veise JU01 User manual

JU01
Keypad Digital Deadbolt
Installation Guide / Programming Instructions
Thank you for purchasing our products. Please review this manual thoroughly before operating your device.
All pictures in this manual are for illustration purpose only. Actual product may vary due to product upgrade.

INSTALLATION
VIDEO
INSTALLATION
VIDEO
Scan to access installation video
www.iveise.com/videos
www.iveise.com
[email protected]
Before you return your product, please
contact our customer service team directly.
Have an issue?
We guarantee a professional service that can
solve your issue in a faster, more efficient manner.

Installation Overview Programming Instructions
STEP 1: Prepare the door and check dimensions
STEP 2: Install the latch and strike
STEP 3: Install exterior assembly
STEP 4: Install interior assembly
STEP 5: Detect left/right hand door installation
IMPORTANT:
TOOL REQUIRED:
P 3
P 4
P 6
P 7
P 8
P 9
P10
P 11
P 12
P 13
At a Glance
How to Use
Definitions
Code Format
Quick Set Up
P 15
P 16
P 16
Factory Default Settings
Troubleshooting
Information & Safety Warnings
Do not use an electric
screwdriver during installation.
Do not load batteries until lock is
completely installed.

Battery
Cover (G)
Interior Assembly
Screws (K)
Latch Screws
(I)
Strike Screws
(H)
Exterior Assembly
(D)
Latch (A)
Strike (C)
Mounting
plate (E)
Mounting Plate
Screws (J)
Interior
Assembly (F)
INSTALLATION OVERVIEW
1

Latch x1 Drive-In Collar (Optional) Strike x1 Exterior Assembly x1
Mounting Plate x1 Interior Assembly x1 Battery Cover x1 Strike Screws x2
Mounting Plate
Screws x2
Interior Assembly
Screws x3
Latch Screws x2
A B C
E F G
L
H
I
J K
D
Reset Tool
Parts List
If any parts are missing
or damaged, please
contact Customer
Support.
2

Measure to confirm
that the hole in the
door edge is 1"
(25mm).
Measure to confirm
that the backset is
either 2-3/8" or
2-3/4" (60 or 70mm)
Make sure the hole in
door frame is drilled a
minimum of 1"
(25mm) deep.
Measure to confirm
that the door is 1-3/8"
to 2" (35 mm or
50mm) thick.
A
Measure to
confirm that the
hole in the door is
2-1/8" (54mm).
B
CD
Prepare the door and check dimensions
1
STEP
3
2-3/8" or 2-3/4"
(60 or 70mm)
1"
25mm
1-3/8" to 2"
(35mm or 50mm)

4
chiseled
not chiseled
Drive-In Collar
(B)
Install the latch and strike
2
STEP
Hold the latch in front of the door hole,
with the latch face flush against the
door edge. Is the slotted hole centered
in the door hole?
No adjustment is required.
Proceed to next step.
Slotted hole is
NOT centered.
A
B
YES
NO
Rotate and pull the
latch as shown to
extend latch.
2-3/4"
(70mm)
2-3/8"
(60mm)
pull
Determine backset
and adjust the latch
Install the latch
Latch Screws (I)
up

CUse a screwdriver to test if
deadbolt works smoothly.
DInstall strike on the door frame.
5
IMPORTANT:
Make sure the hole in door
frame is drilled a minimum of
1" (25mm) deep.
Strike Screws (H)

A B
Mounting Plate Screws(J)
Install exterior assembly
3
STEP
Unlocked
With the latch fully retracted (in the unlocked
position), route the cable below the latch.
Secure the mounting plate with
the supplied screws. Do not
overtighten screws.
6
Before installation, make sure the latch is
fully retracted (in the unlocked position)
IMPORTANT:
Locked
Keep parallel to
door edge.

Install interior assembly
4
STEP
Push the battery cover out in
the direction as illustrated.
Insert the cable
connector to the
socket. Push the
connector in firmly
until it is completely
attached.
Attach Interior
Assembly to
Mounting Plate and
tighten 3 Screws.
Interior Assembly
Screws (K)
A B
CD
Unlocked
Tourque
blade
7
Keep the thumb turn in vertical position and install
the interior assembly.
: After installation, test whether the thumb turn
rotates smoothly.
Horizontal
Note
Do not load batteries until lock is
completely installed.
IMPORTANT:

Reset button
While the door is OPEN and
UNLOCKED, load 3 AA batteries
into the battery compartment.
Note:
For long last, please use all new,
non-rechargeable Alkaline
batteries only.
Press and hold the Reset button on
the interior assembly by using the
reset tool.
This step is required and crucial for the lock
to operate properly.
IMPORTANT:
Detect left/right hand door installation
5
STEP
Reset the lock to teach the lock the orientation of the door.
A B Load the 4th battery and keep holding
the reset button for 3 seconds, until
you hear the sound of "beep". The
latch bolt will extend to learn the
orientation of the door automatically.
C
8
Unlocked

PROGRAMMING INSTRUCTIONS
At a Glance
Exterior Assembly
Keypad
Light Indicater
Reboot Button
Battery Cover
Reset Button
Thumb Turn
Micro USB
Power Port
Interior Assembly
9

How to Use
UNLOCK the door from outside
or
or
LOCK the door from outside
Master code + User code +
Auto Lock Mode
In Auto Lock mode, the bolt
will extend out automatically in
30 seconds after unlocking.
Manual Mode
Press any key on keypad for
2 seconds.
UNLOCK the door from inside
LOCK the door from inside
Auto Lock Mode
In Auto Lock mode, the
device will be locked
automatically.
Rotate the thumb turn to
Unlock position.
Manual Mode
Rotate the thumb turn to Lock Position.
10

• Master Code
Required for programming and feature settings. Master code can be
used to unlock the door under vacation mode. The default master
code needs to be changed before programming.
Property owner & manager should keep this information confidential.
• Auto Lock
Automatically locks the deadbolt 30 seconds after unlocking. This
feature is off by default. You can customize the Auto Lock time delay
between 10 and 99 seconds.
• Emergency Power Port
Emergency USB Port can be used when battery is completely dead.
Supply power by connecting an external power bank to the
micro-USB port and hold the reboot button for 3 seconds.
• Wrong Entry Limit
After 10 unsuccessful attempts at entering a invalid PIN code, the
unit will shut down for 3 minutes.
• Silent Mode
The beep sounds when pressing keypad can be muted. But you will
still hear low battery and system alerts.
• Vacation Mode
This is a security feature for you when you are leaving your home for
vacation or long trip. Enabling vacation mode will restrict all user
codes until master code is entered on keypad. If the lock would be
unlocked by the thumb turn from the inside, the lock will sound an
alarm.
• One Time User Code
This code only can be used once and will be automatically deleted
after used.
• Unlock with Fake code
User can prevent pin code exposure from strangers by entering
random digits before or after pin code.
Definitions Programming Basic
11

Forward number sequence
Backward number sequence
Repeat number sequence
Contain existing code sequence
Programming BasicCode Format
12
1. Master Code(4 to 10 digits): The default Master Code is 12345678 .It is required that you change it to a code of your own before
programming.
2. User Code (4 to 10 digits): A total of 20 User Codes (including one temporary one-time User Code) can be programmed and stored.
3. Both Master Code and User Code don’t support the following combination of numbers.

Quick Set Up
13
IMPORTANT:
The default Master Code is 12345678 . It is required that you
change it to a code of your own before programming.

Notes:
1. Beeps only sound when the Silent Mode is disabled.
2. If the indicators flash red light, it means your setting failed and it will require to re-enter master
mode if you would like to continue your programming.
Enable
Vacation
mode
Disable
Vacation
mode Vacation Mode Disabled
The door was opened
14

Factory Default Settings
The resetting will delete all User Codes
stored in the lock.
IMPORTANT:
How to Reset?
Step 1. Keep the door open and unlocked.
Step 2. Press and hold the Reset button, at the same time take out one
battery and then place it back.
Step 3. Keep holding the Reset button for 3 seconds, until you hear the
sound of rotating and the latch extend automatically.
Settings
Master Code
Auto Lock
Silent Mode
Wrong Code Entry Limit
Shutdown Time
Vacation Mode
Factory Defaut
12345678
Disabled
Disabled
10 times
3 mins
Disabled
Reset button
15

Troubleshooting
Why doesn't the thumb turn rotate after installation completed?
• When the lock is learning wrong orientation of the door, the thumb turn
won't rotate. Please reset your lock by following the steps:
1. Keep the door opened and make sure the latch is retracted and thumb
turn vertical.
2. Press and hold the reset button with one hand and the other hand take
out one battery and place it back.
3. Do not release the reset button after battery is connected, instead,
keep holding it until the latch automatically extend.
• If resetting doesn't solve the issue, you may need to re-install the whole
lock.
Please make sure when you start to install, the lock is in unlocked status;
Please make sure the thumb turn is vertical.
Why does the keypad work improperly? No backlights and no
beeping sound.
There's no power supplied your lock.
Please make sure the cable is properly connected.
We would suggest to use 4 brand-new AA standard alkaline batteries and
please do not mix up used batteries.
What if I forget my Master Codes?
If you forget your Master code, resetting your lock, then the original master
code (12345678) works, and all previous user codes will be deleted.
• Protect your User Codes and Master Code.
• Restrict access to your lock’s interior assembly and routinely check your
settings to ensure they have not been altered without your knowledge.
• Do not use an electric screwdriver during installation.
• This manufacturer advises that no lock can provide complete security by
itself.
• This lock may be defeated by forcible or technical means, or evaded by
entry elsewhere on the property.
• No lock can substitute for caution, awareness of your environment, and
common sense.
• Care should be taken to ensure a long-lasting finish. When cleaning is
required use a soft, damp cloth. Using lacquer thinner, caustic soaps,
abrasive cleaners or polishes could damage the coating and result in
tarnishing.
• The lock meets IP54 water-resistance. It can withstand water splashes ;
however, do not let water and liquids get into the lock.
• Avoid exposure to direct sunlight. Long-term exposure to direct sunlight
may damage the lock.
• The temperature range of the lock is between -4°F to 131°F.
Information & Safety Warnings
