CALIENTE LST WALL-MOUNTED CONVECTOR
Installation manual

1
1
1
2
2
2
3
1
23
4
5mm
Installation manual of CALIENTE LST wall-mounted convector
1 2
3 4
Aer receiving the heater, check it for completeness.
Then in order to install, disassemble the casing by peorming the following steps:
• Remove the grate (1),
• Unscrew the screws that fix the casing to the rear panel (2),
• Remove the casing (3).
In the next step, install the casing in accordance with the diagram presented in picture, turning it,
so that the valve is in the centre of the casing, and then level the casing with the rear panel.
Aer placing and levelling the casing and the exchanger, the valve should protrude from the casing
by approximately 5 mm.
Fix the rear panel along with the aached exchanger to the wall by means of bolts and rawlplugs
supplied in the kit, at the places indicated in picture.
Aer fiing the rear panel, connect the supplying system shown in picture, tightening the nuts which
can be found on the supply and return pos. In order to connect the heating device to the system, the
nuts must be countered.

5 6
7 8
S
Installation manual of CALIENTE LST wall-mounted convector
Aer the heater is connected to the system, vent it. For this purpose, remove the grate, and then
disassemble the masking element, located on the valve side, by unscrewing the Sscrew and pulling the
masking element out of the casing.
The heater is deaerated by unscrewing the screws located in the air-vent shown in picture.
Aer deaerating, tighten the air-vent screw and replace the dismantled masking element and the grate.
Aer the casing is placed with the panel and with the exchanger, install the casing with screws in the
designated places shown in figure 6 by means of the screws supplied with the heater. The number of
the fixing points may vary depending on the heater.
The last element is the grate which should be placed in the casing according to picture.

If you have any questions or doubts concerning conducting installation works, please contact us.: tel.: [phone] or e-mail: [email protected]
