VECTECH 201D User manual

VECTECH 201D Desoldering Tool
Instruction Manual
Thank you for purchasing our products. Please keep
the instruction manual properly for future reference.

Contents
1. Safety Instructions................................................................................1
2. Overview................................................................................................2
3. Product Characteristics.......................................................................2
4. Product Specifications.........................................................................3
5. Functional Descriptions.......................................................................4
5.1. Dimensions................................................................................ 4
5.2. Part Descriptions.......................................................................5
5.3. Key Descriptions.......................................................................6
5.4. Function Descriptions of the Main Interface.........................7
6. Connection............................................................................................ 8
7. Temperature Settings.......................................................................... 8
8. Menu Settings.......................................................................................9
8.1. Channel Temperature Settings...............................................9
8.2. Address Settings.....................................................................10
8.3. Sound Switch Settings...........................................................10
8.4. Password Settings..................................................................10
8.5. Suction Count Settings.......................................................... 11
8.6. Language Settings..................................................................11
8.7. Sleeping Time Settings..........................................................12
8.8. Turn Off Settings.....................................................................12

8.9. Temperature Calibration........................................................ 13
9. Operation.............................................................................................14
10. Cleaning and Maintenance............................................................ 14
10.1. Maintenance of the Desoldering Nozzle.......................... 14
10.2. Checking and Cleaning of the Desoldering Nozzle........15
10.3. Steps of Installing the External Filter................................ 16
10.4. Steps of Installing the External Filter................................ 17
11. Replacing the Heater.......................................................................17
11.1. Steps of Removing the Heater........................................... 17
11.2. Steps of Replacing the Heater...........................................17
12. Troubleshooting............................................................................... 18
13. Selection of Desoldering Nozzles.................................................19

1
1.Safety Instructions
CAUTION
During the installation and use of this product, all electrical safety
regulations of the country and regions must be strictly observed.
The power supply must be disconnected when disassembling the
product. Do not operate with power on.
If the product does not work properly, please contact the supplier or
our company, and do not disassemble or change the product in any
way. We are not responsible for any problems caused by unauthorized
maintenance or modification.
WARNING
Don't install the product in a place where the surface is easy to shake
or be impacted, as it may damage the product.
Don't place the product in places where it may be exposed to rain or
moisture.
The product should be used away from places where there is
magnetic interference.
Don't use in flammable and explosive environments.
After using the desoldering station, the nozzle temperature will be
quite high, which is easy to burn operators and may cause dangerous
accidents.
Don't knock workbench with the desoldering gun to remove residual
flux, which may seriously damage the desoldering gun.
After the desoldering gun is used, a layer of melting tin should be
plated to prolong its life before placing it into the holder.
Please unplug the power cord when the product is not used for a long
time.

2
2.Overview
This desoldering tool uses high-frequency eddy current heating, which
makes the nozzle heat up quickly to melt the solder in the pad of the PC
B through-hole devices. The vacuum pump is started by the switch of
the desoldering gun switch to generate vacuum to suck the liquid tin
into the tin storage tube to achieve the purpose of quickly disassemblin
g the through-hole components. At the same time, it can also be used
for tin removal on the surface of the pad to improve maintenance
efficiency.
3.Product Characteristics
LCD display, touch button for comfortable operation.
Novel appearance design.
Powerful built-in vacuum pump.
Precise digital temperature calibration.
Function of counting tin absorbing times.
Support the function of preventing blockage.

3
4.Product Specifications
Product model
201D
Power consumption
200W
Voltage
AC 220V
Temperature range
300℃～500℃
Temperature stability
±2℃（No load）
Dimensions（L*W*H）
189.5*189.0*135mm
Weight
About 3.2 Kg

4
5.Functional Descriptions
5.1.Dimensions
Unit：mm

5
5.2.Part Descriptions
NO.
Part Descriptions
1
LCD Display
2
Touch Buttons
3
External Filter
4
Desoldering Gun
5
Desoldering Gun Holder

6
5.3.Key Descriptions
Key
Function Descriptions
+/-
Temperature up/down
1. Short press, temperature goes up or down by
1℃.
2. Long press, temperature goes up or down
quickly.
POWER
1. Power on: Press and hold the "POWER" button
to turn on
2. Power off: Press and hold the "POWER" button
to turn off
2/3
Press "2" and "3" keys at the same time to enter
the menu setting interface
1/+/-
1. Press "1" or "+" or "-" to switch the menu in the
menu setting interface.
2. Press "1" to switch parameter options, press "+"
or "-" to change the parameter value in the
parameter setting interface.
1/3
Press "1" and "3" keys at the same time to enter
the temperature calibration interface.

7
5.4.Function Descriptions of the Main Interface
Symbols
Descriptions
Symbols
Descriptions
CH0
Temporary channel
CH1～CH3
Channel 1 to Channel
3 optional
Password lock
No password lock
1. Red indicates the
heating state;
2. Black indicates the
no heating state;
3. Alternating red and
black indicates
constant temperature.
℃
Celsius
Buzzer on
Buzzer off

8
6.Connection
Connecting the desoldering gun assembly: make the external filter and
the hose of the desoldering gun connected (as shown in the figure
below).
1) Insert the power cord into the power socket.
2) Connect the external filter with hose of the desoldering gun.
3) Turn on the power switch, and the desoldering gun starts heating.
(Note: Do not start the desoldering gun switch if the temperature does
not rise to the setting temperature).
Note: The external filter has its connection direction, and it shall be
connected according to the label, otherwise it will affect the suction of the
machine.
7.Temperature Settings
There are 3 temperature channels in total. Press the "1", "2" and "3" keys
on the main unit to quickly select the saved temperature corresponding to
CH1, CH2 and CH3 respectively. The current temperature value can be
changed with the "+" and "-" keys, but the saved temperatures of the 3
temperature channels will not be overwritten.

9
8.Menu Settings
Enter the menu setting interface.
Long press "2" and "3" keys at the same time to enter the menu setting
interface.
8.1.Channel Temperature Settings
1) Press "2" key to enter "Channel Temp"setting interface.
2)Press "1" to select channel 1~3, and press the "+" or "-" to change the
value.
3) Press "2" to save, press "3" to return to the main interface.

10
8.2.Address Settings
1）Press "1", "+" or "-" key to select "Address" interface.
2）Press key "2" to enter address parameter selection, press "+" or "-" to
set the address, and the address setting range is: 001～255.
3）Press "2" to save, press "3" to return to the main interface.
8.3.Sound Switch Settings
1）Press "1", "+" or "-" key to select "Sound Switch" interface.
2）Press "2" to enter the sound switch setting interface. Press "1"
to select ON or OFF to switch the sound function.
3）Press "2" to save, press "3" to return to the main interface.
8.4.Password Settings
1）Press "1", "+" or "-" key to select "Password" interface.

11
2）Press "2" to enter the password input setting interface. Press the "+"
or "-" key to select the value (0 ~ 9) and press "1" to change the digit.
After inputting the old password 000000 (original password), press key
"1" to enter the new password input interface.
3）Press "2" to save, press "3" to return to the main interface.
8.5.Suction Count Settings
1）Press "1", "+" or "-" key to select "Suction count" setting
interface.
2）Press the key "2" to enter the suction count parameter interface. Press
the key "-" to clear the suction count data.
3）Press "2" to save, press "3" to return to the main interface.
8.6.Language Settings
1）Press "1", "+" or "-" key to select "Language" setting interface.

12
2）Press "2" to enter the language selection interface, and press "+" or "-
" to switch between S-Chinese, English and T-Chinese.
3）Press "2" to save, press "3" to return to the main interface.
8.7.Sleeping Time Settings
1）Press "1", "+" or "-" key to select "Sleep" setting interface.
2）Press the key "2" to enter the sleep setting interface, press the "+" or
"-" key to select the sleep setting ON or OFF, after selecting ON, press
the "1" key to set the time, the time setting range is : 001min to 020 mins.
3）Press "2" to save, press "3" to return to the main interface.
8.8.Turn Off Settings
1）Press "1", "+" or "-" key to select "Turn off Setting" interface.
2）Press key "2" to enter the turn off setting interface, press the "+" or "-
" key to select the turn off function ON or OFF, and then press key "1" t
o set the time. The time setting range is 001min ~ 040 mins.
3）Press "2" to save, press "3" to return to the main interface.

13
8.9.Temperature Calibration
It is recommended to recalibrate the temperature of the machine after
replacing the desoldering gun, heating element or nozzle.
1）Set the temperature of the machine according to your needs.
2）When the temperature is stable, test the nozzle temperature with
the thermometer and record the reading value.
3) Long press the keys "1" and "3" at the same time，and the
machine will enter the temperature calibrating mode.
4）Press the "+" or "-" key to input the temperature value on the
thermometer, and press the "2" key to confirm.
5）If the temperature still has errors, repeat the calibration
according to the above steps.
* It is recommended to use a 191/192 thermometer to measure the tip
temperature.

14
* If the password is locked, the temperature cannot be calibrated, and the
correct password must be input to operate.
9.Operation
Melting solder After the set temperature is stable, use the nozzle of the
desoldering tool to melt the solder.
Solder removal After confirming that all the soldering tin has been
melted, press the red switch (trigger) on the handle to suck the soldering
tin.
Note：1）To check if the solder is completely melted, observe the inside of
the aperture and the back of PCB, if it is difficult, use the nozzle to shake
the pin slightly. If it can be moved, it means that the solder has been
melted.
2）Do not shake the pins vigorously. If the pin does not move easily, it
indicates the solder has not been completely melted
3）Do not leave any solder residue in the PCB aperture.
10.Cleaning and Maintenance
10.1.Maintenance of the Desoldering Nozzle
After using the desoldering tool, please make maintenance to ensure
durability. Solder removal efficiency depends on temperature, quality
and quantity of solder and flux. Please follow the following procedures
for maintenance according to the usage of the desoldering tool:
1）Apply a little solder to the plating part of the nozzle to keep the
nozzle shiny.
2）If the nozzle is covered with oxide, the thermal conductivity will be
weakened. Apply a little new solder on the nozzle to exert the thermal
conductivity function.

15
3) Remove the solder inside the nozzle and the heating element, then clea
n the nozzle with the cleaner, and plate a layer of solder on the nozzle to
protect the coating.
Note: After the desoldering gun is used, the temperature is too high.
During maintenance, please wait it to cool down or wear heat insulation
gloves for safe operation.
10.2.Checking and Cleaning of the Desoldering Nozzle
1) Insert the plug into the power socket, and turn on the power switch to
heat the nozzle.
2）Clean the nozzle hole with a nozzle needle.
3)If there is slight wear and tear, please re-solder the nozzle with new sol
der to avoid oxidation.
4) If the nozzle hole is worn or corroded inside and outside, please
replace the nozzle.
Note：a. Since it is difficult to observe the erosion of the nozzle with
naked eyes, if the tin suction efficiency is reduced while the
performance of other parts is good, it may be that the nozzle is
eroded and should be replaced with a new one.
b.Please select the appropriate size of the needle according to the
diameter of the nozzle. If the solder in the nozzle is not completel
y melted, the needle cannot penetrate the nozzle, please check
the solder coating on the nozzle surface.
Needle completely through the nozzle.

16
c. A layer of special alloy is plated inside and outside the nozzle aperture.
If the alloy layer is eroded due to high temperature, the nozzle will not be
able to maintain a proper temperature.
10.3.Steps of Installing the External Filter
1) Press "Off" on the power switch.
2)When the filter pipe is cooled, pull the trachea support column to the ri
ght and take out the filter pipe.
3)Check the spring filter pipe and tin slag ceramic filter cotton.
Note: The spring filter pipe needs to be replaced when two thirds of the s
older is collected and stored.
The tin slag ceramic filter cotton needs to be replaced when it is hardened
due to the accumulation of solder and flux

17
10.4.Steps of Installing the External Filter
Put the spring filter pipe into the filter pipe, and then put the matching
ceramic filter cotton into the filter pipe. Press the trachea support
telescopic button to fix the filter pipe.
Note: If a large filter cotton is loaded into the filter pipe, it may damage
the desoldering gun or reduce the suction efficiency.
11.Replacing the Heater
11.1.Steps of Removing the Heater
1）Unscrew ①Tip Enclosure and ②Nut
2）Pull out ③Nozzle
3）Unscrew three ④Screws with a screwdriver
4）Pull out ⑤Heater
Note: All operating steps are performed with the power disconnected and
the handle cooled.
11.2.Steps of Replacing the Heater
1）Insert ⑤Heater into ⑥Handle body
2）Screw on three ④Screws
3）Insert ③Nozzle
