Lion (VL-EPMe-42) Reference Manual i
Hardware
Reference
Manual
REV. March 2019
Lion
(VL-EPMe-42)
Intel®Core™-based Single Board
Computer with Dual Ethernet,
Video, USB, SATA, Serial I/O,
Digital I/O, Trusted Platform
Module security, Counter/Timers,
Mini PCIe, mSATA, SPX, and
PCIe/104™ OneBank™ Interface

WWW.VERSALOGIC.COM
12100 SW Tualatin Road
Tualatin, OR 97062-7341
[phone]
Fax [phone]
Copyright © 2018-2019
VersaLogic Corp. All rights reserved.
Notice:
Although every effort is made to ensure this document is error-free, VersaLogic makes no representations
or warranties with respect to this product and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose.
VersaLogic reserves the right to revise this product and associated documentation at any time without
obligation to notify anyone of such changes.
*Other names and brands may be claimed as the property of others.

Product Release Notes
Rev 1.0 Production release for the Rev 1.0 board
Rev 1.1
Updated figure 22
Rev 1.2 Updated known issues section
Rev 1.3 Updated pin numbers on figure 13
Rev 1.4
Updated Web links
Rev 1.5 Updated manual to incorporate a no memory SKU
Rev 1.6
Updated schematic and table 10
Rev 1.7 Updated power connector part information
Rev 1.8 Updated V1 jumper information
Rev 1.9
Updated the J2 connector cable information in table 2
Support Page
The Lion Support Page contains additional information and resources for this product including:
Operating system information and software drivers
Data sheets and manufacturers’ links for chips used in this product
BIOS information and upgrades
VersaTech KnowledgeBase
The VersaTech KnowledgeBase contains useful technical information about VersaLogic products, and
product advisories.
Customer Support
If you are unable to solve a problem after reading this manual, visiting the product support page, or
searching the KnowledgeBase, contact VersaLogic Technical Support at [phone]. VersaLogic
support engineers are also available via e-mail at [e-mail].
Repair Service
If your product requires service, you must obtain a Returned Material Authorization (RMA) number by
calling 503-747-2261. Be ready to provide the following information:
Your name, the name of your company, your phone number, and e-mail address
The name of a technician or engineer that can be contacted if any questions arise
The quantity of items being returned
The model and serial number (barcode) of each item
A detailed description of the problem
Steps you have taken to resolve or recreate the problem
The return shipping address
Warranty Repair All parts and labor charges are covered, including return shipping charges for
UPS Ground delivery to United States addresses.
Non-warranty Repair All approved non-warranty repairs are subject to diagnosis and labor charges,
parts charges and return shipping fees. Specify the shipping method you
prefer and provide a purchase order number for invoicing the repair.
Note: Mark the RMA number clearly on the outside of the box before returning.

Contents
Introduction ...................................................................................................................1
Description..........................................................................................................................1
Features and Construction.....................................................................................1
Technical Specifications.....................................................................................................3
Thermal Considerations......................................................................................................3
Block Diagram....................................................................................................................4
Cautions..............................................................................................................................5
Electrostatic Discharge..........................................................................................5
Handling Care........................................................................................................5
Earth Ground Requirement....................................................................................5
Configuration and Setup...............................................................................................6
Initial Configuration ...........................................................................................................6
Basic Setup .........................................................................................................................6
BIOS Setup Utility..............................................................................................................7
Operating System Installation.............................................................................................7
Physical Layout.............................................................................................................8
Dimensions and Mounting..................................................................................................8
Lion Dimensions....................................................................................................8
Hardware Assembly...............................................................................................9
External Connectors ...........................................................................................................9
Lion Connector Functions and Interface Cables .................................................11
VL-CBR-4005 Connector Functions...................................................................13
User I/O Connector..............................................................................................13
On-board Battery.................................................................................................15
Auxiliary I/O Connector......................................................................................15
VL-CBR-4005 Dimensions .................................................................................16
Jumper Blocks .....................................................................................................17
Configuration Switches ....................................................................................................17
System Features..........................................................................................................19
Power Supply....................................................................................................................19
Power Connectors................................................................................................19
Power Requirements............................................................................................20
Power Delivery Considerations...........................................................................20
CPU...................................................................................................................................21
System RAM.....................................................................................................................21
Resetting BIOS to Factory Defaults .................................................................................21
Clearing CMOS RAM and RTC Registers....................................................................... 21

Real Time Clock (RTC)....................................................................................................22
Expansion Bus..................................................................................................................22
PCI....................................................................................................................... 22
PCIe/104*OneBank*............................................................................................23
Interfaces and Connectors .........................................................................................24
User I/O Connector...........................................................................................................24
COM Port Configuration (COM1, COM2).........................................................25
RS-485 Mode Line Driver Control......................................................................25
Serial Port Pinouts...............................................................................................25
Battery Connector.............................................................................................................26
VL-CBR-0203 External Battery Module.............................................................26
USB Interfaces..................................................................................................................27
LEDs.................................................................................................................................28
FPGA Controlled LEDs....................................................................................... 28
Power LEDs......................................................................................................... 28
Power Button....................................................................................................................28
Supported Power States.......................................................................................29
Pushbutton Reset ..............................................................................................................29
Speaker .............................................................................................................................29
Video Interfaces................................................................................................................29
DisplayPort..........................................................................................................30
Console Redirection ............................................................................................30
Ethernet.............................................................................................................................31
Ethernet Connectors ............................................................................................31
Ethernet Status LED............................................................................................32
SATA Port ........................................................................................................................34
PCIe Mini Card / mSATA..............................................................................................34
PCIe Mini Card LEDs .........................................................................................36
SPX Expansion Bus..........................................................................................................36
Thermal Considerations .............................................................................................38
Selecting the Correct Thermal Solution for Your Application ........................................38
Heat Plate.............................................................................................................38
System-level Considerations ...............................................................................39
CPU Thermal Trip Points....................................................................................40
Thermal Specifications, Restrictions, and Conditions ........................................41
Overall Restrictions and Conditions....................................................................41
Heat Plate Only Restrictions and Conditions:.....................................................41
Heat Sink Only Considerations: ..........................................................................41
Heat Sink with Fan Considerations:....................................................................41
EPMe-42 Thermal Characterization.................................................................................42
Test Results.......................................................................................................................43
Installing the VersaLogic Thermal Solutions...................................................................45
Installing the Passive Heat Sink ..........................................................................45
Installing the Heat Sink + Fan Assembly............................................................46
Installing the VL-HDW-408 Heat Pipe Block..................................................... 46
Appendix A – References............................................................................................48

Figures
Figure 1. Major Components and Connectors (Top Side)...............................................................................2
Figure 2. Major Components and Connectors (Bottom Side) .........................................................................3
Figure 3. Lion Board Block Diagram..............................................................................................................4
Figure 4. Lion Dimensions and Mounting Holes.............................................................................................8
Figure 5. Connector Locations (Top Side)......................................................................................................9
Figure 6. Connector Locations (Bottom).......................................................................................................10
Figure 7. VL-CBR-4005 Connectors.............................................................................................................12
Figure 8. Location and Pin Orientation of the User I/O Connector...............................................................14
Figure 9. Location and Pin Orientation of Auxiliary I/O Connector .............................................................15
Figure 10. VL-CBR-4005 Dimensions and Mounting Holes ........................................................................16
Figure 11. As-Shipped Jumper Settings ........................................................................................................17
Figure 12. Location of SW1 Configuration Switch Block.............................................................................18
Figure 13. J19 and VL-CBR-1205 Pin Numbering.......................................................................................20
Figure 14. Location and Pin Configuration of J12 Battery Connector ..........................................................26
Figure 15. VL-CBR-0203 Latching Battery Module.....................................................................................27
Figure 16. Ethernet Connector Pinout ...........................................................................................................32
Figure 17. Location of Ethernet Status LEDs................................................................................................33
Figure 18. EPMe-42EAP CPU Core Temperature Relative to Ambient Temperature..................................43
Figure 19. EPMe-42EBP CPU Core Temperature Relative to Ambient Temperature..................................43
Figure 20. EPMe-42ECP CPU Core Temperature Relative to Ambient Temperature..................................44
Figure 21. Thermal Heat Sink Solution Installation......................................................................................45
Figure 22. Thermal Fan Assembly Solution Installation ...............................................................................46
Tables
Table 1. Connector Functions and Interface Cables......................................................................................11
Table 2. VL-CBR-4005 Functions ................................................................................................................13
Table 3. User I/O Connector Pinout..............................................................................................................14
Table 4. Auxiliary I/O Connector Pinout ......................................................................................................16
Table 5. Jumper Summary.............................................................................................................................17
Table 6. Switch Setting Summary .................................................................................................................18
Table 7. J19 Main Power Connector Pinout..................................................................................................19
Table 8. PCI/104-Express*“A” OneBank Connector (PCIe/104*) Current Ratings .....................................22
Table 9. PCI/104-Express*“B” Connector (PCI) Current Ratings................................................................22
Table 10. PCIe/104* OneBank*Interfaces....................................................................................................23
Table 11. J13 User I/O Connector Pinout .....................................................................................................24
Table 12. COM1-2 Pinout –Connector J14...................................................................................................25
Table 13. COM3-4 Pinout – VL-CBR-4005 Connector J3...........................................................................26
Table 14. USB 3.0 J16, J20 Connector Pinout..............................................................................................27
Table 15. Supported Power States.................................................................................................................29
Table 16. mini DisplayPort Connector Pinout...............................................................................................30
Table 17. Ethernet 0 Connector Pinout .........................................................................................................31
Table 18. Ethernet 1 Connector Pinout .........................................................................................................31
Table 19. Ethernet Status LEDs ....................................................................................................................32
Table 20. SATA Port Pinout .........................................................................................................................34
Table 21. PCIe Mini Card / mSATA Pinout..................................................................................................34
Table 22. PCIe Mini Card LED States..........................................................................................................36
Table 23. SPX Expansion Bus Pinout ...........................................................................................................37

Table 24. CPU Thermal Trip Points..............................................................................................................40
Table 25. Temperature Monitoring Programs...............................................................................................40
Table 26. Absolute Minimum and Maximum Air Temperatures...................................................................41
Table 27. EPMe-42 Thermal Testing Setup..................................................................................................42

Lion (VL-EPMe-42) Reference Manual 1
Introduction
Description
Features and Construction
The Lion is a feature-packed single board computer (SBC) designed to support OEM applications
where high reliability and long-term availability are required. Its features include:
Intel*Core “Kaby Lake”, dual core
processor with clock rates up to 2.8
GHz
Integrated high-performance video. HD
Graphics 620 core - Gen-9 compute
architecture, 24 execution units, and
GPU Turbo Boost. Supports 3
independent displays. Supports
DirectX 12, OpenGL 4.4, OpenCL
2.0.Dual Mini DisplayPort* video
outputs
Up to 16 GB DDR3L memory, one
SO-DIMM socket
Dual Ethernet ports, auto-detect
10Base-T / 100Base-TX / 1000Base-T
Two USB 3.0 ports and four USB 2.0
ports
Trusted Platform Module
2 RS-232/422/485 serial ports
2 RS-232 serial ports
Three 8254 timer/counters
Eight digital I/O lines
1 SATA port, 6 Gb/s
Mini PCIe / mSATA socket, supports
Wi-Fi modems, GPS receivers, flash
storage, and other modules
SPX expansion
PC/104 form factor with PCIe/104*
OneBank*expansion
Customization available
The Lion is compatible with popular operating systems such as Microsoft*Windows*, Windows
Embedded, Linux and VxWorks*.
VL-EPMe-42 boards are subjected to complete functional testing and are backed by a limited five-
year warranty. Careful parts sourcing and US-based technical support ensure the highest possible
quality, reliability, service, and product longevity for this exceptional single-board computer (SBC).
Figure 1 and Figure 2 show the locations of the Lion board’s connectors and major components
on the top side and bottom side of the board, respectively.
1

Introduction
Lion (VL-EPMe-42) Reference Manual 2
Figure 1. Major Components and Connectors (Top Side)

Introduction
3Lion (VL-EPMe-42) Reference Manual
Figure 2. Major Components and Connectors (Bottom Side)
Technical Specifications
See the Lion Data Sheet for complete specifications.
Thermal Considerations
The operating temperature for the Lion is -40°C to +85°C, de-rated -1.1 °C per 305m (1,000 ft.)
above 2,300m (7,500 ft.). All Lion models include a rigid-mount heat plate thermal solution. Refer
to Chapter 6 for information on additional thermal solutions.

Introduction
Lion (VL-EPMe-42) Reference Manual 4
Block Diagram
Figure 3. Lion Board Block Diagram
USB1
2.0
USB2
2.0
PCIe Minicard
or mSATA
Dual
Clik-Mate
Mag Ethernet 1
GigE MAC/PHY
Ethernet 0
GigE PHY
Kaby Lake-U 2+2
SPI Flash
(Primary)
SATA
connector
SPX FPGA
A3P400-FGG144
LPC
PCIe
PCIe-to-PCI
Bridge
Power Input
(+5V)
Regulators & Reset
RST_BTN#
GPIOs (FPGA reprog)
HSIO15 (PCIe 11/SATA1B)
USB 2.0 7
USB 2.0 Port 1
SPI I/F
HSIO11 (SATA 0)
SPI Flash
(backup)
BIOS & ME Flash
XDP
(ITP)
Mag
SMB
Key :
DDR3 (x64) Chan A
HSIO1 (USB 3.0 1)
SMBus
HSUART (1,2)
HSUART (3)
HSIO5 (PCIe 1)
I2C (1)
USB 2.0 3,4,5,6
SDIO
XDP/JTAG
LPC
GPIOs
PCIe CLK0
PCIe CLK1
PCIe CLK2
PCIe CLK3
PCIe CLK4
PCIe CLK5
Bus Switches
SPKR
I2C (0)
FAN
CONN
Control
FANTACH
mini-DP
RTC
BATT MON
Alert to FPGA
Ethernet Status LEDs (x2)
DDI1(DP/HDMI)DP++
SATA
connector
USB 2.0 Port 2
USB 2.0 8
USB 2.0 9
User I/O
PLED
On/Off
PB
RST_BTN# PWR_BTN#
CBR-4005Paddleboard
USB2
2.0
USB3
2.0
AUX
Connector
Batt
I2C
XCVR
COM
CONN
BATT
CONN
USB2(0)
USB2(1)
PCIex1(0)
PCIex1(1)
PCIex1(2)
PCIex1(3)
SMBus
I210
I219
Unavailable
Unavailable
Minicard
XIO2001
H
OSC
HSIO9 (PCIe 5)
HSIO10 (PCIe 6)
HSIO6 (PCIe 2)
HSIO2 (USB 3.0 2)
HSIO12 (SATA 1)
HSIO16 (PCIe 12/SATA2)
Dediprog
Header SD Socket
TPM
AUX/DDC
mux
Reset
PB
PCIe/SATA
E-Mux
SATA
PCIe
Temperature
Sensor
XCVR COM
CONN
SIO8 (GBE/PCIe 4)
eeprom
SMLink0
USB
Type C
USB Type C
Cntrl & Mux
USB
Type C
mini-DP
DP++
AUX/DDC
mux
DDI2(DP/HDMI)
Bus Switches
PWR_BTN#
spkr
PeripheralOn-Board
DDR3L
SDRAM
USB Type C
Cntrl & Mux
SVID to CPU
PM Signals to CPU
PCIe/104 Express
One-Blade
Stack-Down Only

Introduction
5Lion (VL-EPMe-42) Reference Manual
Cautions
Electrostatic Discharge
CAUTION:
Electrostatic discharge (ESD) can damage circuit boards, disk drives, and other
components. Handle circuit board at an ESD workstation. If an approved station is not
available, wearing a grounded antistatic wrist strap provides some measure of
protection. Keep all plastic away from the board, and do not slide the board over any
surface.
After removing the board from its protective wrapper, place the board on a grounded,
static-free surface, component side up. Use an antistatic foam pad if available.
Ship and store the board inside a closed metallic antistatic envelope for protection.
Note: The exterior coating on some metallic antistatic bags is sufficiently conductive to cause excessive
battery drain if the bag comes in contact with the bottom side of the Lion.
Handling Care
CAUTION:
Avoid touching the exposed circuitry with your fingers when handling the board. Though
it will not damage the circuitry, it is possible that small amounts of oil or perspiration on
the skin could have enough conductivity to cause the contents of CMOS RAM to
become corrupted through careless handling, resulting in CMOS resetting to factory
defaults.
Earth Ground Requirement
CAUTION:
All mounting standoffs (four on PC/104 boards, eight on EBX and EPIC boards) should
be connected to earth ground (chassis ground). This provides proper grounding for EMI
purposes.

Lion (VL-EPMe-42) Reference Manual 6
Configuration and Setup
Initial Configuration
Use the following components for a typical development system:
Lion (VL-EPMe-42) computer
VL-ATX power supply
Display with DisplayPort input
Standard I/O paddleboard (VL-CBR-4005)
USB keyboard and mouse
USB CD-ROM drive (optional)
USB SSD or floppy disk drive (optional)
VL-HD35-xxx SATA hard drive (optional)
Use the following VersaLogic cables:
VL-EPH-V6 Mini DisplayPort converter (optional for LVDS)
VL-CBR-2032 Mini DisplayPort to VGA adapter (optional)
VL-CBR-0702 – SATA data cable
VL-CBR-1205 – Main power cable
Install Heat Sink VL-HDW-406 and Fan Assembly VL-HDW-413.
You will also need an operating system (OS) installation CD-ROM.
Basic Setup
The following steps outline the procedure for setting up a typical development system. The Lion
should be handled at an ESD workstation or while wearing a grounded antistatic wrist strap.
Before you begin, unpack the Lion and accessories. Verify that you received all the items you
ordered. Inspect the system visually for any damage that may have occurred in shipping. Contact
[email protected]om immediately if any items are damaged or missing.
Gather all the peripheral devices you plan to attach to the Lion and their interface and power
cables.
Attach standoffs to the board to stabilize the board and make it easier to work with.
1. Install Memory (This product includes 0 memory SKUs. This step assumes a no memory
product is being configured)
Insert the supported DDR3L DRAM module into SO-DIMM socket J2 on the bottom of the
board and latch it into place.
2. Attach Cables and Peripherals
Attach a DisplayPort enabled display to one of the Mini DisplayPort connectors at J6 or
J21. (The VL-CBR-2032 mini DisplayPort to VGA adapter can be used as an alternate
option for VGA displays.)
Plug the VL-CBR-4005 paddleboard into Main User I/O connector.
2

Configuration and Setup
7Lion (VL-EPMe-42) Reference Manual
Plug a USB CD-ROM drive, USB keyboard, and USB mouse into any of the USB
connectors at J3 and J4 of the paddleboard.
Plug the SATA data cable VL-CBR-0702 into one of the SATA connectors. Attach a hard
drive to the connector on the cable.
Optionally, attach a LAN cable to one of the Ethernet connectors on the Lion using the
VL-CBR-1604 dual RJ-45 adapter cable.
3. Install Thermal Solution
See Installing the VersaLogic Thermal Solutions later in this manual
4. Attach Power
Plug the power adapter cable VL-CBR-1205 into socket J19. Attach the motherboard
connector of the ATX power supply to the adapter.
5. Review Configuration
Before you power up the system, double-check all the connections. Make sure all cables
are oriented correctly and that there is adequate power to the VL-EPMe-42 and peripheral
devices.
6. Power On
Turn on the ATX power supply and the video monitor. The presence of a video signal
indicates proper configuration of the system.
7. Select a Boot Drive
During startup, press <CTRL> <B> to display the boot menu. Insert the OS installation CD
in the CD-ROM drive and select to boot from the CD-ROM drive.
8. Install Operating System
Install the operating system according to the instructions provided by the operating
system manufacturer. (See Operating System Installation.)
BIOS Setup Utility
Refer to the BIOS Reference Manual (available on the Lion Support Page) for information on
accessing and configuring settings in the BIOS Setup utility. The BIOS Reference Manual
contains descriptions of all BIOS menus, submenus, and configuration options.
Operating System Installation
The standard PC architecture used on the VL-EPMe-42 makes the installation and use of most of
the standard x86-based operating systems very simple. The operating systems listed on the
VersaLogic OS Compatibility Chart use the standard installation procedures provided by the
maker of the OS. Special optimized hardware drivers for a particular OS, or a link to the drivers,
are available at the Lion Product Support Page.

Lion (VL-EPMe-42) Reference Manual 8
Physical Layout
Dimensions and Mounting
Lion Dimensions
The Lion complies with PC/104-Plus dimensional standards. The figure below shows the boards
dimensions to help with pre-production planning and layout.
Figure 4. Lion Dimensions and Mounting Holes
(Not to scale. All dimensions in inches.)
3

Physical Layout
9Lion (VL-EPMe-42) Reference Manual
Hardware Assembly
The Lion provides both PCI and PCIe/104 OneBank connectors for adding expansion modules to
the bottom of the stack.
The entire assembly can fit on a tabletop or be secured to a base plate. When bolting the unit
down, make sure to secure all four standoffs to the mounting surface to prevent circuit board
flexing. Standoffs secure the top circuit board using four pan head screws. Standoffs and screws
are available as part number VL-HDW-105.
An extractor tool is available (part number VL-HDW-203) to separate the expansion modules from
the stack. Use caution when using the extractor tool not to damage any board components.
External Connectors
Figure 5. Connector Locations (Top Side)

Physical Layout
Lion (VL-EPMe-42) Reference Manual 10
Figure 6. Connector Locations (Bottom)

Physical Layout
11 Lion (VL-EPMe-42) Reference Manual
Lion Connector Functions and Interface Cables
The table below provides information about the function, mating connectors, and transition cables
for Lion connectors. Page numbers indicate where additional information is available.
Table 1. Connector Functions and Interface Cables
Connector
(Note)
Function Mating Connector Transition Cable Cable Description
J2
DDR3L SO-DIMM
—
—
—
J3
COM Ports 3 & 4
Molex 501330-1000
VL-CBR-1014
12” 1mm 10-pin Pico-
Clasp to dual DB-9 Cable
J4
Dual Gigabit
Ethernet
Molex 503149-1600
VL-CBR-1604
12” 16-pin to dual RJ-45
Ethernet cable
J6
Mini DisplayPort 1
—
—
—
J7
PCIe/104
OneBank Stack
Down
—
— —
J8
PCI Stack Down
AMP 1375799-1
—
—
J10
SATA
Standard SATA
VL-CBR-0702
20” SATA Cable
J11
PCIe Minicard /
mSATA socket
Mini PCIe card or
VL-MPEs-F1E series
mSATA Flash Drive
—
—
J12 Battery connector Molex 501330-0200 mating
connector housing
Molex 501334-0100 mating
connector crimp pin for 28-
32 gauge wire
—
—
J13
User I/O: USB,
PLED, power LED,
push-button reset,
power button, PC
speaker, battery
input, I2C, GPIO
Molex 501189-4010
VL-CBR-4005A
12" 1 mm Pico-Clasp
Cable 40-pin to 40-pin on
VL-CBR-4005B
paddleboard
J14
COM Ports 1 & 2
Molex 501330-1000
VL-CBR-1014
12” 1mm 10-pin Pico-
Clasp to dual DB-9 Cable
J16
Micro USB 3.0
USB 3.0 Micro-C
VL-CBR-2402
USB 3.0 Type-C to Type-A
socket cable
J17 SPI
Molex 501330-0900
VL-CBR-0901
8” 9-pin Pico-Clasp to Dual
SPX (SPI) Cable
J18
Heat Sink and Fan
Assembly Provided with HDW-413 fan
assembly (if used)
VL-HDW-413
Fan power cable with 3-pin
connector
J19
Main power input
Molex 51353-1200
VL-CBR-1205
Interface from standard
ATX power supply
J20
Micro USB 3.0
USB 3.0 Micro-C
VL-CBR-2402
USB 3.0 Type-C to Type-A
socket cable
J21 Mini DisplayPort 2 — VL-CBR-2031
VL-CBR-2033
VL-CBR-2032
36” miniDisplayPort to
MiniDisplayPort
miniDisplayPort to HDMI
Active Adapter, 6”
miniDisplayPort to VGA
adapter, 6”
J23 Micro SD socket VL-F41-xxxx micro SD
Flash Drive (SLC)
— —

Physical Layout
Lion (VL-EPMe-42) Reference Manual 12
Figure 7. VL-CBR-4005 Connectors

Physical Layout
13 Lion (VL-EPMe-42) Reference Manual
VL-CBR-4005 Connector Functions
Table 2. VL-CBR-4005 Functions
Reference
Function
PCB Connector
Description
B1
Provides power to CMOS RAM and
RTC registers when main power is
off.
–— Back-up battery
J1 Paddleboard adapter Molex 501571-4007 1 mm, 40-pin
keyed header
J2 Auxiliary I/O (I
2
C,
GPIO, Ethernet
LED, LED power)
FCI 98414-F06-20ULF 2 mm, 20-pin
keyed header
J3
USB1 (top), USB2 (bottom)
USB Type A
USB Host
J4
USB3 (top), USB4 (bottom)
USB Type A
USB Host
D1
Programmable LED (top)
Power LED (bottom)
LED –—
S1
Power button
Pushbutton
–—
S2
Reset button
Pushbutton
–—
SP1
Speaker
Piezo speaker
–—
User I/O Connector
The 40-pin J13 I/O connector incorporates the signals for the following:
Four USB ports
Eight GPIO lines
Three LEDs (two Ethernet link status LEDs and a programmable LED)
I2C clock and data signals
Push-button power switch
Push-button reset switch
Speaker output
This connector uses IEC 61000-4-2-rated TVS components to help protect against ESD damage.
Table 3 provides the pinout of the user I/O connector.
