VersaLogic VL-EPM-31 Quick user guide

Hardware
Reference
Manual
DOC. REV. 25 Jan 2017
BayCat
(VL-EPM-31)
Intel®Atom™-based Single
Board Computer with Dual
Ethernet, Video, USB, SATA,
Serial I/O, Digital I/O, Trusted
Platform Module security,
Counter/Timers, Mini PCIe,
mSATA, PCI/104-Plus
Interface, and SPX.

EPM-31 Hardware Reference Manual ii
WWW.VERSALOGIC.COM
12100 SW Tualatin Road
Tualatin, OR 97062-7341
[phone]
Fax [phone]
Copyright © 2016-2017 VersaLogic Corp. All rights reserved.
Notice:
Although every effort has been made to ensure this document is error-free, VersaLogic makes no
representations or warranties with respect to this product and specifically disclaims any implied warranties
of merchantability or fitness for any particular purpose.
VersaLogic reserves the right to revise this product and associated documentation at any time without
obligation to notify anyone of such changes.
PC/104 and the PC/104 logo are trademarks of the PC/104 Consortium.

EPM-31 Hardware Reference Manual iii
Product Release Notes
Release 1.0
January 2016
First production release
Release 1.1
April 2016
Added information regarding I2C support to Table 8, Table 19, and Table 20.
Release 1.2
August 2016
Updated caption for Figure 23, Updated signal information for pins 6 and 14
in table 14.
Release 1.3
October 2016
Added ISA IRQ information.
Release 1.4
January 2017
Updated terminology for updating RTC registers
Technical Support
The EPM-31 support page, at http://www.versalogic.com/private/baycatsupport.asp, contains
additional information and resources for this product including:
Reference Manuals (PDF format)
Operating system information and software drivers
Data sheets and manufacturers’ links for chips used in this product
BIOS information and upgrades
Utility routines and benchmark software
VersaAPI Version 1.2.x
This is a private page for EPM-31 users that can be accessed only be entering this address
directly. It cannot be reached from the VersaLogic homepage.
The VersaTech KnowledgeBase is an invaluable resource for resolving technical issues with
your VersaLogic product.
If you have additional questions, contact VersaLogic Technical Support at [phone].
VersaLogic support engineers are also available via e-mail at [email protected].
REPAIR SERVICE
If your product requires service, you must obtain a Returned Material Authorization (RMA)
number by calling [phone].
Provide the following information:
Your name, the name of your company, your phone number, and e-mail address
The name of a technician or engineer that can be contacted if any questions arise
Quantity of items being returned
The model and serial number (barcode) of each item
A detailed description of the problem
Steps you have taken to resolve or recreate the problem
The return shipping address

EPM-31 Hardware Reference Manual iv
Warranty Repair All parts and labor charges are covered, including return shipping
charges for UPS Ground delivery to United States addresses.
Non-warranty Repair All non-warranty repairs are subject to diagnosis and labor charges,
parts charges and return shipping fees. Specify the shipping method
you prefer and provide a purchase order number for invoicing the
repair.

Note: Mark the RMA number clearly on the outside of the box before returning. Failure to do
so can delay the processing of your return.
RoHS Compliance
The EPM-31 is RoHS-compliant.
ABOUT ROHS
In 2003, the European Union issued Directive 2002/95/EC regarding the Restriction of the use of
certain Hazardous Substances (RoHS) in electrical and electronic equipment.
The RoHS directive requires producers of electrical and electronic equipment to reduce to
acceptable levels the presence of six environmentally sensitive substances: lead, mercury,
cadmium, hexavalent chromium, and the presence of poly-brominated biphenyls (PBB) and poly-
brominated diphenyl ethers (PBDE) flame retardants, in certain electrical and electronic products
sold in the European Union (EU) beginning July 1, 2006.
VersaLogic Corporation is committed to supporting customers with high-quality products and
services meeting the European Union’s RoHS directive.
Cautions
ELECTROSTATIC DISCHARGE
Electrostatic discharge (ESD) can damage boards, disk drives and other components. The circuit
board must only be handled at an ESD workstation. If an approved station is not available, some
measure of protection can be provided by wearing a grounded antistatic wrist strap. Keep all
plastic away from the board, and do not slide the board over any surface.
After removing the board from its protective wrapper, place the board on a grounded, static-free
surface, component side up. Use an antistatic foam pad if available.
The board should also be protected inside a closed metallic anti-static envelope during shipment
or storage.

Note:
The exterior coating on some metallic antistatic bags is sufficiently conductive to cause
excessive battery drain if the bag comes in contact with the bottom-side of the EPM-31.
LITHIUM BATTERY
To prevent shorting, premature failure or damage to the lithium battery, do not place the board on
a conductive surface such as metal, black conductive foam or the outside surface of a metalized
ESD protective pouch. The Lithium battery may explode if mistreated. Do not recharge,
disassemble, or dispose of in fire. Dispose of used batteries promptly.

EPM-31 Hardware Reference Manual v
MOUNTING SUPPORT
The single board computer must be supported at all four mounting points to prevent excessive
flexing when expansion modules are attached and removed. Flex damage caused by excessive
force on an improperly mounted circuit board is not covered under the product warranty. See
page 15 for more details.
EARTH GROUND REQUIREMENT
All mounting standoffs should be connected to earth ground (chassis ground). This provides
proper grounding for EMI purposes. Figure 1 shows the locations of the board’s mounting holes.
All mounting holes identified in Figure 1 must be connected to earth ground.
Figure 1. Attaching the EPM-31 to Earth Ground

EPM-31 Hardware Reference Manual vi
