Ventrac 4000 series User manual

GET IT DONE!
GETATTACHED
TRACTORS AND ATTACHMENTS

THE VENTRAC STORY
HERITAGE
A Word from the President
We at Venture Products, Inc. appreciate your interest in VENTRAC products. We
know that our company’s achievements hinge on your satisfaction; your business
is what makes our continuous efforts possible, and we thank you.
My father instilled valuable lessons in my brothers and me from our youth,
lessons that set the foundation for the high ethics, standards and quality for which
VENTRAC has become known.
VENTRAC all-wheel drive articulating tractors, attachments and specialty equipment are one of a kind.
Nowhere will you find a product made with higher quality materials, designed with more maneuverability,
flexibility and durability, or backed by a more solid commitment to your satisfaction.
The Steiner family continues to add fresh new ideas and skills as the next generation grows into the
business. We invite you, as well, to become part of our team by discovering how VENTRAC can give you
the versatility to accomplish any job. The VENTRAC team is very proud of their products, and guarantee
that you will be delighted with them as well.
Sincerely,
Dallas Steiner
President
1974 First Compact, Articulating
Tractor
1941 Marvin Steiner, age 26, builds
custom farm equipment.
1978 Model S-16 Tractor
1996 Venture Products introduces the
Freedom 300, a transporter for the
physically disabled.
1998 The Ventrac 4000 series tractor
is introduced.
TODAY The Steiner family continues designing and manufacturing
new and innovative products.
Back: Brothers Dallas, Mark, and Roy Steiner
Front: Cousins Arlin, Ryan, Denver, and Beth Steiner
1999 The Ventrac 3000 series tractor
is introduced.
THE VENTRAC ADVANTAGE
FEATURES
2007 The Ventrac 7000 series tractor
is introduced.
More than 30 commercial-grade attachments comprise the Ventrac MINUTE MOUNT
attachment system. Minute Mount is QUICK, EFFICIENT, and requires NO TOOLS.
With the optional Category One 3-point hitch, non-powered attachments can be operated from
behind the tractor individually or simultaneously with the front.
Versatility
Innovative by Design
Ventrac is innovative in design and extremely practical. Add any of the 30 plus commercial-
grade attachments and you’ll be impressed with the POWER, PERFORMANCE, and
PRODUCTIVITY that can’t be beat. With little or no effort you’ll have all your projects
done. Ventrac will put you ahead!
4231TD wITH MOwER

THE VENTRAC ADVANTAGE
FEATURES
THE VENTRAC ADVANTAGE
FEATURES
4100 AIR COOLED
B&S Vanguard 31hp Gas 2-cyl 895 cc
4200 LIQUID COOLED
Kawasaki 27hp Gas 2-cyl 746 cc
B&S Vanguard 26.5hp Dsl 3-cyl 953 cc
B&S Vanguard 31hp Gas 3-cyl 953 cc
B&SVanguard31hpTurboDsl3-cyl 953cc
3100 AIR COOLED
B&S Vanguard 21hp Gas 2-cyl 627cc
3200 LIQUID COOLED
B&S Vanguard 23.6hp Diesel 3-cyl 850cc
7200 LIQUID COOLED
B&SVanguard31hpTurboDsl3-cyl 953cc
Ventrac offers several engines to meet your
power needs. Choose the VANGUARD
3/LC, the Commercial Power line from Briggs
& Stratton Daihatsu LLC., for the ultimate
combination of reliability and performance.
Discover what happens when you put an
engine this POWERFUL in a machine as
versatile and maneuverable as Ventrac.
Power
Maneuverability
The CENTER-ARTICULATING
FRAME on the 4000 and 3000 series,
along with a tight turning radius, allows for
easy MANEUVERABILITY even in
the tightest of places. The rear-steered 7000
series features a 14” turning radius.
Control
Convenient S.D.L.A. controls are located
next to the operator for precise control of:
Speed - Acceleration and braking
Direction - Forward/Reverse
Lift - Lift of front-end attachments
Auxiliary function - example: angling dozer
blade or dumping the slip scoop
Power Steering
S.D.L.A. Controls
Durability
In the design stage, Ventrac is field tested to ensure that you will only receive a top
notch, DURABLE MACHINE that will work for you year-round. VENTRAC
is built with an all steel, heavy-duty frame. Each unit is carefully assembled and
inspected for quality. We stand by our product with Ventrac’s
three-year residential and two-year commercial V-Plus Warranty.
Our manufacturing facility in Orrville, Ohio is state of the art, utilizing the latest in
laser-cutting technology, robotic welding, and a powder coating paint system.
Made in the USA
3121 wITH V-BlADE 4131 wITH VERSA-lOADER AND PAllET FORkS 4231 wITH POwER RAkE

Comfort Seat
Power Steering
Tachometer & Hour Meter
Parking Brake
Halogen Headlight
Tilt Steering Column*
Articulating/Oscillating Frame
Adjustable Weight
Transfer System*
All-Wheel Drive
3000 Series Standard Features
Five Gallon Fuel Tank
S.D.L.A. Hand Controls
(Speed, Direction, Lift, and Auxiliary)
Engine
3100 AIR COOLED
B&S Vanguard 21hp Gas 2-cyl 627cc
3200 LIQUID COOLED
B&S Vanguard 23.6hp Diesel 3-cyl 850cc
Taillights
2” Rear Receiver Hitch
Patented Tandem Drive Train
Front Hydraulic Couplers
Forward & Reverse Foot Control
3223D wITH STuMP GRINDER
* Standard on 3200, optional on 3100
3000 Series
VENTRAC TRACTORS
The 3000 Series is a power-packed tractor
that puts you out front where the action is
for maximum visibility. Every 3000 series
tractor is built with the same versatility
and performance for which Ventrac is
known.
Standard on the 3000 series is Ventrac’s
S.D.L.A. hand control, which allows for
easy control of Speed, Direction, Lift and
Auxiliary function all with one hand.
These tractors feature all wheel hydrostatic
drive and power steering. Combine
this with a tight 28” turning radius and
you will find the 3000 series can tackle
jobs typically reserved for larger, less
maneuverable machines.
3223D
Get attached using the Minute Mount
System, which allows you to change over
18 attachments quickly and efficiently
from job to job with minimal effort. This is
versatility at its best!
Standard features include:
• Adjustable Weight Transfer System*
• Articulating / Oscillating Frame
• Comfort Seat
• Forward and Reverse Foot Control
• Hydrostatic Drive
• Power Steering
• S.D.L.A. Controls
• Tilt Steering Column*
* Standard on 3200, optional on 3100
28” RADIUS
28” Radius
Ventrac’s patented (T.D.T.) on
the 3000 series efficiently trans-
fers power to where it’s needed
for unparalleled performance.
Tandem Drive Train

The 3100 Ventrac Compact Tractor is small
enough to handle working around tight
spaces and is powerful enough to tackle
the toughest of jobs. The 3100 features
a 21-HP V-Twin gas engine and comes
standard with S.D.L.A. and foot pedal
controls.
3100
3121
Tilt steering and a suspension seat are
optional for added comfort. Weight
Transfer is also optional for added stability
and traction on hills.
Powered by:.
3100 AIR COOLED
B&S Vanguard 21hp Gas 2-cyl 627cc
Whether you’re mowing grass, grinding out
a stump or moving a pile of snow or soil,
the 3200 unit is more than enough tractor
for whatever project comes your way. A
23.6-HP 3-cylinder liquid cooled Diesel
engine provides plenty of power for whatever
the task. The 3200 comes standard with an
adjustable weight transfer system.
3200
Tilt steering column is standard on the 3200.
Powered by:
3223D
shown with mower
3200 LIQUID COOLED
B&S Vanguard 23.6hp Diesel 3-cyl 850cc
D
G

All-Wheel Drive combined with a low
center of gravity and weight transfer
system enables Ventrac to conquer even
the toughest of terrain. S.D.L.A. (Speed,
Direction, Lift and Auxiliary) controls and
easy access operator platform provide
superior ergonomics. Added to all that is the
quick, efficient, Minute Mount System that
allows you to attach over 30 commercial-
grade attachments in about a minute or less
and requires no tools! With the optional,
category one 3-point hitch, non-PTO
powered attachments can be operated on the
rear of the tractor alone or simultaneously
with the front.
Standard features include:
• All-wheel drive
• Roll bar
• Seat belt
• S.D.L.A. controls
• Power steering
• Comfort seat
• Front and rear steel skid plates
• 7.25 gallon fuel tank
And more
4000 Series
VENTRAC TRACTORS
4131
4000 Series Standard Features
All-Wheel Drive
Tachometer & Hour Meter*
Single Hi/Low Range Shifter
Power Steering
Center Articulating & Oscillating Frame
7.25 Gallon Fuel Tank
Roll Bar (R.O.P.S. Certified)
Rear Weights*
2” Rear Receiver Hitch
Comfort Seat
Halogen Headlights
Electric PTO w/Brake
Skid Plates, Front & Rear
Minute Mount Hitch
Dual Hydraulic Oil Filtration
Weight Transfer*
Front Hydraulic Couplers
Front Fenders*
Foot Rests*
Parking Brake
S.D.L.A. Controls
Heavy Duty Axles
Cup Holder
Storage Box
Seat Belt
*Standard on the 4200, Optional on 4100
4231 wITH MOwER
Center Oscillating/
Articulating Frame

4100
The Ventrac 4100 is built on a rugged,
all-steel frame and utilizes a dependable
31-HP Vanguard commercial grade air-
cooled engine. Ventrac’s high efficiency
hydraulic drive system will give you years
of enjoyable performance. Customize the
4100 with a variety of accessories including
weight transfer system, rear weights,
front fenders and more. Drive up and get
attached to over 30 Ventrac Minute Mount
attachments, letting you decide what gets
done and when.
4131
4100 AIR COOLED
B&S Vanguard 31hp Gas 2-cyl 895 cc
4200
The Ventrac 4200 Power Unit takes compact
tractors to a new level. The articulating
and oscillating heavy-duty frame enhances
maneuverability and stability over
traditional tractors by conforming to the
contour of the terrain.
This incredibly rugged and dependable
machine is a wise business investment
for golf courses, schools and universities,
parks, street maintenance departments,
commercial mowing services, contractors,
wineries, farms, property owner
associations, estate homes and anyone
needing to: mow, blow, sweep, edge,
scoop and much, much more.
Increase productivity, control costs, and
improve your return on investment. One
machine can do it all. Get Attached to a
Ventrac... and Get it done!
4200 LIQUID COOLED
Kawasaki 27hp Gas 2-cyl 746 cc
B&S Vanguard 26.5hp Dsl 3-cyl 953 cc
B&S Vanguard 31hp Gas 3-cyl 953 cc
B&SVanguard31hpTurboDsl3-cyl 953cc
4231TD
Vanguard 31hp Turbo Diesel
Pictured with optional Suspension Seat & Hub Caps
4226D
Vanguard 26.5hp
4231
Vanguard 31hp
4227
Kawasaki 27hp
G
D
G
D
Powered by:.
Powered by:.
G
THE ULTIMATE HILL MOWER
Get maximum angle of operation with
the Vanguard 31HP Turbo Diesel engine,
now approved for 30 degrees continuous
operation, when equipped with dual wheels.

2” Rear Receiver Hitch
Power Steering
Halogen Headlights
12 Gallon Fuel Tank
Weight Transfer
Tilt Steering Column
Minute Mount Hitch
7200 Standard Features
Fold Down Roll Bar
Comfort Suspension Seat
S.D.L.A. Controls
Tachometer & Hour Meter
Cup Holder
Forward and Reverse Foot Control
Front Hydraulic Couplers
Electric PTO w/Brake
The newest tractor to join the Ventrac
line-up is the 7200. This rear-steered power
unit features hydrostatic front-wheel-drive,
variable-speed piston wheel motors, and
power steering which gives the operator
enhanced maneuverability and agility over
traditional tractors.
Ventrac’s patented S.D.L.A. control, located
next to the operator, allows for easy control
of Speed, Direction, Lift and Auxiliary
function all with one hand. The 7200 also
comes standard with the Ventrac Minute
Mount System which enables the operator
to quickly and easily switch between
attachments and jobs. Since the attachment
is placed out front of the unit,
the operator has a natural
view offering greater
precision.
Standard features include:
• Rear Wheel Steering Control
• Front Wheel Drive
• Electric High - Low Speed Control
• S.D.L.A. controls Speed, Direction,
Lift, and Auxiliary hydraulics from a
single point
• Heavy Duty 2 Speed Hydrostatic
Wheel Motors
• Weight Transfer System
• Ventrac Minute Mount System
• Forward & Reverse Foot Control
• Tilt Steering Column
• Folding Roll Bar
• Suspension Seat
• 12 gallon fuel tank
And more
7000 Series
VENTRAC TRACTORS
7231TD
7231TD wITH MOwER
7200 LIQUID COOLED
B&SVanguard31hpTurboDsl3-cyl 953cc
Powered by:.
D

Weight 163 lbs. 203 lbs. 225 lbs.
Attachments
MINUTE MOUNT / 3-N-1
All Ventrac attachments mount in about a minute or less.
Ventrac’s Minute Mount System is the ultimate
example of practical engineering put to good use.
Simply drive up to the Ventrac attachment of
choice:
1. Lock onto the holding pins
2. Insert the coupler connections* and/or...
3. Install the drive belt*
4. Engage the belt tensioner*
And you’re ready to go! *As required by attachment
Rear Attachments
Ventrac 4000 series tractors can be equipped with a Category One 3-point hitch. With the
3-N-1 adapter mounted to the optional Category One 3-point hitch, non-powered attachments
can be operated from behind the tractor alone or simultaneously with the front. Versatility by
Design just got better!
AERATOR EB480
The Ventrac Aerator offers the exact tools to address your
turf grass conditions. Choose between core or open spoon
tines. The tines are replaced either individually or by quickly
changing the entire
mounting heads.
Overall
width
54”
Overall height 27”
Overall length 27”
Working width 48”
Aeration density 6 holes/f2
Weight 217 lbs.
AERA-VATOR EA600
The AERA-vator is designed to fracture the soil beneath
the sod without destroying the turf on the surface. This
means that turf is ready for use immediately after treatment.
Penetrating the soil with no slicing or cutting action,
preserves the delicate turf grass roots and stimulates
future growth.
Optional: Seed-box (shown) allows
for over-seeding and
aerating simultaneously.
Overall width 66”
Overall height 22”
Overall length 34”
Working width 60”
Tines 96 (0.5625 x 3.5”)
Weight 350 lbs.
Side-to-side tine travel 1.25”
Vibrating depth 3.75”
Tine vibration frequency 3200 rpm
=est. 800 cyc/min
Aeration density 8 holes/f2
4000 7000 series
Attachments with this symbol can also be
mounted to the rear using Ventrac’s optional
3-point hitch and 3-N-1 adapter.
1234
BLADES
The Dozer Blade is hydraulically angled left and right.
Adjustable skid shoes, removable locking pin, and
reversible cutting edge are standard.
Optional: Polyurethane cutting edge and hard-
ened cutting edge.
KD480 KD600 KD720
Width 48” 60” 72”
Height 22” 22” 22”
Angle (right or left) 30º 30º 30º
Weight 163 lbs. 203 lbs. 225 lbs.
3000 4000 7000 series
BLOWER KA160
The KA160 Power Blower for the 4000 and 7000 series
tractors rotates 180º horizontally left and right with a
standard hydraulic motor controlled
from the operator seat.
Overall width 32.5”
Overall height 22”
Overall length 36”
Fan 16 blade
Wind speed 180 mph
Volume 4000 cfm
Weight 163 lbs.
Hydraulic motor Standard
4000 7000 series
BLOWER LA162
The LA162 Blower for the 3000
series tractor can be angled 180º
horizontally left and right with the
standard hydraulic motor.
Overall width 32.5”
Overall height 22”
Overall length 42”
Fan 16 blade
Wind speed 160 mph
Volume 3400 cfm
Weight 145 lbs.
Hydraulic motor Standard
3000 series
BROOM HB580
The HB580 Broom for the 4000 and 7000 series
tractors is hydraulically driven and can be
angled right or left using the
auxiliary S.D.L.A. lever.
Optional: 12V Actuator allows
the operator to slow or reverse
the rotation of the
bristles from the
operator seat.
Overall width 68”
Overall height 24”
Overall length 54.5”
Broom width 58”
Broom speed 220 rpm*
Weight 382 lbs.
Gauge Wheels Standard
*Engine speed 3200 rpm
BROOM LB540
The LB540 Broom for the 3000 series tractor is hydrau-
lically angled left or right using the Auxiliary lever.
Optional: Belting curtain and outrigger wheels (inset)
for de-thatching your yard.
Broom width 54”
Overall width 60.5”
Overall height 18.5”
Overall length 46.5”
Broom diameter 16”
Broom speed 300 rpm*
Weight 240 lbs.
Gauge wheels Standard
*Engine speed 3200 rpm
EDGER ED200
The Edger is designed to edge sidewalks, curbs, cart
paths, etc. The edging disc can be reversed for shaping
garden and flower beds.
Optional: Weights and blower* for removing
edged debris.
Overall width 54-66”
Overall height 27”
Overall length 45”
Weight 182 lbs.
Weight w/blower 222 lbs.
Disc diameter 20”
Cutting depth 6”
3000 4000 7000 series
*Blower attaches only to 4000 and 7000 series
EXCAVATORS
HJ Excavator buckets allow the
operator to excavate, dig, and
haul material. Its innovative flip-
back design allows for forward
or reverse excavating.
HJ300 HJ480
Overall width 36” 53.5”
Working width 30” 48”
Height 13” 13”
Length 34” 34”
Capacity 3.6 ft3 5 ft3
Ground clearance 11” 11”
Weight 145 lbs. 189 lbs.
3000 4000 7000 series
FIELD MOWER LQ450
The LQ450 Field Mower is designed to cut heavy grass
and small brush growth with three different height
settings. Two counter-rotating blades discharge grass
to the center rear.
Optional: Tree Shield Kit with
branch lifters and wheel cov-
ers for tree farms (rear weights
recommended).
Cutting width 44.5”
Cutting height 2.25” / 3.5” / 4.75”
Height 16”
Length 55”
Weight 243 lbs.
3000 series
GENERATOR HG150
The Ventrac Generator is
great for mobile power or
as a standby unit.
Receptacles include: (4)
120v, 20A receptacles;
(1) 120v, 30A Twistlock,
(1) 240v, 30A Twistlock,
(1) 240v, 50A Range re-
ceptacle.
Maximum watts 15,000
Continuous watts 12,500
Voltage 120/240
Amperage 79.2/39.6
Hertz 60
Phase 1
Req. constant shaft speed 3,000 rpm
Net weight 196 lbs.
4000 7000 series
4000 7000 series
3000 series
3000 4000 7000 series

HM & HP SERIES FINISH MOWERS
All Ventrac finish mowers (HM, HP, LM) feature single
lever height adjustment, easy flip-up deck design, and
rear roller for maximum lawn striping. The HP offset
mower shifts the mowing deck 6.5” to the left for a
shorter cutting radius and increased reach for mowing
around ponds or ditches.
4000 SERIES HM602 HM722 HP722
Width of cut 60” 72” 72”
Cutting height 1.125 - 4.75” 1.125 - 4.75” 1.125 - 4.75”
Length 52” 58” 58”
Weight 385 lbs. 450 lbs. 450 lbs.
4000 7000 series
LM SERIES FINISH MOWERS
3000 SERIES LM440 LM520 LM600
Width of cut 44” 52” 60”
Cutting height 1.5 - 3.75” 1.5 - 3.75” 1.5 - 3.75”
Length 45” 45” 58”
Weight 220 lbs. 273 lbs. 310 lbs.
3000 series
Easy height adjustment.
POWER RAKE KP540
The Power Rake pulverizes, levels, grades and prepares
seed beds with 72 replaceable carbide tips. The
rotor is both driven and angled hydraulically.
Rotation can be changed from the
operator seat.
Overall height 34”
Overall width 62”
Overall length 82”
Rotor width 54”
Height adjustment .125” increments
Height adjustment range 3.5”
Weight 536 lbs.
4000 7000 series
SLIP SCOOPS
Ventrac Slip Scoops are a
must-have attachment allowing
you to dig, level,
and move a variety
of materials.
HE300 HE480
Overall width 36” 52.5”
Working width 30” 48”
Height 15” 16”
Length 34” 34”
Weight 111 lbs. 175 lbs.
Capacity 3.6 f36 f3
3000 4000 7000 series
SNOW BLOWER KX522
With a serrated auger, the KX and LX snow blowers
cut into light or hard-packed snow with ease. Chute is
rotated hydraulically left or right 220º on the KX and
180º on the LX.
Optional: A 12V actuator allows the operator to change
the height of throw from the operator seat. A deep snow
auger is also optional on the KX522.
Width 52”
Height 56.5”
Depth 43.75”
Cutting height 26.5”
Cutting width 48”
Blowing distance Up to 40’
Chute rotation 220º
Weight 475 lbs.
4000 7000 series
SNOW BLOWER LX420
Width (cutting & overall) 42”
Height 52.5”
Length 43”
Throwing distance Up to 40’
Chute rotation 180º
Weight 374 lbs.
3000 series
STUMP GRINDER KC180
The KC180 Stump Grinder features 18 replaceable
carbide cutting teeth for large or small stump removal.
Standard front mounted mirror allows the operator to
see the stump easily while being fully protected from
debris.
Overall height 19”
Overall width 25”
Overall length 35”
Cutterhead width 3.5”
Overall cutterhead diameter 18”
Cutterhead speed 900 rpm*
Cutting depth below ground level 6”
Weight 171 lbs.
*Engine speed 3600 rpm
STUMP GRINDER LC150
The LC150 Stump Grinder features 12 replaceable
carbide cutting teeth. An
adjustable blade hydraulically
lowers for use as a depth,
jackstand and to fill in
stump holes.
Overall height 19.5”
Overall width 21”
Overall length 40”
Cutterhead width 3.5”
Rotor tip speed 2,475 ft/min.*
Rotor rpm 620 rpm*
Cutting depth below ground level 6”
Weight 200 lbs.
*Engine speed 3200 rpm
SOD CUTTER EC240
The Sod Cutter cuts a 24”
wide strip of sod at a user-
adjustable depth.
Cutting width 24”
Height 11.5”
Length 23.5”
Cutting Depth 0 to 2.5”
Weight 41 lbs.
4000 series
Standard mirror on KC180
TERRA RAKES
The Terra Rake is designed to perform a variety of
landscaping jobs. Features include: Hydraulic angling
and gauge wheels that can be mounted front, rear or
removed.
Optional: Hydraulic height adjustment
link (shown), 10” wing extensions.
KR502 KR702
Overall width 52” 70”
Overall width w/extensions 72” 90”
Height 29.5” 29.5”
Length 52” 52”
Weight 242 lbs. 325 lbs.
3000 4000 7000 series
TILLER KL480
The Ventrac Tiller is designed for easy preparation
of gardens and yards. This power-driven front-end
attachment allows the operator to easily monitor the
tiller’s performance. Skid shoe adjustments facilitate
cutting depth. Twenty-four high carbon
tines are durable and are
sequentially spaced to
maximize performance.
Overall width 53”
Working width 48”
Length 41”
Height 22”
Weight 345 lbs.
4000 series
TOUGH CUT MOWER HQ680
The Ventrac Tough Cut Mower is designed for mowing
high grass, thick weeds, and heavy brush. Three heavy-
duty blades counter-rotate to cut and drop materials
evenly without windrowing. Tilt-up deck provides easy
access to the blades.
Optional: Adjustable Swivel
wheels for a more controlled
height of cut.
Working width 68”
Cutting heights 3”, 3.625”, 4.25”
Length 45”
Height 15”
Weight 354 lbs.
4000 7000 series
TRENCHER KY400
The Ventrac Trencher is capable of trenching up to 40
inches deep with a 5.5 inch-wide cut. Depth indicator
allows operator to gauge depth of cut from the operator
seat. Standard features include: Self-adjusting crumb
scraper and combo
terminator/cup chain with
replaceable carbide teeth.
Overall height 27”
Overall width 40”
Overall length 74.5”
Trenching width 5.5”
Trenching depth 40”
Weight 493 lbs.
4000 7000 series
TURBINE BLOWER ET200
The Ventrac Turbine Blower’s front nozzle
hydraulically rotates 360º continuously
on a vertical plane. The front
guard protects the nozzle
while doubling as a deflector
for blowing forward.
Length 69”
Width 27”
Height 34”
Weight 256 lbs.
MPH out of nozzle 175 mph*
MPH out front of deflector 110mph*
Volume 10,000 cfm*
*Engine speed 3650 rpm
V-BLADE KV550
The V-Blade is ideal for sidewalk snow
removal. Both wings can be independently
angled hydraulically forward or
back for greater control.
Optional: Wing extensions,
top deflection flap,
and polyurethane
cutting edge.
Length 31”
Width straight 55”
Width in forward “V” 48.5”
Width in backward “V” 48”
Height 21”
Weight 240 lbs.
Wing angle 30º each
3000 4000 7000 series
VERSA-LOADER KH500
Discover the versatility and ease of the Ventrac
Versa-Loader (shown with standard bucket). Drive up
and attach in minutes
without tools or
heavy lifting. Once
connected,choose
the standard
bucket or six other optional
attachments which also feature
Ventrac’s Minute Mount system
to get the job done.
Overall height on tractor 67”
Overall width 41.5”
Overall length w/standard bucket 75”
Overall length - tractor, loader & std. bucket 111”
Width of standard bucket 48”
Capacity of standard bucket (struck) 5 f3
Weight w/o tools 508 lbs.
Lift capacity including tool 500 lbs.
Lift height (at pivot points) 77”
Oil tank capacity 6 gal.
Gallon/min. @ 3600 rpm 9.5 gpm
4000 series (Loader is not compatible with the Cab)
MULCH BUCKET
9 cu. ft.
POST HOLE DIGGER
Fast drive motor
BOOM LIFT
TINE FORKS
TREE AUGER
Slow drive motor
PALLET FORKS
LOADER ATTACHMENTS
3000 series
4000 7000 series
4000 7000 series

Accessories
PERFORMANCE OPTIONS
3000 SERIES 3100/3200
CAB
All-weather protection
REAR WEIGHT
BRACKET &
WEIGHTS
Increased traction and
stability
ROLL CAGE
AND SEAT BELT
TIRE OPTIONS
All-terrain tires
(Standard: Turf tires)
12-V SWITCH
& PLUG
For select attachments
and accessories.
(Models: LX, KR, KV,
ES)
3100 (Standard on 3200)
TILT STEERING
COLUMN
For comfort adjustment
ADJUSTABLE
WEIGHT
TRANSFER
7000 SERIES 7200
REAR
WEIGHTS
TIRE OPTIONS
All-terrain tires
(Standard: Turf tires)
12-VOLT
SWITCH &
PLUG
For select attachments
(Models: EA, HB, KX,
KR, KV, ES)
All Tractors 3000/4000/7000 series
ARM RESTS
SPREADER 220
Designed to spread
salt, seed, fertilizer, and
Penn Mulch
3000 series: Front
mount only with 2-N-1,
not compatible w/ cab.
Optional drop curtain
SUSPENSION
SEAT
Features tilt-back, lum-
bar support and weight
adjustment
(Standard on 7200)
2-N-1
Doubles as a front
weight bracket and
tow hitch (shown with
optional weights)
4000 SERIES 4100/4200
CAB
All-weather protection
SLOPE
INDICATOR
For gauging degree of
operation
CANOPY
Protection from sun
and rain
STROBE/WORK
LIGHT
For increased roadside
safety and night opera-
tion of the 3-point hitch
CHROME HUB
CAPS
TIRE OPTIONS
Turf and bar tires
(Standard: All-terrain)
DUAL WHEEL KIT
For operating on grades
up to 30º and for
increased traction, weight
distribution and stability
on slopes.
12-VOLT
SWITCH &
PLUG, FRONT
For select attachments
(Models: EA, HB, KX,
KR, KV, ES)
FOOT
DIRECTIONAL
CONTROL
12-VOLT
OUTLETS, REAR
For operating Ventrac
spreader, cell phone,
radio, etc.
FOLD DOWN
ROLL BAR
R.O.P.S. approved roll
bar that can be folded
down for low-clearance
areas
WHEEL
EXTENSIONS
Increases tread width 6
inches for added stability
REAR ACCESSORIES - 4000 SERIES
3-POINT HITCH
Category one 3-point
Hitch for mounting rear
implements
3-N-1 ADAPTER
Attaches to the 3-point
Hitch for mounting select
3-N-1 attachments,
counterweights, and
towing
HYDRAULIC
TOP LINK
4100 (Standard on 4200)
ADJUSTABLE
WEIGHT
TRANSFER
KIT
FOOT RESTS
FRONT
FENDERS
REAR WEIGHTS
TACH/HOUR
METER
Rear
Hydraulic
Valves 3-Point
Controls
Optional extension

3121 3223D
Engines Vanguard 21 HP V-Twin Air-Cooled Gas (627 cc)^ Vanguard 23.6 HP Liquid Cooled Diesel 3-cyl (850 cc)^^
Drive All-Wheel Drive (AWD) All-Wheel Drive (AWD)
Tires Standard: Turf 18x10.5-10 18x10.5-10
Optional: All-Terrain 18x11-10 18x11-10
Electrical 450 Cranking Amps 12-V / 50 Amps 450 Cranking Amps 12-V / 40 Amps
Fuel Tank Capacity 5.0 Gallons 5.0 Gallons
Dimensions Wheelbase 38” 38”
Length 72” 72”
Overall Height 47” 47”
Width 40.5” 40.5”
Travel Speed* 7 mph 7 mph
Weight** 850 lbs 1050 lbs
Turning Radius 28” 28”
Steering Power Power
PTO Electric w/Brake Electric w/Brake
^ 20.1 hp gross @ 3200 rpm in the 3121 ^^ 22.7 hp gross @ 3200 rpm in 3223D
SPECIFICATIONS
4131 7200
Engine Vanguard 31 HP 2-Cyl Gas, Air-Cooled (895cc) Vanguard 31 HP Turbo DSL 3-Cyl (953)
Drive All-Wheel Drive (AWD) Front Wheel Drive, Rear Steered
Tires Standard: All Terrain 22x12-8 Front: Turf 24x12-12 Rear: Turf 18x9.5-8
Optional: Turf 22x11-10 Front: All Terrain 24x12
Optional: Bar 21x11-8
Electrical 450 Cranking Amps 12-V / 50 Amps 450 Cranking Amps 12-V / 40 Amps
Fuel Tank Capacity 7.25 Gallons 12 Gallons
Dimensions Wheelbase 43” 55”
Length 77” 81”
Overall Height (top of roll bar) 67” 78”
Width w/Single Turf Tires 48” 54” w/turf tires
Width w/Dual Turf Tires 70” -
Travel Speed* Low Range 5.2 mph 7.5 mph
High Range 10 mph 15 mph
Weight** 1,290 lbs 1,600 lbs
Turning Radius 43” 14”
Steering Power Power (Rear)
PTO Electric w/Brake Electric w/Brake
* Speeds vary according to tire size, type and inflation **Weight varies according to engine size, accessories, attachments and tire options
4100
3000 Series
7200
4226D 4227 4231 4231TD
Engine Vanguard 26.5 HP Kawasaki 27 HP Vanguard 31 HP Vanguard 31 HP
DSL 3-Cyl (953 cc) Gas 2-Cyl (715 cc) Gas 3-Cyl (953 cc) Turbo DSL 3-Cyl (953 cc)
Drive All Wheel Drive (AWD) All Wheel Drive (AWD) All Wheel Drive (AWD) All Wheel Drive (AWD)
Tires Standard: All-Terrain 22x12-8 22x12-8 22x12-8 22x11-8
Optional: Turf 22x11-10 22x11-10 22x11-10 22x11-10
Optional: Bar 21x11-8 21x11-8 21x11-8 21x11-8
Electrical 450 Cranking Amps 450 Cranking Amps 450 Cranking Amps 450 Cranking Amps
12-V / 40 Amps 12-V / 20 Amps 12-V / 40 Amps 12-V / 40 Amps
Fuel Tank Capacity 7.25 Gallons 7.25 Gallons 7.25 Gallons 7.25 Gallons
Dimensions Wheelbase 43” 43” 43” 43”
Length 77” 77” 77” 77”
Overall Height (top of roll bar) 67” 67” 67” 67”
Width w/Single Turf Tires 48” 48” 48” 48”
Width w/Dual Turf Tires 70” 70” 70” 70”
Travel Speed* Low Range 5.2 mph 5.2 mph 5.2 mph 5.2 mph
High Range 10 mph 10 mph 10 mph 10 mph
Weight** 1,493 - 1,630 lbs 1,493 - 1,630 lbs 1,493 - 1,630 lbs 1,493 - 1,630 lbs
Turning Radius 43” 43” 43” 43”
Steering Power Power Power Power
PTO Electric w/Brake Electric w/Brake Electric w/Brake Electric w/Brake
* Speeds vary according to tire size, type and inflation
**Weight varies according to engine size, accessories, attachments and tire options
SPECIFICATIONS
4200

Versatility by Design
Venture Products Inc.
328 E. Water St.
P.O. Box 148
Orrville, OH 44667
USA
Toll Free: 1-866-VENTRAC (1-866-836-8722)
Local: 330-683-0075
Fax: [phone]
Email: [email protected]
Web: www.ventrac.com
To find a dealer near you go to:
www.ventrac.com
For more information contact your nearest dealer:
Venture Products reserves the right to make changes to product design and specifications without notice.
Venture Products Inc. 2078
Made in the USA
