Vent-Axia Sentinel Operating instructions

Copyright © 2009 Vent-Axia Limited. All rights reserved.
Sentinel
Kinetic MVHR &
Cooker Hood
User, Installation, Commissioning &
Servicin
g
Instructions
Stock Ref. N°
441483 Kinetic CWL
441484 Kinetic CSL
441485 Kinetic CWR
441486 Kinetic CSR
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.
Read in conjunction with Sentinel Kinetic MVHR Installation &
Commissioning and Operation & Monitoring Documents

Safety Information
2 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
IMPORTANT
PLEASE READ THESE INSTRUCTIONS
CAREFULLY BEFORE COMMENCING
INSTALLATION.
1. READ THE SAFETY INSTRUCTIONS ON PAGE 2 OF
THE SENTINEL KINETIC MVHR INSTALLATION &
COMMISSIONING AND OPERATION & MONITORING
DOCUMENTS
2. IF THE EXTRACTOR HOOD IS INSTALLED IN A ROOM
CONTAINING A FUEL-BURNING APPLIANCE, THE
INSTALLER MUST ENSURE THAT AIR REPLACEMENT
IS ADEQUATE FOR BOTH THE EXTRACTOR HOOD FAN
AND THE FUEL-BURNING APPLIANCE.
3. DO NOT CONNECT THE EXTRACTOR HOOD DUCTING
TO CHIMNEYS, FLUES OR AIR DUCTS SERVING THE
ROOM.
4. DO NOT SITE WHERE AMBIENT TEMPERATURES ARE
LIKELY TO EXCEED 50ºC. DO NOT DO ANY FLAMBÉ
COOKING UNDERNEATH THE HOOD. WHEN FRYING,
NEVER LEAVE THE PAN UNATTENDED IN CASE OF
FIRE. THIS APPLIANCE IS NOT SUITABLE FOR USE
ABOVE AN EYE LEVEL GRILL.
5. WARNING: FAILURE TO COMPLY WITH THE
CLEANING INSTRUCTIONS MAY RESULT IN A RISK OF
FIRE. THE APPLIANCE EFFICIENCY DEPENDS ON THE
CONDITION OF THE FILTERS.
6. All regulations and requirements MUST be strictly
followed to prevent hazards to life and property both
during and after installation, and during any
subsequent servicing and maintenance.
Disposal
This product should not be disposed of with household
waste. Please recycle where facilities exist. Check with
your local authority for recycling advice.

About this Document
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 3
Contents
Product Description 4
Sentinel Kinetic MVHR with Cooker Hood .....................................4
User Information.............................................................................5
Technical Specification 6
Sentinel Kinetic with Cooker Hood Technical Specification...........6
Installation 10
Overview ......................................................................................10
Before Installing the Unit..............................................................10
Unit Installation.............................................................................10
Fitting the Cooker Hood to the Metal Duct Unit............................11
Attach Ducting..............................................................................14
Electrical Installation.....................................................................14
Commissioning.............................................................................14
Maintenance.................................................................................15
Caring for the Unit........................................................................15
Cooker Hood Cleaning Interval....................................................15
Removing Filters. .........................................................................15
Spares..........................................................................................16
Troubleshooting............................................................................16
Appendix A: Options and Accessories 17
CO2 / Temperature Sensor………………………………..17
Normal / Boost switch……………………………………....17
Humidistat …………………………………………………...17
Wireless Boost Switch……………………………………...17
UK Building Regulations (Part F)
Declaration of Conformance
The Sentinel Kinetic conforms to the 2010 Building
Regulations (Part F - Means of Ventilation requirements)
for installed performance of a ducted mechanical extract
fan when installed in accordance with the instructions in
this document.

Product Description
4 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Product Description
Sentinel Kinetic MVHR with Cooker Hood
The Vent-Axia Sentinel Kinetic Mechanical Ventilation Heat Recovery (MVHR) unit is a heat recovery unit
with a Cooker Hood designed for the energy efficient ventilation of houses and similar dwellings, conforming to
the latest requirements of the Building Regulations document F 2010.
In case of a fire or severe overheating on the hob, the unit is fitted with an intumescent fire damper to close the
duct as required by BRE Digest 398 and a thermal fuse to switch off the electrical power.
The unit is designed to be mounted in the kitchen above a cooker hob in a standard cupboard space for
continuous 24-hour exhaust ventilation of stale moist air from bathrooms, toilets and kitchens. The unit should
be switched to boost mode by extending the cooker hood during cooking, or by use of any of the standard
switches or sensors. As the stale air is extracted, a heat exchanger within the unit retains up to 90% of the heat
and transfers it to the supply air entering the bedrooms and lounge.
Figure 1: Sentinel Kinetic with cooker hood (Right Hand version shown)

Product Description
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 5
Models
441483, 441484, 441485, 441486 - Sentinel Kinetic with Cooker Hood and with summer bypass. An
internal damper is activated when the outside temperature is equal to, or greater than, the pre-set ‘Comfort
Temperature’ (adjustable between 16 and 30°C). The damper opens allowing cooler fresh air to bypass
the Heat Recovery Cell and reduce the internal temperature to the pre-set ‘Comfort Temperature’. When
the inside air temperature reaches the pre set ‘Comfort Temperature’ the bypass damper closes. (See
page 10 within the Operation & Monitoring leaflet for further information). Note that when the cooker hood
is extended the heat recovery cell bypass opens ensuring that grease and other contaminants from
cooking do not reduce its efficiency during normal use.
Accessories
441838 - Plug-in integral humidity sensor.
441865 - Wireless enable kit (consists of wireless receiver and one wireless switch).
437827 - Additional wireless switch (up to four may be connected).
441780 - Vent-wise accessory pack.
443131 – Wired remote control.
A range of sensors can be used to manage system demand and control the ventilation rate. These include an
internal humidity sensor, humidity sensors for independent mounting in rooms, wireless receiver and wireless
boost switches, CO2sensor, manual switches and pull cords. For these alternative control options, see
www.vent-axia.com
User Information
Operation of Cooker Hood
The unit is operated in boost mode when the telescopic hood is pulled out. Close it to return the unit to its
Normal Flow Rate.
Important Note:
Do not hold on to or place any object on telescopic hood whilst is open, since this can cause damage to its
functioning component parts
Operation of Cooker Hood Light
Access can be gained to the light switch when the telescopic hood is opened. The light may be left on with the
hood closed if required. However, make sure you switch it off when you have finished using it.
Cleaning Instruction
Refer to page 15 of this document.

Technical Specification
6 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Technical Specification
Sentinel Kinetic with Cooker Hood Technical Specification
Performance
Airflow Refer to Sentinel Kinetic Installation & Commissioning Document page 5
Flow for cooker hood adjustable using the integral damper.
Sound levels (@ 3 m) 20 dB(A) (normal), 36 dB(A) (boost). Detailed sound spectra available from Vent-Axia.
Power
AC Voltage Input 220-240 V AC (single phase)
AC Frequency Input 50 Hz nominal
Supply Fuse 3 A (located in fused spur)
Product Fuse 2 A (located on main PCB)
Rated Power Total 176 W (max.) including (2x28W cooker hood low energy bulbs)
Physical
Weight 28 kg
Spigot diameter 125 mm
Condensate pipe diameter 22 mm
Environmental
IP Rating IP22
Operating Temperature -10C to +45C
Air Intake Temperature As above
Operating Humidity 0% to 95% RH
Storage Temperature -10C to +45C
Storage Humidity 0% to 95% RH
For all other technical details, please see the Product Catalogue or our website at www.vent-axia.com

Technical Specification
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 7
Figure 2: Sentinel Kinetic with Cooker Hood Dimensions

8 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Figure 3: Sentinel Kinetic with RIGHT HAND Cooker Hood Dimensions

Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 9
Figure 4: Sentinel Kinetic with LEFT HAND Cooker Hood Dimensions

Installation
10 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Installation
Overview
The following instructions are intended to help prevent potential hazards and should be carried out only by a
qualified electrician and installer.
Before Installing the Unit
Inspect the Unit
When taking delivery of the unit, check the items delivered against the delivery note. Inspect the unit for
damage in transit. If in doubt, contact Customer Services. The Sentinel Kinetic with cooker hood is made up of
two separate boxes. Each box containing the Sentinel Kinetic HR with metal duct assembly should come with
an accessory pack containing wall brackets, condensate drain link pipes, worm-drive clips, fixings and product
documentation. Each box containing the cooker hood should contain an accessory pack consisting of black
protective box for cooker hood socket and plug connection, screws, cable receptors and product documentation.
A template to aid marking out the wall for drilling is printed on the carton.
Lift and Move the Unit Safely
The weight of this unit is 28 kg. Always use appropriate lifting techniques and appliances when moving heavy
equipment.
Check Site Requirements and Safety Notices
Check that the physical and environmental conditions for the site meet, or exceed, the requirements detailed in
the Technical Specification on page 6.
Read and observe the safety notices listed in IMPORTANT on page 2.
Unit Installation
READ THE SENTINEL KINETIC INSTALLATION & COMMISSIOING DOCUMENT BEFORE INSTALLING
THIS UNIT. In particular, ensure that any external switches, sensors and electrical connections are made prior
to the unit being mounted on the wall.
The Sentinel Kinetic Cooker Hood is only suitable for installation above a domestic cooker or cooker hob. The
unit with cooker hood must be sited a minimum of 650mm above an electric hob and 750mm above a
gas hob.
It will fit in a 600 mm (external) x 300 mm deep (internal) kitchen wall cupboard space above the hob.
The wall should have sufficient strength to support the unit.
Take into consideration the position of the electrical services and the condensate drain.
Ensure there is adequate access for installation, operation and maintenance.
It is recommended that a local mains and sensor terminal connection box is installed within 1m of the unit to
facilitate future maintenance, rather than wiring these directly to the unit.
The unit MUST always be mounted vertically with ducting exiting vertically. Do not use this unit as a support for
any other equipment.
Select Unit Orientation
The unit may be purchased as left or right hand, where left hand refers to the connections to atmosphere being
on the left side of the unit.

Installation
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 11
Condensate Horizontal Discharge Installation
To install the condensate horizontal outlet refer to Sentinel Kinetic Installation & Commissioning document page 11.
Spigot Installation
See Sentinel Kinetic Installation & Commissioning document page 13. Note, only vertical spigots can be used on this
product.
Fitting the Cooker Hood to the Metal Duct
Unit
1. Before fitting the unit to the wall, unpack the
cooker hood, locate the four self-cutting screws
and protective box for the cooker hood cable plug
and socket.
2. Pull out the telescopic hood and remove the two
metal filters by releasing the grey plastic springs
and sliding. (fig. 5)
3. Before fixing the cooker hood to the bottom of the
metal duct, take off the “L” shaped duct front
cover by removing three screws.
Fitting Cooker Hood to Right Hand Unit
Before fitting the cooker hood, you should
identify whether the installed unit is Left
Hand or Right Hand, see page 8.
If the unit is Left Hand, then follow
instructions on page13
1. Rest the unit on its back ready to connect the
cooker hood to the bottom of metal ducting.
2. First lead the cooker hood cable through the
hole at the bottom of the metal duct adaptor
(fig. 6). Then align the cooker hood by choosing
adjustable hole positions to suit, then fit it to the
metal duct unit using four screws provided.
3. Carefully lead the cooker hood cable and plug
into the metal duct and connect it with the cable
with the socket ensuring that the locating lugs
align. It is important that the cable is routed
away from the fire damper.
4. Place the assembled socket and plug in the
protective box provided shown (fig. 7). Ensure
the grommet is lined up with the rib and tuck in
cable assembly shown by arrow before putting
the cover together. Put the boxes together and
secure using the screws provided.
Figure 5: Telescopic extractor hood
Figure 6: Inserting with plug through the hole
Figure 7: Telescopic extractor hood

Installation
12 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
5. Replace the “L” shaped duct front cover and
tighten the three screws
Wall Mounting
6. A wall mounting template can be obtained from
Vent Axia technical support or refer to pages 8
& 9 for dimensions.
7. If you are in receipt of wall mounting template,
fix the template to the wall and ensure that it is
level.
8. Mark the position of the condensate outlet and
the four upper and four lower fixing holes.
9. See page 8 & 9. To install the condensate
outlet refer to Sentinel Kinetic Installation &
Commissioning document page 11.
10. Drill and plug the wall at the fixing points.
11. Locate the bottom supporting bracket provided
then use four screws to fix to the wall. Ensure
the angled flange is pointing towards you.
12. The upper four screws should now be fitted
ready for keyhole fixing slots to engage. Leave
6 – 10 mm protruding.
13. Lift the unit and offer it to the upper screws
sliding downwards, making sure that the lower
part of the back plate of the unit fits into the
lower supporting bracket.
14. Complete the fixing of the condensate drain as
shown on page 11 of the Sentinel Kinetic
manual.
15. Fix hanging brackets supplied to the front door
panel, then offer it to the pre-fitted bushes.
Spacers may be used to pack out the bushes to
maintain the line of the cupboard doors.

Installation
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 13
Fitting Cooker Hood to Left Hand Unit
1. Remove the cooker hood light cover using
cross type screwdriver.
2. After removing the light cover, turn the cooker
hood to its opposite face. Unscrew the cable
clip from inside, then insert the cable with its
connector (fig. 8) through aperture gently by
pulling it to your right as far as it will extend.
3. Feed the cable with its plug through the
aperture on the right hand side (fig. 9).
4. Turn the cooker hood to its opposite face, pull
the cable through as far as it extends. Use the
existing cable clip and its screw to secure the
cables to the hood as shown (fig. 10).
5. Now the cooker hood is ready to fit to the
metal duct unit.
6. Go to instructions for Fitting Cooker Hood to
Right Hand Unit, items 1-15 on pages 9 and
10.
Figure 8: Passing cable through
Figure 9: Insert cable opposite direction
Figure 6: Using cable clip to secure the cable

Installation
14 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Attach Ducting
See the Sentinel Kinetic Installation & Commissioning document.
Electrical Installation
See the Sentinel Kinetic Installation & Commissioning document.
Commissioning
See the Sentinel Kinetic Installation & Commissioning document.
Setting the Cooker Hood Flow
Adjust the damper to give the correct flow as determined by the system designer.
Airflow

Installation
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 15
Maintenance
Caring for the Unit
Heat recovery units, by their very nature, require regular maintenance. The Sentinel Kinetic has been designed
to facilitate access to enable maintenance to be carried out easily.
WARNING
THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY
DURING MAINTENANCE.
Cooker Hood Cleaning Interval
For MVHR unit maintenance, refer to Sentinel Kinetic Installation & Commissioning and Operation & Monitoring
documents.
Item Action
Cooker Hood Filters Clean Filters every six months or more frequently if the style of cooking requires it. For
instruction how to remove filters see below.
Cooker Hood Adaptor Switch off the unit at the wall isolator before cleaning any component. Remove cover and
wipe the interior clean every six months or more frequently if the style of cooking requires it.
After cleaning ensure that the cover is replaced correctly and screws tightened. Do not use
water or spray cleaning agents for cleaning the space, however a damp or dry cloth may be
used.
Removing Filters.
a) Rear Filter – To remove the rear filter grip and pull inwards the grey levers at either side and slide the
filter forwards and downwards.
b) Front Filter – To remove the front filter grip and pull inwards the grey levers at either side and drop
the filters downwards.
c) The filters can be washed in a dishwasher or soapy water. Thoroughly dry the filters and reassemble
in reverse order.

Installation
16 Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning
Spares
The following spares may be ordered from Vent-Axia:
Table 1: Spares
Part No Description
441768 Main Power Board
441767 Control Panel
441774 Filters, 2-pack (bypass version 438222)
441764 Heat Recovery Cell (bypass version 438222)
441759 Supply Motor
441760 Exhaust Motor
441776 Summer Bypass
456510 Thermal Cut-out Fuse
441542 Low Energy Bulb
372777 Light Cover
372743 Cooker hood filters (set of two)
Troubleshooting
See the Sentinel Kinetic installation & commissioning documentation.

Appendix A: Options and Accessories
Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning 17
Appendix A: Options and Accessories
Humidistats
An optional internal humidistat is available as an accessory. (Part Number 441838). This adjusts the fan speed
proportionally depending on the temperature and relative humidity levels in the extracted air whilst avoiding
nuisance tripping at night time when temperatures drop and relative humidity naturally rises. The unit does not
just look for relative humidity levels above a set point, which can be unreliable in products that extract from
multiple rooms, but it also looks for a rapid increase in relative humidity typically generated by such activities as
showering or cooking.
For further details on options and accessories, refer to Sentinel Kinetic installation & commissioning
documentation.

Head Office: Fleming Way, Crawley, West Sussex, RH10 9YX.
UK NATIONAL CALL CENTRE, Newton Road, Crawley, West Sussex, RH10 9JA
SALES ENQUIRIES: Tel: [phone] Fax: [phone]
TECHNICAL SUPPORT Tel: [phone] Fax: [phone]
For details of the warranty and returns procedure please refer to www.vent-axia or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX
442876G © 2013 Vent-Axia Limited. All rights reserved. 0713
