VAT 47146-E7 Series Assembly instructions

Installation, Operating &
Maintenance Instructions
600243EC
Edition
2018
-
11
-
05
RF all-metal gate valve
with compact or extended pneumatic actuator
Series 47
DN 40 – 250 mm (I. D. 1½" – 10")
This manual is valid for the following product ordering numbers:
With compact actuator
With extended actuator
47
146
-
.
E7
.
-
....
47148- . E7 . - ....
47232- . E7 . - ....
47236- . E7 . - ....
47239- . E7 . - ....
47240- . E7 . - ....
47244- . E7 . - ....
4
7
132
-
. E .
.
-
....
47146- . E .. - ....
47148- . E .. - ....
47232- . E .. - ....
47236- . E .. - ....
47239- . E .. - ....
47240- . E .. - ....
47244- . E .. - ....
Sample pictures

Series 4
7
2
/
28
Edition
2018
-
11
-
05
600243EC
Imprint
Manufacturer
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Website:
Phone:
Fax:
Email:
www.vatvalve.com
[phone]
[phone]
[email protected]om
Publisher VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Editor VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Print VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Copyright © VAT Vakuumventile AG 2018
No part of these instructions may be reproduced in any way (photo-
copies, microfilms or any other reproduction processes) nor may it be
manipulated with electronic systems, duplicated or distributed without
written permission from VAT. Offenders are liable to pay damages.
The original VAT firmware and updated state of the art versions of the
VAT firmware are intended for use with VAT products. The VAT firmware
contains a limited, time unlimited user license. The VAT firmware may not
be used for purposes other than those intended nor is it permitted to
make copies of the VAT firmware. In particular, it is strictly forbidden to
give copies of the VAT firmware to other people.
The use of trade names, brand names, trademarks, etc. in these
Instructions does not entitle third parties to consider these names to be
unprotected and to use them freely. This is in accordance with the
meaning of the laws and acts covering brand names and trademarks.

Series 47
600243EC
Edition
2018
-
11
-
05
3
/
28
Contents
1 Description of product........................................................................4
1.1 Identification of product....................................................................................4
1.2 Use of product.................................................................................................4
1.3 Related documents..........................................................................................4
1.4 Important information.......................................................................................4
1.5 Technical data.................................................................................................4
2 Safety ...................................................................................................5
2.1 Compulsory reading material...........................................................................5
2.2 Danger levels ..................................................................................................5
2.3 Personnel qualifications...................................................................................6
2.4 Safety labels....................................................................................................6
3 Design and Function...........................................................................7
3.1 Design.............................................................................................................7
3.2 Function..........................................................................................................8
4 Installation...........................................................................................9
4.1 Unpacking.......................................................................................................9
4.2 Installation into the system.............................................................................10
4.2.1 Preparation for installation..................................................................11
4.2.2 Mounting to the system.......................................................................12
4.3 Compressed air connection ...........................................................................14
4.4 Electrical connection......................................................................................15
5 Operation...........................................................................................16
5.1 Normal operation...........................................................................................16
5.2 Operation under increased temperature.........................................................17
5.3 Bake-out........................................................................................................18
5.4 Behavior in case of compressed air pressure drop.........................................18
5.5 Behavior in case of power failure...................................................................18
5.5.1 Manual emergency operation..............................................................18
5.6 Trouble shooting............................................................................................20
6 Maintenance ......................................................................................21
6.1 Maintenance intervals....................................................................................21
7 Repairs...............................................................................................22
8 Dismounting and Storage.................................................................23
8.1 Dismounting..................................................................................................24
8.2 Storage .........................................................................................................24
9 Packaging and Transport.................................................................25
9.1 Packaging .....................................................................................................26
9.2 Transport.......................................................................................................26
10 Disposal.............................................................................................27
11 Spare parts ........................................................................................28

DESCRIPTION OF PRODUCT Series 4
7
4
/
28
Edition
2018
-
11
-
05
600243EC
1 Description of product
1.1 Identification of product
The fabrication number and order number are fixed on the product directly or by means of
an identification plate.
made in Switzerland
Fabrication No.:
47 . . .- . . . .- . . . ./ . . . .
A - . . . . . .


Fabrication number
Order number
1.2 Use of product
Use product for clean and dry vacuum applications only. Other applications are only allowed
with the written permission of VAT.
1.3 Related documents
•Product data sheet
•Dimensional drawing
1.4 Important information
This symbol points to a very important statement that requires particular
attention.
Example:
VAT disclaims any liability for damages resulting from inappropriate packaging.
1.5 Technical data
See product data sheet and dimensional drawing.

Series 47 SAFETY
600243EC
Edition
2018
-
11
-
05
5
/
28
2 Safety
2.1 Compulsory reading material
Read this chapter prior to performing any work with or on the product. It contains important
information that is significant for your own personal safety. This chapter must have been
read and understood by all persons who perform any kind of work with or on the product
during any stage of its serviceable life.
NOTICE
Lack of knowledge
Failing to read this manual may result in property damage.
Firstly, read manual.
These Installation, Operating & Maintenance Instructions are an integral part
of a comprehensive documentation belonging to a complete technical
system. They must be stored together with the other documentation and
accessible for anybody who is authorized to work with the system at any
time.
2.2 Danger levels
DANGER
High risk
Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
Medium risk
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Low risk
Indicates a hazardous situation which, if not avoided, may result in minor or
moderate injury.
NOTICE
Command
Indicates a hazardous situation which, if not avoided, may result in property
damage.

SAFETY Series 4
7
6
/
28
Edition
2018
-
11
-
05
600243EC
2.3 Personnel qualifications
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
2.4 Safety labels
Label Part No. Label size
(mm) Location on valve
DN 40 – 100: T-9001-155
DN 160 – 250: T-9001-156 20 × 20 80 × 80 On protective covers of flanges
Table 2-1

Series 47 DESIGN AND FUNCTION
600243EC
Edition
2018
-
11
-
05
7
/
28
3 Design and Function
3.1 Design
With compact actuator:
type 47 ... - . E7 . - .... With extended actuator: type 47 ... - . E .. - ....
Figure 3-1
1 Actuator
2 Valve body
3 Connecting flange
4 Sealing surface
5 Distance piece

DESIGN AND FUNCTION Series 4
7
8
/
28
Edition
2018
-
11
-
05
600243EC
3.2 Function
Valve is closed and opened pneumatically.
Closing: The valve mechanism moves towards the valve opening until it touches the
mechanical stop. Due to continued pressure, valve gate (1) with the assembled VATRING
(7) and counter-plate (2) spread apart from the guide plate (3).This effect leaktight closing.
Opening: When the end position is reached, the RF contact band (6), which is clamped to
the patented VATKIPP mechanism (7), will spread apart and couple to the flange to provide
a low RF resistance during its operation.
OPEN
CLOSED
Figure 3-2
1 Valve gate
2 Counter-plate
3 Guide plate
4 Support
5 VATRING
6 RF contact
7 VATKIPP
Valve seat side
67 1 5 3 2 4

Series 47 INSTALLATION
600243EC
Edition
2018
-
11
-
05
9
/
28
4 Installation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Heavy weight
Physical overstraining.
Use a crane to lift the product.
4.1 Unpacking
•
Make sure that the supplied products are in accordance with your order.
•Inspect the quality of the supplied products visually. If it does not meet
your requirements, please contact VAT immediately.
•Store the original packaging material. It may be useful if products must be
returned to VAT.
Open the plastic bag protecting the valve only at the points where you need
access to the eyebolts (1) for fastening the crane hooks; see «Figure 4-1» on
page 10. Keep valve in the plastic bag until it is being installed into the
system.
NOTICE
Wrong lifting
Valve may crash and get damaged.
Use only the eyebolts shown in the dimensional drawing and in «Figure 4-1»
on page 10 to lift the valve. Using any other components (e. g. position
indicators, solenoid valves) to lift the valve is strictly forbidden.
NOTICE
Sensitive product
Valve parts may get damaged.
–
When lifting the valve, pay attention that the valve does not touch any solid
objects.
– Lift valve carefully and put it down on a clean surface or
mount it to a clean
system.

INSTALLATION Series 4
7
10
/
28
Edition
2018
-
11
-
05
600243EC
Use a crane for lifting valve DN100 and higher out of the transport box; see «Figure 4-1».
Weight of standard valves; see chapter «1.5 Technical data».
1 Eyebolts
2 Lifting ropes
A Valve movement
direction
B Support required
to stabilize the
valve
Figure 4-1
4.2 Installation into the system
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not connect or supply electrical power and compressed air before the
product is completely mounted in the system.
NOTICE
Contamination
Product may get contaminated.
Always wear cleanroom gloves when handling the product.
NOTICE
Force effect from other components of the system
Valve body may get deformed and/or malfunctions may occur.
– Do not use valve to support other components.
– Make sure that forces from other components do not impair the valve;
use bellows sections, for instance.

Series 47 INSTALLATION
600243EC
Edition
2018
-
11
-
05
11
/
28
4.2.1 Preparation for installation
WARNING
Danger of injury in case of insufficient skills
Inappropriate handling may cause serious injury or property damage.
Make sure that the valve does not topple or fall down while removing the
protective covers from the flanges.
NOTICE
Sensitive product
Valve parts may get damaged.
When removing the protective covers from the flanges, be careful to avoid
damage to the valve.
1. Remove plastic bag.
2. Remove screws (2) and protective covers (3); see «Figure 4-2».
3. Remove O-rings (4).
1 Eyebolts to fasten
the crane hooks
2 Screws (quantity
depends on valve
size)
3 Protective covers
4 O-rings
Figure 4-2
Store screws, protective covers and O-rings. They may be useful when valve
needs to be repacked.

INSTALLATION Series 4
7
12
/
28
Edition
2018
-
11
-
05
600243EC
4. Clean sealing surfaces; see «Figure 3-1» on page 7, with a cleanroom wiper soaked
with pure alcohol (Isopropanol).
5. Clean surface with clean, oil free compressed air.
4.2.2 Mounting to the system
The valve seat side is marked with the symbol «∇» on flange «A»;
see «Figure 4-3».
1. Mount valve to your system by using appropriate flange screws
(different quantity of screws required – depending on valve size).
2. Initially, mount four screws evenly in crosswise order until the seal touches the sealing
surface.
3. Afterwards, mount all screws evenly in crosswise order.
4. Tighten all screws with the torques appropriate for the property classes of the screws.
5. Do not block Leak detection port, see sample picture at «Figure 4-4». Please find the
exact position of the Leak detection port on the dimensional drawing.
1 Flange B
2 Flange A
3 Marking for valve seat side
(symbol «∇»)
4 Screw holes
Figure 4-3

Series 47 INSTALLATION
600243EC
Edition
2018
-
11
-
05
13
/
28
Leak detection port
Figure 4-4

INSTALLATION Series 4
7
14
/
28
Edition
2018
-
11
-
05
600243EC
Compressed air connection
WARNING
Valve in open or closed position
Risk of injury when compressed air is connected to the valve.
Connect compressed air only when:
– valve is installed in the vacuum system
– moving parts cannot be touched
NOTICE
Wrong sequence of connections
Valve mechanism may get damaged when electrical power is being
connected before compressed air is connected.
Always connect compressed air before connecting electrical power.
Use clean, dry or slightly oiled air only.
Admissible air pressure range, see product data sheet.
Supply compressed air pressure only after the supply line is properly
mounted to the actuator.
1. Connect compressed air supply line according the specification on the product data
sheet and; see «Table 4-1».
Execution Procedure
Without solenoid
valve
47 ... - . E14- ....
47 ... - . E24- ....
47 ... - . E72- ....
Connect relevant compressed air line to connection CLOSE.
Afterwards, connect relevant compressed air line to connection
OPEN.
Supply admissible compressed air to connection “close” first!
Standard solenoid
valve
47 ... - . E44- ....
47 ... - . E74- ....
Connect relevant compressed air supply line to connection
OPEN/CLOSE.
Supply admissible compressed air to connection “open/close”.
Impulse solenoid
valve (option)
47 ... - . E44- ....
47 ... - . E74- ....
Connect relevant compressed air supply line to connection
OPEN/CLOSE.
Supply admissible compressed air to connection “open/close”.
Table 4-1

Series 47 INSTALLATION
600243EC
Edition
2018
-
11
-
05
15
/
28
4.3 Electrical connection
DANGER
Electric shock
Parts being under voltage will result in serious injury or death.
Do not touch parts being under voltage.
NOTICE
Wrong sequence of connections
Valve mechanism may get damaged when electrical power is being
connected before compressed air is connected.
Always connect compressed air before connecting electrical power.
NOTICE
Wrong voltage
Electrical components may get damaged.
Supply electrical components with the correct voltage.
1. Connect position indicator according to product data sheet.
2. Connect the contacts of the solenoid valve connector according to the wiring diagram
on the product data sheet, specification on solenoid coil and; see «Table 4-2».
Execution Procedure
Without solenoid
valve
47 ... - . E14- ....
47 ... - . E24- ....
47 ... - . E72- ....
n. a.
Standard solenoid
valve
47 ... - . E44- ....
47 ... - . E74- ....
Connect one connector to the magnetic coil.
Impulse solenoid
valve (option)
47 ... - . E44- ....
47 ... - . E74- ....
Connect the relevant connector to the open and close magnetic
coil.
Table 4-2

OPERATION Series 4
7
16
/
28
Edition
2018
-
11
-
05
600243EC
5 Operation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Do not operate before product is installed completely into the vacuum system.
5.1 Normal operation
Valve is closed and opened pneumatically.
For technical details, see product data sheet.
Make sure that compressed air is supplied at the specified pressure;
see also chapter «0 Compressed air connection».
Make sure that the connect voltage is supplied.
Check voltage specification on coil; see also chapter «4.3 Electrical
connection».
Action Execution Procedure
To open
the valve Without solenoid
valve
47 ... - . E14- ....
47 ... - . E24- ....
47 ... - . E72- ....
Supply compressed air to connection “open”.
Release air through connection “closed”.
Standard solenoid
valve
47 ... - . E44- ....
47 ... - . E74- ....
Supply specified voltage to the magnetic coil.
Impulse solenoid
valve (option)
47 ... - . E44- ....
47 ... - . E74- ....
Supply an impulse of specified voltage to the coil for
opening (pulse duration min. 50 ms).
Table 5-1

Series 47 OPERATION
600243EC
Edition
2018
-
11
-
05
17
/
28
Action Execution Procedure
To close
the valve Without solenoid
valve
47 ... - . E14- ....
47 ... - . E24- ....
47
...
-
. E72
-
....
Supply compressed air to connection “close”.
Release air through connection “open”.
Standard solenoid
valve
47 ... - . E44- ....
47 ... - . E74- ....
Cut voltage supply to the magnetic coil.
Impulse solenoid
valve (option)
47 ... - . E44- ....
47 ... - . E74- ....
Supply an impulse of specified voltage to the coil for
closing (pulse duration min. 50 ms).
Table 5-2
5.2 Operation under increased temperature
Maximum allowed temperature, see product data sheet.
NOTICE
Inconstant temperatures
Performance of the valve may deteriorate.
– Actuate valve only after the bake-out temperature has been stable for two
hours.
– If valve must be actuated during bake-out, make sure that the heating or
cooling rate does not exceed 10 °C per hour in the temperature range
from 100 °C to 200 °C (version with compact actuator).
from 100 °C to 300 °C (version with extended actuator).
– Make sure that the temperature differences over the whole body do not
exceed 30 °C.

OPERATION Series 4
7
18
/
28
Edition
2018
-
11
-
05
600243EC
5.3 Bake-out
Inside under vacuum pressure ≤10
-
5
mbar to prevent oxidation.
compact extended
Valve: ≤200 °C in open and
closed position ≤300 °C in open and closed position
Actuator: standard: ≤200 °C for max.100 h *≤200 °C for max.100 h *
option:
10
6
Gy (10
8
rad) ≤140 °C for max.100 h *≤140 °C for max.100 h *
option:
10
8
Gy (10
10
rad) ≤200 °C *≤200 °C *
Position
indicator:
standard: ≤80 °C ≤80 °C
option: 200 °C ≤200 °C ≤200 °C
Solenoid valve: ≤80 °C ≤80 °C
Heating and cooling rate:
DN 40 – 160
DN 200 – 250
≤50 °C / h
≤25 °C / h
≤50 °C / h
≤25 °C / h
Table 5-3
*Applied high temperatures and radiation exposure are weakening the sealing materials of
the actuator. A combination of both will shorten the lifetime.
5.4 Behavior in case of compressed air pressure drop
See product data sheet.
5.5 Behavior in case of power failure
See product data sheet.
5.5.1 Manual emergency operation
WARNING
Movable parts
Human body parts may get jammed and severely injured.
Keep human body parts away from movable parts.
The solenoid valves are provided with manual emergency operation (slotted
screw). This screw allows actuating the valve in case of a power failure.
Compressed air must be supplied.

Series 47 OPERATION
600243EC
Edition
2018
-
11
-
05
19
/
28
Standard solenoid valve
To close the valve: Turn the slotted screw (1) counter-clockwise to its stop.
To open the valve: Turn the slotted screw (1) clockwise to its stop.
1 Slotted screw
Figure 5-1
For remote operation make sure that the slotted screw is turned counter-
clockwise
to its stop.
Impulse solenoid valve
To close the valve: Turn the slotted screw (3) – coil CLOSE – clockwise to its stop.
As soon as valve is closed, turn screw back to its original position.
To open the valve: Turn the slotted screw (2) – coil OPEN – clockwise to its stop.
As soon as valve is open, turn screw back to its original position.
1 Coil OPEN
2 Slotted screw of coil OPEN
3 Slotted screw of coil CLOSE
4 Coil CLOSE
Figure 5-2
For remote operation make sure that both slotted screws are turned counter-
clockwise to their stop (original position).
1
2
3 4
1

OPERATION Series 4
7
20
/
28
Edition
2018
-
11
-
05
600243EC
5.6 Trouble shooting
Failure Check Action See
Valve
mechanism does
not move
Air pressure Connect
compressed air «0 Compressed air connection»
Electrical power Connect electrical
power «4.3 Electrical connection»
Operating
pressure Adjust operating pressure «0 Compressed air connection»
Position of
slotted screw Turn slotted screw to the correct position «5.5.1 Manual emergency operation»
Leak at gate Condition of gate
seal Please contact VAT www.vatvalve.com
Condition of
valve gate Please contact VAT www.vatvalve.com
Operating
pressure Adjust operating pressure «0 Compressed air connection»
Leak at body Condition of
bonnet seal and
sealing surface Please contact VAT www.vatvalve.com
Condition of
bellows Please contact VAT www.vatvalve.com
Whistling sound
during opening
or closing – No action required
when valve is actu-
ated at atmosphere –
–
No action required
when valve is actu-
ated in vacuum as
long as the sound is
not excessive
–
Table 5-4
If you need any further information, please contact one of our service centers. You will find
the addresses on our website www.vatvalve.com.
