1/ 4
GLT-299-7-11 Rev. 0
Jun 12, 2018
Instruction Manual
VDOT-ADP Adapter Mounting Plate
Before Installation
Please read these instructions carefully and keep for future reference.
The information in this document is subject to change without notice. For updates please refer to our
website.
Note: Follow the requirements for the installation of the products in accordance with the Specifications.
Otherwise it may cause damage to equipment.
Note: Do not install the product in any location where oil, dust, iron powder, chemicals, or hydrogen sulphide
may occur or affect the product. It may cause damage to equipment.
This package contains the following items:
Main unit………………………………………………………………………………………………………………………………………………………1
Instruction Manual………………………………………………………………………………………………………………………………1
Section 1 – INTRODUCTION
VDOT-ADP Adapter Mounting Plate is designed to be used with the model VDOT-STB-RL and VDOT-STB-SCI
when the bases are installed with 4” square or octagonal electrical box.
Section 2 – DIMENSIONS
160.0 (6.3)
8.2 (0.32)
mm (Inch)
Figure 1: Dimension of VDOT-ADP
ZETA ALARMS LIMITED
72-78 MORFA ROAD, SWANSEA, SA1 2EN
http://www.velocitydetection.com
2/ 4
GLT-299-7-11 Rev. 0
Jun 12, 2018
Section 3 – BASE MODELS
There are 2 base models available for use with the VDOT-ADP.
Model
Description
Instruction manual
Diameter
Number of
Terminal
Applicable electrical box
3-1/2”
Oct
4” Oct
4”
Square
VDOT-STB-RL
Relay base
GLT-299-7-9
4 inch
6
✓
-
-
(with VDOT-ADP)
6 inch
-
✓
✓
VDOT-STB-SCI
Short circuit isolator base
GLT-299-7-8
4 inch
4
✓
-
-
(with VDOT-ADP)
6 inch
-
✓
✓
Section 4 – INSTALLATION
Please refer to VDOT-STB-RL or VDOT-STB-SCI instruction manual for details. Fit the convex part of the base
into the concave part of the adapter mounting plate to attach to the base. Pass the field wiring through the cable
opening in the center and from the rear of the base and adapter mounting plate. Install the base and the plate to
an electrical box with screws via the base and the plate mounting holes. Connect the field wiring to the base
terminals, as detailed in VDOT-STB-RL or VDOT-STB-SCI instruction manual.
VDOT-ADP
Electrical box
VDOT-STB-SCI or VDOT-STB-RL
Figure 2: Installation to 4” octagonal electrical box
*Tapping screws (M4) are not included in the package
*Screws (M4) are not included in the package
3/ 4
GLT-299-7-11 Rev. 0
Jun 12, 2018
Section 5 – SPECIFICATION
UL Ambient Installation Temperature
Range
0℃( 32°F) to 38℃(100°F)
Operating Temperature Range
-10℃( 14°F) to 55℃( 131°F)
Storage Temperature Range
-20℃( -4°F) to 60℃(140°F)
Max Relative Humidity
Up to 95%RH,non-condensing
Environment
Indoor dry use only
Dimensions:
Φ160mm x 8.2mm H(Φ6.3 in. x 0.32 in. H)
Weight:
Approximately 60g (2.1 ounces)
Conformity
UL268, UL521
FOR WARRANTY SERVICE, RETURN TO:
ZETA ALARMS LIMITED
72-78 MORFA ROAD, SWANSEA, SA1 2EN
http://www.zetaalarmsystems.com
VDOT-ADP
Electrical box
VDOT-STB-SCI
or VDOT-STB-RL
Figure 3: Installation to 4” square electrical box
*Tapping screws (M4) are not included in the package
*Screws (M4) are not included in the package
4/ 4
GLT-299-7-11 Rev. 0
Jun 12, 2018
Section 6 – WARRANTIES
6.1 Zeta warrants to the customers that:
(a) all products supplied hereunder will be of merchantable quality and will comply with any specification
agreed between Zeta and customer.
(b) it is not aware of any rights of any third party in the market which would or might render the sale of the
products, or the use of any of the trade marks on or in products, or the use of any of the trade marks on or
in relation to the products, unlawful.
6.2 In the event of any breach of the Zeta’s warranty in Clause 1.1(a) whether by reason of defective materials,
production faults or otherwise, Zeta’s liability shall be limited to:
(a) replacement of the products in question; or
(b) at the Zeta’s option, repayment of the price where this had been paid.
And the warranty period is three (3) years from the shipment from Zeta’s factory.
6.3 Notwithstanding anything to the contrary in this warranty terms, Zeta shall not be liable to the customer by
reason of any representation or implied warranty, condition or other term or any duty at common law, or
under the express terms of this warranty terms, for any consequential loss or damage whether for loss of
profit or otherwise and whether occasioned by the negligence of Zeta or its employees or agents or
otherwise, arising out of or in connection with any act or omission of Zeta relating to Zeta or supply of the
products, their use by any customer.
6.4 Customer shall indemnify Zeta against all loss, damages, liabilities, costs and expenses which Zeta may
suffer or incur as a result of or in connection with any breach by customer of this warranties terms or any
laws or regulations of any jurisdiction or any rules of any governing authorities.
