Ventev Terrawave User manual

www.ventev.com/infra [email protected] 800.851.4965
Ventev’s 2.4/5 GHz 6 dBi High Density Multiple-Input and
Multiple-Output (MIMO) Directional Wi-Fi Antenna is
designed to operate with any manufacturer's latest 802.11ac
Waves I & II WLAN access points. The antenna's gain and
directional beam delivers on the modern user demand for
high-capacity connectivity. Four dual-band leads ensure
exceptional performance while simplifying connection to the
access point. An articulating mount enables the antenna to
be positioned precisely where coverage is needed and
comes with mounting hardware to support mast and/or wall
mounting.
Every Ventev antenna is RoHS compliant and covered by
Ventev’s two-year TerraNet warranty program.
For more information or to purchase, contact Ventev:
800.851.4965 or [e-mail].
2.4/5 GHz 6 dBi Wi-Fi Directional Antenna with 4 RPSMA
Male Connectors
SPECIFICATIONS RADIATION PATTERNS
SKU: 274556
Model Number: M6060060P1D43602C
Frequency Range: 2.4/5 GHz
Gain: 6 dBi
Vertical Beamwidth: 60°/70°
Polarization: Vertical
VSWR: ≤2.0
Isolation: ≥20dB
Maximum Input Power: 20W
# of Ports: 4
Connector Type: RPSMA Male
Antenna Cable: 36”
Dimensions: 10 x 5.6 x 1.4”
Weight: 1.2 lbs.
Operating Temperature: -40°F to 158°F
Wind Rating: 60 mph
Terrawave by Ventev

www.ventev.com/infra [email protected] 800.851.4965
2.4/5 GHz 6 dBi Wi-Fi Directional Antenna with 4 RPSMA
Male Connectors
Mounting Bracket Information
Installation Instructions:
1. Place the bracket on the back of the panel antenna. Attach the antenna to the mast.
2. Use the client to test and adjust the receive signal strength (RSSI) and adjust the azimuth and
elevation to maximize the RSSI. Tighten each nut and seal the antenna connector.
