VBike Canada 2020 User manual

www.vbike.ca
LEXO 20 / LEXO 20s / LEXO ST / LEXO STs
Owner’s Manual
2020
vBike Canada
VBIKE
CANADA

vBike Canada

Contents
VBIKE MANUAL
02
VBIKE MODELS
7-12
BATTERY CHARGING
& WARNING
19-21
LCD DISPLAY
FUNCTIONS
28-30
WARRANTY
33-34
SAFETY CHECK
03
UNBOXING
13-16
OPERATING YOUR
NEW EBIKE
22
MAINTAINING
YOUR EBIKE
31
WELCOME
01
PRE-RIDE
INSPECTION
4-6
BATTERY
17-18
VBIKE
COMPONENTS
23-27
SIZING
32

Congratulations
on Your
Purchase of vBike
vBike tries all its best to offer you an enjoyable
experience with your electric bike
Thank you for choosing vBike.
It is necessary to read this manual carefully before
using your ebike. It will help you keep your
ebike in good condition. More importantly,
this will ensure your safety while using the ebike.
Customer Service:
[email protected]
Marketing & Sale:
[email protected]
Toll Free:
[phone]
Website:
www.vbike.ca
If you have any questions please
do not hesitate to contact us
1

VBIKE
MANUAL
vBike manual contains details for you about the products, information about operation,
maintenance and also other useful tips. It is essential to read and understand this entire
manual before using your ebike in order to drive safe and prevent accident.
The warnings concerning the safe operation and maintenance help you to get more familiar
with your ebike and drive safe. Failure to read and understand this manual can face you with
danger.
Please read carefully and pay more attention to the parts which are mentioned as Attention,
note or parts which has “CAUTION” Symbol as they include the information which help you
drive safe.
Keep this manual for your reference. But you are seriously recommended to download and
review the latest version of manual from the vBike website at "www.vbike.ca/help" because
all content in this manual is subject to change or withdrawal without notice so you can have
the access to the latest version of the manual. vBike do all its best to ensure the accuracy of
its documentation and assumes no responsibility or liability if any errors or inaccuracies
appear within.
As riding any kind of bike comes along with some risks which cannot be predicted or avoided
and it is impossible to foretaste all conditions that can happen during riding, this manual
makes no representations about the safe use of ebikes under all situations and it is the sole
responsibility of the rider.
www.vbike.ca
vBike Canada
2

Safety
Check
Read this entire manual before assembling or using your new vBike electric bike.
Do not disassemble or replace the original vBike electrical components on your bike.
Doing so will invalidate your warranty and could put you in danger.
Be 16 or older
Wear an approved bicycle or motorcycle helmet
Keep your e-bike in good working order
You also need to follow the same rules of the road as regular cyclists.
You must check your local regulation to ensure that you are riding legally and safely.
These laws may specify the need for mandatory equipment, use of hand signals,
and where you can ride.
What Ebike Riders Need
www.vbike.ca/regulations/
If you are riding your ebike out of Canada
You must check your local regulation to ensure that
you are riding legally and safely.
Helmets and Local Laws
Always wear a helmet when riding your ebike. Ensure that the helmet fits your head and is
securely tightened down. Before riding, read local laws and comply with all rules relating to
biking and ebiking in your area. If you attach a seat for children to the ebike they must
also be wearing a properly fitted helmet at all times.
Since some of the provinces in Canada have slightly different regulations surrounding electric
bikes,the customers must check their local regulation to ensure that they are riding legally
and safely. To learn more about provincial regulations go to:
If You Are Riding Ebikes in Canada
Failure to wear a helmet when riding may result in serious injury or death.
3
CAUTION
CAUTION
CAUTION
www.vbike.ca
vBike Canada

4
Pre-ride
Inspection
Before each ride it is necessary to inspect your ebike to ensure there are no loose fasteners or
accessories. If you are not sure how to conduct a complete check of the condition of your ebike
before every ride, you should consult a certified, reliable bike mechanic for assistance.
Make sure to specifically check that both the front and rear axles are secure. Ensure all hardware is
secured and all approved accessories are properly attached to your ebike. Check to ensure the
handlebar, handlebar stem, and seat post are properly fastened, aligned, and fitted to the user.
Tires and Wheels
The tire pressure of both wheels needs to be checked before riding to ensure the tires are inflated
to the recommended pressure (most common 20-22 PSI). The rider is highly recommended to check
the suggested pressure which is printed on the side of the tire wall. Tires without the correct amount
of air pressure can reduce performance, increase tire and component wear and make riding your
bike unsafe. Check the tires and inner tubes to be in good working condition and make sure there is
no visual damage. If you notice any puncture, cut or damage in tires or inner tube, you have to
replace them.
Battery and Battery Charger
The battery MUST be locked onto the frame battery mount properly before use and make sure the
battery is operating properly. It is recommended to unplug the battery charger from the outlet, and
store it in a safe location before you ride.
Chain Cranks and Pedals
Make sure the chain is clean, oiled and runs smoothly, the pedals are securely tightened to the cranks
and the cranks are strongly tightened and are not bent.
Motor Drive Assembly and Throttle
Check all power cables running to the motor to be secured and undamaged and make sure the motor
is spinning smoothly and motor bearings are in good working order.
Electrical Cables
Check connectors to be fully seated and free from debris and make sure all cables and cable housing
to be free from damage. Make sure headlight, taillight and brake light are functioning properly.
Brakes
Your wheels should always spin straight. If they wobble side to side or up and down or if the wheels
become untrue or spokes loosen, they must be repaired. Do not attempt to true or tighten unless you
have adequate knowledge, tools and experience. It is highly recommended to ask a certified, reliable
bike mechanic for repairment.
Check brake pads for wear and ensure they are not over worn and are correctly positioned in relation
to the rims. Make sure brake cables are lubricated, properly adjusted, and show no obvious wear.
Pull the brake levers to make sure your brakes are free from damage and are working accurately.
When you fully squeeze the brake levers, ensure neither the front or rear brake levers touch the
handlebar. If you find a problem take your bike to a certified, trustworthy bike mechanic to have the
brakes repaired.
www.vbike.ca
vBike Canada

Tips For Riding Safe
Electric bike riders need to become adapted to the power controls before riding. So, you
should ride your new bike in an open area and set the power assist level to “0”. When you feel
self-assured operating your bike, you can increase the power assist gradually. Keeping your hands
over the brake levers is good practice. The brake levers have motor inhibitors that will shut down the
motor power when applied. If for any reason you lose control, apply the brake levers immediately to
shut down the motor power. Never stop your ebike by using your feet because you will lose you
balance and you can be injured.
Maintenance
It is important to perform proper maintenance and often fine-tune your ebike to ensure
optimal performance and safe riding. Regularly lubricate your chain, gear shifter, sprocket and all
moving parts. Always check the condition of your ebike before riding and make sure that it is well
maintained. Your cables, spokes and chain can be stretched after an initial break-in period of
80-160 km (50-100 mi), and bolted connections can be loosened. You are recommended to ask a
certified, reputable bike mechanic perform a tune-up on your ebike after your initial break-in in
period of 80-160 km.
Electric bikes are suitable for one person to ride. In order to avoid the wheel center of gravity shift
or unstable operation, please do not carry people. For safety of your cycling, please do not use
electric bikes for minors, pregnant women and the elderly.
The charger must be stored in a cool and dry place as not to cause a short circuit inside the charger.
So, do not carry it with the bike as possible to avoid damaged caused by collision.
It is really important to have the proper air pressure in your tires. Never underinflate or
overinflate your tires. Low pressure can result in loss of control and overinflated tires can burst.
Always Inflate your tires from a regulated air source with an available pressure gauge. Inflating your
tires with an unregulated air source may overinflate them, resulting in a burst tire. The suggested
pressure is printed on the side of the tire walls.
Before changing a tire or tube, make sure that all air pressure has been removed from
the inner tube prior to removing the tire from the rim. Failure to remove all air pressure from the inner
tube could result in serious injury.
This manual is not intended as a detailed service or repair manual. Seek assistance from your local
bike shop mechanic at a reputable bike shop with all the proper certifications and qualifications.
If you do not have the experience, skill, or tools to
complete maintenance or adjustment of your bike, it is
seriously recommended to ask certified, reputable bike
mechanic to check your bike and ensure it is safe to ride.
5
CAUTION
CAUTION
CAUTION
CAUTION
www.vbike.ca
vBike Canada

6
Liability Disclaimer
Riding any kind of ebike comes along with some risks which can’t be predicted or avoided. By
choosing to ride an ebike, you assume the responsibility for that risk. Taking proper care of ebike
components can lower the risk of sudden failure of components but cannot prevent it. These sudden
failures could cause serious harm, injury or death to the rider. If you notice abnormalities in any
component on the ebike, please take it to a licensed mechanic to be repaired or replaced immediate-
ly. You are responsible for your own actions while using an electric bike. MAPTEC Inc. (vBike) is not
responsible/nor liable for any accidents or injuries or death (whether caused by you or others) that
may occur during your use. We recommend contacting your insurance provider to determine if your
current insurance policy would cover you in the event of an accident.
Do Not Engage in Extreme Riding
Bikes and ebike parts have strength and integrity limitations. Extreme riding, such as jumping,
stunting, etc., can damage ebike components and face the rider with serious injury or death. As
electric bikes are heavier and faster than normal bikes, the rider should pay more caution and care
while riding."
Riding in wet conditions
The vBike Electric Bikes can stand up to light rain showers without sustaining damage. However, the
ebike and its mechanical and electrical components are not waterproof. We do not recommend
storing or using the ebike in wet conditions if it is not absolutely necessary. It is recommended not
to ride at wet condition unless when it is necessary. In Wet condition the rider should consider
decreasing speed and increasing braking distances. Feet or hands can slip in wet conditions and
cause serious injury or death. The warranty for the vBike Electric Bikes does not cover water
damage, salt damage and corrosion.
Riding at Night
It is recommended not to ride at night unless when it is necessary. Riding at night have more risks
than riding during the day as a result of decreased visibility so riders are encouraged to exercise
increased caution. Before riding at night, you need to check that reflectors are installed on your ebike
and the front headlight and rear taillight are turned on and adjusted so other people on the road can
see them obviously. It is suggested to wear bright clothing at night if possible.
Street Legality
Under Canadian regulations, ebikes sold by MAPTEC Inc. (vBike) in Canada are street legal. PLEASE
NOTE, it is important for you to check your local laws to ensure that you are riding legally and safely.
For technical assistance or warranty claims contact vBike at support @vbike.ca "
Max Weight
The max weight that the bike can safely carry is a total weight of 330 lbs. If the rear rack is attached
to the bike the max weight it can hold is 55 lbs. So, in the case of loading for example 40 lbs. on rear
rack, maximum rider weight could be 290 lbs. Failure to adhere to these weight limits may result in
damage to the bike, the rack, or cause serious injury to the rider.
[email protected].
Avoid riding an ebike while you are under the influence of
alcohol, drugs or any other substance or condition which
could weaken your motor functions and judgement (like
other vehicles).
www.vbike.ca
vBike Canada

7
LExO st
www.vbike.ca
vBike Canada
27.5" X 18.5" Foldable
32 km/h - 500w
5.2 - 6.8ft
SHIMANO 8 Speed
14-34 Teeth
Double Shoulder Pressure
Shock Absorber
Bafang Motor
Shimano Mechanical
Disk Brake
6-8h
LG/Panasonic/Samsung 48v
14Ah/17Ah/20Ah

LExO STs
8
www.vbike.ca
vBike Canada
27.5" X 18.5" Foldable
32 km/h - 500w
5.2 - 6.8ft
SHIMANO 8 Speed
14-34 Teeth
Double Shoulder Pressure
Shock Absorber
Bafang Motor
TEKTRO Hydraulic
Disk Brake
6-8h
LG/Panasonic/Samsung 48v
14Ah/17Ah/20Ah

LExO 20
9
www.vbike.ca
vBike Canada
27.5" X 18.5" Foldable
32 km/h - 500w
5.2 - 6.8ft
SHIMANO 8 Speed
14-34 Teeth
Double Shoulder Pressure
Shock Absorber
Bafang Motor
6-8h
LG/Panasonic/Samsung 48v
14Ah/17Ah/20Ah
Shimano Mechanical
Disk Brake

10
LEXO 20s
www.vbike.ca
vBike Canada
27.5" X 18.5" Foldable
32 km/h - 500w
5.2 - 6.8ft
SHIMANO 8 Speed
14-34 Teeth
Double Shoulder Pressure
Shock Absorber
Bafang Motor
TEKTRO Hydraulic
Disk Brake
6-8h
LG/Panasonic/Samsung 48v
14Ah/17Ah/20Ah

11
www.vbike.ca
vBike Canada
Models LEXO STs
Battery LG/Panasonic/
Samsung
LEXO ST
14Ah/17Ah/20Ah 14Ah/17Ah/20Ah
Hub Motor (Min/Max) 500w/800w 500w/800w
Motor
Suspension Front Fork
TEKTRO/SHIMANO
Brake System
SHIMANO Gear System
KENDA KRUSADE Tire
Rims
Leather Handle Grip
Foldable
Bright LED Front/ Rear Light
LED Rear Brake Light
Fenders
Rear Rack
Bell
Rider Height
Bafang
Yes
Mechanical
(With Motor Inhibitor)
8 Speed 14-34 Teeth
4" X 20" Reflective Stripe
Spoke Rim
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5.2 - 6.8ft
Bafang
Yes
Hydraulic
(With Motor Inhibitor)
8 Speed 14-34 Teeth
4" X 20" Reflective Stripe
Cast Alloy Rim
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5.2 - 6.8ft

12
www.vbike.ca
vBike Canada
LEXO 20
14Ah/17Ah/ 20Ah
LEXO 20s
14Ah/17Ah/ 20Ah
500w/800w 500w/800w
Bafang
Yes
Mechanical
(With Motor Inhibitor)
8 Speed 14-34 Teeth
4" X 20" Reflective Stripe
Spoke Rim
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5.2 - 6.8ft
Bafang
Hydraulic
(With Motor Inhibitor)
8 Speed 14-34 Teeth
4" X 20" Reflective Stripe
Cast Alloy Rim
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5.2 - 6.8ft
Yes

13
Unboxing
You received Your ebike in the box 100% assembled. Following instructions are intended to serve
you as a guide for unboxing and getting familiar with the new ebike.
As shipping can sometimes be bumpy, the ebike may need some adjustments upon
being received and unboxed. The most affected parts are gear shifter guard and fenders. If you have
any problem please contact us at [email protected].
The box includes:
Getting Started
1- Completely Assembled vBike
2- Battery
3- Battery charger
4- Two battery keys
5- vBike owner manuals
vBike Canada
CAUTION
Before riding your ebike, remove everything from the box and make sure you received all above listed
items. If anything is missing or damaged do not hesitate to contact [email protected] for assistance.
Please keep one of the battery keys as your backup in a safe place.
For video instructions on how to unbox and unfold your vbike please visit
www.vbike.ca/support
CAUTION
www.vbike.ca
vBike Canada

As soon as the safety clasp is locked, move the safety pin sideways thus
it is inserted into the clasp and locked it in place.
Folding and
Unfolding
the Bike
Unfolding the Bike
You receive your vBike electric bikes fully assembled.
You just need to make sure everything is properly secured.
vBike electric bike folds at the handlebars and in the center of the frame.
Pull the handlebars to
the upright position
and push the clasp
down tightly.
Stand near where the battery is exposed. Grab the handlebar stem and rear end of the bike, lift the
bike slightly off the ground and swing the bike to its closed position.
Second Step: Unfolding the Frame
Pull up the latch and pull off the clamp and
move it to A 180 degree position.
Make sure that U-Lock is set in the position, push
the clamp to lock in the place, then move the
latch ounterclockwise as a second lock.
First Step: Unfolding the Handlebar
14
www.vbike.ca
vBike Canada
U-Lock

Unfolding the Pedals
Note: For folding the bike: Please pull the toggle outwards and lower it to its folding position
PREPARING TO RIDE
Pull the toggle outwards and lower it into its unfold-
ing position
Do pre-ride Inspection (as mentioned in Pre-Ride Inspection Section) and before riding make sure
all components are properly secured otherwise serious harm or death could happen. This includes
all parts of ebike such as brake system, lights, tires, fenders, pedals, handlebars, handlebar clamp,
cranks, seat, and seatpost clamp.
Ensure you are not able to twist the seat or stem out of alignment by hand.
You need to check your saddle to be positioned at the proper height for you. Sit on the saddle while
you are facing forward, place the ball of your foot on the pedal at its lowest point. at this time your
leg should be almost straight with a slight bend at your knee. At this height, when the pedal is at its
lowest point you should be able to pedal the ebike without overextending your leg. If you need to
overextend your legs and your hips move side to side during pedaling, it means the seat must be
lowered.
For adjusting your seat post height unlatch the seat post clamp. Move the seat post to the favorite
height and close the seat post clamp (as you can see in the picture).
As suspension system on seat post increase 10cm (4”) to minimum height of ebike,
minimum recommended rider’s height for using suspension seat post is 160cm (5’ 4”).
Riders with height less than 160cm (5’ 4”) are recommended to use regular seat post.
Make sure to hear the pedal lock into
place once in the unfolded position
CAUTION
www.vbike.ca
vBike Canada
Be sure you have read and understood the vBike manual carefully and completely.
18
15

16
Recommended
Torque Values
Ensure all cables and connectors at the front of the bike are securely connected,
otherwise certain components may not work accurately such as the front and rear light, the motor
inhibitor switches, LCD display, and throttle. The motor inhibitor switches shut the motor off as soon
as the rider hits the brakes.
If these switches do not operate precisely, it will take longer to slow down which in
some riding situations could cause injury or death to the rider, so you need to check all cable and
connectors regularly.
It is recommended that fasteners be tightened to the manufacturer's specification found below:
To adjust the angle of your seat, first loosen the nuts on both sides of the seat, then move the seat
to the desired angle and after that tighten the nuts. You can see the nuts in the picture.
Part Required Torque (N*m)
Hub 35-44
Reector 4-5
6-8
Disc mounting bolts
2-3
Brake Lever
8-10Rear Derailleur
15-17Seatpost
18-19
Saddle
35
Pedals
38-44
Bottom Bracket Parts
30-34Headset Parts
5-6Stem
4
Handlebars
CAUTION
CAUTION
www.vbike.ca
vBike Canada

17
www.vbike.ca
vBike Canada
Battery
Operating Your Battery
Your bike comes with a 48V 14Ah / 17Ah / 20Ah lithium ion battery (base on your ebike model) with
LG / Panasonic / Samsung cells. Key operating features of the battery can be found on this page.
Your bike’s battery comes with a set of keys that are used to keep it LOCKED/UNLOCKED to the
frame. Each battery has a unique set of keys.
Please keep one of the battery keys as your backup in a safe place."
CAUTION
For your battery security, please keep the battery key in LOCKED position and take
out the key. Only when you need to remove battery for any reason, use the key for UNLOCK the
battery.
CAUTION
In this photo you can see the battery key
positions. 1.Unlock Position 2. Locked /OFF
position 3. ON position.
When your key is in the unlock position, you will
be able to remove your battery from the frame.
For LEXO 20 / LEXO 20s / LEXO ST / LEXO STs
Push the key in firmly and turning clockwise
your key from the unlocked position to the
locked/OFF position. In this position the
battery will be locked to the frame while your
vBike is OFF and you can take out the key.
When your key is in the ON position, you will
be able to turn ON your vBike.
1.UNLOCK
3.ON
2.LOCKED/OFF
