Venga VG RVC 3001 WH User manual

Manuel de l’utilisateur - Produit 1:
Venga! Robot Aspirateur, Laveur de sol, Navigation Gyroscope
et App, Blanc, VG RVC 3001 WH

I/B V 211015
VG RVC 3001 –DC 14.4V –Li-ion 2600mAh
Robot vacuum cleaner
Roboterstaubsauger
Aspirateur robot
Robot aspirador
Robot aspirapolvere
Robotstofzuiger
EN
DE
FR
ES
IT
NL

VG RVC 3001
2
ENGLISH
IMPORTANT SAFEGUARDS
Please read these instructions carefully before using the
appliance, and always follow the safety and operating instructions.
Important: This appliance can be used by children over 8 years
old and people with reduced physical, sensory or mental
capacities or with a lack of experience or knowledge if they have
been given supervision or instructions concerning the safe use of
the appliance and the risks involved. Children should not play with
the appliance. Cleaning and user maintenance should not be done
by children unless they are older than 8 years and supervised.
Never leave the appliance and its power cord unsupervised and
within reach of children less than 8 years old or irresponsible
persons when it is plugged into the wall or when it is cooling down.
❑Check that your mains voltage corresponds to that stated on
the appliance.
❑From time to time check the appliance for damage. Should it
be damaged, have it checked by a competent and qualified
electrician (*).
❑Only use the appliance for domestic purposes and in the way
indicated in these instructions.
❑Never immerse the appliance in water or any other liquid for
any reason whatsoever (see chapter "Cleaning and
Maintenance"). Keep it dry.
❑Never use the appliance near hot surfaces.
❑Unplug the appliance before cleaning it. Never use the
appliance with its adapter outside and always place it in a dry
environment.
❑Never use accessories or an adapter that are not
recommended by the producer (see characteristics of the
adapter). They could constitute a danger to the user and a risk
of damage to the appliance.
❑Never use the appliance to vacuum matches, pointed objects,
cigarette butts or other flammable objects.
EN

3
VG RVC 3001
❑Never move the appliance by pulling the power cord. Make
sure the power cord cannot get caught in any way. Do not use
the power cord to hang your appliance. Do not wind the power
cord around the appliance and do not bend it.
❑This product is suitable for cleaning indoor wood floors, rubber
floors, ceramic tiles and short-haired carpets, but it is not
suitable for cleaning plush carpets.
❑Do not use this product on stairs.
❑Do not use this product in potentially hazardous environments,
such as gas stations, oil depots, chemical factories and other
flammable or explosive places.
❑Do not use this product to remove flammable or volatile liquids,
such as gasoline, kerosene, paint, detergent, alcohol, perfume,
floor cleaner and so on.
❑Do not stand or sit on the machine.
❑Pay attention to babies, children or pets when using this
product, in order to avoid danger.
❑If you use the appliance with a damaged air filter, the appliance
might get damaged. Make sure to check the good quality and
placement of the filter.
❑Never replace the batteries yourself. If they are to be replaced,
please contact a competent and qualified electrician (*).
❑When you decide to throw away the appliance, make sure to
remove the batteries and to dispose of them in an ecological
manner by handing them in at a place destined to this end.
❑Always unplug the appliance before removing the batteries.
❑If liquid coming out of the batteries comes into contact with
clothes or skin, immediately clean the polluted surface with
clear water and consult a doctor.
❑If the appliance contains rechargeable batteries, do not replace
them with ordinary batteries.
(*) Competent and qualified electrician: after-sales department of
the producer or importer or any person who is qualified,
approved and competent to perform this kind of repairs in order
to avoid all danger. In case of need you should return the
appliance to this electrician.

VG RVC 3001
4
DEVICE
Cliff sensors
Wheels
Main power switch
Dust bin
Charge contact pins
Swivel wheels
Side brushes
Battery pack
Rolling brush
Dock button
To send the robot back
to the charging
dock, press on the robot
or on the remote control.
On/off button
Press and hold on to turn
the power on or off.
Press to start cleaning.
Anti-collision sensors

5
VG RVC 3001
ACCESSORIES
Boundary strips
CHARGING DOCK
Central brush
Charging dock
Adapter
Remote control
(with batteries)
Dust bin
Water tank
Cleaning
brush
Side brushes
Sponge filter and
HEPA filter
Cleaning cloths

VG RVC 3001
6
REMOTE CONTROL
Automatic cleaning
Cleaning direction
control
Time setup
Spot cleaning
Room cleaning
Display screen
Return to charging
dock
Start/Stop
Schedule setup
Edge Cleaning
Max suction
Install 2 AAA batteries before using the remote control for the first time. Make sure the
positive and negative ends are facing the correct polarity direction as marked in the
battery compartment. (see “+”and “-”markings)
LED light
Status
Breathing orange
Charging
Solid green
Standby / Cleaning / Fully charged
Solid orange
Low power and returning to charging
dock
Off
Robot is off
Flashing / Solid red + Beeping
An error has occured. Refer to the
Troubleshooting - Error Tone section in this
instruction manual for solutions
QUICK START
Plug in the charging dock, and place
the remaining excess cable into the
cable storage space at the bottom of
charging dock.
Note: if you don't put the excess cable
into the trunking, it may get tangled
with the robot while charging or
cleaning.
A. Charging dock position
1. Place the charging dock on a
hard, level surface and against a
wall.

7
VG RVC 3001
2. Place the charging dock against
the wall. Make sure the area is
open and uncluttered, leaving at
least:
•2 meters in front of the
charging dock
•1 meter on both sides of the
charging dock
3. Plug the round connector of the
adapter into the power socket on
the charging dock and the other
end into a wall outlet.
Install the charging dock in a location
that your Venga! robot can easily
access. It is recommended to place
the charging dock against a wall, and
on a hard, level surface rather than on
a rug or carpet. Always keep the
charging dock plugged in, otherwise
the robot will not automatically return
to it. Make sure there are no obstacles
between the robot and the charging
dock, or the robot will not be able to
find the charging dock.
B. Install side brushes
Attach side brushes to the bottom of the
robot by pressing a brush into each slot.
C. Turn on the main power switch on
the bottom of robot

VG RVC 3001
8
D. Activate the robot
Place the robot onto the charging
dock, making sure the metal charging
contacts on the charging dock
match up with those underneath the
robot. If successful, you will hear a
series of tones. Once the power
button illuminates, the Venga! robot is
ready for use.
E. Start cleaning cycle
Press the power button once to
wake up the robot.
Press the power button again to
start a cleaning cycle (or press the
“Auto” button on the remote control).
If its battery gets low before finishing a
cleaning cycle, the robot will
automatically return to the charging
dock.
lf the charging dock is inaccessible,
the robot will return to its starting
location and the cycle will end.
In this case, please place the robot on
its dock manually.
F. Pause
To pause the robot, press the
button or press the button on the
remote control.
To resume the cleaning cycle, press
the button again.
To send robot back to the charging
dock, press the button.
G. Power off
To end the cleaning cycle and put
your robot in standby mode, press
and hold the button until the
robot‘s indicator light turns off.

9
VG RVC 3001
HOME CLEANING
AUTOMATIC CLEANING
•The robot will start to zigzag using
the built-in gyroscope.
•After cleaning the open areas, the
robot will enter edge cleaning
mode and will clean along walls
and around furniture legs.
•Once the robot finishes its cleaning
cycle, it returns to the charging
dock to recharge.
Note: If its battery gets low (below 20%)
before finishing a cleaning cycle, the
robot automatically returns to the
charging dock.
MOP CLEANING
The robot is equipped with a water tank
that enables the robot to mop floors.
1. Attach the cloth and fill the tank
with water.
2. Remove the dust bin.
3. Place back the water tank and start
the robot.
Tip: you can also use the mopping
function as a dry polishing function.
When finished, empty the water tank,
rinse it with clean water and store it dry
or it may become cloggy and smelly.
Check that the 4 water drainage holes
are not blocked and unblock them if
necessary with a small needle.
SPOT CLEANING
When you select spot cleaning, the
robot cleans a defined area by
spiraling outward about 1 meter in
diameter, and back inward.
When you use this mode, the robot
boosts is vacuum power to provide
the best cleaning possible.
To start place your robot on top of the
spot to clean and press “spot
cleaning” on the remote control.

VG RVC 3001
10
MAXIMUM SUCTION
The robot increases its suction power
to provide a deeper cleaning process
when you press the “max” button on
the remote control. Maximum suction
is off by default. Please be aware that
this extra boost of power will consume
more energy and that the robot will
have to return to the base more often
for charging.
EDGE CLEANING
After the robot finishes cleaning the
open areas of your floor, it uses “edge
cleaning“ mode to clean along walls
and around furniture legs. If you want
it to enter this mode at any point,
press the “edge cleaning” button on
the remote control.
ROOM CLEANING
When a specific room needs to be
cleaned, please press the “room
cleaning” button on the remote
control. The robot will start to zigzag to
clean the open areas, and it will finish
in edge cleaning mode to completely
clean the target room.
Note: the robot will clean and then
stop after 30 minutes in this mode.
Make sure to confine the robot to a
room by closing the door.
RETURN TO CHARGING DOCK
When at any point the robot’s power
drops below 20%, it will enter auto
charge mode. This means that it will
attempt to return to its charging dock.
As the maximum signal range is 6 m,
the robot will use edge cleaning
mode to find the charging dock.
Make sure there are no obstacles
between the robot and the charging
dock.

11
VG RVC 3001
CLEANING SCHEDULE
Your Venga! robot has cleaning schedule settings which allow you to customize when
robot cleans your home. These settings are available only through the remote control.
Note: Please make sure the remote control is located near the robot while setting the clock
or schedule as it has to communicate with the robot.
1. Set the remote control's clock
Press the button on the
remote control, and then
the hour section begins to
flash in the clock display
setting window.
Press the or button to
select the desired figures.
Press the or button to
select the minute or hour
section.
Then press the button.
the robot will "BEEP" when
the clock setting is
completed.
2. Setting a cleaning schedule
Press the button on
the remote control, and
then the hour section
begins to flash in the clock
display setting window.
Press the or button to
select the desired figures.
Press the or button to
select the minute or hour
section.
Then press the button.
The robot will beep when
the clock setting has been
completed.
3. Canceling the cleaning schedule
Press and hold the button for approximately 4 seconds on the remote control, the
robot will beep when the cleaning schedule has been cancelled completely.

VG RVC 3001
12
USE THE BOUNDARY STRIP
The boundary strip serves as a virtual wall and allows you to keep your robot vacuum
cleaner away from any area or item you do not want to clean. The robot vacuum
cleaner will recognize the strips and will not cross into the blocked-off area.
1. Identify the area or item you do not want the robot vacuum to get close to.
2. If necessary, use scissors to cut the strip to a shorter length. Make sure you measure
the length correctly before cutting.
3. Apply the supplied strips of adhesive tape to lay the boundary strip flat on the floor.
Make sure the strip is placed flat on the floor or under an area rug.
WIFI CONFIGURATION
•Download the TUYA APP (suitable for Android and iOS systems) and open it.
•If using the app for the first time, click Sign up to register.
•After successfully registering to the app, log in and click on the “+” icon on the upper
right side to add your device.
•Click Small Home Appliances on the left side then select Robot Vacuum (Wi-Fi).
•Select the right Wi-Fi network, enter your Wi-FI password and then click Next.
•Check the box that is located on the bottom of the screen then click Next.
•Once it has been added successfully, click on your device to enter the interface and
control the robot vacuum cleaner remotely.

13
VG RVC 3001
CARE AND MAINTENANCE
To keep your Venga! robot running at peak performance and be relieable, please perform
the following care procedures. If you notice the robot picking up less dust or debris from
your floor, then please empty the dust bin and clean the filter and the rolling brush.
Cleaning the brushes is important as hair may remain stuck and block it.
Recommended cleaning/replacement frequency:
Cleaning
Replacing
Dust bin
After each use
-
Filters
Once every week
Every 2 months
Rolling brush
Once every week
Every 6-12 months
Side brushes
Once every month
Every 3-6 months(or when visibly
worn)
Brush guard
Once every month
Every 3-6 months(or when the
silicone rubber strip on the brush
guard becomes visibly worn)
Charging pins
Once every month
-
Swivel wheel
Once every month
-
Emptying robot's bin
1. Press bin release button to remove
the bin.
2. Open bin’s hatch to empty it.
Cleaning the robot's filter
1. Remove filter by grasping the white
tab.
2. Shake off debris by tapping the filter
against your trash container.

VG RVC 3001
14
Cleaning robot 's rolling brush,side brush, swivel wheel and sensors.
1. Take out the rolling brush, clean the
vacuuming channel with a cloth.
2. Clean the rolling brush: if any hair or
threads or yarn got stuck, simply cut
them with the help of the cleaning
tool knife that has been provided
with your Venga! robot. Then remove
everything carefully. Only if the
central brush can rotate freely, your
Venga! robot can work to your
satisfaction.
3. Remove the side brush, use a cloth
to remove the dust from the brush.
4. Pull out the swivel wheel, then clean
the swivel wheel with the cleaning
tool.
5. Dust off the cliff sensors to maintain
the best performance.

15
VG RVC 3001
TROUBLESHOOTING –ERROR TONE
Your Venga! robot will tell you when something is wrong with a two-tone distress sound. The
indicator will also blink or light up in red. Refer to the chart below to resolve the robot’s
problem.
For some errors, rebooting the robot may resolve the problem. To reboot the robot, use the
power switch on the underside of the robot. You will hear a sound signal signifying a
successful reboot.
ROBOT BLINKS AND
INDICATES
LIKELY CAUSE
WHAT TO DO
Solid red
indicator
light
BEEP Once
The front wheel is stuck
Clean the front wheel and
press the power button to
restart the robot.
BEEP Twice
Robot's side brush is stuck
Clean the side brush and
press the power button to
restart the robot.
BEEP Three
times
Robot's vacuum fan is
stuck or its filter is
clogged
Remove and empty robot's
bin. Clean the robot's filter.
Then, briskly tap the bin to
loosen any remaining
trapped debris.
BEEP Four
Times
Robot's rolling brush can't
turn
Remove and clean the
robot's rolling brush
and caps.
Breathing
red
indicator
light
BEEP Twice
Bumper is stuck
Check whether the bumper
is flexible.
BEEP Three
times
Robot's cliff sensors are
dirty, it is hanging over a
drop edge, or it is stuck
on a dark surface
If the robot is hanging over
a drop edge, or is placed
on a dark surface, start it in
a new location. Otherwise,
wipe its cliff sensors with a
dry cloth.
BEEP Four
Times
Robot cannot return to its
charging dock or starting
position
Ensure there are no
obstacles in front of the
charging dock or starting
position. Wipe the charging
contacts on both the
charging dock and robot
with a clean, dry cloth.
Note: the cliff sensors prevent the robot from tumbling downstairs and steep drops. They
may work less effectively if dirty or used on reflective/very dark-coloured floors.
Also, the cliff sensors can be triggered by strong sunlight. If light causes the robot to move
in an unusual pattern, please use the curtains to block sunlight from entering the room or
start the robot later, when the sun has gone.

VG RVC 3001
16
FREQUENTLY ASKED QUESTIONS
The robot cannot be
activated.
•Make sure the main power switch is in the ON position.
•Make sure the battery is fully charged.
•Replace the batteries (2 AAA) in the remote control.
•Make sure the remote control is within range (5 m) of the
robot.
•If you still have trouble, turn off the main power switch and
then turn it back on.
The remote control
does not work.
•Replace the batteries in the remote control.
•Make sure the robot is turned on and is fully charged.
RVC 3000 stops
working suddenly.
•Check if the robot is trapped or stuck on an obstacle.
•Check if the battery level is too low.
•If you still have trouble, turn off the main power switch,
wait for 2 seconds, and then turn it back on.
You can’t schedule
cleaning.
•Make sure the main power switch on the bottom of robot
is switched on.
•Make sure the time, time of day (AM/PM), and the
scheduled time have been set correctly.
•Check if robot’s power is too low to start cleaning.
Suction power is
weak.
•Check if any obstructions are blocking the suction inlet.
•Empty the dust bin.
•Clean the filters with a vacuum cleaner or a cleaning
brush.
•Check if the filters are wet due to water or other liquid on
the floor. Air-dry the filters completely before use.
RVC 3000 can’t be
charged.
•Check if the indicator light on the charging dock lights up.
If not, contact the service center to repair or replace the
charging dock.
•Dust off the charging contact pins with a dry cloth.
•Check if you can hear a beep when robot returns to the
charging dock. If not, contact the service center to repair
or replace the charging dock.
Robot can’t return to
the charging dock.
•Remove objects within 1 m to the left and right side and
within 2 m of the front of the charging base.
•When robot is in the vicinity of the charging dock, it will
return more quickly. However, if the charging dock is
located far away, robot will need more time to return.
Please be patient as it works its way back.
•Clean the charging contact pins.
The rolling brush
doesn’t rotate.
•Clean the rolling brush.
•Check if the rolling brush and brush guard have been
installed properly.
Robot movements or
travel path are
abnormal.
•Clean the sensors carefully with a dry cloth.
•Restart robot by turning the power switch off and on.

17
VG RVC 3001
PROTECTION OF THE ENVIRONMENT –DIRECTIVE 2012/19/EU
In order to preserve our environment and protect human health, the waste electrical and
electronic equipment should be disposed of in accordance with specific rules with the
implication of both suppliers and users. For this reason, as indicated by the symbol on
the rating label or on the packaging, your appliance should not be disposed of as unsorted
municipal waste. The user has the right to bring it to a municipal collection point performing
waste recovery by means of reuse, recycling or use for other applications in accordance
with the directive.
ERP DECLARATION –REGULATION 1275/2008/EC
We, TKG SRL, hereby confirm that our product meets the requirements of regulation
1275/2008/EC. Admittedly, our product does not dispose of a function to minimize the
power consumption, which should according to regulation 1275/2008/EC put the product
in off or standby mode after finishing the main function, but this is practically impossible, as
it would compromise the main function of the product so strongly, that using the product
would no longer be possible!
For this reason we always tell the customer in our instruction manual to unplug the
appliance immediately after use.
The user manual is by simple request also available in electronic format from the after-
sales service (see warranty card).

VG RVC 3001
18
DEUTSCH
WICHTIGE SICHERHEITSVORSCHRIFTEN
Lesen Sie aufmerksam die Gebrauchsanleitung, bevor Sie Ihr
Gerät benutzen, und befolgen Sie immer die
Sicherheitsvorschriften und die Gebrauchsanweisung.
Wichtig: Das Gerät kann von Kindern ab 8 Jahren und von
Personen mit einer körperlichen, sensorischen, geistigen oder
motorischen Behinderung oder einem Mangel an Erfahrung und
Kenntnissen verwendet werden, sofern diese Personen
beaufsichtigt oder über den sicheren Gebrauch des Geräts
unterrichtet wurden und die damit verbundenen Gefahren
verstanden haben. Kinder dürfen nicht mit dem Gerät spielen.
Reinigung und Benutzer-Wartung dürfen nicht durch Kinder
durchgeführt werden, es sei denn, sie sind älter als 8 Jahre und
beaufsichtigt. Lassen Sie Ihr Gerät und sein Netzkabel nie
unbeaufsichtigt und in Reichweite von Kindern jünger als 8 Jahre
oder unverantwortlichen Personen, wenn es an der Steckdose
hängt oder wenn es abkühlt.
❑Kontrollieren Sie, ob die Netzspannung mit der auf dem
Ladegerät vermerkten Spannung übereinstimmt, bevorSie das
Gerät benutzen.
❑Überprüfen Sie regelmäßig, ob das Gerät nicht beschädigt ist.
Bei Beschädigung, lassen Sie es von einem Fachmann (*)
überprüfen. Wenn die Anschlussleitung des Adapters
beschädigt ist, kann diese nicht repariert werden, sondern
muss der ganze Adapter von einem Fachmann (*) durch einen
identischen oder baugleichen Adapter ausgewechselt werden.
Vergewissern Sie sich, dass alle Eigenschaften des neuen
Adapters denen des alten Adapters entsprechen.
❑Benutzen Sie das Gerät nur zu Haushaltszwecken, wie in der
Bedienungsanleitung angegeben.
DE

19
VG RVC 3001
❑Tauchen Sie das Gerät niemals in Wasser oder andere
Flüssigkeiten, weder zum Reinigen, noch zu einem anderen
Zweck (siehe Abschnitt "Reinigung und Pflege").
❑Benutzen Sie das Gerät nicht in der Nähe einer Wärmequelle.
❑Ziehen Sie den Stecker aus der Steckdose, bevor Sie die
Ladestation reinigen. Benutzen Sie das Gerät mit dem Adapter
nicht im Freien. Bewahren Sie es an einem trockenen Platz
auf.
❑Benutzen Sie nur Zubehör, welches vom Lieferanten
empfohlen wurde, und einen geeigneten Adapter (siehe
Abschnitt "Eigenschaften des Adapters"). Anderes Zubehör
stellt eine Gefahr für den Benutzer dar und das Gerät könnte
dadurch beschädigt werden.
❑Ziehen Sie niemals an der Anschlussleitung, um das Gerät zu
bewegen. Verwenden Sie die Anschlussleitung auch nicht um
das Gerät aufzuhängen. Achten Sie darauf, dass die
Anschlussleitung nicht zufälligerweise irgendwo hängen bleibt
und dies zum Fall des Gerätes führen könnte. Wickeln Sie die
Anschlussleitung nicht um das Gerät herum und knicken Sie
sie nicht.
❑Benutzen Sie Ihr Gerät nicht um Streichhölzer, spitze
Gegenstände, Zigaretten, Zigarettenstummel oder andere
brennbare Gegenstände aufzusaugen.
❑Dieses Gerät eignet sich für die Reinigung von Holzfußböden,
Gummi-Fußböden, Keramikfliesen und Kurzhaarteppich im
Hause, aber nicht für die Reinigung von Plüschteppich.
❑Benutzen Sie das Gerät nicht auf Treppen.
❑Benutzen Sie das Gerät nicht in explosionsgefährdeter
Umgebung, wie zum Beispiel in der Nähe von Tankstellen,
Öldepots, Chemiewerken und anderen leicht entzündlichen
oder explosionsfähigen Stoffen.
❑Benutzen Sie das Gerät nicht um brennbare oder schnell
verdampfende Flüssigkeiten, wie zum Beispiel Benzin,
Petroleum, Lack, Reinigungsmittel, Alkohol, Parfüm,
Fußbodenreiniger usw. zu entfernen.
❑Stehen oder sitzen Sie nicht auf dem Gerät.
