Vax PowerWash 2500w User manual

PowerWash
2500W Complete
P86-P4-T
LET’S GET STARTED.
IDEAL FOR THE
MOST CHALLENGING
CLEANING TASKS

Let’s talk safety
Do’s
• Always wear suitable clothing footwear and eye protection
whilst using the pressure washer.
• Always connect the water supply, remove the lance and squeeze
the trigger to run water through the machine before switching
the power on.
• Always use a suitable hose connector to match the coupling on
the pressure washer with a non-return valve at tap end of the
supply hose.
• Always unplug the pressure washer before cleaning or carrying
out any maintenance.
• Always turn o and unplug the pressure washer before
disconnecting or connecting the hose. After use always wrap the
pressure hose and power cord around the storage clips provided.
Basic
safety
precautions
This pressure washer is intended for household use only and
NOT for commercial or industrial use.
• This pressure washer is for outdoor use only.
• It is your responsibility to check the suitability of the surface to
be cleaned. Vax cannot be held responsible for damage caused.
• Keep ngers, hair and loose clothing from moving parts and
openings whilst using the pressure washer.
• When using the pressure washer the recommended working
distance between the nozzle and surface area or object to be
cleaned is 30cm.
Don’ts
• Don’t leave the pressure washer unattended or running
when not in use for more than 5 minutes without depressing
the trigger.
• Don’t use the pressure washer if it has been dropped, damaged
or immersed in water.
• Don’t use the pressure washer if the power cord or plug is
damaged.
• Don’t handle the plug of the pressure washer with wet hands.
• Don’t use the pressure washer without the supply hose
(minimum length 7.5m) in place and unwind the hose fully
from the reel.
PLEASE KEEP THESE ORIGINAL INSTRUCTIONS.

• Always release any built up pressure in the handle prior to disconnecting the
hose and ensure water inlet lter is clean prior to storage in a cool dry place.
• Always use only CE approved 13amp extension cords with RCD,
non-approved extension cords may overheat. Care should be taken to arrange
the extension cord as it could be a trip hazard.
• Always make sure the power/extension cord is fully unwound and prevent the
power/extension cord from getting wet during use.
• Always replace the fuse in the plug with a British 13amp fuse. Always protect
the power cable from heated surfaces or near open ames.
• Always carry the pressure washer by the handle.
• Always check the water hose and accessories are not damaged, broken or
worn before use.
• This appliance can only be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Vax only recommend the use of Vax genuine accessories and detergent to be
used with this pressure washer. The use of non-branded Vax accessories and
detergent will invalidate your warranty.
• For safe transportation, ensure that the pressure washer is unplugged
and secure.
• Don’t use the pressure washer without the water lter in place.
• Don’t pull or carry this pressure washer by the power cord.
• Don’t use the power cord as a handle, pull the power cord around corners
or sharp edges, or close a door over the power cord.
• Don’t unplug the pressure washer by pulling on the power cord.
• Don’t aim the pressure washer at people, animals, plants, electrical
components, wires, or the pressure washer itself.
• Don’t use the pressure washer on electrical components, damaged/delicate
paint surfaces, tyres, engines/motors.
• Don’t use the pressure washer with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the rating label.

Thank you for buying this Pressure Washer.
Taking care of your outdoor cleaning
This pressure washer is designed to make outdoor cleaning tasks as eective and ecient
as possible and this user guide will help you get the most out of your machine.
Completing outdoor cleaning tasks using a Vax pressure washer will keep your outdoor
items and surfaces cleaner for longer.
Taking care of your Pressure Washer
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your outdoor cleaning tasks.
We’re here if you need us
Instead of taking me back to the shop,
simply visit our online support:
vax.co.uk/support
Still need to get in touch?
Our UK based Customer Care Team are here to support you.
For help with assembly, operational or performance problems, or buying and tting new accessories,
you can nd all our contact details at vax.co.uk/contact
This user guide can be found online at: vax.co.uk/support

Pressure Hose
Trigger Handle
Lance
Jet Nozzle
Turbo Nozzle
Detergent Nozzle
Nozzle Cleaning Tool
Water Inlet Connector
Car Brush
Rotary Brush
Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
What to do if it goes wrong
Getting in touch
Accessories
Included with
your machine
Power Wash
Patio Brush
Extension Tube
Universal Detergent

Getting to know your machine
On/o switch
Handle
Trigger handle
storage
Water inlet
and connector
(already installed)
Power cord and
pressure hose
storage hook
Water outlet
Lance storage
Wheel
Detergent tube
Name PowerWash 2500W Complete
Model P86-P4-T
Voltage 220-240V~50Hz
Wattage 2500W
Max Pressure 180 bar
Rated Pressure 120 bar
Max Flow Rate 510L/Hr
Sound pressure level:
LpA dB(A) 79
Sound power level:
LwA dB(A) 94
LwA dB(A) K (uncertainty) 91,6
Vibration (m/s2) K (uncertainty) 0,5 m/s21,5
Technical Specication
Universal Detergent
1-9-133398-00
Patio & Decking Detergent
1-9-133401-00
Wash & Protect Vehicle Detergent
1-9-133400-00
Accessories & Consumables
Subject to technical change without notice. To purchase consumables and accessories, please visit vax.co.uk

Assembling your pressure washer
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE.
Attach both wheels
and push until they click
into place.
Attach the hose connector
to water inlet by turning
clockwise until tight.
To attach the handle into the top
of the pressure washer, align
the handle with the screw holes
making sure not to trap the
solution tube. Slide together and
insert 2 screws and turn clockwise
to tighten.
Always make sure the pressure washer and water supply is o before connecting or disconnecting the hose
and accessories.
To purchase consumables and accessories, please visit vax.co.uk

Using your machine
IMPORTANT: Always remove the pressure hose fully from the reel when in use.
To connect the pressure hose to the
trigger handle, press the pressure
hose release button and push the
pressure hose to lock into position.
Gently pull the pressure hose to make
sure it is locked securely.
Push the pressure hose
rmly to the water outlet
and turn the pressure hose
collar clockwise to tighten.
Whilst rmly pushing
the lance into the trigger
handle turn clockwise
to lock into position.
Preparing your pressure washer for use
To remove the lance from the
trigger handle rmly push and
twist the lance anti-clockwise.
When unlocked pull to remove.
Always make sure the trigger safety lock is in the LOCKED position when not in use or connecting/disconnecting the
pressure hose.
Always check water hose, pressure hose, lance and accessories are not damaged, broken or worn before use.
TIP
Always make sure the
pressure washer is
switched OFF before
connecting/disconnecting
the pressure hose,
lance, accessories or
detergent bag.
A trigger safety lock is located
underneath the handle. The safety
lock should always be in LOCKED
position before connecting/
disconnecting the pressure hose
to the trigger handle.
LOCKED
UNLOCKED

Using your machine
Make sure the water supply is
not connected. Firmly push the
water hose pipe with suitable
connector onto the water inlet
to lock into position.
Connect the water hose pipe
to a suitable water supply and
turn the water on.
Before plugging the machine in, press
the unlock safety button on the trigger
handle and squeeze the trigger until
water starts to ow through the nozzle.
Push switch to ‘I’ position to
turn on. The machine will run
for a few seconds then stop
but no water will be released.
Squeeze the trigger on the trigger
handle to release a high pressured
water jet, and start cleaning.
Push switch to ‘O’
position to turn o.
IMPORTANT: Always use an RCD (Residual Current Device) adaptor when using this pressure washer.
CAUTION: Don’t leave the pressure washer running when not in use, or more than 5 minutes to prevent overheating.
Connect the power cord
to the mains supply via
an RCD adaptor.
CAUTION
Don’t aim the pressure
washer directly at people,
animals, plants, electrical
components, wires or the
pressure washer itself.
Before switching the pressure washer on, the trigger handle must be squeezed to release water and any airlocks in the
machine or pressure hose. Always release any pressure build up in the handle prior to disconnecting the hose.

Using your accessories
The turbo nozzle has a more concentrated spray and is ideal for use on very dirty surfaces, patios or masonry.
As it is not tted with a pressure regulator it is not suitable for use on delicate or painted surfaces.
Using your machine
IMPORTANT: Always make sure the machine is switched o and the safety button on the trigger handle is LOCKED
before connecting/disconnecting the lance, nozzle or accessories.
To attach the jet nozzle,
t the lance with a rm
push and twist clockwise
to lock into place.
Hold down the release button on the
lance, push the jet nozzle and lance
rmly together until you hear an audible
CLICK. Release the button and gently
pull the jet nozzle to make sure it is
locked securely before use.
Squeeze the trigger on the trigger
handle to release a high pressured
water jet, and start cleaning.
Squeeze the trigger on the trigger handle to release
a high pressured water jet, and start cleaning.
To attach the turbo
nozzle, t the lance
with a rm push and
twist clockwise to lock
into place.
Hold down the release button on the
lance, push the turbo nozzle and lance
rmly together until you hear an audible
CLICK. Release the button and gently pull
the turbo nozzle to make sure it is locked
securely before use.
Never use the turbo nozzle
on cars, tyres and engines.
CAUTION
The jet nozzle has a wider spray and is ideal for use on surfaces such as cars, garden furniture, decking and boats.

Push the extension tube onto
the patio brush head and turn
clockwise to secure. Twist and
push the patio head collar to lock
the extension tube into position.
To remove the extension
tube from the trigger
handle, rmly push and
twist the extension tube
anti-clockwise to unlock.
Pull to remove.
Using the patio brush (included in selected models only, see ‘Included with your machine’)
Using your machine
Attach the extension tube onto the
trigger handle, push rmly and
twist clockwise to lock into place.
To remove the patio brush
from the extension tube, twist the
patio head collar anti-clockwise.
Push and twist the patio brush
anti-clockwise to unlock, pull
to remove.
Switch on the pressure washer
and squeeze the trigger to release
water spray.
IMPORTANT: When using your pressure washer the recommended working distance between the nozzle and
surface area or object to be cleaned is 30cm.
After connecting the pressure hose, lance and accessories check they are securely tted and locked in place
before switching on.
Always release any pressure build up in the handle prior to disconnecting the hose and accessories.
Don’t use if the lance and accessories are damaged, broken or worn.
Always check brushes are clean and free from grit/hard debris before use.
TIP
The extension tube can be used
to extend all accessories and
ideal for hard to reach areas and
surfaces.
The outdoor brush is a soft
bristled brush ideal for making
easy work of cleaning garden
furniture.
The car brush is a soft bristled
brush and perfect for tackling
tough dirt on delicate
surfaces ideal for wheels
and car mirrors.

Using your machine
Using the car brush (included in selected models only, see ‘Included with your machine’)
Using the outdoor brush (included in selected models only, see ‘Included with your machine’)
Using the rotary brush (included in selected models only, see ‘Included with your machine’)
Attach the car brush to the trigger
handle. Firmly push the car brush
and trigger handle together, turn
clockwise to lock into position.
Switch on the pressure washer and
squeeze the trigger to release water
spray or water and detergent mix.
To remove the brush from the
trigger handle rmly push and
twist the lance anti-clockwise
to unlock. Pull to remove.
Attach the outdoor brush to the
trigger handle. Firmly push the
outdoor brush and trigger handle
together, turn clockwise to lock
into position.
Switch on pressure washer and
squeeze trigger to release water
spray or water and detergent mix.
To remove the outdoor brush from
the trigger handle rmly push and
twist the lance anti-clockwise
to unlock. Pull to remove.
Whilst rmly pushing the rotary
brush into the trigger handle turn
clockwise to lock into position.
Switch on the pressure washer
and squeeze the trigger to
release water spray or water
and detergent mix.
To remove the rotary brush from
the trigger handle rmly push and
twist the lance anti-clockwise to
unlock. Pull to remove.

Using your machine
Unhook the solution tube and
insert into the solution bag.
Solution only dispensed with
the trigger handle, lance and
solution nozzle, or car/outdoor/
rotary brush if supplied.
Switch the pressure washer on
and squeeze trigger to dispense
the water and solution mix.
After use rinse the pressure washer
to prevent blockages. Inset the
solution tube into a bucket of fresh
water (Max 40�C), turn the
machine on and squeeze
the trigger for 1 minute.
Using solution with your pressure washer
IMPORTANT: When using solution make sure you follow the dilution instructions and use Vax solution only.
Solution can only be used with the trigger handle, lance and solution nozzle, or car/outdoor/rotary brush
if supplied. Solution CANNOT be used with the jet and turbo nozzles.
TIP
Always make sure the
pressure washer is
switched OFF before
connecting/disconnecting
the pressure hose,
lance, accessories or
detergent bag.

To access the water
lter, unscrew water inlet
connector and remove.
Always store tools and power cord
into the allocated storage slots.
Maintenance
Storage
Let’s talk technical
To remove the water lter,
pinch the inner water lter
tab with pliers and gently pull.
The water lter can be rinsed
under running water periodically.
IMPORTANT: Always rinse fresh water through your pressure washer and accessories for 1 minute after using
detergent to prevent blockages.
IMPORTANT: Before storing your machine always make sure no water remains in the pressure washer or hose/
accessories to prevent frost damage. Keep in a dry place above zero degrees and out of the reach of children.
TIP
Leave the trigger handle
attached when storing
the pressure hose.

Removing a blockage in the lance and nozzles
Let’s talk technical
To remove the lance from trigger handle
rmly push and twist the lance anti-clockwise,
when unlocked pull to remove.
To remove the nozzle press the
nozzle release button and pull.
Insert the nozzle cleaning tool into the
end of lance and nozzles to remove
any dirt or debris.
Before carrying out any
maintenance make sure
the machine is switched o
and unplugged.
CAUTION

What to do if it goes wrong
SolutionProblem
• Check the contents panel on the box to make sure the part is included with
your machine.
There is an
accessory missing
• Make sure the on/o switch is set to the ‘I’ position.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a British
13amp fuse.
• Check if your RCD has been tripped, if it has tripped, reset it.
• The power cord may be damaged.
Why won’t the pressure
washer turn on?
• The pump may have stopped, make sure the on/o switch is set to the ‘I’ position
and check the plug fuse.
• The pump may have stopped. This may be because of overheating due to poor
water supply. Check the water ow rate to your water supply.
• Hose may be blocked or kinked, check for leaks in the hose and clear any
blockages. Straighten out the hose to ensure no kinks and check the hose pipe
connections to the tap and water inlet.
• There may be an air lock. To remove, unlock the trigger safety lock and squeeze
the trigger to release water before the machine is switched on.
• Check assembly of detergent application bottle. Go to ‘Using your machine.’
Nozzle/accessory may be blocked, clear any blockages and clean nozzle. Go to
‘Lets talk technical.’
Why won’t the water/
detergent dispense?
• Hose may be blocked or kinked, check for leaks in the hose and clear any
blockages. Straighten out the hose to ensure no kinks and check the hose pipe
connections to the tap and water inlet.
• Nozzle may be blocked, clear any blockages and clean nozzle. Go to ‘Lets talk
technical.’
• Remove and clean the water inlet lter. Go to ‘Taking care of your machine.’
• Check the water ow rate to your water supply.
Why won’t the
pressure washer reach
operating pressure?

Getting in touch
†Registration required. Terms and conditions apply, see vax.co.uk for details.

Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Universal detergent 1-9-133398-00
Universal detergent to aid the break down and removal of stubborn
dirt, moss, and grime.
Patio & Decking detergent 1-9-133401-00
Patio & decking detergent to aid the break down and removal of stubborn dirt
from patio and decked areas.
Wash & Protect vehicle detergent 1-9-133400-00
Wash & protect vehicle detergent to aid the removal of road dirt, oil and grease
from vehicles, and provide short term protection against weathering conditions.
Standard lance 1-9-133749-00
Standard lance connection between your trigger handle and attachments.
Detergent nozzle 1-9-133759-00
A detergent nozzle to directly apply detergent to surfaces to help loosen
dirt, moss, and grime.
Attachable detergent bottle 1-2-133752-00
A detergent nozzle to directly apply detergent to surfaces to help loosen
dirt, moss, and grime.
Trigger handle 1-2-133750-00
A smooth shape hand handle with an easy squeeze trigger and a built in
safety lock for easy on/o trigger release.

Turbo nozzle 1-9-133753-00
A high pressure turbo nozzle to blast away tough embedded dirt from high trac areas.
Jet nozzle 1-9-133787-00
Jet nozzle to apply concentrated pressure to dislodge dirt and grime on all surface types.
Patio cleaning set 1-9-133767-00
A large circular cased brush, supplied with an extension tube for cleaning concentrated areas
quickly and eciently. Ideal for: Patios, Decking, Driveways, Garage doors.
Rotary brush 1-9-133766-00
A rm bristled brush with 360 degree rotation, providing extra scrub power for an extra clean.
Ideal for: Car alloy wheels, Car grills.
Car brush 1-9-133765-00
A soft bristled brush, perfect for agitating tough dirt from sensitive surfaces.
Ideal for: Car mirrors, Car body.
Outdoor brush 1-9-133769-00
A handy outdoor brush, perfect for gently removing dirt from various outdoor surfaces.
Ideal for: Garden furniture, Conservatories.
Extension tube 1-9-133768-00
An additional connection tube providing you extra reach.
Replacement hose (10m) 1-9-133751-00
An additional high pressure hose, highly durable and resistant to weather conditions.

Notes
