Vent-Axia SDX100B Assembly instructions

PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH THE ILLUSTRATIONS.
PLEASE SAVE THESE INSTRUCTIONS
SDX
In-Line Centrifugal Duct Fans
Stock Ref. N°
SDX100B
SDX125B
SDX150B
SDX200B
SDX250B
SDX315B
SDX150HB
SDX200HB
SDX250HB
SDX315HB
Installation and Wiring Instructions
220-240V~50Hz

2
Installation and Wiring Instructions for the SDX IN-LINE CENTRIFUGAL DUCT FAN range.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE COMMENCING THE INSTALLATION
DO NOT install this product in areas where the following may be present or occur:
•Excessive oil or a grease laden atmosphere.
•Corrosive or flammable gases, liquids or vapours.
• Ambient temperatures higher than 40°C or less than –5°C.
• Possible obstructions which would hinder the access or removal of the Fan.
•Sudden ductwork bends or transformations close to the Fan.
SAFETY AND GUIDANCE NOTES
A. All wiring to be in accordance with the current I.E.E. Regulations, or the appropriate standards of your country and MUST be
installed by a suitably qualified person.
B. The Fan should be provided with a local double pole isolator switch having a contact separation of at least 3mm.
C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label.
D. The Fan should only be used in conjunction with the appropriate Vent-Axia products.
E. It is recommended that the connection to the fan connecter terminals is made with flexible cable.
F. When the Fan is used to remove air from a room containing a fuel-burning appliance, precautions must be taken to avoid
back-flow of gases into the room from the open flue of gas or other appliance. Ensure that the air replacement is adequate
for both the fan and the fuel-burning appliance.
G. The Fan should not be used where it is liable to be subject to direct water spray for prolonged periods of time.
H. Where ducted Fans are used to handle moisture-laden air, a condensation trap should be fitted. Horizontal ducts should be
arranged to slope slightly downwards away from the Fan.
I. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
J. Young children should be supervised to ensure that they do not play with the appliance.
K. Note:- This is a class 1 appliance and MUST be earthed.
A. INSTALLATION.
The unit is designed as an in-line duct fan to be positioned between lengths of ducting. Short duct runs terminating close to the
fan (i.e. within 1.5m) must incorporate suitable guards unless the fan is mounted higher than 2.1m above the floor. If flexible
ducting is used it should be fully extended to obtain the best results. Position the fan at the highest point on the system with both
ducting runs sloping downwards from this point. In circumstances where an excessive amount of moisture is present in the air
then a condensation trap should be installed. When siting the appliance ensure that there is sufficient space to allow access for
any servicing and maintenance.
Attaching the mounting feet
Select the image that relates to your fan.
For horizontal mounting
For horizontal mounting For Vertical mounting
For Vertical mounting

3
B. WIRING.
WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM
THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE.
THE SDX FANS ARE CLASS 1 AND MUST BE EARTHED.
1. Remove terminal box cover & screws and put to one side.
2. Select and follow the wiring diagrams.
3. Check all connections have been made correctly and ensure all terminal connections and cable clamps/gland
are securely fastened.
4. The cable entry must be made using the cable gland provided.
5. Replace terminal box cover & screws.
6. Ensure the impeller rotates and is free from obstructions
C. OVER-HEATING PROTECTION.
The fan motor is fitted with Thermal Overload Protection. This will automatically switch the fan off in the event of a
fault condition. If this occurs isolate the fan, check for and remove any obstruction, leave for a short time for the
motor to cool before reconnecting. If this recurs, Isolate and call your service engineer.
D. SERVICING AND MAINTENANCE.
WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED
FROM THE POWER SUPPLY DURING MAINTENANCE.
1. At intervals appropriate to the installation, the fan should be inspected and cleaned to ensure there is no build
up of dirt or other deposits.
The SDX fans have sealed for life bearings, which do not require lubrication.
230 Volt D.O.L. Starter
A suitable sized overload
relay must be fitted to
provide motor protection.
42
N.B. Links between
terminals 1 to A1 & 3 to 6,
must be fitted.
6
135
2395
96 24
A1
A2
E
N~ E L
1 Phase Supply
(220-240V 50 Hz).
N
E
FAN TERMINALS
L
E
N~
EL
1 Phase Supply
(220-240V 50 Hz).
N
E
FAN TERMINALS
L
LN
Switched spur
unit

4
