Vax PowerWash VPW4 User manual

PowerWash
2500W – VPW4
Heavy duty Pressure Washer
Perfect for the most challenging cleaning needs,
including large outdoor areas, brickwork and
commercial vehicles.
VPW4 vax.co.uk

Thank you for buying this Pressure Washer.
Taking care of your outdoor cleaning
The pressure washer is designed to make outdoor cleaning tasks as eective and ecient
as possible and this user guide will help you get the most out of your machine.
Completing outdoor cleaning tasks using a Vax pressure washer will keep your outdoor
items and surfaces cleaner for longer.
Taking care of your Pressure Washer
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your outdoor cleaning tasks.
Let’s talk safety
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0844 412 8455 (ROI) 1-800 928 308
Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the pressure washer before calling.
Alternatively, you can write to us at:
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK
Let us know what you think @VaxUK
This pressure washer is intended for household use only and
NOT for commercial or industrial use.
• ThisPressurewasherisforoutdooruseonly.
• Itisyourresponsibilitytocheckthesuitabilityofthesurface
to be cleaned. Vax UK Ltd cannot be held responsible for
damage caused.
• Keepngers,hairandlooseclothingfrommovingpartsand
openings whilst using the pressure washer.
• Whenusingyourpressurewashertherecommendedworking
distance between the nozzle and surface area or object to be
cleaned is 30cm.
• Thisappliancecanonlybeusedbychildrenagedfrom8years
and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children should not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
• VaxonlyrecommendtheuseofVaxgenuineaccessoriesand
solution to be used with this pressure washer. The use
of non-branded Vax accessories and solution will invalidate
your warranty.
Basic safety precautions
3Always wear suitable clothing footwear and eye protection
whilst using the pressure washer.
3Always connect the water supply, remove the lance and squeeze
the trigger to run water through the machine before switching
the power on.
3Always use a suitable hose connector to match the coupling
on the pressure washer with a non-return valve at tap end
of the supply hose.
3Always unplug the pressure washer before cleaning or carrying
out any maintenance.
3Always turn o and unplug the pressure washer before
disconnecting or connecting the hose, after use always wrap the
pressure hose and power cord around the storage clips provided.
3Always release any built up pressure in the handle prior to
disconnectingthehoseandensurewaterinletlterisclean
prior to storage in a cool dry place.
3Use only CE approved 13amp extension cords with RCD,
non-approved extension cords may overheat. Care should be
taken to arrange the extension cord as it could be a trip hazard.
3Always make sure the power/extension cord is fully unwound and
prevent the power/extension cord from getting wet during use.
3Always replace the fuse in the plug with a British 13amp fuse.
Always protect the power cable from heated surfaces or near
open ames.
3Always carry the pressure washer by the handle.
3Always check water hose and accessories are not damaged,
broken or worn before use.
Don’ts
Do’s
8Don’t leave the pressure washer unattended or running
when not in use for more than 5 minutes without depressing
the trigger.
8Don’t use this pressure washer if it has been dropped,
damaged or immersed in water.
8Don’t use pressure washer if the power cord or plug is
damaged. Please contact our Customer Care Line on (UK)
0844 412 8455 (ROI) 1-800 928 308.
8Don’t handle the plug of the pressure washer with wet hands.
8Don’t use the pressure washer without supply hose (minimum
length 7.5m) in place and unwind the hose fully from reel.
8Don’tusethepressurewasherwithoutthewaterlterinplace.
8Don’t pull or carry this pressure washer by the power cord.
Don’t use the power cord as a handle, pull the power cord
around corners or sharp edges or close a door over the
power cord. Don’t unplug pressure washer by pulling on
the power cord.
8Don’t aim the pressure washer at people, animals, plants,
electrical components, wires, or the pressure washer itself.
8Don’t use the pressure washer on electrical components,
damaged/delicate paint surfaces, tyres, engines/motors.
8Don’t use the pressure washer with incorrect voltage as this
may result in damage or injury to the user. The correct voltage
is listed on the rating label.

Contents Getting to know your machine
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
What to do if it goes wrong
Getting in touch
Accessories
Notes
Pressure hose
reel handle
Water outlet
Solution tube
Handle
Pressure hose reel
Power cord
hook
Trigger handle storage
Lance
storage
On/o switch
Water inlet and connector
(already installed)
Wheel
Pressure Washer
Included with
your machine
Pressure hose
Trigger handle
Lance
Turbo nozzle
Nozzle cleaning tool
Name Pressure Washer
Voltage 2500W
Wattage 220-240V~50Hz
Max Pressure 180 bar
Working Pressure 120 bar
Flow Rate 510L/Hr
Technical Specication
Subject to technical change without notice.
Universal detergent
1-9-133398-00
Patio & Decking detergent
1-9-133401-00
Wash & Protect
vehicle detergent
1-9-133400-00
Accessories & Consumables
*To purchase consumables and accessories, please visit vax.co.uk
Water inlet connector
Jet nozzle
(blue nib)
Solution nozzle
(white nib)

Attach both wheels
and push until they click
into place.
Whilst holding the handle
to secure the machine, pull
the pressure hose slowly
to remove fully from the
hose reel.
To connect pressure hose to trigger handle,
press the pressure hose release button and
push pressure hose to lock into position.
Gently pull the pressure hose to make sure
it is locked securely.
Attach the hose connector
to water inlet by turning
clockwise until tight.
Push the pressure hose
rmlytothewateroutlet
and turn the pressure hose
collar clockwise to tighten.
Whilstrmlypushing
the lance into the trigger
handle turn clockwise
to lock into position.
Assembling your pressure washer
Preparing your pressure washer for use
Always make sure the pressure washer and water supply are o before connecting or disconnecting the hose
and accessories.
Getting started Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE IMPORTANT: Always remove the pressure hose fully from the reel when in use.
Always make sure the trigger safety lock is in the LOCKED position when not in use or connecting/disconnecting the
pressure hose.
Always check water hose, pressure hose, lance and accessories are not damaged, broken or worn before use.
To attach the handle into the top of the
pressure washer, align the handle with the
screw holes making sure not to trap the
solution tube. Slide together and insert
2 screws and turn clockwise to tighten.
A trigger safety lock is located underneath
the handle. The safety lock should always
be in LOCKED position before connecting
/disconnecting the pressure hose to the
trigger handle.
To remove the lance from the
triggerhandlermlypushand
twist the lance anti-clockwise.
When unlocked pull to remove.
TIP
After connecting pressure
hose, lance and accessories
checktheyaresecurelytted
and locked in place before
turning on.
LOCKED
UNLOCKED

Never use the turbo nozzle on cars,
tyres and engines.
WARNING
To attach the jet nozzle,
tthelancewitharm
push and twist to lock
into place.
The jet nozzle has a wider spray and is ideal for use on surfaces areas such as cars, garden furniture,
decking and boats.
To attach the turbo
nozzle,tthelancewith
armpushandtwistto
lock into place.
Using your accessories
The turbo nozzle has a more concentrated spray and is ideal for use on very dirty surfaces, patios or masonry.
Asitisnotttedwithapressureregulatoritisnotsuitableforuseondelicateorpaintedsurfaces.
Using your machine
Hold down the release button on the
lance, push the jet nozzle and lance
rmlytogetheruntilyouhearan
audible CLICK. Release the button and
gently pull the jet nozzle to make sure it
is locked secure before use.
Hold down the release button on the
lance, push the turbo nozzle and lance
rmlytogetheruntilyouhearanaudible
CLICK. Release the button and gently pull
the turbo nozzle to make sure it is locked
securely before use.
Squeeze the trigger on the
trigger handle to release
a high pressured water jet,
and start cleaning.
IMPORTANT: Always make sure the machine is switched o and the safety button on the trigger handle
is LOCKED before connecting/disconnecting the lance, nozzle or accessories.
Make sure water supply
is not connected. Firmly
push the water hose pipe
with suitable connector
onto the water inlet to
lock into position.
Connect water hose pipe to
a suitable water supply and
turn water on.
Before plugging the
machine in, press the
unlock safety button
on the trigger handle
and squeeze the trigger
until water starts to ow
through the nozzle.
IMPORTANT: Always use an RCD adaptor when using this pressure washer.
WARNING: Don’t leave the pressure washer running when not in use, or for more than 5 minutes to prevent overheating.
Before switching the pressure washer on, the trigger handle must be squeezed to release water and any airlocks in the
machine or pressure hose. Always release any pressure build up in the handle prior to disconnecting the hose.
Connect the power cord
to the mains supply via
an RCD adaptor.
Push the ‘I’ switch to turn on.
The machine will run for a
few seconds then stop but no
water will be released.
Squeeze the trigger on the trigger
handle to release a high pressured
water jet, and start cleaning.
Don’t aim the pressure washer
directly at people, animals, plants,
electrical components, wires or the
pressure washer itself.
WARNING
Push ‘O’ switch to turn o.
Using your machine
Squeeze the trigger on the trigger handle to release a high
pressured water jet, and start cleaning.

Toaccesswaterlter,
unscrew water inlet
connector and remove.
Always store tools and
power cord into the
allocated storage slots.
Maintenance
Storage
Taking care of your machine
Toremovewaterlter,pinch
theinnerwaterltertabwith
pliers and gently pull.
Waterltercanberinsed
under running water
periodically.
Using your machine
IMPORTANT: Always rinse fresh water through your pressure washer and accessories for 1 minute after using
solution to prevent blockages.
IMPORTANT: Before storing your machine always make sure no water remains in the pressure washer or hose/
accessories to prevent frost damage. Keep in a dry place above zero degrees and out of the reach of children.
TIP
Leave the trigger handle attached
when storing the pressure hose.
Unhook the solution tube and
insert into the solution bag.
Solution only dispensed with
the trigger handle, lance and
solution nozzle, or car/outdoor
/rotary brush if supplied.
Switch the pressure washer on
and squeeze trigger to dispense
the water and solution mix.
After use rinse the pressure washer
to prevent blockages. Inset the
solution tube into a bucket of fresh
water (Max 40�C), turn the
machine on and squeeze
the trigger for 1 minute.
Using solution with your pressure washer
Always make sure the pressure
washer is switched OFF before
connecting/disconnecting the
pressure hose, lance, accessories
or solution bag.
WARNING
IMPORTANT: When using solution make sure you follow the dilution instructions and use Vax solution only.
Solution can only be used with the trigger handle, lance and solution nozzle, or car/outdoor/rotary brush
if supplied. Solution CANNOT be used with the jet and turbo nozzles.

Before carrying out any
maintenance make sure the
machine is switched o and
unplugged.
WARNING
Taking care of your machine
To remove the lance from
triggerhandle,rmly
push and twist the lance.
To unlock, pull to remove.
Removing a blockage in the lance and nozzles
To remove nozzles press
the nozzle release button
and pull.
Insert the nozzle cleaning tool
into the end of lance and nozzles
to remove any dirt or debris.
Let’s talk technical
Storing the hose
To begin storing your pressure
hose, place the collar end of
the hose to the right of the reel.
Ensuring one velcro strap is at
this end.
Guide the pressure hose with
one hand whilst turning the reel
slowly until hose has wrapped
around twice.
To recoil the remainder of the
hose, secure the machine by
holding the handle and turn the
reel handle slowly.
Once coiled, wrap the second
velcro strap around the already
coiled hose and secure.
Push the velcro strap through
the hole at the side of the hose
reel and pull tight.
Pull the velcro strap over the
reel and secure.
IMPORTANT: Before storing your machine always make sure no water remains in the pressure washer or hose
/accessories to prevent frost damage. Keep in a dry place above zero degrees and out of the reach of children.

SolutionProblem
What to do if it goes wrong Getting in touch
There is an
accessory missing
Why won’t my pressure
washer turn on?
Why won’t the water
/solution dispense?
Why won’t my pressure
washer reach operating
pressure?
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the pressure washer
before calling.
•Checkthe‘Thispackcontains’panelontheboxtomakesurethepart
is included with your machine.
•Makesuretheon/oswitchissettothe‘I’position.
•Theplugmaynotbefullypushedintotheelectricalsocket.
•Checkthefuseintheplugifthisneedsreplacing,alwaysreplacewith
a British 13amp fuse.
•CheckifyourRCDhasbeentripped,ifithastripped,resetit.
•Thepowercordmaybedamaged.PleasecontactourCustomerCare
Line on (UK) 0844 412 8455 (ROI) 1-800 928 308.
•Hosemaybeblockedorkinked,checkforleaksinthehoseandclear
any blockages. Straighten out the hose to ensure no kinks and check
the hose pipe connections to the tap and water inlet.
•Nozzlemaybeblocked,clearanyblockagesandcleannozzle.
Go to the ‘Lets talk technical’ page.
•RemoveandcleanthewaterinletlterGotothe‘Takingcareofyour
machine’ page.
•Checkthewaterowratetoyourwatersupply.
•Thepumpmayhavestopped,makesuretheon/oswitchissettothe
‘I’ position and check the plug fuse.
•Thepumpmayhavestopped.Thismaybebecauseofoverheatingdue
to poor water supply. Check the water ow rate to your water supply.
•Hosemaybeblockedorkinked,checkforleaksinthehoseandclear
any blockages. Straighten out the hose to ensure no kinks and check
the hose pipe connections to the tap and water inlet.
•Theremaybeanairlock.Toremove,unlockthetriggersafetylock
and squeeze the trigger to release water before the machine is
switched on.
•CheckassemblyofsolutionapplicationbottleGotothe‘Using
your machine’ pages. Nozzle/accessory may be blocked, clear any
blockages and clean nozzle Go to the ‘Lets talk technical’ page.

Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Jet nozzle 1-9-133787-00
Jet nozzle to apply concentrated pressure to dislodge dirt and grime on all surface types.
Turbo nozzle 1-9-133753-00
A high pressure turbo nozzle to blast away tough embedded dirt from high trac areas.
Patio cleaning set 1-9-133767-00
A large circular cased brush, supplied with an extension tube for cleaning concentrated areas
quickly and eciently. Ideal for: Patios, Decking, Driveways, Garage doors.
Rotary brush 1-9-133766-00
Armbristledbrushwith360degreerotation,providingextrascrubpowerforanextraclean.
Ideal for: Car alloy wheels, Car grills.
Car brush 1-9-133765-00
A soft bristled brush, perfect for agitating tough dirt from sensitive surfaces.
Ideal for: Car mirrors, Car body.
Outdoor brush 1-9-133769-00
A handy outdoor brush, perfect for gently removing dirt from various outdoor surfaces.
Ideal for: Garden furniture, Conservatories.
Extension bar 1-9-133768-00
An additional connection tube providing you extra reach.
Replacement hose (10m) 1-9-133751-00
An additional high pressure hose, highly durable and resistant to weather conditions.
Universal detergent 1-9-133398-00
Universal detergent to aid the break down and removal of stubborn dirt, moss, and grime.
Patio & Decking detergent 1-9-133401-00
Patio & decking detergent to aid the break down and removal of stubborn dirt from patio
and decked areas.
Wash & Protect vehicle detergent 1-9-133400-00
Wash & protect vehicle detergent to aid the removal of road dirt, oil and grease from vehicles,
and provide short term protection against weathering conditions.
Standard lance 1-9-133749-00
Standard lance connection between your trigger handle and attachments.
Detergent nozzle 1-9-133759-00
A detergent nozzle to directly apply detergent to surfaces to help loosen dirt, moss, and grime.
Attachable detergent bottle 1-2-133752-00
A detergent nozzle to directly apply detergent to surfaces to help loosen dirt, moss, and grime.
Trigger handle 1-2-133750-00
A smooth shape hand handle with an easy squeeze trigger and a built in safety lock for easy
on/o trigger release.

NotesNotes

Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 0QH, UK
email: inf[email protected] website: vax.co.uk
Version 1.0
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the VPW series is manufactured in compliance with the following Directives:
Safety:2006/95/ECLowVoltageDirective.EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
@VaxUK
