veise RZ-A User manual

RZ-A
Keypad Digital Deadbolt
Installation Guide / Programming Instructions
Thank you for purchasing our products. Please review this manual thoroughly before operating your device.
All pictures in this manual are for illustration purpose only. Actual product may vary due to product upgrade.

INSTALLATION
VIDEO
INSTALLATION
VIDEO
Scan to access installation video
www.iveise.com/videos
www.iveise.com
[email protected]
Before you return your product, please
contact our customer service team directly.
Have an issue?
We guarantee a professional service that can
solve your issue in a faster, more efficient manner.

Installation Overview Programming Instructions
STEP 1: Prepare the door and check dimensions
STEP 2: Install the latch and strike
STEP 3: Install exterior assembly
STEP 4: Install interior assembly
STEP 5: Detect left/right hand door installation
P 3
P 4
P 6
P 7
P 8
P 9
P10
P 11
P 12
P 13
At a Glance
How to Use
Definitions
Code Format
Quick Set Up
P 15
P16
Factory Default Settings
Troubleshooting
IMPORTANT:
TOOL REQUIRED:
Do not use an electric
screwdriver during installation.
Do not load batteries until lock is
completely installed.

INSTALLATION OVERVIEW
1
Battery
Cover (G)
Strike Screws
(H)
Interior Assembly
Screws (K)
Exterior Assembly
(D)
Strike (C)
Mounting
plate (E)
Backup key (M)
Latch (A)
Interior
Assembly (F)
Mounting
plate Screws (J)
Latch Screws
(I)

Latch x1 Drive-In Collar (Optional) Strike x1 Exterior Assembly x1
Mounting Plate x1 Interior Assembly x1 Battery Cover x1 Strike Screws x2
Mounting plate
Screws x2
Interior Assembly
Screws x3
Latch Screws x2
A B C
E F G
L
H
I
J K
D
Reset Tool x1 MBackup Key x2
Parts List
If any parts are missing or damaged, please contact Customer Support.
2

Measure to confirm
that the hole in the
door edge is 1"
(25mm).
Measure to confirm
that the backset is
either 2-3/8" or
2-3/4" (60 or 70mm)
Make sure the hole in
door frame is drilled a
minimum of 1"
(25mm) deep.
Measure to confirm
that the door is 1-3/8"
to 2" (35 mm or
50mm) thick.
A
Measure to
confirm that the
hole in the door is
2-1/8" (54mm).
B
CD
Prepare the door and check dimensions
1
STEP
3
2-3/8" or 2-3/4"
(60 or 70mm)
1"
25mm
1-3/8" to 2"
(35mm or 50mm)

4
chiseled
not chiseled
Drive-In Collar
(B)
Install the latch and strike
2
STEP
Hold the latch in front of the door hole,
with the latch face flush against the
door edge. Is the slotted hole centered
in the door hole?
No adjustment is required.
Proceed to next step.
Slotted hole is
NOT centered.
A
B
YES
NO
Rotate and pull the
latch as shown to
extend latch.
2-3/4"
(70mm)
2-3/8"
(60mm)
pull
Determine backset
and adjust the latch
Install the latch
Latch Screws (I)
up

CUse a screwdriver to test if
deadbolt works smoothly.
DInstall strike on the door frame. Make sure the hole in door frame is
drilled a minimum of 1" (25mm)
deep.
IMPORTANT:
Strike Screws (H)
5

A B
Mounting plate Screws(J)
Keep parallel to
door edge.
Install exterior assembly
3
STEP
With the latch fully retracted (in the unlocked
position), route the cable below the latch, and
insert the tourque blade through the slot in the
latch.
Secure the mounting plate with the
supplied screws. Do not overtighten
screws.
6
Tourque
blade
Unlocked
Before installation, make sure the latch is
fully retracted (in the unlocked position)
IMPORTANT:
Locked

C
Unlocked
Keep the thumb turn in vertical position and install
the interior assembly.
: After installation, test whether the thumb turn
rotates smoothly.
Note
Install interior assembly
4
STEP
Do not load batteries until lock is
completely installed.
IMPORTANT:
Push the battery cover out in
the direction as illustrated.
Insert the cable
connector to the
socket. Push the
connector in firmly
until it is completely
attached.
Attach Interior
Assembly to
Mounting Plate and
tighten 3 Screws.
A B
D
7
Interior Assembly
Screws (K)
Horizontal

Unlocked
While the door is OPEN and
UNLOCKED, load 3 AA batteries
into the battery compartment.
Note:
For long last, please use all new,
non-rechargeable Alkaline
batteries only.
Press and hold the Reset button on
the interior assembly by using the
reset tool.
This step is required and crucial for the lock
to operate properly.
IMPORTANT:
Detect left/right hand door installation
5
STEP
Reset the lock to teach the lock the orientation of the door.
A B Load the 4th battery and keep holding
the reset button for 3 seconds, until
you hear the sound of "beep". The
latch bolt will extend to learn the
orientation of the door automatically.
C
8
Reset button

PROGRAMMING INSTRUCTIONS
At a Glance
Exterior Assembly Interior Assembly
9
Reset Button
Thumb Turn
Battery Cover
Keypad
Keyhole
Multi-Function
Button(MFB)

How to Use
UNLOCK the door from outside
or
LOCK the door from outside
Master code + User code +
Auto Lock Mode
In Auto Lock mode, the bolt
will extend out automatically in
30 seconds after unlocking.
Manual Mode
Press any key on keypad for
2 seconds.
UNLOCK the door from inside
LOCK the door from inside
Auto Lock Mode
In Auto Lock mode, the
device will be locked
automatically.
Rotate the thumb turn to
Unlock position.
Manual Mode
Rotate the thumb turn to Lock Position.
or
10

• Master Code
Required for programming and feature settings. Master code can be
used to unlock the door under vacation mode. The default master
code needs to be changed before programming.
Property owner & manager should keep this information confidential.
• Auto Lock
Automatically locks the deadbolt 30 seconds after unlocking. This
feature is off by default. You can customize the Auto Lock time delay
between 10 and 99 seconds.
• Key Unlock
Key Unlock is always available when the batteries are completely
dead or valid User Codes are forgotten.
• Low Battery Indicator
If you hear 10 beeps along with 10 red light flashing after pressing
any key to lock or unlock the door, that’s an alert for replacing
batteries. Please replace with 4 brand new AA alkaline batteries and
do not mix used and new batteries. All settings are stored in the lock
while the batteries are removed and replaced.
• Wrong Entry Limit
After 10 unsuccessful attempts at entering a invalid PIN code, the
unit will shut down for 3 minutes.
• Silent Mode
The beep sounds when pressing keypad can be muted. But you will
still hear low battery and system alerts.
• Vacation Mode
This is a security feature for you when you are leaving your home for
vacation or long trip. Enabling vacation mode will restrict all user
codes until master code is entered on keypad. If the lock would be
unlocked by the thumb turn from the inside, the lock will sound an
alarm.
• One Time User Code
This code only can be used once and will be automatically deleted
after used.
• Unlock with Fake code
User can prevent pin code exposure from strangers by entering
random digits before or after pin code.
Definitions Programming Basic
11

1. Master Code(4 to 10 digits): The default Master Code is 12345678. It is required that you change it to a code of your own before
programming.
2. User Code (4 to 10 digits): A total of 20 User Codes (including one temporary one-time User Code) can be programmed and stored.
3. Both Master Code and User Code don’t support the following combination of numbers.
Forward number sequence
Backward number sequence
Repeat number sequence
Contain existing code sequence
Programming BasicCode Format
12

Quick Set Up
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
Silent
Mode
Delete
User
Code
Add
User
Code
Change
Master
Code
Press
Press
Press
Press
Wait for green light flash
Wait for green light flash
Succeed
Green light flash
Silent Mode Disabled
Green light flash
Silent Mode Enabled
Green light flash
Succeed
Green light flash
Succeed
Green light flash
Wait for green light flash
Wait for green light flash
Wait for green light flash
Wait for green light flash
New Master Code +
New User Code +
New Master Code +
New User Code +
Unwanted User Code +
13
The default Master Code is 12345678 .
It is required that you change it to a code of
your own before programming.
IMPORTANT:

Master Code +
Enable
Vacation
mode
Disable
Vacation
mode Vacation Mode Disabled
The door was opened
Add
One-Time
Code
Set Auto
Lock Time
Auto
Lock
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
+ Master Code +
Wait for long green lights
Press
Press
Press
Press
Wait for green light flash
Wait for green light flash
Wait for green light flash Wait for green light flash
Wait for green light flash Vacation Mode Enabled
Green light flash
Auto Lock Enabled
Green light flash
Auto Lock Disabled
Green light flash
Press
New User Code +
Enter New Duration Time
（10-99）
+
New User Code +
Succeed
Green light flash
Succeed
Green light flash
+
+
14
Notes:
1. Beeps only sound when the Silent Mode is disabled.
2. If the indicators flash red light, it means your setting failed and it will require to re-enter master mode if you would like to continue your programming.

Factory Default Settings
The resetting will delete all User Codes stored
in the lock.
IMPORTANT:
How to Reset?
Step 1. Keep the door open and unlocked.
Step 2. Press and hold the Reset button, at the same time take out one
battery and then place it back.
Step 3. Keep holding the Reset button for 3 seconds, until you hear the
sound of rotating and the latch extend automatically.
Settings
Master Code
Auto Lock
Silent Mode
Wrong Code Entry Limit
Shutdown Time
Vacation Mode
Factory Defaut
12345678
Disabled
Disabled
10 times
3 mins
Disabled
Reset button
15

Troubleshooting
Why does not the latch extend but the motor is rotating
when resetting my lock?
Improper installation may have caused the issue. Please follow the
steps to review:
1. Please make sure the latch and strike are aligned.
2. Please slightly loosen the mounting screws on the external
assembly keypad and the latch bolt if the screws are over-tight-
ened.
3. Please open your door and reset the lock.
Why does not the latch extend and the motor isn't rotating
when resetting my lock?
The deadbolt latch should be retracted(unlocked) through all your
installation process.
The thumb turn should be vertical in your installation steps 4C and 5A.
Please open your door and reset the lock.
When I attempt to lock/unlock my deadbolt, why does the
latch go in and out for a few times?
It happens when the latch and strike are misaligned.
Please make sure the bolt hole on the door frame is at least 1 inch
deep, so that the bolt can be fully extended.
Please check if the door can be closed properly, the deadbolt should
not impact the strike or door frame on the door frame side, it should go
directly into the hole properly.
Why does my lock only work properly when the backup key
is in? Why am I unable to pull the key out in the unlocked
position?
You may need to re-install the whole lock.
Please make sure when you start to install, the lock is in unlocked
status;
Please make sure the thumb turn is vertical.
Please do not put the backup key in the lock.
What does 5 short and fast beeps mean while program-
ming?
It alerts you either time-out or wrong entry.
Please be sure to complete each setting step within 5 seconds.
Please change the default master code in the first time programming.
Please be sure the user code is with correct format and with 4 to 10
digits.
What if I forget my Master Codes?
If you forget your Master code, resetting your lock, then the original
master code (12345678) works, and all previous user codes were
erased.
16

201-44-Lock-RZ-A-V1
• Protect your User Codes and Master Code.
• Restrict access to your lock’s interior assembly and routinely check your
settings to ensure they have not been altered without your knowledge.
• Do not use an electric screwdriver during installation.
• This manufacturer advises that no lock can provide complete security by
itself.
• This lock may be defeated by forcible or technical means, or evaded by
entry elsewhere on the property.
• No lock can substitute for caution, awareness of your environment, and
common sense.
• Care should be taken to ensure a long-lasting finish. When cleaning is
required use a soft, damp cloth. Using lacquer thinner, caustic soaps,
abrasive cleaners or polishes could damage the coating and result in
tarnishing.
• The lock meets IP54 water-resistance. It can withstand water splashes ;
however, do not let water and liquids get into the lock.
• Avoid exposure to direct sunlight. Long-term exposure to direct sunlight
may damage the lock.
• The temperature range of the lock is between -4°F to 131°F.
Information & Safety Warnings
