to opposite short side and press it
fully into groove.
Make sure to have gate (2); see «Figure 6-2»; on seat side «∇»;
see «Figure 6-4» on page 19.
Align mechanism with opening of upper part of body.
16. Apply compressed air (air pressure approx. 1 bar) and move mechanism slowly into
upper valve body (5).
Provide sufficient free space in order to prevent the mechanism from
touching any objects.
17. Disconnect compressed air from valve.
18. Lift upper valve body (5) carefully back into the lower valve body (1) without touching
the body wall.
The tips of the triangles «∇» of both body parts must face each other;
see «Figure 6-3 » on page 19 and «Figure 6-4» on page 19.

Series 121 MAINTENANCE
600968EA
Edition
2015
-
11
-
16
19
/
27
DN 63–100
DN 160
or higher
Figure 6-3
19. For DN 160 or higher: Swing back both screws (2); see «Figure 6-4».
20. Tighten the screws (2) with the appropriate torque specified in chapter
«6.2 Tightening torque specifications».
21. Connect electrical power supply.
22. Connect compressed air supply.
23. Close the valve.
1 Lower valve body
2Screws
3 Bonnet seal
4 Gate
5 Upper valve body
Valve seat side
Figure 6-4
Valve is ready for use.

REPAIRS Series
121
20
/
27
Edition
2015
-
11
-
16
600968EA
7 Repairs
Repairs may only be carried out by the VAT service staff. In exceptional cases, the
customer is allowed to carry out the repairs, but only with the prior consent of VAT.
Please contact one of our service centers. You will find the addresses on our website
www.vatvalve.com.
