Versapers EMOTION 4G User manual

ENG
Terms of parts How to assemble How to use
Precautions for safe use Cautions during operation
Before requesting for repair
020104
05 06 08
09 10 11
Versapers Slowjuicer for Household Use
1. Read ‘Precautions for safe use’ (Page 6) and use the appliance properly.
2. After you finish reading the manual, keep it in a convenient location for future reference.
3. Use this apliance only in areas which have the correct power supply and voltage.
4. Any quality improvements are subject to change without notice.
Juice Cap and
Extraction Packing
When squeezing screw
stops during operation
Product Specifications /
Warranty

14
15
10
5
7
Pusher
Hopper
Squeezing screw
Fine Strainer
Coarse Strainer
Spinning Brush
Silicon Brush
Chamber
Pulp Outlet
Juice Outlet
Juice Cap
Pulp Container
Juice Container Lid
Base
Juice Container
Small Cleaning Brush
Cleaning Brush
Operating Switch
9
10
11
12
13
14
15
16
Power Cord
17
18
1
2
3
4
5
6
7
8
8-1
8-2
1
2
3
4
6
8
8-1
9
11
13
17
16
Terms of parts
18
Terms of parts
8-2
12
Instruction Manual
EN/NL

02 03
12 3 4
!
!
How to assemble
5
TIP
Assemble the strainer under the groove of spinning brush
just as in the picture.
After fitting the hopper on the chamber, turn it clockwise
until it is locked completely.
Mount the chamber set on the base.Assemble each part in its proper place by
turning it left and right in the chamber just
as in picture no.1.
Spinning
brush
grooves
Squeezing
screw
Spinning brush groove
Assemble the squeezing screw as in the
picture above.
Lock the squeezing screw by turning it and push it in
the spinning brush grooves.
If the chamber set is not correctly assembled, the chamber can not be closed.
* If the strainer is not placed
below the groove, the hopper
can not be locked.
Even if the hopper is
assembled in the
opposite direction,
the juicer can still be
operated.
The silicone packing can be
detached and cleaned.

04
1
3
2
How to use
ON
REV
정지상태
Stop
[On]
On
[Rev]
Reverse
누름
작동스위치
ON
REV
[On]
On
[Rev]
Reverse
Press
Press the [ON] button to start.
Insert ingredients gradually in the hopper
chute and gently press with the pusher.
After extraction is completed, place the
switch in stop position to stop.

05
Juice Cap and Extraction Packing
Extraction packing
CLOSED
Juice cap
Juice cap
Juice cap
packing
1
3
2
Juice Cap
Extraction Packing
This is the cap of juice outlet in the chamber.
Close the juice cap and fill up with juice in the chamber with various ingredients. You can easily
make mixed fruit juice or vegetable juice.
This is the pulp stopper made of silicone at the bottom of the chamber.
Make sure to always close the extraction packing before use, as shown below.
For cleaning, open the extraction packing and clean with the small cleaning brush.
Close juice cap and press the
[ON] button to start.
When juice starts filling up the
chamber, you can mix banana,
soaked nuts, soft berries, etc.
and liquids such as milk, etc. as
well as vegetables and fruits like
smoothies.
Open juice cap to pour out as
much as you need and close
without any drops.
The juice cap hinge can be
damaged with improper use or if
twisted. Please handle with care.

APPLIANCES CAN BE USED BY PERSONS WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE IN
A SAFE WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL
NOT PLAY WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE
MADE BY CHILDREN. THIS APPLIANCE SHALL NOT BE USED BY CHILDREN. KEEP THE
APPLIANCE AND ITS CORD OUT OF REACH OF CHILDREN.
NEVER DISASSEMBLE THE CHAMBER SET DURING OPERATION OR INSERT FINGERS,
FOREIGN OBJECTS SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE OR JUICE
OUTLET. It may cause injury, accident or failure.
FOR SAFETY, YOU MUST USE A GROUNDED POWER OUTLET. ALSO, DO NOT DO THE
GROUNDING ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.
It could cause electric shock, fire, malfunction or explosion. Be sure to use the electrical outlet with ground connection.
DO NOT OPERATE THE SWITCH WITH WET HANDS. It may cause an electric shock or fire.
DO NOT MOISTEN THE BASE OR SPLASH WATER ON THE BASE.
Be careful not to let any liquids or other substances get into the switch on the appliance.
WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED OR THE POWER PLUG
BECAME LOOSE, DO NOT OPERATE IT. It may cause electric shock, fire or injury.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR BY
YOURSELF. DO NOT INSERT FINGERS, FOREIGN SUBSTANCES OR OBJECTS SUCH AS
PINS INTO GAPS OR HOLES IN THE BASE.
It may cause a fire, electric shock or failure. For any technical support, contact the authorized local Customer Care
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER
ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
If the power cord is damaged, it may cause electric shock or fire.
PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL SOCKET.
It may cause an electric shock or a fire.
DO NOT USE OTHER THAN 230V - 240V AC. It may cause electric shock, fire or abnormal performance.
If the voltage is different, it may shorten the life of the motor or cause a failure.
DO NOT PLUG IN NOR UNPLUG WITH WET HANDS. It may cause electric shock or injury.
06
Warning
Caution
Precautions for safe use
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as follows.
When violating the instructions on the warning labels, it may cause
serious injury, death or damage to the appliance.

DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY. It may cause injury or a failure.
NEVER PUT A FINGER, FORK OR SPOON, ETC. INTO JUICE OUTLET. It may cause injury or a failure.
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE POWER CORD INTO ITS SLOT.
OPEN THE WINDOW TO VENTILATE FULLY AND IMMEDIATELY. It may cause injury or a
IF THE SQUEEZING SCREW ROTATION IS STOPPED IN NORMAL OPERATION, PRESS
[REVERSE/REV] BUTTON AND HOLD FOR 2~3 SECONDS AND THEN AFTER REVERSE
OPERATION IS COMPLETELY STOPPED, PRESS [ON] BUTTON AGAIN. If such a stop event
continues during the operation, the parts may be damaged and performance may be deteriorated due to overheating in a
motor. When the problem continues, immediately stop the appliance and contact the local Customer Care Center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE BASE, DISASSEMBLE THE
CHAMBER SET OR PARTS AND TRY TO LOCK THEM. It may cause an injury or a failure. Any act of
event needed, switch off first and unplug the power cord.
WHEN USING THE APPLIANCE, BE CAREFUL FOR A NECKTIE, LONG NECKLACE, SCARF,
ETC. NOT TO BE ENTANGLED INTO HOPPER CHUTE. It may cause injury, failure or breakage.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE. It may cause injury or failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME. It may cause
a motor failure due to overheating. Cool it down sufficiently about 5 minutes and operate it again.
WHEN PLACING INGREDIENTS INTO THE HOPPER CHUTE, ONLY USE THE PUSHER
PROVIDED. It may cause injury or failure.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE OR DROP IT. It may cause electric shock,
fire or damage.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL OR EXCESSIVE HEATING,
SMOKE, STOP USING IMMEDIATELY AND CONTACT THE LOCAL CUSTOMER CARE
CENTER. When using a new appliance, it gives off a smell and the smell disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE. ALWAYS DISCONNECT THE APPLIANCE
FROM THE SUPPLY IF IT IS LEFT UNATTENDED AND BEFORE ASSEMBLING,
DISASSEMBLING OR CLEANING. WHEN UNPLUGGING THE POWER CORD, MAKE SURE
TO HOLD THE POWER CORD. Pulling on the wire to unplug may cause electric shock or fire.
DO NOT WASH AT HIGH TEMPERATURES OF 80ºC OR HIGHER. DO NOT PUT THE
APPLIANCE IN A DISHWASHER, A DRYER OR A MICROWAVE ETC. It may cause a failure or parts
deformation.
THE APPLIANCE WEIGHS ABOUT 6KG (13.6LB). WHEN MOVING THE APPLIANCE,
ENSURE TO MOVE IT HOLDING GRIPS TIGHTLY AT THE BASE BOTTOM WITH BOTH
HANDS. If attempting to hold chamber or the edge of the base, the base falls causing an injury or failure.
07
Caution When violating the labeling requirement, it may cause serious injury or damage to the appliance.

08
Note Frozen fruit or withered ingredients that have been stored in the refrigerator for a long time
may give us less extracted amount or may even be impossible. Some fruits may deliver only
pulp or puree but no juice at all.
We recommend you drink green vegetable juice and fruit juice immediately after extraction
rather than keeping them for long time.
You may use the appliance for crushing spices (garlic, red pepper) in small teaspoon
amounts, but not for grinding grains. It may cause damage or failure.
Do not re-squeeze residues expelled through the pulp outlet.
Soft fruits can be re-squeezed.
Do not operate the appliance before putting in the ingredients.
Cautions during operation
Fruits with hard seeds such as apricot, cherries, plum, peach etc. that are hard to chew with our
teeth should be pitted before juicing.
-
Do not use the appliance for more than 30 minutes continuously.
It may cause a failure due to overheating of the motor.
When using continuously, stop it and leave it 5 minutes of interval and then you may use it again.
-
Never insert a finger, fork or spoon etc. into juice outlet during the operation.
Utensils such as chopsticks etc. inserted into the Juice outlet during operation may get stuck in the
spinning brush and may cause damage of parts.
-
Do not press the ingredients with anything except the pusher.
It may stuck to the squeezing screw and cause injury and failure.-
Do not operate the switch with wet hands.
It may cause electric shock or fire. Do not put foreign objects near the switch.-
For stalk vegetables with strong fiber such as celery, parsley etc. cut them into a small size about
2~3cm or ideally 1 cm length, before putting them into the hopper chute.
-
Do not insert sesame seeds, coffee beans, bark of the tree, Chinese pepper, etc. which cannot be
extracted.
-
Do not put in fruits preserved in alcohol, sugar, honey, etc. (grapes, apricot, berries, etc) It may cause
damage or failure.
-

09
1
2
Note
When the squeezing screw stops during operation
<REV>
<ON>
Caution when using the reverse function
<ON>
<REV>
<STOP>
Be sure to let the squeezing screw come to a complete stop before you
switch the direction of the rotation.
If after following the directions above the
squeezing screw still doesn't rotate
forward, please unplug the power cord,
disassemble the chamber set and clean
it. Then try it again.
When using the [ON] or [Rev]
b u t t o n , m a k e s u r e t h a t t h e
squeezing screw stops completely.
[Rev] is the button to push back the
ingredients upward.
[Rev] only works while pressing the
button, and the rotation of the
squeezing screw stops If you release
the button.
Press the [On] button to
operate after reverse operation
completely stops.
Press the [Rev] button on the
operating switch for 3~5 seconds
and stop it. Repeat this 2~3times.

The Appliance does not work.
Make sure that the power cord is properly plugged in.
Check if the hopper is assembled properly. If the hopper has not been locked into place, the
appliance will not operate as a safety feature.
Check if the appliance is assembled according to the directions in the manual.
Refer to instructions for assembly in the manual or consult with your Customer Service Center for
additional assistance.
The hopper does not open.
There might be a lot of residues inside. Put the lever in half-closed position, and press [Extract]
button to release residues. Press [Reverse] button for 3~4 seconds and stop it. Repeat this
process 2~3times.
Have you placed any foreign substances or solid objects (hard seed such as persimmon seed) in
the juicer?
Press [Reverse] button and push the ingredients back up toward the hopper chute.
Do not attempt to open by force. Please contact your local Customer Service Center for
assistance.
The appliance stops during normal operation.
Have you inserted heavy loads or large pieces of ingredients into the appliance?
Refer to page 9 of the manual and follow the guideline for using the [Reverse] button.
If the issue is not resolved after following the above process, please contact your local Customer
Service Center.
Juice leaks over the base.
Have you inserted a lot of ingredients into the hopper chute? If you insert a large amount of
ingredients compared to the pulp outlet, the packing is slightly pushed away, so the juice leaks out
of the gap. Do not put too much ingredients by force and just add them gradually for extraction.
Also check from time to time if the pulp exit is running smoothly during operation.
The Chamber shakes when squeezing.
Slight shaking may be caused by the motor.
Depending on the texture of the ingredient, there may be slight to more pronounced shaking of
This is a normal phenomenon as the squeezing screw rotates and it is not a malfunction. Hard
ingredients (e.g carrot, potato, radish, beet, etc.) may cause more shaking than soft ingredients.
There are fine lines or scratch marks around the squeezing screw.
These are molding marks resulting from the normal manufacturing process.
This is a normal product and there is no problem for use.
If you need additional information, please contact your local Customer Service Center or visit
www.versapers.com. When applying for after-sales service, please have the manufacturer’s
serial number or bar code available.
10

You can register your purchase on the website of Versapers. http://versapers.com/warranty. Your
warranty is executed at the local distributor where you have purchased the product.
Always keep your invoice or receipt as original proof of purchase in case of making a claim on the
warranty. This certifies that the Versapers Slow Juicer is warranted by Versapers to be free from
defects in material construction and workmanship.
The motor warranted for five (10) years and other parts are warranted for two (2) years from the date
of purchase to the original purchaser.
This warranty does not apply to damages caused by accident, misuse, abuse, commercial use,
alteration, failure to follow operating instructions, or damage caused by parts or service unauthorized
by Versapers.
Damages caused by transportation must be claimed with carrier. Versapers disclaims all
responsibilities for consequential damages from incidental losses caused by use of this appliance. If
service should be necessary, please contact our local Customer Care Center for technical support.
11
Product Specifications
Product Name
Model Name
Rated Voltage
Rated Frequency
Rated Power
Consumption
Versapers Slow Juicer
RPM
Emotion 4G
230-240 V
50 Hz
150 W
43 rpm
Warranty
Cord Length
Motor
Fuse
Weight
Outward
Dimension
Rated
1.4 m
Operating Hour
Single-phase induction motor
250 V 5 A
6.2 kg (13.6 lb)
Width 251 mm
Length 178 mm
Height 411 mm
Less than 30 minutes
Manufacturer : Versapers
Versapers webpage : www.versapers.com

4G_V1.0_ENCopyright© All Rights Reserved by Versapers
Juice fruits like apple, pear, kiwi, cucumber, etc. put them with seeds
and peels. However, apple seeds contain toxicity, so it better to
remove them.
Apple, pear, kiwi,
cucumber
∗This is a reference about how to trim the ingredients, if you have allergies, please choose ingredients which are
suitable for you.
∗Please refer to the recipe book for the product usage of each ingredient.
Also ideal to make juice from soft fruits like banana, strawberry, kiwi to
achieve a consistency similar like a smoothie or soup.
Fine Strainer
Fine strainer has tiny and fine holes good to make clean juice.
Coarse strainer
Coarse strainer has larger holes so is good to make thick juice
with flesh in it.
Separate each grape from the cluster. Peel the pomegranate and use
flesh only.
Pomegranate,
grapes
Peel off the skin of watermelon, orange, grapefruit and cut them in the
right size.
Watermelon, orange,
grapefruit
Cut fibrous ingredients in small sized chunks less than 3 cm. The
shorter you cut the fibres, the easier it is for juicing.
Water parsleys,
angelica, celery, kale
Cut these ingredients in short pieces, a handfull at a time. Add carrot
afterwards to push the pulp trough.
Wheatgrass, chives
Fruits like mango, cherry, peach, or plum, etc. have hard seeds which
are hard to swallow. Those seeds might cause stoppage or parts
damage, so they must be removed before using it.
Mango, cherry,
peach
www.versapers.com
A Dutch brand, made in South Korea
Which strainer to use, fine or coarse?
How to trim the ingredients?
