VC 12760-OHR Technical document

IB_12760-OHR
Installations- und Betriebsanleitung
GERMANY
R
C
ÄnderungeninTechnik,DesignundAusstattungvorbehalten
VC-videocomponents.... aligned for professional videosystems
Dear Customer!
By selecting this VC product you have chosen a professional
device, which guarantees highest possible quality and
reliability.
Please read the following instructions carefully before
comissioning the product in order to be able to take full
advantage of all quality features regarding this product line.
GERMANY
R
CMounting and Operating Manual
Digital Video Recorder
Art. Nr. 12760-OHR
without changeable drive
Art. Nr. 12760-HHR
with changeable drive
Art. Nr. 12760-CHR
with CD-RW
Art. Nr. 12760-DHR
with DVD-RW
©2007 All contents of this document may change without prior notice
IB_12760-OHR / 09.102007

1
•
••
• Contents
ContentsContents
Contents
•
••
• Chapter 1.
Chapter 1. Chapter 1.
Chapter 1. Specification & System organization
Specification & System organizationSpecification & System organization
Specification & System organization
1. Product Contents List -------------------------------------------------------- 3
2. System Organization ---------------------------------------------------------
•Chapter 2. Product Description
Chapter 2. Product DescriptionChapter 2. Product Description
Chapter 2. Product Description
1. AVR-1612 / 812 Front Panel --------------------------------------------------- 5
2. AVR-1612/812 Rear Panel --------------- - - --------------------------------- 7
3. AVR- 12 Front Panel- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
. AVR- 12 Rear Panel -------------------------------------------------------- 9
5. Remote Controller --- - - -- - - - -- -- ---- -- -- --- -- -- --- - --- -- -- -- --- -- --- - --- -- 10
•
••
• Chapter 3.
Chapter 3. Chapter 3.
Chapter 3. Display
DisplayDisplay
Display
1. System Power ON ---------------------------------------------------------- 11
2. Screen View Selection ------------------------------------------------------ 12
3.Display Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
. PTZ/FOCUS Control -------------------------------------------------------- 13
5. System Power OFF --------------------------------------------------------- 13
•
••
• Charpter
CharpterCharpter
Charpter .
. .
. Search
SearchSearch
Search
Go to Search Mode --------------------------------------------------------- 1
1. Search by Date/Time ------------------------------------------------------- 1
2. Search by Event ----------------------------------------------------------- 15

2
•
••
•INDEX
•
••
• Chapter 5. SETUP
Chapter 5. SETUPChapter 5. SETUP
Chapter 5. SETUP
 Go to Menu -------------------------------------------------------------- 16
 Go to System Setup -------------------------------------------------------- 16
1. Display ------------------------------------------------------------------ 17
2. Camera ----------------------------------------------------------------- 21
3. Sound ------------------------------------------------------------------ 22
. System ------------------------------------------------------------------ 25
5. Event/Sensor ------------------------------------------------------------- 30
6. Disk Management ---------------------------------------------------------- 31
 Go to Record Menu -------------------------------------------------------- 3
1. Recording Operation -------------------------------------------------------- 3
2.Timer/motion setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 35
3. Alarm Record Schedule ----------------------------------------------------- 3
. Panic setup --- ----- ----- -- --- -- ----- ----- -- --- -- ------------ --- --- 37
 Go to Archiving ----------------------------------------------------------- 38
1. CD-RW and USB Back up --------------------------------------------------- 38
• IMPORTANT SAFETY INSTRUCTIONS ----- - -- -- --- - - - - - - - -- -- ------ - - - - - - ------- 0

3
1. Product contents List
1. Product contents List1. Product contents List
1. Product contents List
Please Confirm the Contents When open Package.


Basic Contents
Basic ContentsBasic Contents
Basic Contents
Remote Controller
User’s Manual Remote Client Program
Install CD
AAA Battery X 2
Power Cable


Option Contents
Option ContentsOption Contents
Option Contents
HDD
CD-RW USB Memory
1. Specification & Organization

2. System Organization
2. System Organization2. System Organization
2. System Organization
NETWORK
NETWORKNETWORK
NETWORK
Camera #1-8(16)
Alarm Sensor #1-8(16) Relay Out
VCR VGA
Monitor AV Monitor
Remote Client PC Image Printer
Video In
Video Out
TCP/IP
Alarm Input/Out
Remote
Controller
CD-RW
(It is not supported at the AVR- 00SX)
Backup
AVI Backup
WEB Client
USB
1. Specification & Organization

5
2. Description 8,16CH)
•Channel Selection Button is Prior to DISPLAY.
• When Remote Controller Sensor Input is Blocked by Something, it Cause 1Remote Controller
do NOT Work Properly.
• When Press any Button, it Operate with Beep Sound.
Tip
TipTip
Tip
1. Front Panel
1. Front Panel1. Front Panel
1. Front Panel
POWER
POWERPOWER
POWER : System Power On/Off
SHORTCUT
SHORTCUT SHORTCUT
SHORTCUT : Shortcut button for convenience.
CD/DVD RW :
CD/DVD RW : CD/DVD RW :
CD/DVD RW : Back up image to CD/DVD RW
HOLD :
HOLD : HOLD :
HOLD : Hold Current Jog/Shuttle position
RETURN
RETURNRETURN
RETURN : Cancel/Deselect/Return to previous screen
Direction / Navigation Button :
Direction / Navigation Button : Direction / Navigation Button :
Direction / Navigation Button : UP/DOWN/LEFT/RIGHT
ENTER
ENTERENTER
ENTER : Confirm/ Select next screen
CHANNEL
CHANNELCHANNEL
CHANNEL Select
SelectSelect
Select button
buttonbutton
button : Select Channel or Input Password.
FOCUS
FOCUSFOCUS
FOCUS : Adjust Focus (Near/ Far) or Reverse Play /Rewind
PAUSE
PAUSEPAUSE
PAUSE : Pause playback
IRIS
IRISIRIS
IRIS: Adjust Iris (Open/Close) or Forward Play / Fast forward
Jog shuttle :
Jog shuttle : Jog shuttle :
Jog shuttle : Outer wheel –variable REW or FF : Inner wheel –scroll frame – by frame while paused
1
2
3
10
11
9
8
7
6
5
12
123
11
12
9
8
765 10

6
2. Description
* Shortcut button
* Shortcut button* Shortcut button
* Shortcut button
123
9
8
7
6
5
DISPLAY
DISPLAYDISPLAY
DISPLAY : Select Screen Division Mode or Rotation Mode.
SEQ
SEQSEQ
SEQ : Select sequence screen mode.
PANIC
PANICPANIC
PANIC : Urgent Recording as setup.
ZOOM
ZOOMZOOM
ZOOM : Digital zoom on Live or Playback image
LOCK
LOCKLOCK
LOCK : Front Panel Lock Button (Default password: 123 )
(Default password: 123 )(Default password: 123 )
(Default password: 123 )
When locked, “LOCK”is displayed on screen. Press lock button to unlock.
ARCHIVE
ARCHIVEARCHIVE
ARCHIVE : Go to archiving setup menu. (Default password : 123 )
(Default password : 123 )(Default password : 123 )
(Default password : 123 )
PTZ
PTZPTZ
PTZ : Go to Camera PTZ Control.
SETUP
SETUPSETUP
SETUP : Go to System Setup.
SEARCH
SEARCHSEARCH
SEARCH : Go to Search Mode.
1
2
3
9
8
7
6
5
* FOCUS / IRIS button
* FOCUS / IRIS button* FOCUS / IRIS button
* FOCUS / IRIS button
FOCUS
FOCUSFOCUS
FOCUS IRIS
IRISIRIS
IRIS
1 2 3
1
2
3
NEAR :
NEAR : NEAR :
NEAR : Set camera focus (Near & Far) or Reverse Play/Rewind.
FAR :
FAR : FAR :
FAR : Set camera focus far.
CLOSE :
CLOSE : CLOSE :
CLOSE : Close camera iris.
OPEN :
OPEN : OPEN :
OPEN : Open camera iris.

7
•Do not power on the unit all cable connections have been made.
2. Rear Panel
2. Rear Panel2. Rear Panel
2. Rear Panel
2. Description
Tip
TipTip
Tip
1
2
3
7
6
5
Video IN / Loop :
Video IN / Loop : Video IN / Loop :
Video IN / Loop : BNC Video Input Port/ Loop Output (1-8/16)
11
12
9
8
10
13
Monitor out :
Monitor out : Monitor out :
Monitor out : BNC Main Monitor Output.
SVHS
SVHSSVHS
SVHS : S-Video Main Monitor Output.
Spot #1 ~ # :
Spot #1 ~ # : Spot #1 ~ # :
Spot #1 ~ # : x BNC Output to individually – Sequenced Spot Monitors
Audio In :
Audio In : Audio In :
Audio In : x RCA Audio Line Input Terminal
Audio Out :
Audio Out : Audio Out :
Audio Out : RCA Audio Line Out Terminal
Alarm
AlarmAlarm
Alarm : 8/16 x Input TTL Alarm/Sensor Input Terminal
USB :
USB : USB :
USB : USB port for use the USB memory stick and USB HDD Backup.
VGA OUT
VGA OUTVGA OUT
VGA OUT : VGA Main Monitor Output (to a computer Monitor)
RS
RSRS
RS-
--
-232C
232C232C
232C : Serial Configuration Port for Program Debugging.
RS
RSRS
RS-
--
- 85
8585
85 : Serial Interface for PTZ device connection and control
Ethernet (TCP/IP)
Ethernet (TCP/IP)Ethernet (TCP/IP)
Ethernet (TCP/IP): 10/ 100 Ethernet LAN/WAN connection (for Remote Access and configuration)
POWER :
POWER : POWER :
POWER : Power Cable connection.
Relay
RelayRelay
Relay : 8/16 x Relay Output Terminal
12
98 10 13
1 2 3
76 511

8
2. Description 4CH)
1. Front Panel
1. Front Panel 1. Front Panel
1. Front Panel
•Channel Selection Button is Prior to SCR Mode.
• When Remote Controller Sensor Input is Blocked by Something, it Cause 1
Remote Controller do NOT Work Properly.
• When Press any Button, it Operate with Beep Sound.
•In Case of CD-RW, the Real Appearance will be Differ from the above Picture 1
Depends on its Model.
Tip
TipTip
Tip
1 2 3 765
11 1298 10 13 1 15
CD-RW : CD-RW Device for Backup.
Remote Controller Sensor Input.
Channel Selection Button : Select Channel or Input Password.
Led Indicator : Indicate Present System Status Information.
( POWER: System On/Off , RECORD: Record On/Off ,
NETWORK: Client Network Connection Status, ALARM: Alarm Sensor Detection Status )
Search Controller: Searching Recorded Data or Control Menu & PTZ/FOCUS.
HOLD : Hold Jog dial.
JOG dial
Eject : Eject CD
USB Port: USB port for use the USB memory stick and USB HDD Backup
SCR MODE : Select Screen Division Mode or Rotation Mode.
SEARCH : Go to Search Mode for Searching Data.
MENU : Go to System Menu.
PTZ/FOCUS : Go to Camera PTZ/FOCUS Control.
RETURN : Cancel Setup or Return to Previous Mode.
ENTER : Apply Changing Setup.
1
2
3
7
6
5
11
12
9
8
10
13
1
15

9
2. Rear Panel
2. Rear Panel2. Rear Panel
2. Rear Panel
2. Description
• When System Installation, Please Install under System Power Off Status.
•Please Use Specific Adaptor when Power Supply.
Tip
TipTip
Tip
2 75 1298 10 13
1 3 6 11
Video In : BNC Port for Connection of DVR & Camera. ( Camera Connectable)
Loop Back : Output DVR Camera Video to Loop Back Port. ( BNC Port)
Monitor Out : Output DVR Video to AV Monitor.
Spot Out : Output Spot-out Video to AV Monitor.
NTSC/PAL : Select NTSC or PAL Type.
VGA OUT : Output Video to a Computer Monitor by Connected VGA (Option)
SVHS : Output Video by Connected SVHS.
Audio Out : Output Audio Data.
Audio In : Audio Input Terminal Related with #1~ Camera.
Ethernet (TCP/IP) : Port for Cross cable. (Possible to Remote Surveillance.)
Alarm/Relay/RS- 85 : Connect Port for Sensor, Relay, & PTZ.
RS-232C : Connect Port for Program Debug.
DC Power Input : Power Supply by DC 12V Adaptor.
1
2
3
7
6
5
11
12
9
8
10
13

10
POWER
POWERPOWER
POWER
System
ON/OFF
MENU
MENUMENU
MENU : Open System Setup Menu
RETURN
RETURNRETURN
RETURN
Cancel / Deselect
Previous Screen
ENTER
ENTERENTER
ENTER : Apply / Select /Go to Next Sereen
Channel Selection Buttons
Change Display
Mode
Search Menu PTZ/IRIS Mode
•There are buttons on the controller that are unused, and their descriptions have been omitted.
•Every Button on the controller will function the same as its corresponding button on the Front Panel
• Remote Controller will only work when used within line-of-sight of the IR remote sensor on the DVR.
If there are many DVRs within line-of-sight of the controller, they will all respond to the controller.
Navigation Buttons
Navigation ButtonsNavigation Buttons
Navigation Buttons : Used for Playback Control, Menu
Navigation, and PTZ/Focus Control
3. Remote Controller
3. Remote Controller3. Remote Controller
3. Remote Controller
2. Description

11
1. System Power ON
1. System Power ON1. System Power ON
1. System Power ON
•Press power button to start system.
•After Checking Hard Disk, display mode is shown.1
•Initial Screen View Mode is Quad Division Mode and Recording Mode.
<Picture of Power On after Finishing Installation>
3. Display
•Check System status LEDs
Power : Indicates System (On/Off)
Record : Indicates Recording (On/Off)
Network : Indicates Network/LAN Client connection Status
Tip
TipTip
Tip
CAMERA
2005/01/01
00:00:00
•Each Channel Indicates Camera Name & Recording Status.
•Present Time & Date shown on Status Bar at a bottom of screen.

12
3. Display Mode
3. Display Mode3. Display Mode
3. Display Mode
• User can select from a variety of multi-screen display modes (1/ /6/8/9/13/16ch)
•The initial display mode is set to either 8ch or 16ch mode.
3. Display
2. Screen View Selection
2. Screen View Selection2. Screen View Selection
2. Screen View Selection
•Select One Channel using the channel selection buttons (1-8/16).
• Use the display button to change the multi-channel Display mode.
•Press channel selection button twice to view the channel on full screen.
When this unit is connected with a remote client PC, a
Network status icon will appear on the Status Bar
•This icon indicates the current network conditions
- Green: Network is connected and stable.
- Blue: Network is connected, but is unstable.
- Red: Network is very unstable.

13
3. Display
•Each PTZ function is manipulated by using a button on the Front Panel or on the Remote controller.
•Some of the notations on the PTZ menu are abbreviated. (P: Pan, T: Tilt, Z: Zoom, F: Focus, I: Iris)
•All of the functions on the PTZ menu are labeled along with the Front Panel/ Controller button that control it.
. PTZ/FOCUS Control
. PTZ/FOCUS Control. PTZ/FOCUS Control
. PTZ/FOCUS Control
•Control Camera Movement of PTZ (Pan/Tilt/Zoom) devices.
•Press PTZ Button to switch into PTZ mode. (Status Bar is replaced by PTZ controls)
5. System Power Off
5. System Power Off5. System Power Off
5. System Power Off
•Press power button to power system off.
•Input password and press enter to shutdown system.
•Don’t disconnect AC power without completing shutdown.
•System Log-On User Account Types are ‘Administrator’, ‘Manager’, ‘User’
Administrator: Access All Function (Power On, Shutdown, Setup, Search, Backup)
Manager: System Power On, Live View, Search, Playback
User: System Power on and Live View
Tip
TipTip
Tip

1
200 /01/01
00:00:00 >


Go to Search Mode
Go to Search ModeGo to Search Mode
Go to Search Mode
•Press search button and Log-In.
(as administrator or manager )
• Use directional keys to navigate search menu.
•To open/ advance each sub menu, Press enter
•To return to a previous menu screen, Press return.
( Repeatedly pressing return will exit out of all menus.)
1. Search by Time
1. Search by Time1. Search by Time
1. Search by Time
- Search by a recorded Date/ Time
Move cursor to select the date on the calendar.
Press enter to open selected date.
Recorded timeline will appear.
Move cursor to the specific time, and press enter. (The timeline
is divided into 15 minutes segments)
Menu will be hidden from view, and playback will
start playing from the selected date/ time forward.
•The recorded date & time is shown on the status bar.
•The current playback mode (Play, Pause, FF, REW)
is indicated with on icon on the bottom-right of the screen.
• The channel selection and display buttons will work the
same as in live view mode, setup, PTZ and archiving
buttons don’t work in the playback mode.
4. Search

15
•Video Playback Controls
 : Basic playback mode (Normal speed (1X) forward playing)
 : Normal speed (1x) backward playing
 : Pause playback (Enable the JOG wheel)
 : Fast forward (2x ~ 6 x speed)
 : Fast rewind (2x ~ 6 x speed)
 : Variable FF/REW Speed, same as # 
 Use JOG or press normal forward/backward button while paused, to advance previous/next frame.
2. Search by Event
2. Search by Event2. Search by Event
2. Search by Event
- Search Video with based on alarm/sensor events, motion recording events and system events
•Alarm, Motion, System can be selected at the same time by checking the checkbox next
to each of the desired options (V)-(ENTER)
•To change Date/ Time selection, Press enter and use the directional keys to
Increase or decrease the value. When desired value is set, Press enter.
Select start date & end date of the event search.
Alarm : Search alarm/sensor events within the selected
date/time period.
Motion : Search for motion recording events within the
selected period
Timer : Search for schedule change or recording setup
change events with the selected period.
System : Search for power on/off events or other system
events within the selected period
Event search results display in the lower window
Channel selection : choose the channels to search
4. Search
Tip
TipTip
Tip

16


Go to setup
Go to setupGo to setup
Go to setup
Press setup button.
Unit will ask for login/password Entry.
Input password using by channel selection button.
After login, select a submenu and press enter.
•The Initial password for the Admin account is 123 .
• On-Screen display will show the password digit as : ****
•To set up or edit user accounts, or Login/ Password information, go to
System setup->System -> User management submenu.
•You may only enter into the setup menu from live view mode.
•Choose “ System Setup”to enter into the setup menu.
5. Setup


Go to System setup
Go to System setupGo to System setup
Go to System setup
Tip
TipTip
Tip

17
1.Display
1.Display 1.Display
1.Display
- Allows configuration of display properties
•Status Bar : Recording mode icon (on/off), (Recording: Red, Pre-recording : Green)
•Camera Title: Show/Hide camera name (on/off).
•Event Icon: Show/Hide event icon (on/off).
•Border : Show/Hide border Grid (on/off) in multi-channel mode.
•Border Color : Select color of border Grid. (White, Blue, Red, Yellow, Green, Gray)
• Menu transparency : Setup menu transparency.
• Motion Sensor : Toggle Motion Detection (Off/Active / Inactive)
- Active : Display motion sensor of motion detection area.
- Inactive : Display motion sensor except motion detection area.
- Off : No display of motion sensor.
• Motion sensor color : Setup motion sensor color.
• Motion transparency : Setup motion transparency.
•
•
ENTER
ENTERENTER
ENTER
RETURN
RETURNRETURN
RETURN
•Live view display options are edited within this submenu.
•Navigate menu by using directional buttons
Select the desired menu category and press “Enter”
Return to previous menu (or live view mode)
1
11
1-
--
-1. OSD
1. OSD1. OSD
1. OSD
5. Setup
• When have finished changing settings,
Press to confirm the changes.
Tip
TipTip
Tip

18
5. Setup
•Sequence dwell : Set up channel sequence cycle time (1-60 sec).
•Spot-out dwell : Setup spot-out time cycle(1~60 sec.).
•De-interlace mode : Remove interlacing in high resolution & low frame.
* This applies only D1 resolution. (70 X 80)
•Alarm pop-up mode: alarm channel will go full screen on activation.
•Alarm pop-up dwell: alarm pop-up time (1~60sec.)
• Motion pop-up mode : motion channel will go full screen on activation.
• Motion pop-up dwell : motion pop-up time(1~60sec.)
•Display mode : select display mode. (VGA/AV)
1
11
1-
--
-2. MONITOR
2. MONITOR2. MONITOR
2. MONITOR
