Veilux VP-ATDNC27X User manual

SPECIFICATIONS
3015 Eagle Drive, Suite 100, Grand Prairie, Texas 75052
Local Number: [phone] / Fax: [phone]
[email protected]
www.veilux.net
OBJECT AUTO-TRACKING
DAY/NIGHT CAMERA
VP-ATDNC27X
FEATURES
MODEL NUMBERS
VP-ATDNC27XI In-Ceilling
VP-ATDNC27XO Outdoor
VP-ATDNC27XS Surface Mount
In-Ceiling OutdoorSurface
•1/4” VEILUX Super HAD CCD / High Resolution: 480 TV Line
•Stabilized Images by Reducing Flickering
•Motion Auto Tracking, Intelligent Surveillance with Alarm Function
•Preset, Auto Cruise & Pattern Scan Function
•Multi Communication Protocol Supported, Baud Rate Programmable
•360° Continuous Pan
•0° to 9° Tilt From Horizontal Plane Auto Flip 180°
•Iris & Focus, White Balance, Backlight Compensation - Auto / Manual
•Weatherproof (IP-66) - (Outdoor Only)
•Built-in Auto Focus / Auto Iris
•27x Optical Power Zoom Lens / 10x Digital Zoom (Max. 270x)
•TDN (ICR) / On-Screen Menu Control (OSD)
•Nine Backlight Compensation (BLC) Zones
•Video Transmission Distance Adjustable (3 Step)
•RS-232C TTL Interface / Electronic Sensitivity-up (DSS)
•12VDC
ITEM VP-ATDNC27X
Mounting Type Surface, In-Ceiling, Wall, Pole
Signal System NTSC PAL
Scanning System 2:1 Interface
Scanning Freq(H) 15.734 KHz
Scanning Freq(V) 59.94 Hz
Image Sensor 1/4” VEILUX Super HAD CCD
Sync. Sensor Internal
Total Pixels No. 811 (H) x 508 (V) 410K
Effective Pixels 768 (H) x 494 (V) 380K
Hor. Resolution More than 480 TV Lines
Video Output
Level 1.0 Vp-p (75Ω, Composite)
Pan / Tilt Speed Pan: 0.05°~400°/sec;
Tilt: 0.03°~240°/sec
S/N Ratio More than 48dB (AGC Off)
Digital Zoom 10x
Lens 27x Zoom Video AF
(F1.6 (W), F3.2 (T) f=3.6~97.2mm)
Panning Range Pan: 0°~360° Continuous; Tilt: 0°~90°
Track Speed 0°~100°/sec
Min. Illumination
Day Mode 1Lux (30IRE), Night Mode
0.5Lux (30IRE), DSS 0.001Lux
(128FLD, 30IRE)
Day & Night IR Cut FIlter & Digital Slow Shutter
480
TV LINES
VOLTAGE 12DC
24AC
D&N
NIGHT DAY
OPTICAL/
DIGITAL
ZOOM
Auto White
Balance
AWB
AGC
OFF ON
Auto Gain
Control 0.001
LUX
Back Light
Compensation
BLC
OFF ON
FLICKERLESS
PAN/TILT/ZOOM
CONTROLLER

SPECIFICATIONS
3015 Eagle Drive, Suite 100, Grand Prairie, Texas 75052
Local Number: [phone] / Fax: [phone]
[email protected]
www.veilux.net
OBJECT AUTO-TRACKING
DAY/NIGHT CAMERA
VP-ATDNC27X
ITEM VP-ATDNC27X
White Balance Auto / Push Auto / Outdoor / Indoor /
Special
AGC Auto / Manual (0~255)
BLC 9 Backlight Compensation Zones
Flickerless On / Off
Electronic Shutter
Speed 1/60~1/10,000s (Manual, 8 Steps)
Digital Slow Shutter 2FLD~128FLD / Off
OSD Menu On/Off
Focus Mode Auto / Manual
Input / Output
Connector
Power: 2 Pin Terminal / RS-485: 2 Pin
Circle Connector / PTZ Control: 3 Pin
Circle Connector / Video
Preset Position No. 256
Auto Cruise Auto Switch from 0 to 54 Preset Pos’
Sequentially
Pattern Scan P/T/Z Scan from 55 to 63 Preset Pos’
Automatically
Comm. Port RS-485
Spectra Address 0~255
Operating Temp -25°C ~ +70°C (w/o Heater) /
-50°C ~ +70°C (with Heater)
Power Consumption Max. 4.56 W / 380mA
Power Voltage 12VDC (9V~15V)
Dimensions 48 (W) x 51.6 (H) x 86 (D) mm
Weight (Net) Approx. 250g
