Operating Instructions
VEGADIS 62
Document ID:
36469
Indication
and adjustment

Contents
1About this document
1.1Function.................................. 4
1.2Target group .............................. 4
1.3Symbolism used............................ 4
2For your safety
2.1Authorised personnel ........................ 5
2.2Appropriate use ............................ 5
2.3Warning about misuse ....................... 5
2.4General safety instructions .................... 5
2.5CE conformity ............................. 6
2.6Fulfillment of NAMUR recommendations .......... 6
2.7Environmental instructions..................... 6
3Product description
3.1Structure ................................. 7
3.2Principle of operation ........................ 8
3.3Packaging,transport and storage ............... 9
4Mounting
4.1General instructions ......................... 11
4.2Instructions for installation ..................... 11
5Connecting to power supply
5.1Preparing the connection ..................... 13
5.2Connection technology and steps ............... 14
5.3Wiring plan................................ 17
5.4Connection HART standard.................... 17
5.5Connection HART multidrop ................... 18
5.6Connection signal conditioning instruments ........ 20
5.7Switch-on phase............................ 21
6Set parameters
6.1Adjustment system .......................... 22
6.2Modes ................................... 23
6.3Parameter description........................ 24
7Set up sensors
7.1Adjust the sensor ........................... 35
7.2Scale the indication ......................... 35
7.3Correct sensor adjustment .................... 37
7.4PACTware/DTM and PLICSCOM ............... 37
8Diagnosis and service
8.1Maintenance .............................. 39
8.2Error messages ............................ 39
8.3Remove interferences ........................ 40
8.4How to proceed in case of repair................ 40
2VEGADIS 62
Contents
36469-EN-120329

9Dismounting
9.1Dismounting steps .......................... 42
9.2Disposal ................................. 42
10 Supplement
10.1Technical data ............................. 43
10.2HART communication ........................ 45
10.3Dimensions ............................... 48
Safety instructions for Ex areas
Please note the Ex-specificsafety information for installation and
operation in Ex areas.These safety instructions are part of the
operating instructions manual and come with the Ex-approved
instruments.
Editing status:2012-03-19
VEGADIS 62 3
Contents
36469-EN-120329

1About this document
1.1Function
This operating instructions manual provides all the information you
need for mounting,connection and setup as well as important
instructions for maintenance and fault rectification.Please read this
information before putting the instrument into operation and keep this
manual accessible in the immediate vicinity of the device.
1.2Target group
This operating instructions manual is directed to trained qualified
personnel.The contents of this manual should be made available to
these personnel and put into practice by them.
1.3Symbolism used
Information,tip,note
This symbol indicates helpful additional information.
Caution:If this warning is ignored,faults or malfunctions can
result.
Warning:If this warning is ignored,injury to persons and/or serious
damage to the instrument can result.
Danger:If this warning is ignored,serious injury to persons and/or
destruction of the instrument can result.
Exapplications
This symbol indicates special instructions for Ex applications.
lList
The dot set in front indicates a list with no implied sequence.
àAction
This arrow indicates a single action.
1Sequence
Numbers set in front indicate successive steps in a procedure.
4VEGADIS 62
1About this document
36469-EN-120329

2For your safety
2.1Authorised personnel
All operations described in this operating instructions manual must be
carried out only by trained specialist personnel authorised by the plant
operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2Appropriate use
The VEGADIS 62 is an indicating and adjustment unit without external
energy for looping into 4…20 mA/HART circuits.
You can find detailed information on the application range in chapter
"Product description".
Operational reliability is ensured only if the instrument is properly used
according to the specifications in the operating instructions manual as
well as possible supplementary instructions.
2.3Warning about misuse
Inappropriate or incorrect use of the instrument can give rise to
application-specific hazards,e.g.vessel overfill or damage to system
components through incorrect mounting or adjustment.
2.4General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and guidelines.The instrument must only be operated in a
technically flawless and reliable condition.The operator is responsible
for the trouble-free operation of the instrument.
During the entire duration of use,the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new
regulations.
The safety instructions in this operating instructions manual,the
national installation standards as well as the valid safety regulations
and accident prevention rules must be observed by the user.
For safety and warranty reasons,any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer.Arbitrary
conversions or modifications are explicitly forbidden.
The safety approval markings and safety tips on the device must also
be observed.
VEGADIS 62 5
2For your safety
36469-EN-120329

2.5CE conformity
The device fulfills the legal requirements of the applicable EC
guidelines.By affixing the CE marking,we confirm successful testing
of the product.
You can find the conformity certificate in the download section under
www.vega.com.
2.6Fulfillment ofNAMUR recommendations
The device fulfills the requirements of the applicable NAMUR
recommendations.
2.7Environmental instructions
Protection of the environment is one of our most important duties.That
is why we have introduced an environment management system with
the goal of continuously improving company environmental protection.
The environment management system is certified according to DIN
EN ISO 14001.
Please help us fulfil this obligation by observing the environmental
instructions in this manual:
lChapter "Packaging,transport and storage"
lChapter "Disposal"
6VEGADIS 62
2For your safety
36469-EN-120329

3Product description
3.1Structure
The indicating and adjustment unit VEGADIS 62 consists of a housing
with a terminal insert as well as an integrated indicating and
adjustment module.Dependent on the order specification,a mounting
adapter for wall,carrier rail or tube mounting belongs to the housing.
The type label on the housing contains the most important data for
identification and use of the instrument:
2
1
8
7
3
4
5
6
Fig.1:Structure of the type label (example)
1Instrument type
2Product code
3Voltage supply/Signal output
4Protection rating
5Ambient temperature
6Order number
7Serial number of the instrument
8Document ID
With the serial number of the instrument on the type label you have
access to the following data on our homepage:
lArticle number of the instrument (HTML)
lDelivery date (HTML)
lOrder-specific instrument features (HTML)
lOperating instructions at the time of shipment (PDF)
lOrder-specific sensor data for an electronics exchange (XML)
lTest certificate "Measuring Accuracy"(PDF)
Go to www.vega.com,"Service" "VEGA Tools"and "serial number
search".
This operating instructions manual applies to the following instrument
versions:
lSoftware from 2.00
lSoftware from 2.10 (with the functions Password and Logout)
Constituent parts
Type label
Serial number
Scope of the operating
instructions manual
VEGADIS 62 7
3Product description
36469-EN-120329

The scope of delivery encompasses:
lIndicating and adjustment unit
lDocumentation
-this operating instructions manual
-Ex-specific"Safety instructions"(with Ex versions)
-if necessary,further certificates
3.2Principle of operation
The VEGADIS 62 is an external indicating and adjustment unit without
external energy for 4…20 mA/HART sensors.The instrument is used
for remote measured value indication and adjustment.It is looped in
any position directly into the signal cable.
The housing of VEGADIS 62 contains a filter element for ventilation.
Hence the insturment is also used for atmospheric pressure
compensation of a connected suspension pressure transmitter
VEGAWELL 52.
Fig.2:Connection of the VEGADIS 62 to a suspension pressure transmitter
The VEGADIS 62 can be also used as external indication for a four-
wire sensor or a VEGAMET signal conditioning instrument with active
4…20 mAoutput.
The VEGADIS 62 is suitable for operation of all continuously
measuring VEGA sensors with HART output >5.0:
Scope of delivery
Application area
Operation
8VEGADIS 62
3Product description
36469-EN-120329

lRadar and ultrasonic sensors
lSensors with guided microwave
lCapacitive probes
lPressure transmitter
lPrevious instrument versions (replacement for VEGADIS 12)
The operation of respective sensors from other manufacturers is also
possible.
The VEGADIS 62 acts like a HART handheld with limited functions.
The following adjustment functions are available:
lMin./Max.adjustment
lzero/span adjustment (live adjustment)
lDamping
Basic mode:when used in a 4…20 mAsignal cable,the VEGADIS
62 works as a pure indicating instrument.It measures the current in the
current loop and shows it as digital value as well as via a bargraph.All
settings of VEGADIS 62 are carried out manually via the buttons in the
front.
Adjustment volume:Indication scaling
HART standard:when used with a 4…20 mA/HART sensor,the
VEGADIS 62 operates as automatic indicating and HART adjustment
instrument.The VEGADIS 62 powered via the current loop listens
continuously to the HART communication of the control system with
the sensor.Changes of unit and/or measuring range are adapted
automatically.
The parameter adjustment of the sensor is carried out via HART
communication.During the parameter adjustment,the VEGADIS 62
operates as a Secondary Master to the sensor.
Adjustment volume:Sensor functions,indication scaling
HART multidrop:The VEGADIS 62 can also be used as indicator for
a bus participant on a HART multidrop system.For this purpose,it is
looped into the bus and the address of the participant is set in the
VEGADIS 62.The instrument reads out the measured values with unit
via the HART signal and displays them.
Adjustment volume:Sensor function damping,indication scaling
3.3Packaging,transport and storage
Your instrument was protected by packaging during transport.Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environment-
friendly,recyclable cardboard.For special versions,PE foam or PE foil
is also used.Dispose of the packaging material via specialised
recycling companies.
Modes
Packaging
VEGADIS 62 9
3Product description
36469-EN-120329

Transport must be carried out under consideration of the notes on the
transport packaging.Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt.Ascertained transit damage or
concealed defects must be appropriately dealt with.
Up to the time of installation,the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated,the packages must be stored only under
the following conditions:
lNot in the open
lDry and dust free
lNot exposed to corrosive media
lProtected against solar radiation
lAvoiding mechanical shock and vibration
lStorage and transport temperature see chapter "Supplement -
Technical data -Ambient conditions"
lRelative humidity 20 …85 %
Transport
Transport inspection
Storage
Storage and transport
temperature
10 VEGADIS 62
3Product description
36469-EN-120329

4Mounting
4.1General instructions
Use the recommended cables (see chapter "Connecting to power
supply")and tighten the cable gland.
You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cable entry.Rain and condensation water can thus drain off.This
applies mainly to outdoor mounting as well as installation in areas
where high humidity is expected (e.g.through cleaning processes)or
on cooled or heated vessels.
4.2Instructions for installation
VEGADIS 62 for wall mounting is supplied with a mounting socket.
62 mm
(2.44")
12 mm
(0.47")
7 mm (0.28")
85 mm (3.35")
Fig.3:VEGADIS 62 for wall mounting,bottom view of mounting plate.
1Drilling dimensions
VEGADIS 62 for mounting on carrier rail is supplied with a mounting
adapter.
1 2
Fig.4:VEGADIS 62 for carrier rail mounting
1Carrier rail adapter
2Carrier rail
Moisture
Wall mounting
Carrier rail mounting
VEGADIS 62 11
4Mounting
36469-EN-120329

VEGADIS 62 for tube mounting is supplied with a meas.instrument
holder and four screws M5x12 as mounting accessory.The meas.
instrument holder is mounted to the socket of VEGADIS 62.
1
3
2
Fig.5:VEGADIS 62 for tube mounting
14screws M5x12
2Measuring instrument holder
3Tube
Tube mounting
12 VEGADIS 62
4Mounting
36469-EN-120329

5Connecting to power supply
5.1Preparing the connection
Always keep in mind the following safety instructions:
lConnect only in the complete absence of line voltage
lIf voltage surges are expected,install overvoltage arresters
Power supply and current signal are carried on the same two-wire
cable.The voltage supply range can differ depending on the sensor.
The data for power supply are specified in chapter "Technical data".
Provide a reliable separation between the supply circuit and the mains
circuits according to DIN VDE 0106 part 101.
Keep in mind the following additional factors that influence the
operating voltage:
lOutput voltage of the power supply unit can be lower under
nominal load (with a sensor current of 20.5mAresp.22 mAin
case of fault message)
lInfluence of additional instruments in the circuit (see load values in
chapter "Technical data")
Operation of VEGADIS 62 in a HART multidrop system with the signal
conditioning instruments VEGAMET 625 or VEGASCAN 693 is not
supported.
The instrument is connected with standard two-wire cable without
screen.If electromagnetic interference is expected which is above the
test values of EN 61326-1for industrial areas,screened cable should
be used.
For instruments with housing and cable gland,use cable with round
cross-section.Acable outer diameter of 5…9mm (0.2…0.35 in)
ensures the seal effect of the cable gland.If you are using cable with a
different diameter,exchange the seal or use a suitable cable gland.
We generally recommend the use of screened cable for HART
multidrop mode.
With plastic housing,the NPT cable gland or the Conduit steel tube
must be screwed without grease into the threaded insert.
Max.torque for all housings see chapter "Technical data"
If screened cable is necessary,connect the cable screen on both ends
to ground potential.In the sensor,the screen must be connected
directly to the internal ground terminal.The ground terminal on the
outside of the housing must be connected to the potential equalisation
(low impedance).
Safety instructions
Voltage supply
Connection cable
Cable gland ½NPT
Cable screening and
grounding
VEGADIS 62 13
5Connecting to power supply
36469-EN-120329

If potential equalisation currents are expected,the connection on the
processing side must be made via a ceramic capacitor (e.g.1nF,
1500 V). The low frequency potential equalisation currents are thus
suppressed,but the protective effect against high frequency interfer-
ence signals remains.
Warning:
Significant potential differences exist inside galvanization plants as
well as on vessels with cathodic corrosion protection.Considerable
equalisation currents can flow over the cable screen if the screen is
grounded on both ends.
To avoid this in such applications,the cable screen must be connected
to ground potential only at one end (in the switching cabinet). The
cable screen must not be connected to the internal ground terminal in
the sensor and the outer ground terminal on the housing must not be
connected to the potential equalisation!
Information:
The metal parts of the instrument (antenna,transmitter,concentric
tube,etc.) are conductive connected with the inner and outer ground
terminal on the housing.This connection exists either directly metallic
or with instruments with external electronics via the screen of the
special connection cable.
You can find specifications to the potential connections within the
instrument in chapter "Technical data".
5.2Connection technology and steps
The connection of the signal cable is carried out via spring-loaded
terminals in the housing.
The indicating and adjustment module is connected via a cable with
coupling to the housing.
Proceed as follows:
1Unscrew the housing cover
Connection technology
Connection procedure
14 VEGADIS 62
5Connecting to power supply
36469-EN-120329

2Remove the indicating and adjustment module by turning it slightly
to the left
Fig.6:Dismounting of the indicating and adjustment module
3Loosen compression nut of the cable glands
4Remove approx.10 cm (4in)of the signal cable mantle,strip
approx.1cm (0.4in)insulation from the ends of the individual
wires
VEGADIS 62 15
5Connecting to power supply
36469-EN-120329

5Insert the cable into the sensor through the cable entry
Fig.7:Connection steps 5and 6
6Insert the wire ends into the terminals according to the wiring plan
Note:
Solid cores as well as flexible cores with cable end sleeves are
inserted directly into the terminal openings.In case of flexible cores
without end sleeves,press the terminal with a small screwdriver;the
terminal opening is freed.When the screwdriver is released,the
terminal closes again.
7Check the hold of the wires in the terminals by lightly pulling on
them
8Connect the screen to the internal ground terminal,connect the
outer ground terminal to potential equalisation
9Attach the indicating and adjustment module again and turn it
slightly to the right
10 Tighten the compression nut of the cable glands.The seal ring
must completely encircle the cable
11 Screw the housing cover back on
The electrical connection is finished.
Note:
The terminal block is pluggable and can be removed from the
electronics.To do this,lift the terminal block with a small screwdriver
and pull it out.When inserting the terminal block again,you should
hear it snap in.
16 VEGADIS 62
5Connecting to power supply
36469-EN-120329

5.3Wiring plan
12
+ ( ) (-)
3 4
+ ( ) (-)
12
3
Fig.8:Wiring plan VEGADIS 62
1To the sensor
2For power supply
3Coupling for the connection cable to the indicating and adjustment module
5.4Connection HART standard
The following illustrations show in a simplified way the use of
VEGADIS 62 in conjunction with a HART sensor.The HART
communication resistance in the signal cable is always required for a
low impedance power supply.It is absolutely necessary to install it
between voltage supply and the VEGADIS 62.
Note:
Ifthe instrument is powered via a VEGAMET signal conditioning
instrument,then the communication resistor is already included in the
signal conditioning instrument.Acommunication resistor in the signal
cable must not be installed.
~
=
1
243
Fig.9:VEGADIS 62 in conjunction with an individual sensor
1Sensor
2VEGADIS 62
3HART resistance >150 Ω (necessary with low impedance power supply)
4Voltage supply/Processing
Overview
VEGADIS 62 17
5Connecting to power supply
36469-EN-120329

12
+
( ) (-)
3 4
+
( ) (-)
1
2
4
3
Fig.10:Connection of VEGADIS 62 with low impedance power supply
1Sensor
2VEGADIS 62
3HART resistor >150 Ω
4Voltage supply/Processing
5.5Connection HART multidrop
The following illustrations show in a simplified way the use of
VEGADIS 62 in conjunction with a HART sensor.The HART
communication resistance in the signal cable is always required for a
low impedance power supply.It is absolutely necessary to install it
between voltage supply and the VEGADIS 62.
Note:
Ifthe instrument is powered via a VEGAMET signal conditioning
instrument,then the communication resistor is already included in the
signal conditioning instrument.Acommunication resistor in the signal
cable must not be installed.
Connection with low im-
pedance power supply
18 VEGADIS 62
5Connecting to power supply
36469-EN-120329

~
=
1
243
Fig.11:Installation example with one VEGADIS 62 per sensor in a Multidrop
system
1Sensor
2VEGADIS 62
3HART resistance >150 Ω (necessary with low impedance power supply)
4Voltage supply/Processing
~
=
1
243
Fig.12:Installation example with one VEGADIS 62 for several sensors in a
Multidrop system
1Sensor
2VEGADIS 62
3HART resistance >150 Ω (necessary with low impedance power supply)
4Voltage supply/Processing
Overview
VEGADIS 62 19
5Connecting to power supply
36469-EN-120329

12
+
( ) (-)
3 4
+
( ) (-)
1
2
4
3
Fig.13:Connection of VEGADIS 62 with low impedance power supply
1Sensor
2VEGADIS 62
3HART resistor >150 Ω
4Voltage supply/Processing
5.6Connection signal conditioning instruments
The following illustrations show the simplified connection of VEGADIS
62 to a signal conditioning instrument VEGAMET or a four-wire sensor
with active 4…20 mAoutput.
+-
12
+-
34
18 17 16 15 14 13 12 11 10 9 8 76 5
N- L1+
on
1
2
12
%
1 2 3
Fig.14:Connection of the VEGADIS 62 as external indication to a signal
conditioning instrument or a four-wire sensor
1Sensor
2Signal conditioning instrument
3VEGADIS 62
Connection with low im-
pedance power supply
20 VEGADIS 62
5Connecting to power supply
36469-EN-120329
