Ventev Terrawave User manual

www.ventevinfra.com [email protected] 800.851.4965
Ventev’s 2.4/5 GHz 6 dBi Quad Patch Ceiling Mounted
Antenna is ideal for high density venues such as lecture halls,
auditoriums and convention centers. With dual-band leads,
each cable supports both 2.4 and 5 GHz to support demanding
indoor applications in 802.11n, 802.11ac and Wi-Fi 6 wireless
communication systems. It features four cables with RPTNC
plugs exiting from the back of the antenna and a low-profile
design.
Every Ventev antenna is covered by the company’s two-year
TerraNet warranty program.
For more information or to purchase, contact Ventev:
800.851.4965 or [email protected].
RADIATION PATTERNS
Terrawave by Ventev
2.4/5 GHz 6 dBi Wi-Fi Quad Patch Ceiling Mounted
Antenna with 4 RPTNC Male Connectors
Specifications
SKU 280856
Model Number M6060060P23602NBC
Frequency Range 2.4/2.5 GHz
Gain 6 dBi
Vertical Beamwidth: 55° ± 10°/35° ± 10°
Horizontal Beamwidth: 55° ± 10°/ 35° ± 10°
Polarization: Vertical
VSWR ≤ 2/ ≤ 2.5
Maximum Input Power 20 Watts
# of Ports 4
Connector Type RPTNC Male
Cable Length 36”
Dimensions 10.3 x 10.3 x 1.4”
Weight 4.1 lb
Mounting Method(s) Ceiling Mounting

www.ventev.com/infra [email protected] 800.851.4965
2.4/5 GHz 6 dBi Wi-Fi Quad Patch Ceiling Mounted
Antenna with 4 RPTNC Male Connectors
Mounting Instructions
Figure 1
Figure 2
Figure 2 close up
Figure 3
Drill 1” hole in ceiling tile (See Figure 1).
2. Pull leads through drilled hole and ensure antenna
is flush against ceiling tile (See Figure 2).
3. Tighten screw mount until antenna is securely
fastened (See Figure 3).
4.Insert ceiling tile into grid.
