Vertu SIGNATURE TOUCH User manual

HANDMADE IN ENGLAND
S I G N A T U R E T O U C H
U S E R G U I D E V E R S I O N 1 . 0

Contents
Introduction 5
Your Signature Touch phone 5
Help and support 5
Safety 6
Safety 6
Your phone 7
Package contents 7
Features and keys 7
Antenna locations 9
Headset 9
Change the volume 10
Getting started 11
Insert the SIM card 11
Charge the phone 12
Switch the phone on or off 13
Touch screen actions 14
Start-up process 15
Use your phone when it is locked 16
Explore 17
About the home screen 17
Status and notification bar 17
Status and notification icons 18
Clock widget 19
Back, home and recent apps 19
Add widgets to the home screen 19
Favourites tray 20
Aeroplane mode 20
Apps 21
About apps 21
Recommended apps 21
Apps precautionary advice 21
Baidu App Search 21
Manage and restore apps 22
Close apps 22
Uninstall apps 22
Vertu Services 23
About Vertu Services 23
Calls 25
About calls 25
Make and answer calls 25
Call the last number dialled 26
Quickly call your favourites 26
Listen to your voicemail 26
Divert calls to another number 27
Make a conference call 27
Contacts 28
About contacts 28
Call, text or email contacts 28
Add contacts 29
Join contacts 29
Edit or delete a contact 29
Save a number from a call or message 29
Mark contacts as favourites 30
Personalise contacts 30
Transfer contacts 30
Messaging and email 31
About messaging 31
Send and read messages 31
Send a message to a group 31
Manage messages 31
Corporate email setup 32
Personal email setup 32
Music 33
About music 33
Get music 33
Set up music 33
Play music 33
Maps and navigation 35
AutoNavi™ Maps 35
Personalising your phone 36
Widgets 36
Shortcuts 36
Ringtones 36
Wallpapers 37
Assign sounds to actions 37
Display settings 37
Contents
© 2014 Vertu Corporation Limited. All rights reserved. 2

Auto-rotate 37
Screen lock 38
Date and time settings 38
Language and region settings 38
Social networks 39
Add an account 39
Delete an account 39
Synchronise contacts 39
Managing accounts 40
Configure sync options 40
Add and delete accounts 40
Browser 41
About the web browser 41
Browse the web 41
Connect to the internet 42
Add a bookmark 42
Downloads 42
Camera 43
About camera 43
Take and share photos 43
Camera settings 44
Record and share a video 44
Video settings 45
Gallery 46
About gallery 46
View and edit photos and videos 46
Share photos and videos 46
View an album 46
Create a folder 47
Assign contact images and wallpaper 47
Take a screen shot 47
Office tools 48
Clock 48
Calculator 48
Calendar 48
Connectivity 50
WLAN 50
Bluetooth 50
Set your phone to sync with your
computer 51
Copy between the phone and a PC 52
Tethering and portable hotspot 52
NFC 52
Phone management 54
System update 54
Free up phone memory 54
Optimise data usage 54
Data roaming settings 55
Back up and restore your phone 55
Set your phone to lock automatically 55
Change your PIN code 55
Access codes 55
Master reset 56
Tips and tricks 57
General tips 57
Extend battery life 58
FAQs 59
Questions 59
How can I extend the battery life of my
phone? 59
How can I reduce my data costs,
especially when abroad? 60
How do I transfer music from my
computer to my phone? 60
How do I setup an email account on my
phone? 61
How do I transfer contacts to my phone?61
How do I transfer photos from my phone
to my computer? 61
How do I set my music as ringtone? 61
How do I change the font size on my
phone? 62
How do I check if I have the latest
software updates on my phone? 62
Why have I got no connectivity? 62
Why is my internal storage less than
advertised? 62
How do I protect my phone from
unauthorised use? 62
Contents
© 2014 Vertu Corporation Limited. All rights reserved. 3

How do I find the IMEI number of my
phone? 62
How can I clear the log of my calls or the
list of people I have contacted
frequently? 63
Why does my phone get warm? 63
How do I know how much storage I have
on my phone? 63
How do I set a photo as my wallpaper? 63
Accessories 64
Battery charger 64
Data cable 64
Wired stereo headset 65
Specifications 66
Specifications 66
Care of your phone 68
General care 68
Embroidery 68
Exotic leathers 69
Leather 69
Non-precious metals 69
Precious metals 69
Precious stones 70
Sapphire and ceramics 70
Safety and warranty 71
Safety text 71
Additional care and maintenance 75
Manufacturer's Limited Warranty 76
Software application notices for the
phone 79
Environmental 81
Export and controls 83
Copyright and trademark notices 83
SAR (Specific Absorption Rate) notice -
RM-980C 83
Declaration of Conformity 85
Contents
© 2014 Vertu Corporation Limited. All rights reserved. 4

Introduction
Your Signature Touch phone
This user guide is intended to provide you with details on how to use the prominent features on your
Signature Touch.
To access the exclusive privileges and benefits such as Vertu Life, Vertu Concierge, and Vertu Certainty,
you must register your phone.
The pictures used in this user guide are provided for illustration purposes only. They may differ from the
exact appearance of your Signature Touch.
Help and support
To find out more about using your phone:
lContact Vertu Customer Service by either pressing the Vertu key or through the Vertu Certainty
app.
lRefer to the user guide on your phone from the Vertu Certainty app, or on the Vertu website at
http://www.vertu.com/help-and-support/user-guides-and-downloads.aspx.
lUse the setup wizards available on the phone to help you with registration to create an email
account.
Compliance information
You can find compliance information on a retractable metal flap that is located in the SIM compartment.
For instructions on accessing the SIM compartment, see "Insert the SIM card" on page 11. The
information displayed includes the IMEI number, serial number, product name and 2D barcode.
Introduction
© 2014 Vertu Corporation Limited. All rights reserved. 5

Safety
Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user
guide for further information.
Switch off in restricted areas
Switch the device off when mobile phone use is not allowed or when it may cause
interference or danger, for example, in aircraft, in hospitals or near medical
equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted
areas.
Road safety comes first
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
Interference
All wireless devices may be susceptible to interference, which could affect
performance.
Qualified service
Only qualified personnel may install or repair this product.
Keep your device dry
Your device is not water-resistant. Keep it dry.
Protect your hearing
To prevent possible hearing damage, do not listen at high volume levels for long
periods. Exercise caution when holding your device near your ear while the
loudspeaker is in use.
Safety
© 2014 Vertu Corporation Limited. All rights reserved. 6

Your phone
Package contents
lSignature Touch phone
lTwo wall chargers (AC-32V), each with a Chinese-style plug
lTwo microUSB cables 1200mm (CA-225DV)
lV Collection Wired Headset, Type WH-4V/WH-5V
lPolishing cloth
lNanoSIM to microSIM adapter
lCollateral pack, including Quick Start Guide, Warranty Booklet, and Authenticity Card
The package contents may vary slightly in accordance with the materials used in your particular phone
and with regional regulations.
Features and keys
Front
Earpiece speaker
Headset connector
Notification light
Volume up key
Volume down key
Front camera
Ambient light sensor
Microphone
Loudspeaker (Stereo)
Your phone
© 2014 Vertu Corporation Limited. All rights reserved. 7

Back
LED flash
MicroUSB connector
Vertu key
Power key/screen lock
Noise-cancelling microphone
Main camera
Quarter turn latch
Back cover
Your phone
© 2014 Vertu Corporation Limited. All rights reserved. 8

Antenna locations
Avoid touching the antenna areas while the antennas are in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power levels during operation.
Headset
Use the headset provided to connect to your phone. Alternatively, you can connect any compatible
headsets.
Your phone
© 2014 Vertu Corporation Limited. All rights reserved. 9

Change the volume
Press the volume keys to change the volume of your ringtone or adjust the volume during a call. The
Dolby Sound interface appears, use it to adjust the volume and settings on your phone.
Touch to open Dolby sound quick options.
Touch to open volume settings panel to customize music, ringtones, notifications, and alarms.
Touch to open the standard Android sounds settings view.
Your phone
© 2014 Vertu Corporation Limited. All rights reserved. 10

Getting started
Insert the SIM card
Your Signature Touch phone is equipped to work with a microSIM card. If you are currently using a
nanoSIMcard, please use the adapter included in the sales pack.
!
Important: Use of a nanoSIM card without the adapter may damage the card or your phone and
may corrupt data stored on the card.
To avoid damaging the SIM card or your phone, follow these steps carefully:
1. To insert your SIMfirstly lift the quarter turn latch and turn anti-clockwise to open the back cover.
2. Next open the SIM door and place your microSIM into the cavity as shown.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 11

3. Finally, close the SIM door and lock into place (pictured). Then close the back cover.
Charge the phone
The internal battery needs activating prior to first use, and it is recommended to charge the battery at this
point as it may not have been supplied with a full charge. Connect the supplied USB data cable into the
charging port on the side of the phone. Then connect the other end of the cable to the USB port on your
Vertu mains charger.
!
Important: Use only chargers, cables and accessories supplied by Vertu.
If the phone indicates a low charge, do the following:
1. Connect the supplied wall charger to the wall outlet and then insert the microUSB connector into
your phone.
2. When the battery is fully charged, disconnect the charger from the phone and then from the wall
outlet.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 12

Note:
lYou can use the phone while it is charging.
lIf the battery is completely discharged, it may take several minutes before the charging indicator is
displayed or before you can make any calls.
lThe phone can not be activated using the Vertu Wireless Powerpack.
Other ways to charge the battery
You can also charge your phone by connecting it to your computer using the USB cable, or by placing it on
the optional Vertu Wireless Charging Stand.
Note: Your phone charges quicker when connected to the wall charger.
Extend battery life
For tips on how to extend battery life, see "Extend battery life" on page 58.
Switch the phone on or off
Switch on: Press and hold the Power key until the phone vibrates.
Switch off: Press and hold the Power key, and then touch Power off.
In the unlikely event that your phone stops responding, reboot it. To reboot, press and hold the Power
and Volume Down keys, at the same time, until the phone vibrates. This takes approximately 10 seconds.
Note: Always remember to power off your phone before removing and inserting a SIM card. This action
will ensure that your network connectivity is restored.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 13

Touch screen actions
!
Important: Avoid scratching the touch screen. Never use a pen, pencil, or other sharp object on the
touch screen.
Touch
To select an item on the screen, touch it.
Touch and hold
To select an item and the actions associated with it, touch and hold.
Drag
Touch and hold the item, and then slide your finger across the screen.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 14

Flick
Scroll quickly between views or through lists.
Pinch or double-touch
Place two fingers on an item, such as a photo or web page, and then slide your fingers apart to zoom in or
together to zoom out.
Or, simply double touch the item to zoom in or out.
Start-up process
1 Vertu registration
If you are a new Vertu customer you will be asked to create a Vertu account. If you already own a Vertu
phone you can simply log in to your existing account with your Vertu username and password.
Completing Vertu registration will give you access to unique privileges and benefits relevant to you.
Tip: For quick access to the range of exclusive services, press the Vertu key.
2 Recommended apps
For more on the apps that Vertu recommend, see "Recommended apps" on page21.
3 Transfer contacts
Transfer contacts to your phone with your SIM card.
For information on transferring contacts, see "Transfer contacts" on page30.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 15

Use your phone when it is locked
To unlock the screen, touch Home or press the Power key and then touch and drag to .
You can lock the screen either by pressing the Power key or by simply leaving the screen to time out.
For more information on different screen lock types, see "Screen lock" on page38.
Getting started
© 2014 Vertu Corporation Limited. All rights reserved. 16

Explore
About the home screen
The home screen acts as a gateway to the functions on your phone while also providing you with all the
latest information:
1
3
2
4
5
1
Status and notification bar
2
Widget
3
Apps menu
4
Favourites tray
5
Back, Home and Recent
Apps
Status and notification bar
Status information, such as time, network signal strength and battery level indicator, is displayed at the top
right of the screen.
Any notifications, such as new messages or calendar appointments, are displayed in the top left of the
screen. To see your notifications, touch the bar and drag down. Touch a notification to open it.
You can also quickly control your WLAN, Bluetooth, GPS, mobile data, USB connectivity and display
options from the status and notification bar.
Touch Home to close the status notification bar.
Tip: Flick the notification left or right to clear it from the list.
Explore
© 2014 Vertu Corporation Limited. All rights reserved. 17

Status and notification icons
Network (full signal) New Gmail
No network WLAN connected
G
GPRS data connection WLAN available
Warning Bluetooth™ connected
H+ (fastest data) Bluetoothconnected to an aptX® compatible accessory
Battery (full charge) GPS (location found)
Battery (charging) GPS (searching)
Battery (empty) USB connected
Active call Downloading
Missed call Uploading
New voicemail Preparing SD card
Calendar reminder Background data sync
New SMS Alarm set
New MMS Silent
New chat Vibrate
New email Aeroplane mode on
Explore
© 2014 Vertu Corporation Limited. All rights reserved. 18

Clock widget
The clock widget on the home screen displays the following information:
lAnalogue clock with a digital date indicator
lAlarms set for the next 12 hours
lFree and busy periods, taken from the calendar, around the clock bezel
lLocal time. If you are roaming, the clock displays both the local time and the time at your home
location.
To set an alarm, touch the centre of the clock.
To display an appointment, touch the appropriate quadrant of the clock, and then touch the pop-up to
open the appointment. To clear the appointment, touch the screen.
Back, home and recent apps
You can use the three icons on the bottom of your screen to navigate between screens and apps.
1 32
1
Back
2
Home
3
Recent apps
Touch Back to go back to your previous screen.
Touch Home to move an app to the background and return to the home screen. Touch and hold Home to
go to the search screen.
Touch Recent apps to view a list of the apps you have used most recently.
Add widgets to the home screen
Widgets are apps that provide live content such as news, weather forecasts and messages.
To add widgets to the home screen:
1. Touch Apps and touch WIDGETS at the top of the screen.
2. Flick left to view all widgets.
3. To select a widget, touch and hold it, and then drag it to the home screen.
Explore
© 2014 Vertu Corporation Limited. All rights reserved. 19

To see the widget menu options, open the widget and touch .
To resize certain widgets, such as Calendar, touch and hold the widget and then release it. The widget is
then highlighted and you can drag it to the size required.
Note: Downloaded apps from Baidu may automatically download other associated widgets. To check
your widgets, touch Apps and then touch WIDGETS.
Favourites tray
The favourites tray appears at the bottom of the home screen. Use it to access your favourite apps
quickly.
To remove an app from the favourites tray, touch and hold the app then drag to Remove at the top of the
screen.
Note: You cannot remove the Apps shortcut from the favourites tray.
To add an app to the favourites tray, touch Apps. Touch and hold the app, and drag it to the
favourites tray.
Aeroplane mode
To turn off all the wireless connections on your phone, press and hold the Power key>Aeroplane mode.
Tip: Aeroplane mode helps to conserve battery power.
Explore
© 2014 Vertu Corporation Limited. All rights reserved. 20
