Veilux VVIP-2L2812 User manual

User’s Manual
V1.4
VVIP-2L2812 Vandal Dome
Network Camera
The Art of Surveillance
®

--Content--
CHAPTER 1 PROFILE...................................................... - 1 -
1.1FUNCTIONS AND CHARACTERISTICS ............................... - 1 -
1.2APPLICATIONS........................................................... - 2 -
CHAPTER 2 INSTALLATION............................................. - 2 -
2.1CAUTIONS................................................................ - 2 -
2.2MEASUREMENTS ....................................................... - 3 -
2.3PACKING CONTENTS ................................................... - 4 -
2.4INSTALLATION VANDAL DOME......................................... - 6 -
2.5OPTIONAL ACCESSORIES ............................................. - 8 -
2.6HARDWARE CONNECT ................................................. - 9 -
CHAPTER 3 PARAMETER SETUP.................................. - 11 -
3.1SETUP PARAMETER BY IE BROWSER............................. - 12 -
APPENDIX..................................................................... - 12 -
This manual is suitable for IP DOME-IR series

- - 1 - -
Chapter 1 Profile
This network camera is an embedded digital surveillance product. It
adopts embedded Linux as the operation system and SOC hardware platform.
Has a characteristic of high efficiency and flexibility for system adjustment,
small size, high stability and long term reliability.
1.1 Functions and Characteristics
Basic Function
Video compression tech: adopts H 264 video compression tech, high
compression ratio.
Network functions: integrate TCP/IP protocols and video, alarm, voice data
supported, built-in WEB browser, IE live view supported.
PTZ control function: control for PTZ, kinds of decoder protocols and dome
cameras supported. Can be connected via the RS485 output.
Alarm function: signal parameter alarm input, on-off parameter alarm
output, motion detective, video lost, mask alarm, alarm link output.
Voice speech: Has audio input to give remote audio / recordings.
POE power supply supported. (optionally installed)
User management: multi-level user access management.
Compression Handling Function
Multi stream hardware compression, adopts H.264 compression standard
on video compression, not only support change code ratio, but also
support change frame ratio, while setting up video image quality, it’s able
to restrict compression bit rate of video image.
1920*1080p, 1600*1200p, 1280*720p, D1(PAL:704*576, NTSC:704*480),
CIF(PAL:352*288, NTSC:352*240), QCIF(PAL:176*144, NTSC:240*160)
supported
OSD supported for date and time, full user control setup.
Remote view andtransmission function
One self-compliant 10M/100M Ethernet interface as standard accessory.
PPPoE, DHCP, DDNS protocol supported.
Available to set parameter, browse real time video, check network camera
state through applications or IE browser. Available to realize alarm link and
save compressed bit rate through network.
Available to realize remote upgrade and maintenance through network.

- - 2 - -
1.2 Applications
Suitable for circumstances required for network remote surveillance
ATM, Bank Counter, Supermarket, Factory etc
Nursing House, Kindergarten, School etc.
Intelligent door management system
Intelligent Building, intelligent community management system
Electricity station, telecom base station etc unmanned on duty system
Outdoor bridge, tunnel, crossing traffic etc surveillance system
flowing line and warehouse surveillance
24h surveillance to road traffic
Remote surveillance to forest, fountain and river etc.
Chapter 2 Installation
2.1 Cautions
Please check carefully while unpacking, be sure articles inside accordance
to the list
Please read this chapter carefully before installation
Be sure to off all concerned power while installation
Check power and voltage in case to damage facility because of
unmatched voltage
Installation circumstance: do not install in circumstances of high humidity
or high temperature, please keep good ventilation, and pay attention to
defend rain, avoid installing in high vibrating installations.
In times of malfunction, do not attempt to dismantle and service the
camera yourself. Please refer to qualified serving personnel to repair or
contact our technical department to solve the problems.
Supplied accessories are optional with all model, please refer to your local
sales for details of any additional parts required. The Packing list may
indicate Junction box plate, this would only be suitable for some parts of
the world, so may not be available for your country, please check with your
sales for details on this.

- - 3 - -
2.2 Measurements

- - 4 - -
2.3 Packing contents
2.3.1 Packing contents list
2.3.2 Junction box plate

- - 5 - -
2.3.3 Junctionbox installation types

- - 6 - -
2.4 Installation vandaldome

- - 7 - -

- - 8 - -
2.5 Optional accessories

- - 9 - -
2.6 Hardware connect
2.6.1 Hardwareinterface
Interface Connection
Network
interface (NIC)
Connect to Ethernet device, such as Ethernet
exchanger, HUB etc. See 2.6.3 for network
connection.
Audio
in/output
Connect to audio in/output device, such as tone alarm
(impedance: 1kΩ).
Power (DC12V) Standard 2.1mm x 5.5mm socket type Middle Pin +
outer is -. Or terminal block marked with + and -
Alarm output
(COM OUT)
Connect to alarm output, 1 channel on-off
parameter(the connected power must be within range
of DC12V and 300mA), detailed connection method
see 2.6.2
Alarm input
(COM IN)
Connect to alarm input, 2 channel signal alarm
(DC5V~DC12V).
RS-485
interface Connect to RS-485 device, such as Pan/Tilt, PTZ etc.
Video output 1 channels BNC Video output for lens focusing.
SD card insert
grooveInsert SD card for local recording.
RESET RESET button, restore ex-factory value.

- - 10 - -
2.6.2 Alarm input/output connection
Alarm inputconnection demonstration
Alarm output connectiondemonstration
Alarm output is in fact on-off (No voltage), outside power is needed while
connection alarm. Outside power must be within DC12V and 300mA while
connection DC power.
2.6.3 Selection ofreticle
（1）Twisted-pair to connection interface of network camera with
HUB(straight connection cable)

- - 11 - -
（2）Twisted-pair to connection interface of network camera with
PC(cross connection cable)
Chapter 3 Parameter setup
Some network parameters must be setup first after finishing installation,
includes IP address, subnet mask, port etc.
1. Setup parameters such as IP address and PPPoE etc through IE
browser
2. Setup parameters through applications on NVMS Software.
Please confirm PC and network camera already be connected, and that
you can PING between the two devices!

- - 12 - -
3.1 Setup parameter by IEbrowser
The default IP:192.168.0.120, default port:30001, user: admin, password:
admin
Login network camera by IE, input IP address, and will shoot out logging in
window, input username and password, click “login” to enter IE client interface.
Function detailed guide please refer to “Network Video Manager System
Manual”.
Important Note: to check device by IE, the premise is to set browser security
level, open IE browser, enter “tool/Internet option/security/user-defined level”,
set security level ”security level-low”, or directly set “ActiveX, Widget and
Insert ”to open. Some models may not require the security if they have a code
signed ActiveX component.
Appendix
ModelParameter Description
1.3 MP Image Sensor 1/3” MT9M033 COMS
Minimum
illumination
0.5Lux @ F1.2
0Lux（LED-ON）
S/N Ratio ≥48dB
VVIP-2L2812
Image Frame
Rate
PAL:1280x720p@25fps
NTSC:SXGA(1280x960p)@22.5fps
Parameter Description
Video out 1 BNC（PAL/NTSC, 1.0Vp-p，75Ω）

- - 13 - -
Video
Compression H.264(ISO/IEC 14496-10)/MJPEG
Bit stream
Control CBR、VBR
Audio
Input/Output
1 internal Microphone In, 1 External Microphone In,
1 Audio Line Out
G711/8KHz，16bits
Audio
Compression G723.1/6.3kbps (Options)
AMR (Options)
Audio bit stream 6.3Kbps
OSD Time/date/channel NO./
channel name/user-defined
Audio and video
sync Support
Motion
detection Support
Heartbeat Support
Two-way voice
talkback Support
Alarm and event
handling
Through built-in dynamic detection or external input or
planned to trigger the events; Through FTP, Email and
HTTP uploading images and issued a notice
Network
transmission
control
Embedded network bandwidth adaptive flow control
technology
Web Server Microsoft Internet Explorer Version 5.5 or higher
Network
Protocol
IPv4/v6、RTP/RTCP、TCP/UDP、HTTP、DHCP、
DNS、FTP、DDNS、PPPOE、SMTP
Network
Ethernet RJ-45,10/100Base-T

- - 14 - -
Alarm
Input/Output 1 Alarm Input，1 Alarm Output
RS485 1 Output (1 Input Options)
IR-LED 850nm×21 Pcs IR-LED
IR-LED Driver ON 1~3Lux; OFF 5~8 Lux
SD Card Support MicroSD/HC, MiniSD/HC
Safely Watchdog, Password protection
Temperature
( )℃
-10-60℃, RH10-90% (RUN)
-20-70℃, RH0-95% (STORE)
Supplied
Voltage 9～12VDC ±5%，1000mA
POE 802.3af POE(Power over Ethernet)
01.BSM.11.0072901

- - 15 - -
