Verasys Boiler Controller
Quick Start Guide
LC-VAC3000-0 Code No. Lit 12013353
Issued June 2019
Figure 1: LC-VAC3000-0
About this guide
This quick start guide provides the basic information you need to
configure and install the Boiler Controller and application.
For further information, refer to the Verasys® 32 Point 24 VAC
Application Controller Installation Instructions (24-10143-01515), and
Verasys Boiler Controller Application Note (LIT-12013275) on
QuickLit.
For more information or to access Quicklit, scan the following QR
codes:
Mounting the controller
To mount the controller, complete the following steps:
1. Mount a 20 cm (8 in.) section of
35 mm (1.3 in.)DIN rail
horizontally.
Note: Mount the controller in the horizontal position.
2. On the back of the controller, extend the two mounting clips as
shown in the following figure.
3. Place the controller on the DIN rail.
4. To secure the controller on the DIN rail, push the bottom
mounting clips up as shown in the following figure.
5. To remove the controller from the DIN rail, pull the bottom
mounting clips out to the extended position and carefully lift the
controller off the DIN rail
LC-VAC3000-0 QR code QuickLit QR code
Figure 2: Pull lower mounting clips down
Figure 3: Pull lower mounting clips down

Verasys Boiler Controller Quick Start Guide
2
Wiring the controller
The system bus terminal block is a blue, removable, 4-terminal plug
that fits into a board-mounted jack. To wire the controller, complete
the following steps:
1. Wire the removable system bus terminal block as shown in
Figure .
2. Wire any other devices that you want to connect on the system
bus in a daisy-chain configuration using 3-wire twisted, shielded
cable as shown in Figure 5.
Figure 4: System bus terminal block wiring
Figure 5: Daisy-chain wiring configuration
Enable the end of line (EOL) switch
If the controller is at the beginning or end of the line on the system
communication bus, you must activate the EOL switch.
1. To disengage and remove the plastic cover press down on the top
of the controller.
Note: Ensure that you do not disconnect the ribbon cable that
connects the controller to the board display.
Note: The EOL switch is a red block with a white switch located
directly above the system bus terminal block.
2. Turn the EOL switch on by moving the white switch to the right.
Wiring the supply power terminal block
The 24 VAC supply power terminal block is a gray, removable,3-
terminalplugthatfitsintoa board-mounted jack on the top right of the
controller.
Wirethe 24 VACsupply powerwiresfrom the transformer to the HOT
and COM terminals on the terminal plug, as shown in Figure 6.
Note: Do not use the middle terminal on the supply power
terminal block.
Note: The supply power wire colors may be different on
transformers from other manufacturers. Refer to the transformer
manufacturer’s instructions and the project installation drawings for
wiring details.
Figure 6: Supply power terminal block wiring
Wiring options
Configurable outputs 1, 2, and 3, and triac binary outputs 8 and 9 are
rated for a maximum current draw of 0.5 A. It is best practice to use
pilot relays when you use these outputs to drive contactors.
You can choose a pilot relay with a manual override function. You can
also use software to reverse the polarity of the output. This means
that you can drive contactors with contacts that are normally open
(fail off) or normally closed (fail on).
Table 1: Daisy-chain wiring configuration
No. Description
1Terminating device on the system bus
2System bus terminal block plugs
3Daisy chained device on a system bus segment
4To next device on the system bus segment
+
COM
SHD
1
2
3
4
4
+
COM
SHD
+
COM
SHD
Table 2: Supply power terminal block wiring
No. Description
1Supply power terminal block jack
2Supply power terminal block plug
3Wires from Johnson Controls® 90 VAC to 24 VAC, Class 2
power transformer
(COM)(24 VAC)
HOT
COM
24V~
HOT
COM
1
2
3

Verasys Boiler Controller Quick Start Guide
3
Table 3: Boiler controller point to point wiring diagram
(Part 1 of 3)
No Description Object
name
1Primary or secondary HWP 1 output (to pump
VFD) xHWP1- O
2Primary or secondary HWP 2 output (to pump
VFD) xHWP2- O
3Primary or secondary HWP 3 output (to pump
VFD) xHWP3- O
4Primary or secondary HWP 4 output (to pump
VFD) xHWP4- O
5Relay coil combustion damper command CD-C
6Relay coil boiler 1 command BLR1-C
7Relay coil boiler 2 command BLR2-C
8Relay coil boiler 3 command BLR3-C
9Relay coil boiler 4 command BLR4-C
10 Relay coil boiler pump 1 command BP1-C
Figure 7: Point to point wiring diagram
Ad dr ess : SEE RISER
DIAG RA M
PWR COM + -
SE NSO R
BUS
+ -
SY STEM
BUS
COM SHL D
IN 4 IN 5 IN 6 IN 7 IN 8 IN 9 ICOM7-12 IN 14 ICOM 14 IN 15 ICOM 15 IN 16 ICOM 16 IN 17 ICOM 17
UNIVERSALBI NA RY
CONFIGURABLE
OUT10NO
OCOM10
BI NA RY
HOT
24 VA C
INPUT
COM
VAC3000
OUT1 OCOM1 OUT2 OCOM2 OUT3 OCOM3
24V~
COM
24 VA C
OUT
IN 18 ICOM 18 +15V COM
+ -
MOD BUS
COM
OCOM4
OUT4
PWM COM
OUT5 PWM
PWM
OUT6NO OCOM6 OUT7NO OCOM7 OUT8NO OCOM8 OUT9NO OCOM9 OUT11-A
OUT11-B
OUT12-A
OUT12-B
OUT13-A
OUT13-B
OUT14-A
OUT14-B
IN 13 ICOM 13
COM 24V~
IN 12 IN 11 IN 10 ICOM 4-5-6
ICOM 1-2-3
IN 3 IN 2 IN 1
MS/TP
MS/TP
++
+
-
+
+
-
1
2
3
14
15
16
17
18
24
VDC
OUT
COM
15 VDC
+VDC
OUT
COM
15 VDC
20
21
22
23
+
-
+
-
4
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
NO C
CNO NOC CNO NO CC
NO CNO CNO
36
29 30 31 32 33 34
NO C
CNOCNOCNOCNO
5
9
7
8
11
13
12
6
10
19
26 27 28 35
25
11 Relay coil boiler pump 2 command BP2-C
12 Relay coil boiler pump 3 command BP3-C
13 Relay coil boiler pump 4 command BP4-C
14 24 V COM
15 24 V HOT
16 From last device
17 To next device
18 Zone temperature sensor that can initiate
boilers at night. ZN-T
19 Shutdown command EMERG-
STOP
20 Primary hot water flow PHW-F
21 Hot water differential pressure HW-DP
22 Outside air temperature OA-T
23 Hot water return temperature HWR-T
Table 3: Boiler controller point to point wiring diagram
(Part 2 of 3)
No Description Object
name

Verasys Boiler Controller Quick Start Guide
4
24 Hot water supply temperature HWS-T
25 Boiler 1 alarm status BLR1-A
26 Boiler 2 alarm status BLR2-A
27 Boiler 3 alarm status BLR3-A
28 Boiler 4 alarm status BLR4-A
29 Boiler pump 1 status BP1-S
30 Boiler pump 2 status BP2-S
31 Boiler pump 3 status BP3-S
32 Boiler pump 4 status BP4-S
33 Secondary hot water pump 1 status SHWP1-
S
34 Secondary hot water pump 2 status SHWP2-
S
35 Secondary hot water pump 3 status SHWP3-
S
36 Secondary hot water pump 4 status SHWP4-
S
Table 3: Boiler controller point to point wiring diagram
(Part 3 of 3)
No Description Object
name

Verasys Boiler Controller Quick Start Guide
5
GROUND
TX-1
24 VA C
24V
COM
12 0VA C PO WER
120VAC
GROUND
PS-1
24 VA C
24V
COM
SA SA
1 2 4 8 16 32 64 12 8
ON
Ad dr ess :
SA
FC
OUT 9 OCOM 9 OUT 10 OCOM 10 OUT11 OCOM 11 OUT 12 OCOM 12 OUT 13 OCOM 13 OUT 14 OCOM 14 OUT 15 OCOM 15 OUT 16
ANAL OG OUTP UT
HOT
24V
COM
IOM5731
SA PWR COM + -
+ -
COM SHL D
SA/FC BUS
OCOM 16
OUT 1
OCOM 1
OUT 2
OCOM 2
OUT 3
OCOM 3
OUT 4
OCOM 4
OUT 5
OCOM 5
OUT 6
OCOM 6
OUT 7
OCOM 7
OUT 8
RELAY OUTPUT
OCOM8
FC EOL
IN
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
+
-
+
-
1
2
3
4
5
6
7
8
910
11
12
13
14
15
16
Table 4: IOM5731 point to point wiring diagram
(Part 1 of 2)
No Description Object Name JCI part
no
1Boiler 1 isolation valve
command BLR1-ISO-C Relay contact
2Boiler 2 isolation valve
command BLR2-ISO-C Relay contact
3Boiler 3 isolation valve
command BLR3-ISO-C Relay contact
4Boiler 4 isolation valve
command BLR4-ISO-C Relay contact
5Secondary hot water pump
1 command SHWP1-C RIBU1C
6Secondary hot water pump
2 command SHWP2-C RIBU1C
7Secondary hot water pump
3 command SHWP3-C RIBU1C
8Secondary hot water pump
4 command SHWP4-C RIBU1C
9To next SA device
10 From last SA device
11 Bypass valve output (to
pump VFD) BYP-O
12 Hot water mixing valve
output (to pump VFD) HWMIX-O Valve
13 Boiler or boiler-setpoint 4
output (to pump VFD) BLR4-O/ BLR4SP-O VFD
14 Boiler or boiler-setpoint 3
output (to pump VFD) BLR3-O/ BLR3SP-O VFD
15 Boiler or boiler-setpoint 2
output (to pump VFD) BLR2-O/ BLR2SP-O VFD
16 Boiler or boiler-setpoint 1
output (to pump VFD) BLR1-O/ BLR1SP-O VFD
Table 4: IOM5731 point to point wiring diagram
(Continued) (Part 2 of 2)
No Description Object Name JCI part
no
Figure 8: IOM5731 point to point wiring diagram

Verasys Boiler Controller Quick Start Guide
6
Setting the controller address using the local display
1. To access the menu, press ENT.
2. To navigate to the Controller menu use the up and down
arrows and press ENT.
3. Navigate to the Network section and press ENT.
4. Navigate to the Address section and press ENT.
5. The address defaults to 4. Press ENT again.
The address blinks.
6. To increase or decrease the address value, use the up or down
arrows.
7. To confirm the address value, press ENT.
The address stops blinking and the old address appears.
8. To refresh the screen, press the up or down arrows. The new
address appears.
9. Press ESC until you return to the main screen that shows the
system is operational.
Configuring sensors
To configure the installed sensors, complete the following steps:
1. Navigate to the Details menu.
2. Navigate to the Sensors section.
3. Select the installed sensors using the drop-down menus for each
parameter.
Commissioning the system
To activate the outputs and verify system operation, use the
Commissioning menu. From the Commissioning menu, change
Start Commissioning to Trigger and adjust outputs individually.
Configuration menu options
The following table describes the System Configuration menu on
the Smart Building Hub (SBH).
Technical specifications
Table 5: System Configuration menu options
(Part 1 of 2)
Menu option Description Range
Number of Boilers Sets the number of
boilers Adjustable: 1-4
Primary Pump Type Sets the type of primary
pumps in the system Adjustable:
• Constant Speed
• Variable Speed
Constant Primary
Pump Sets the pump configuration Adjustable:
• Dedicated
• Parallel
Number of Pumps Sets the number of
primary pumps Adjustable: 1-4
Primary Pump
Operation Type Sets the pumps operation type Adjustable:
• Duty/Standby
• Lead/Lag
Number of
Secondary Pumps Sets the number of secondary pumps (if
any)
Adjustable:
0-4
Secondary Pump
Operation Type Sets the pump operation type Adjustable:
• Duty/Standby
• Lead/Lag
Bypass Valve
Installed If there are no secondary pumps, this
sets the installation of a
bypass valve
Adjustable:
• No
• Yes
Enable Alarms This option sets the
enabling/disabling of
alarms
Adjustable:
• Disable
• Enable
Product code
numbers LC-VAC3000-0 Verasys 32 point 24 V Application Controller with Display
Supply
voltage 24 VAC, 20 VAC minimum / 30 VAC maximum, 50/ 60 Hz, power supply class 2
North America, safety extra-low voltage (SELV)
Europe
Power
consumption 20 VA maximum for LC-VAC3000-0 VArating does not include any power supplied to the
peripheral devices connected to binary outputs
(BOs) or configurable outputs (COs). This can
consume up to 12 VA for each BO or CO for a
possible total consumption of an additional 60 VA
maximum.
Ambient
conditions Operating: -20°C to 70°C (-4°F to 158°F); 10% to 95% RH noncondensing; pollution degree 2
Storage: -40°C to 85°C (-40°F to 185°F); 5% to 95%
RH noncondensing
Addressing BACnet® MS/TP: valid field controller device
addresses 4–127
Device addresses 0–3 and 128–255 are reserved
and not valid field controller addresses
Communica-
tions bus BACnet® MS/TP, through RS-485: 3-wire system bus between the supervisory
controller and field controller
4-wire sensor bus between controller, network
sensors and other SA devices, includes a lead to
source 15 VDC supply power from controller to bus
devices
Processor RX631 Renesas® 32-bit microcontroller
Memory 16 MB flash memory and 8 MB RAM
Table 5: System Configuration menu options
(Part 2 of 2)
Menu option Description Range

Published in U.S.A. www.johnsoncontrols.com
Verasys Boiler Controller Quick Start Guide
Verasys® and Johnson Controls® are registered trademarks of Johnson Controls
All other marks herein are the marks of their respective owners. © 2019 Johnson Controls
Building Technologies and Solutions
507 E. Michigan Street, Milwaukee, WI 53202
7
North American emissions compliance
United States
Canada
Mounting Horizontal on single 35 mm DIN rail mount
is preferred, or screw mount on flat surface
with three integral mounting clips on
controller. Mount the controller on a wall or
DIN rail inside an enclosure rated at least
IP20.
Housing Enclosure material: Polycarbonate
LEXAN® SABIC EXL9330
Dimensions (H x W
x D) 164 mm x 125 mm x 53 mm (6.45 in. x 4.92
in. x 2.08 in.) excluding terminals and
mounting clips.
Weight 0.5 kg (1.1 lb)
Compliance United States: cULus Listed, File
E107041, CCN
PAZX, UL 916, Energy Management
Equipment FCC Compliant to CRF47, Part
15, Subpart B, Class A
Canada: cULus Listed, File E107041, CNN
PAZX7 CAN/CSA C22.2 No.205, Signal
Equipment Industry Canada Compliant,
ICES-003
Europe: Johnson Controls declares that
this product is also in compliance with the
essential requirements and other relevant
provisions of the EMC Directive Declared
as Electronic Independently mounted
control, suitable for DIN rail mounting.
Intended to mount in remote panel. Type
1.C (Microinterruption), 330 V rated
impulse voltage. 125°C ball pressure test.
Australia and New Zealand: RCM Mark,
Australia/NZ Emissions Compliant
This equipment has been tested and found to comply with the limits
for a Class Adigital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when this equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
may cause harmful interference, in which case users will be required
to correct the interference at their own expense.
This Class (A) digital apparatus meets all the requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
