Ventev M6060060P1D43602V User manual

www.ventev.com/infra [e-mail] 800.851.4965
Ventev’s 802.11n/ac antennas are designed to operate
with any manufacturer’s enterprise-class APs. This 2.4/5
GHz 6 dBi directional antenna features four dual-band
antennas in a single unit, where each pigtail is 2.4 and 5
GHz. This solution allows engineers to simplify
deployments by using only one antenna for dual band
access points.
Every Ventev antenna is RoHS compliant and is covered
by Ventev’s two-year TerraNet warranty program.
For more information or to purchase, contact Ventev:
800.851.4965 or [email protected].
2.4/5GHz 6dBi Wi-Fi Directional Antenna
with 4 RPTNC Male Connectors
SPECIFICATIONS RADIATION PATTERNS
SKU: 503910
Model Number: M6060060P1D43602V
Frequency Range: 2400-2500 MHz I 5150 –5850 MHz
Gain: 6 dBi
Bandwidth: 100 MHz-700 MHz
Polarization: Vertical
Horizontal beamwidth: 105°/125°
Vertical beamwidth: 60°/70°
VSWR: ≤ 2.0
Isolation: ≥20 dBi
Nominal Impedance: 50 Ohms
Maximum Input Power: 20W
Connector: 4 RPTNC Male
Cable Length: 36”
Dimensions: 10.0” x 5.6” x 1.4”
Antenna Weight: 1.2 lbs
Randome Material and Color: UV ABS, White
Operating Temperature (F°): -40°~ +158°
Wind Load 60 mph
5 GHz
2.4 GHz
H Plane E Plane
H Plane E Plane

www.ventev.com/infra [e-mail] 800.851.4965
2.4/5GHz 6dBi Wi-Fi Directional Antenna
with 4 RPTNC Connectors
Mounting Bracket Information
Installation Instructions:
•Place the bracket on the back of the panel antenna. Attach the antenna to the mast.
•Use the client to test and adjust the receive signal strength (RSSI) and adjust the azimuth and elevation to
maximize the RSSI. Tighten each nut and seal the antenna connector.
