veise VS01 User manual

VS01
Keypad Digital Deadbolt
Installation Guide / Programming Instructions

Battery
Cover (G)
Interior Assembly
Screws (K)
Latch Screws
(I)
Strike Screws
(H)
Exterior Assembly
(D)
Latch (A)
Strike (C)
Mounting
plate (E)
Mounting Plate
Screws (J)
Interior
Assembly (F)

Latch x1 Drive-In Collar (Optional) Strike x1 Exterior Assembly x1
Mounting Plate x1 Interior Assembly x1 Battery Cover x1 Strike Screws x2
Mounting Plate
Screws x2
Interior Assembly
Screws x3
Latch Screws x2
A B C
E F G
L
H
I
J K
D
Reset Tool
Parts List
If any parts are missing
or damaged, please
contact Customer
Support.

Measure to confirm
that the hole in the
door edge is 1"
(25mm).
Measure to confirm
that the backset is
either 2-3/8" or
2-3/4" (60 or 70mm)
Make sure the hole in
door frame is drilled a
minimum of 1"
(25mm) deep.
Measure to confirm
that the door is 1-3/8"
to 2" (35 mm or
50mm) thick.
A
Measure to
confirm that the
hole in the door is
2-1/8" (54mm).
B
CD
Prepare the door and check dimensions
1
STEP
2-3/8" or 2-3/4"
(60 or 70mm)
1"
25mm
1-3/8" to 2"
(35mm or 50mm)

chiseled
not chiseled
Drive-In Collar
(B)
Install the latch and strike
2
STEP
Hold the latch in front of the door hole,
with the latch face flush against the
door edge. Is the slotted hole centered
in the door hole?
No adjustment is required.
Proceed to next step.
Slotted hole is
NOT centered.
A
B
YES
NO
Rotate and pull the
latch as shown to
extend latch.
2-3/4"
(70mm)
2-3/8"
(60mm)
pull
Determine backset
and adjust the latch
Install the latch
Latch Screws (I)
up

Strike Screws (H)

A B
Mounting Plate Screws(J)
Install exterior assembly
3
STEP
Unlocked
With the latch fully retracted (in the unlocked
position), route the cable below the latch.
Secure the mounting plate with
the supplied screws. Do not
overtighten screws.
Before installation, make sure the latch is
fully retracted (in the unlocked position)
IMPORTANT:
Locked
Keep parallel to
door edge.

Install interior assembly
4
STEP
Push the battery cover out in
the direction as illustrated.
Insert the cable
connector to the
socket. Push the
connector in firmly
until it is completely
attached.
Attach Interior
Assembly to
Mounting Plate and
tighten 3 Screws.
Interior Assembly
Screws (K)
A B
CD
Keep the thumb turn in vertical position and install
the interior assembly.
Unlocked
Tourque
blade
Horizontal

Exterior Assembly
Keypad
Light Indicater
Reboot Button
Battery Cover
Reset Button
Thumb Turn
Micro USB
Power Port
Interior Assembly

Master code User code

201-00-Lock-VS01-V1
