Ventev M6025040O3D302MW User manual

www.terrawave.com [email protected] 1-800-851-4965
2.4/5 GHz Micro Omni Antenna with 2.5/4 dBi Gain
and 3 RPTNC leads
The TerraWave Dual Band Micro Omni Antenna is optimized for small form factor/aesthetic and mobile Wi-Fi
applications. This aesthetically-pleasing antenna includes three dual-band Wi-Fi pigtails and RPTNC
connectors. The antenna is an ideal partner for three connector dual-band Wi-Fi Access Points where low
profile and/or aesthetics is a major deployment consideration. This multi-use antenna can also be used in
vehicles for communications, location tracking, and fleet management.
Every TerraWave antenna is covered by
the company’s two-year TerraNet warranty program. For more information, contact a regional sales executive
at 210-375-8482, 800-851-4965 or [email protected], or visit www.terrawave.com.
Specifications
Model M6025040O3D302MW
Frequency Range 2400-2500 MHz 4900 - 5850 MHz
Gain 2.5 dBi 4 dBi
Impedance 50 ohms
Polarization Vertical
Power 50 watts
Size 3.54” x 1.57”
Weight 4.4 oz
Connector RPTNC male
Port number 3
Bandwidth 100 MHz
950 MHz
VSWR ≤2 ≤2
Mounting Method Surface Mount

www.terrawave.com [email protected] 1-800-851-4965
2.4/5 GHz Micro Omni Antenna with 2.5/4 dBi Gain
and 3 RPTNC leads
Installation
Outdoor Flat Surface Installation
Indoor Ceiling Mount Installation
Note: The TerraWave SKU 509824 provides an L-Bracket mounting alternative
for mast or wall mounting (sold separately)
Antenna
Flat Surface
Diameter 12 mm
M12*1 Nut
Connectors
Antenna
Ceiling
Diameter 12 mm
M12*1 Nut
Connectors

www.terrawave.com [email protected] 1-800-851-4965
2.4/5 GHz Micro Omni Antenna with 2.5/4 dBi Gain
and 3 RPTNC leads
Port 1: 2450MHz
H Plane E Plane
Radiation Patterns
Port 1: 5500MHz
H Plane E
Port 2: 2450MHz
H Plane E

www.terrawave.com [email protected] 1-800-851-4965
2.4/5 GHz Micro Omni Antenna with 2.5/4 dBi Gain
and 3 RPTNC leads
H Plane E Plane
Port 2: 5500MHz
H Plane E Plane
Port 3: 2450MHz
Port 3: 5500MHz
H Plane E Plane
