Veilux VPIP-D110X User manual

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Rev2.2(Sep.2009)

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
2

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
3
Directions
Veilux VPIP-D110X / VPIPI-D110X series network cameras are designed for outdoor/indoor use. Don‟t use Veilux V
PIP-D110X / VPIPI-D110X in an environment that exceeds the limited range.
Be careful not to cause any physical damage by dropping or throwing the Veilux VPIP-D110X / VPIPI-D110X
network camera. Especially keep the network camera out of reach from children.
Do not disassemble Veilux VPIP-D110X / VPIPI-D110X or After Service Follow-up is not possible.
Use only the AC power adapter which conforms to the specification in data sheet or optionally provided AC
power adapter with the Veilux VPIP-D110X / VPIPI-D110X.
If you would like to use the Veilux VPIP-D110X / VPIPI-D110X for security, monitoring, please check the legal
regulations within the country.
Note
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, use and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into and outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help.

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
4
Warning & Caution
If you fail to read this information and
handle the product incorrectly, death or
serious injury may occur.
The unit should be installed by trained
personnel.
Always stop using when the product emits
smoke or abnormal heat.
Never install the product in area exposed to
water, oil or gas.
Never install the product on a ceiling that
cannot hold its weight.
Never touch the power cord with wet hands.
Clean only with dry cloth.
Never install the product in extremely high or
low temperature.
Never drop, hit strongly nor vibrate the
product.
Never expose the product to direct sunlight
or severe ray.
Never touch the front glass of the product.
Never install the product in areas exposed
to rain or water
This symbol is intended to alert the user to
the presence of un-insulated “dangerous
voltage” within the product‟s enclosure that
can cause electric shock.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
If you fail to read this information and handle the
product incorrectly, death or serious injury may occur
The unit should be installed by trained
personnel.
Never install the product in area exposed
water, oil or gas.
Never install the product on a ceiling that
cannot hold its weight.
Never touch the power cord with wet hands.
Input power: With Camera - 24V AC
18 watts at 24V AC
Heater: 18watts
Fan: 2watts
The heater activates at +10℃(±5℃),
deactivates at +15℃(±5℃)
The fan activates at +45℃(±5℃),
Deactivates at +35℃(±5℃)
Never install the product in area exposed to
water, oil or gas.
Never install the product on a ceiling that
cannot hold its weight.
Input power: With Camera - 24V AC
18 watts at 24V AC
Heater: 18watts
Fan: 2watts
The heater activates at +10℃(±5℃),
Deactivates at +15℃(±5℃)
The fan activates at +45℃(±5℃),
Deactivates at +35℃(±5℃)
Additional Warning &
Caution for Veilux VPIP-D110X

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
5
Revision History
Date
Rev. No
Description
2006-12-06
1.0
Creation of the document
2009-09-09
2.1
Revision of the Dip Switch and Specification.
2009-09-22
2.2
Revision of the wall bracket

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
6
1. Introduction .........................................................................................................................................................8
1.1. Overview........................................................................................................................... 8
1.2. Features of Veilux VPIP-D110X / VPIPI-D110X................................................................... 8
1.3. Applications of Veilux VPIP-D110X / VPIPI-D110X............................................................ 11
2. Product Description...........................................................................................................................................12
2.1. Package Contents........................................................................................................... 12
2.2. Preview........................................................................................................................... 12
2.3. PC Requirements............................................................................................................ 13
2.4. Physical description......................................................................................................... 13
2.5. Specification of the analog camera module and PTZ part.................................................. 17
2.6. Quick Installation Guide................................................................................................... 20
3. Connecting Veilux VPIP-D110X / VPIPI-D110X to IP Network.........................................................................23
3.1. Connecting to LAN .......................................................................................................... 23
3.2. Connecting to xDSL/Cable Modem................................................................................... 24
4. IP-Installer.........................................................................................................................................................25
4.1. Main window of IP-Installer .............................................................................................. 25
5. Configuring Veilux VPIP-D110X / VPIPI-D110X in Administrative Mode..........................................................26
5.1. Log On............................................................................................................................ 26
5.2. Basic Setup..................................................................................................................... 28
5.3. Network Configuration ..................................................................................................... 30
5.4. Wireless Configuration (This is not applicable to Veilux VPIP-D110X / VPIPI-D110X network
camera)...................................................................................... Error! Bookmark not defined.
5.5. User Admin & Time Setup................................................................................................ 33
5.6. Sensor & Capture Setup.................................................................................................. 36
5.7. Alarm Device Setup......................................................................................................... 37
5.8. Motion Region Setup....................................................................................................... 39
5.9. PTZ Setup....................................................................................................................... 41
5.10. Encryption Set up.......................................................................................................... 44
5.11. Upgrade & Reset........................................................................................................... 46
5.12. Status Report ................................................................................................................ 48
6. Tips for Using Veilux VPIP-D110X / VPIPI-D110X............................................................................................49
6.1. Alarm (for Sensor input) and AUX(for Relay output) .......................................................... 49
6.2. Trouble Shooting............................................................................................................. 52
6.3. Web Viewer..................................................................................................................... 54
Table of Contents

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
7
Appendix 1. On Site Installation of Veilux VPIPI-D110X.......................................................................................59
Appendix 2. On Site Installation of Veilux VPIPI-D110X.......................................................................................64
Appendix 3. DIP Switch Setting ............................................................................................................................73

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
8
1. Introduction
1.1. Overview
The Veilux VPIP-D110X / VPIPI-D110X is a state-of-the-art Speed Dome network camera which transmits
synchronized video and audio data in real time with D1 resolution at full frame rate. This is possible through
MPEG4 CODEC technology, which provides high quality video with highly compressed data streams. The Veilux
VPIP-D110X / VPIPI-D110X can be connected, controlled and monitored from a remote location through an IP
connection over internet or intranet. Unlike CCTV or DVR, the Veilux VPIP-D110X / VPIPI-D110X is easy to install
and owner will experience cost and space savings in the installation owing to the state of the art technologies
embedded in the system. Based on Embedded Software Solution (Embedded Web Server, Embedded Streaming
Server, and Network Protocol), the Veilux VPIP-D110X / VPIPI-D110X ensures unprecedented performance and
stability to be an ideal network camera solution for system integration solutions. Veilux VPIP-D110X / VPIPI-
D110X is offered with standard Ethernet interface.
1.2. Features of Veilux VPIP-D110X / VPIPI-D110X
World Most Silent Speed Dome IP Camera
1 channel synchronized real time Video/Audio streaming MPEG-4 video, ADPCM audio.
Bi-directional audio communication
Real time audio communication between Veilux VPIP-D110X / VPIPI-D110X and Client PC
The viewer assisted recording and playback functions
World Most Silent Speed Dome IP Camera (Outdoor Type)
1/4 “Sony Ex-view CCD 26x,18x / Super HAD CCD 22x
Filter Changeable Type Day & Night
IP66 water-resistant (VPIP-D110X only)
432x Zoom (36X Optical with 12x Digital zoom) Selectable
Max 30 frames/sec(NTSC) and Max 25frames/sec(PAL) @ D1 resolution
Support both interpolation and interlace
Versatile PTZ control
Client viewer assisted PTZ control,
Dedicated virtual system controller for PTZ control on the client
Simultaneous connection & control over IP and RS485
4 Alarm sensor inputs / 2 relay outputs
Motion detection –Up to 3 motion detection zones. Arbitrary shape motion detection zone
Motion detection can initiate video recording, which is sent to the user through FTP and/or E-mail.

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
9
Resolution
- NTSC : 704x480, 352x240, 176x144. - PAL/SECAM : 704x576, 352x288, 176x144
Remote administration control
Entire operational parameter set up, Software upgrade
Various Mounting Brackets(optional)
Wall, Pipe, Gooseneck mounting brackets
Corner mount adaptor, Pole mount adaptor
Built-in Fan / Heater(Veilux VPIP-D110X Only)

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
10
Detailed Features of Speed Dome part
General Features of Outdoor Housing (iCan
World most silent speed dome camera
Adoption of timing belt, specialized gear, and other lo
w-noise-technologies reduced mechanical vibration whi
ch significantly enhances durability and quality of the
camera. This camera is the perfect match, both indoo
r and outdoor, for demanding security and monitoring
applications.
0.024°dome system accuracy with 1/8
micro step
By adopting 1/8 micro step and twin gear system, the dome
camera achieved 0.024°rotational accuracy. It provides
excellent precision for delicate control such as preset positions.
Reliable RAM-Material
The mechanical stability achieved by using high qualit
y materials (e.g., stepping motor, slip ring, timing belt
and power condenser) improves the durability and lif
e time of the camera. The camera housing is made of
fire resistant material (UL grade 94 V-0).
Preset position compensation
It minimizes the effect of low frequency vibration caused by
wind or other impact for maintaining precise positioning. It is
useful for outdoor surveillance and traffic monitoring
applications.
Long life-time Slip Ring ( Passed 6 month
test of 20milion rotations)
Equipped with slip ring that passed 20 millions rotations
performed for 6 months.
Protected RS485 terminals. (Against
misconnection of the power line)
RS-485 circuit is protected against false connection of the power
source for ensured communication channel.
Filter changeable True Day/Night
Automatic IR cut filter ensures near-true color video for
day time while providing quality B/W video under low
illumination. The efficiency of the monitoring can be
improved by using this feature used together with DSS
(Digital Slow Shutter). This feature is available only for
18X and 26X zoom module.
Hot Keys
This camera supports various hot key functions
for ease of control by other controllers or DVRs.
Various Surveillance Functions
Auto Scan continuously repeats movement between two
preset positions with various speed and dwell time.
8 Group Tour : Up to 8 Programmable Group tours are
supported. Each group can be configured to have up to 60
preset positions with different speed and dwell time
165 Preset positions : Up to 165 programmable preset
positions. Each preset position can be labeled by up to 16
characters
8 Patterns : up to 8 user-defined patterns. Each pattern can
last up to 60 seconds and can be named with up to 16
characters. Total of 480 second of pattern monitoring is
possible.
8 Sectors : Up to 8 user-defined sectors. Each sector can
be labeled by up to 16 characters
24 Privacy Masking Zones : Up to 24 user-defined
privacy masking zone. Each zone can be labeled by up to 16
characters (18X, 26X only)
4 Alarm input and 2 relay out : 4 alarm inputs and 2
relay outputs that can be matched with preset, tours, and
patterns for versatile monitoring functions.
High speed Pan & Tilt movement
Maximum speed for the panning and tilting are 350°/sec and
250°/sec, respectively, for preset movement. The high speed
will enable quick movement to the spot you want to watch..
200°/S –Manual Operation speed
This camera provides up to 200°/sec of manual speed and it‟s
adjustable from 100°/sec to 200°/sec
1/4”Sony Ex-View CCD
Sony Ex-view HAD CCD for excellent sensitivity and low
smear levels (18X 26X 36X only)
Multiple language support
Intelligent Pan/Tilt Controlling
Pan and tilt speed is adjusted in connection with zoom factor.

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
11
1.3. Applications of Veilux VPIP-D110X / VPIPI-D110X
IP surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.,
Real time Internet broadcasting
Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.,)
Teleconference (Bi-directional audio conference)
Remote Learning
Weather and environmental observation

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
12
2. Product Description
2.1. Package Contents
Open the package and check if you have the followings:
AC Adapter is optionally provided
2.2. Preview
Veilux VPIP-D110X / VPIPI-D110X
IP-Installer
NVXR-64
MPEG-4 Speed Dome Network Camera
PC software to allocate IP
parameters to Veilux VPIP-
D110X / VPIPI-D110X
PC software to view and record theA/V
streaming data transmitted from Veilux
VPIP-D110X / VPIPI-D110X
1. All items of indoor speed dome net
work camera
2. Manual for outdoor housing
3. Outdoor Housing
4. Wall Mount Bracket
5. Screw (M4x15 screw 4EA)
6. Safety Cable
VPIPI-D110X = VPIPI-D110X +
Outdoor Housing +
Wall Mount Housing
1. Camera main body
2. CD(Manual, S/W)
3. Ceiling Mount Bracket
4. Wrench
5. Screw (Ø 3x6 screw 2EA,
Ø4x16 screw 5EA )
6. Safety Wire
7. Ceiling Cover
8. Cable ties
9. Terminal Block
(1 EA of 2Pin, 3Pin , 5Pin ,6Pin)
Veilux VPIPI-D110X
(
Veilux VPIP-D110X
Veilux VPIPI-
D110X
Veilux VPIP-
D110X

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
13
2.3. PC Requirements
AV streaming data received from Veilux VPIP-D110X / VPIPI-D110X can be decoded or stored in a PC running i-
NVR program which is a viewing & recording program for a PC. Minimum requirement of the PC is described
below:
Recommended
CPU
Pentium IV 2GHz above
Main Memory
512MB above
Operating system*
Windows XP/ Vista/ 7 (32 bit)
Web browser
Internet Explorer 6.0 above
Graphic Card
Ati Radeon Series
Network
100 Base-T Ethernet
* Operating Systems supported: Windows 2000 Professional
Windows XP Professional / Windows XP Home Edition/ Windows Vista/ 7
2.4. Physical description
2.4.1 Bottom View and Connections

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
14
Fig. 2-1 Bottom View of Veilux VPIP-D110X / VPIPI-D110X
- Input/Output Connectors at Bottom panel of Veilux VPIP-D110X / VPIPI-D110X
Connector
Name
Description
ALARM
. 4 Alarm inputs(Signal pin number : 1, 2, 3, 4), 2 GND(ground) signals
. Connect external alarm sensors such as the infrared, heat, magnetic sensor to
network camera.
. Sensor type(Normal Open or Normal Close) can be selected using Virtual System
Controller (Keyboard Emulator) in i-NVR (for detailed information, please refer to
the i-NVR user‟s guide in CD)
AUX
. 2 Relay outputs and 1 ground (GND) signal
. Connect external alarm generators such as sirens, flashing light, etc., to network
camera.
Please refer to the section 6.1 for more detailed description.
NETWORK
. RJ45 connector, 100Base-T.
. Connects Veilux VPIP-D110X / VPIPI-D110X to IP network
RS485
. Connect external device such as System Controller (Keyboard) or DVR to Veilux
VPIP-D110X / VPIPI-D110X network camera
VIDEO OUT
. Composite video output from the camera.
LINE OUT
. Connect a speaker with amplifier.
. Audio/voice from client at remote site can be output through the line out terminal
in bi-directional audio mode of iNVR or NVR-Pro.
MIC/LINE IN
. Connect external Microphone or audio to network camera.
Input audio/voice is compressed in network camera for synchronized
transmission with video to client PC through IP network
AC24V
. Connect 24 Volt AC adaptors to this terminal for supplying power to the network
camera.
. AC adapter which is compliant to the specification for Veilux VPIP-D110X /
VPIPI-D110X should be used. Misuse of power supply can cause damage
to Veilux VPIP-D110X / VPIPI-D110X.
Veilux assumes no responsibility for misuse of the power supply.

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
15
2.4.2 Dimension and basic parts of Veilux VVIP-D110X / VPIPI-D110X
A. Dimension
A-1. Veilux VPIPI-D110X
Fig 2.2 Dimension of Veilux VPIPI-D110X (unit : mm)
A-2. i Veilux VPIP-D110X (Veilux VPIPI-D110X + Outdoor Housing)
Fig.2-3 Dimension of Veilux VPIP-D110X

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
16
B. Exterior and Interior of View
B-1.Common part of Veilux VPIP-D110X / VPIPI-D110X
Fig.2-5 Common part of Veilux VPIP-D110X / VPIPI-D110X
B-2.Outdoor Housing

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
17
Fig.2-6. Outdoor housing
2.5. Specification of the analog camera module and PTZ part
2.5.1. Zoom cameras
Veilux VPIP-D110X / VPIPI-D110X are offered with 5 types of zoom camera modules as described in the following
table.
Camera module
Lens
Misc.
18X Zoom
Sony Zoom Camera module
PAL or NTSC
10 & 23X Zoom
Samsung Zoom Camera module
PAL or NTSC
26X Zoom
Sony Zoom Camera module
PAL or /NTSC
30X Zoom
Samsung Zoom Camera module
PAL or /NTSC
36X Zoom
Sony Zoom Camera module
PAL or /NTSC
2.5.2 Detailed specifications
Model
18X Optical
(Sony)
26XOptical
(Sony)
27X Optical
(Samsung)
33X Optical
(Samsung)
36X
Optical
(Sony,
WDR)
37X Optical
(Samsung)
Pan / Tilt
Pan Rotation
Angle
360˚Endless
Pan Speed
Manual
0.5˚~ 200˚/sec(64step)
Preset
Max 300˚/sec, Min 10˚/sec
Tilt Rotation Angle
-2˚~ 90˚
Tilt Speed
Manual
0.5˚~ 45˚/sec(64step)
Preset
Max 250˚/sec, Min 200˚/sec
System Accuracy
0.024˚
Functions
Presets
165 positions with 16 character labels available for each position with different
speed steps
Group Tour
Max. 8 Programmable group tours(each one consisting of up to 60 preset steps
with different steps)
Auto Pan
Programmable Auto Scan
Pattern
8 Programmable Patterns(total 480 seconds)
Sector
8 Selectable Sectors with 16 characters
Password
Protection
Yes
Privacy Zone
24
24
8
8
24
8
Alarm Input
4 alarms (with various programmable states)

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
18
Alarm Actions
Activate preset, Group scanning or output per alarm input
Aux Output
2 Replay Output
Auto Flip
ON / OFF
OSD Menu
Yes
Communication
RS-485
Protocol
Built in Pelco-D, Pelco-P
Others
Motor Type
Stepping motor
Micro Steps
1/8 Micro Step
Camera
Module
Image Sensor
1/4" Sony
Exview
HAD CCD
1/4"Sony
Exview
HAD CCD
1/4"Sony
super
HAD CCD
1/4"Sony
super
HAD CCD
1/4"Sony
Exview
HAD CCD
1/4"Sony
super
HAD CCD
Total
Pixels
NTSC
811(H) * 508(V) 410K
PAL
795(H) * 596(V) 470K
Number Of
Effective
Pixels
NTSC
768(H) * 494(V) 380K
PAL
752(H) * 582(V) 440K
Horizontal
Resolution
NTSC
470TV line
470TV line
550TV
line(Color)
680TV
line(B/W)
550TV
line(Color)
680TV
line(B/W)
530TV
line(Color)
550TV
line(Color)
680TV
line(B/W)
PAL
460TV line
460TV line
530TV
line(Color)
Lens
Optical
18x Optical
Zoom
(F=1.4~3.0,
f=4.1~73.8mm)
26x Optical
Zoom
(F1.6~3.8,
f=3.5~91.0mm)
27x Optical
Zoom
(F= 1.6 ~
2.9 ,
f=3.5 ~
94.5mm)
33x Optical
Zoom
(F= 1.6 ~
3.6 ,
f=3.5 ~
115.5mm)
36x Optical
Zoom
(F=1.6 ~
4.5 ,
f=3.4 ~
122.4mm )
37x Optical
Zoom
(F= 1.6 ~
3.9 ,
f=3.5 ~
129.5mm)
Digital
12x
216x with
12x
312x with
12x
324x with
12x
396x with
12x
432x with
12x
444x with
Day & Night (ICR)
Auto/ Day/ Night
Digital Slow
Shutter
ON/ OFF
Min.
Illumination
Normal
Mode
0.05Lux
0.14Lux
0.4Lux
0.4Lux
0.1Lux
0.7Lux

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
19
Night
Mode
0.01Lux
0.05Lux
0.02Lux
0.02Lux
0.01Lux
0.061Lux
Sens-
up :
256x
0.00007Lux
0.00007Lux
0.00007Lux
Luminance S/N
Ratio
More than 50dB
Video Output
Composite video output 75 ohm terminated
BLC
ON / OFF
Flickerless
ON / OFF

Veilux VPIP-D110X / VPIPI-D110X User’s Guide
Website: www.Veilux.net Phone # [phone]
(April 2011)
20
2.6. Quick Installation Guide
Brief information for rapid installation is provided in this section. For more detailed information you are
recommended to refer to pertinent documentations provided with the product or refer to Veilux‟s home page
(http://www.Veilux.net)
1. Apply power to Veilux VPIP-D110X / VPIPI-D110X and Connect Veilux VPIP-D110X / VPIPI-D110X to
LAN like the following picture.
Fig. 2-5 Connecting Network camera and PC
2. Install “IP installer” and “NVXR-64” on your PC.
Detailed information for installing these programs can be found in [IP-Installer User’s Guide] and
[NVXR-64 User’s Guide],respectively.
3. Assign IP address to Veilux VPIP-D110X / VPIPI-D110X using IP installer.
Identify the type of the network environment and set up IP address. Detailed process of setting up IP
address can be found in [IP-Installer User’s Guide].If network type is xDSL or Cable modem you need
supplementary information provided by your ISP.
4. Connect to Veilux VPIP-D110X / VPIPI-D110X in Administrator Mode for initial parameter set-up.
All parameters are set to factory default state when Veilux VPIP-D110X / VPIPI-D110X are delivered.
You are asked to configure the system for your environment in administration mode. Detailed information
of using administration mode can be found in [5. Configuring Veilux VPIP-D110X / VPIPI-D110X in
Administrative Mode]. Among the parameters, the parameters in the following table should be set-up
