LAD-MM Series Mobile Ladder Stands
Receiving instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at [phone]. The department
can also be contacted online at https://www.vestil.com/page-parts-request.php
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-manuals.php.
Table of Contents
Page
Specifications…………..…………………….………………………………………………….…….…
2
Signal Words………….……............................................................................................................
3
Safety Instructions………………………..…………………………………...…………………...…….
3
Exploded Views and Bills of Materials…..………………………………….……………………......
4 – 8
LAD-MM-(2; 3; & 4)-(P & G)…………………………………………………………………….………
4
LAD-MM-(5; 6; & 7)-(P & G)……………………………………………………………………….……
5
LAD-MM-(8; 9; & 10)-(P &G)………………………………………………………………………….…
6
LAD-MM-11-(P & G)………………………………………………………………………………………
7
LAD-MM-12-(P & G)………………………………………………………………………………………
8
Assembly Instructions…..…………………………………………………………………………...……
9, 10, 11
Record of Satisfactory Condition………………………………………………………………...……
11
National Standards………………………………………………………………………………………
12
Using the Ladder……..…………..………………………………………………………………………
12
Inspections & Maintenance…………..........................................................................................
12 - 13
Labeling Diagram………...…........................................................................................................
13
Limited Warranty…………...……………………………………………………...…………..…………
14
Vestil Manufacturing
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: [phone] -or- Toll Free [phone]
Fax: [phone]
Web: www.vestil.com Email: [e-mail]

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 2 of 14
SPECIFICATIONS
Documents that provide specifications for LAD-RAF series mobile ladder stands are available online to anyone who
visits Vestil’s website. Specifications include dimensions, net weight, and capacity information. To access the
appropriate specifications document, navigate to the LAD-MM webpage at
https://www.vestil.com/product.php?FID=608.Scroll the page to the entry for the ladder you purchased. Click the
button in the “PDF” column that looks like a pencil inside a blue box. A PDF file will open. This file is the specifications
document. Print a copy of the document and keep it with your copy of this manual. The following specifications are
provided for convenience only. Refer to your printed specifications document.
Model Number of
steps
A:
Overall
height
B:
Overall
width
C:
Railing
height
D:
Platform
height
E:
Usable
length
F:
Overall
length
Step
slope Capacity Net Weight
LAD-MM-2-P
2
50”
291/2”
30”
20”
271/4”
381/2”
58°
350 lb.
69 lb.
LAD-MM-3-P 3 60” 29
1
/2” 30” 30” 33
1
/2” 38
7
/16” 58° 350 lb. 82 lb.
LAD-MM-4-P
4 70” 29
1
/
2
” 30” 40” 39
3
/
4
” 42
5
/
8
” 58° 350 lb. 100 lb.
LAD-MM-5-P 5 80” 29
1
/2” 30” 50” 46” 49
3
/4” 58° 350 lb. 119 lb.
LAD-MM-6-P
6 90” 29
1
/2” 30” 60” 52
1
/4” 56
11
/16” 58° 350 lb. 135 lb.
LAD-MM-7-P
7
100”
291/2”
30”
70”
581/2”
623/8”
58°
350 lb.
150 lb.
LAD-MM-8-P
8 110” 29
1
/2” 30” 80” 64
3
/4” 68
5
/8” 58° 350 lb. 169 lb.
LAD-MM-9-P
9
120”
291/2”
30”
90”
71”
747/8”
58°
350 lb.
185 lb.
LAD-MM-10-P
10 130” 29
1
/2” 30” 100” 77
1
/4” 81
1
/8” 58° 350 lb. 202 lb.
LAD-MM-11-P
11
140”
32”
30”
110”
831/2”
873/8”
58°
350 lb.
222 lb.
LAD-MM-12-P
12 156” 32” 36” 120” 89
3
/4” 93
1
/4” 58° 350 lb. 247 lb.
LAD-MM-2-G
2
50”
291/2”
30”
20”
271/4”
381/2”
58°
350 lb.
70 lb.
LAD-MM-3-G 3 60” 29
1
/2” 30” 30” 33
1
/2” 38
1
/2” 58° 350 lb. 84 lb.
LAD-MM-4-G
4 70” 29
1
/2” 30” 40” 39
3
/4” 43
5
/8” 58° 350 lb. 101 lb.
LAD-MM-5-G
5 80” 29
1
/2” 30” 50” 46” 49
3
/4” 58° 350 lb. 121 lb.
LAD-MM-6-G
6 90” 29
1
/2” 30” 60” 52
1
/4” 56
11
/16” 58° 350 lb. 137 lb.
LAD-MM-7-G
7
100”
29
1
/2”
30”
70”
58
1
/2”
62
3
/8”
58°
350 lb.
152 lb.
LAD-MM-8-G
8 110” 29
1
/2” 30” 80” 64
3
/4” 68
5
/8” 58° 350 lb. 172 lb.
LAD-MM-9-G
9
120”
291/2”
30”
90”
71”
747/8”
58°
350 lb.
188 lb.
LAD-MM-10-G
10 130” 29
1
/2” 30” 100” 77
1
/4” 81
1
/8” 58° 350 lb. 205 lb.
LAD-RF-11-G
11
140”
32”
30”
110”
831/2”
873/8”
58°
350 lb.
225 lb.
LAD-RF-12-G 12 156” 32” 36” 120” 89
3
/4” 93
1
/4” 58° 350 lb. 250 lb.

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 3 of 14
SIGNAL WORDS
SIGNAL WORDS IN THIS MANUAL DRAW THE READER’S ATTENTION TO IMPORTANT SAFETY-RELATED MESSAGES.
SAFETY INSTRUCTIONS
Vestil strives to identify foreseeable hazards associated with the use of its products, but no manual can address every
conceivable risk. Reduce risk by applying sound judgment whenever using this device. Acquire a copy of the latest
version of ANSI A14.7 (“A14.7” or the “Standard”). Apply all parts of the Standard that concern using, inspecting,
maintaining & repairing the ladder. Keep a copy of this manual with the ladder at all times, e.g. inside a plastic pouch
attached to the frame. Anyone who uses this ladder must be made aware that a copy of the manual is available and
where to find it.
If this product is used improperly or carelessly, the user and/or bystanders might sustain serious
personal injuries or could even be killed. ALWAYS use the product properly:
•Read & understand the entire manual before assembling, using, inspecting, or servicing the ladder.
•DO NOT use this ladder unless you are in good health. NEVER use the ladder while under the influence of alcohol or
drugs, including prescription medication that affects balance, perception, or judgment.
•DO NOT exceed the capacity/rated load. The total weight applied to the ladder (weight of the user plus tools, etc.)
must not be greater than the capacity. The capacity is provided on label 1153. See LABELING DIAGRAM on p. 14.
•Wear appropriate footwear. DO NOT wear high-heeled shoes or footwear with smooth soles.
•DO NOT use the ladder on uneven, sloped, or unstable surfaces. ONLY use the ladder on even, level surfaces.
•Make sure that you will not contact overhead objects with either your body or with the ladder during use.
•Avoid electrical shock! Take precautions to prevent any contact, or possible contact, with an energized, insulated
conductor (electrical line).
•Remove foreign matter, e.g. mud, from your shoes before walking on the ladder. Only wear slip-resistant shoes.
•Only stand on the steps or the platform. DO NOT climb onto the railing. DO NOT slide on the railing.
•DO NOT access, or egress from, any step or the platform from another elevated surface unless the ladder is positively
secured against movement.
•ALWAYS face the stairs and use the handrails while ascending and descending the ladder.
•DO NOT increase the height of the platform or of a step by standing on other objects placed on the ladder.
•Inspect the ladder as described in INSPECTIONS & MAINTENANCE on p. 12-13. DO NOT use the ladder unless it is in
Satisfactory Condition. ONLY use manufacturer-approved replacement parts when repairs are necessary.
•DO NOT use the ladder if the caps on the front legs are significantly worn. See applicable EXPLODED VIEW on p. 4-8.
Caps should prevent the ladder from sliding. If either or both caps are too worn to function properly, replace them
before using the ladder again.
•ONLY use the ladder to access elevated working positions. DO NOT use the ladder for any other purpose. DO NOT
store materials and/or equipment on the steps or platform. Always unload the ladder before leaving it unattended.
•DO NOT position an occupied ladder in front of a door unless that door is secured in an open position, is locked, is
attended, or is barricaded.
•DO NOT lean, or reach, over the handrails or guardrails of the ladder. Position the ladder as close to the work as
possible. Reposition the ladder to prevent overreaching. Overreaching could cause instability and result in a fall.
•Avoid sudden shifts while on the ladder. DO NOT push, pull, or lean on the handrails or guardrails.
•DO NOT skip steps. Climb the ladder one step at a time.
•DO NOT attempt to move the ladder while someone is using it. The ladder must be unoccupied before it is moved.
•DO NOT use the ladder to transport people or objects. DO NOT ride on the ladder
•DO NOT remove or obscure any label. Each label must be readable, undamaged, and present in the appropriate
location. See LABELING DIAGRAM on p. 13.
•DO NOT modify this ladder! Unauthorized modifications automatically void the LIMITED WARRANTY (p. 19) and might
make the ladder unsafe to use.
•Only locking fasteners should be used. During assembly, confirm that there are only locking nuts. Contact TECHNICAL
SERVICE (see cover page) if you find non-locking nuts. Lock nuts can only safely be used once. Discard used lock nuts
and install new lock nuts after unfastening any connection.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
!
!
!

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 4 of 14
Item
Part no.
Description
Qty.
1
44-647-053
44-647-054
44-647-053
44-647-052
44-647-006
44-647-010
Weldment, step frame:
LAD-MM-2-P
LAD-MM-2-G
LAD-MM-3-P
LAD-MM-3-G
LAD-MM-4-P
LAD-MM-4-G
1
1
1
1
1
1
2
44-514-299
44-514-300
44-514-301
Weldment, back leg:
2-step, 26” step: LAD-MM-2-P & LAD-MM-2-G
3-step, 26” step: LAD-MM-3-P & LAD-MM-3-G
4-step, 26” step: LAD-MM-4-P & LAD-MM-4-G
1
1
1
3 44-524-059
44-524-038
Weldment, handrail:
LAD-MM-2-P; LAD-MM-2-G; LAD-MM-3-P; & LAM-MM-3-G
LAD-MM-4-P & LAD-MM-4-G
2
2
4
08-145-008
Snap hook,
1
/
4
”
2
5
16-132-009
Wheel, PP-4/1.25-W
2
6
44-014-331
44-014-332
44-014-233
Frame, base support:
LAD-MM-2-P & LAD-MM-2-G
LAD-MM-3-P & LAM-MM-3-G
LAD-MM-4-P & LAD-MM-4-G
2
2
2
7
99-024-027 Square cap, 1” x 1”, 60 Duro. 2
8
99-025-025
1” plastic plug
4
9
99-145-031
3
/
16
” chain 24”
1
10
11055
Hex bolt, gr, A, zinc plated,
5
/
16
”-18 x 1”
4
11
11060
Hex bolt, HHCS,
5
/
16
”-18UNC x 1
3
/
4
”
10
12
11113 Hex bolt, gr. A, plain finish, 3/8”-16 x 21/2” 2
13
33006
Flat washer, zinc plated, USS,
5
/
16
”
4
14
37021 Nylon insert lock nut, gr. 2, zinc finish, 5/16”-18 14
15
37024
Nylon insert lock nut, gr. 2, zinc finish,
3
/
8
”-16
2
Exploded View and Bill of Materials:
LAD-MM-2-P & LAD-MM-2-G
LAD-MM-3-P & LAD-MM-3-G
LAD-MM-4-P & LAD-MM-4-G
*NOTE: Diagram shows LAD-MM-2-P.

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 5 of 14
Exploded View & Bill of Materials:
LAD-MM-5-P & LAD-MM-5-G
LAD-MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
*NOTE: Diagram shows LAD-MM-5-P.
Item
Part no.
Description
Qty.
1
44-647-007
44-647-011
44-647-008
44-647-012
44-647-009
44-647-013
Weldment, step frame:
LAD-MM-5-P
LAD-MM-5-G
LAD-MM-6-P
LAD-MM-6-G
LAD-MM-7-P
LAD-MM-7-G
1
1
1
1
1
1
2
44-514-302
44-514-303
44-514-304
Weldment, back leg:
5-step, 26” step: LAD-MM-5-P & LAD-MM-5-G
6-step, 26” step: LAD-MM-6-P & LAD-MM-6-G
7-step, 26” step: LAD-MM-7-P & LAD-MM-7-G
1
1
1
3
44-524-057
44-524-039
44-524-040
Weldment, handrail:
LAD-MM-5-P & LAD-MM-5-G
LAD-MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
2
2
2
4
08-145-008 Snap hook, 1/4” 2
5
16-132-009
Wheel, PP-4/1.25-W
2
6
44-014-320
44-014-238
44-014-243
Frame, base support:
LAD-MM-5-P & LAD-MM-5-G
LAD-MM-6-P & LAD-MM-6-G
LAD-MM-7-P & LAD-MM-7-G
2
2
2
7
99-024-027 Square cap, 1” x 1”, 60 Duro. 2
8
99-025-025
1” plastic plug
4
9
99-145-031 3/16” chain 24” 1
10
11055
Hex bolt, gr, A, zinc plated,
5
/
16
”-18 x 1”
4
11
11060 Hex bolt, HHCS, 5/16”-18UNC x 13/4” 14
12
11113
Hex bolt, gr. A, plain finish,
3
/
8
”-16 x 2
1
/
2
”
2
13
33006
Flat washer, zinc plated, USS,
5
/
16
”
4
14
37021
Nylon insert lock nut, gr. 2, zinc finish,
5
/
16
”-18
18
15
37024
Nylon insert lock nut, gr. 2, zinc finish,
3
/
8
”-16
2

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 6 of 14
Exploded View & Bill of Materials:
LAD-MM-8-P & LAD-MM-8-G
LAD-MM-9-P & LAD-MM-9-G
LAD-MM-10-P & LAD-MM-10-G
*NOTE: Diagram shows LAD-MM-8-P.
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
44-647-061
44-647-060
44-647-063
44-647-062
44-647-065
44-647-064
Weldment, step frame:
LAD-MM-8-P
LAD-MM-8-G
LAD-MM-9-P
LAD-MM-9-G
LAD-MM-10-P
LAD-MM-10-G
1
1
1
1
1
1
6
44-014-400
44-014-401
44-014-402
Frame, base support:
LAD-MM-8-P & -G
LAD-MM-9-P & -G
LAD-MM-10-P & -G
2
2
2
7
99-024-027
Square cap, 1” x 1”, 60 Duro.
2
8 99-025-025 1” plastic plug 4
9 99-145-031 3/16” chain 24” 1
2
44-514-305
44-514-306
44-514-307
Weldment, back leg:
LAD-MM-8-P & -G
LAD-MM-9-P & -G
LAD-MM-10-P & -G
1
1
1
10 11055 Hex bolt, gr, A, zinc plated,
5/16”-18 x 1” 4
11 11060 Hex bolt, HHCS, 5/16”-18UNC x
1
3
/
4
”
18
3
44-524-082
44-524-083
44-524-084
Weldment, handrail:
LAD-MM-8-P & -G
LAD-MM-9-P & -G
LAD-MM-10-P & -G
2
2
2
12 11113 Hex bolt, gr. A, plain finish, 3/8”-
16 x 21/2” 2
13 33006
Flat washer, zinc plated, USS,
5
/16”
4
4 08-145-008 Snap hook, 1/4” 2 14 37021
Nylon insert lock nut, gr. 2, zinc
finish,
5
/16”-18
22
5 16-132-009 Wheel, PP-4/1.25-W 2 15 37024
Nylon insert lock nut, gr. 2, zinc
finish,
3
/8”-16
2

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 7 of 14
LAD-MM-11-P & LAD-MM-11-G Exploded View & Bill of Materials
Item Part no. Description Qty. Item Part no. Description Qty.
1 44-647-067
44-647-066
Weldment, 11-step frame:
LAD-MM-11-P
LAD-MM-11-G
1
1
9 99-024-027 Square cap, 1” x 1”, 60 Duro. 2
2 44-514-308
Weldment, back leg, 11-
step, 26” step
1 10 99-025-025 1” plastic plug 4
3 44-514-310 Assembly, outrigger, right 1 11 99-145-031 3/16” chain 24” 1
4 44-514-311 Assembly, outrigger, left 1 12 11055
Hex bolt, gr, A, zinc plated,
5
/16”-18 x 1”
4
5 44-524-085 Weldment, handrail 2 13 11060
Hex bolt, HHCS, 5/
16
”-18UNC x
1
3
/4”
18
6 16-132-009 Wheel, PP-4/1.25-W 2 14 11113
Hex bolt, gr. A, plain finish,
3
/
8
”-
16 x 2
1
/2”
2
7 08-145-008 Snap hook, 1/4” 2 15 33006
Flat washer, zinc plated, USS,
5
/16”
4
8 44-014-403 Frame, base support 2 16 37021
Nylon insert lock nut, gr. 2, zinc
finish,
5
/16”-18
22
17 37024
Nylon insert lock nut, gr. 2, zinc
finish,
3
/8”-16
2

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 8 of 14
LAD-MM-12-P & LAD-MM-12-G Exploded View & Bill of Materials
Item Part no. Description Qty. Item Part no. Description Qty.
1 44-647-069
44-647-068
Weldment, 12-step frame:
LAD-MM-12-P
LAD-MM-12-G
1
1
9 99-024-027 Square cap, 1” x 1”, 60 Duro. 2
2 44-514-309
Weldment, back leg, 12-step,
26” step
1 10 99-025-025 1” plastic plug 4
3
44-514-310 Assembly, outrigger, right 1
11
99-145-031
3/16” chain 24” 2
4 44-514-311 Assembly, outrigger, left 1 12 11055
Hex bolt, gr, A, zinc plated, 5/
16
”-
18 x 1”
4
5 44-524-086 Weldment, handrail 2 13 11060
Hex bolt, HHCS, 5/
16
”-18UNC x
1
3
/4”
18
6 16-132-009 Wheel, PP-4/1.25-W 2 14 11113
Hex bolt, gr. A, plain finish, 3/
8
”-16
x 2
1
/2”
2
7 08-145-008 Snap hook, 1/4” 4 15 33006 Flat washer, zinc plated, USS, 5/16” 4
8 44-014-404 Frame, base support 2 16 37021
Nylon insert lock nut, gr. 2, zinc
finish,
5
/16”-18
22
17 37024
Nylon insert lock nut, gr. 2, zinc
finish,
3
/8”-16
2

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 9 of 14
ASSEMBLY INSTRUCTIONS
WARNING
Read this manual before assembling the ladder. Improper assembly might make the ladder unsafe to use.
•Inspect the ladder components prior to assembly. Examine each part of the ladder immediately after
delivery from the shipper. Look for damage that might have occurred during shipping. DO NOT assemble
or use the ladder stand if you notice any damage to one or more of the steps or to any other structural
element (step weldment, back leg weldment, base supports, and handrails) of the ladder. Using the ladder
stand despite weakness of a frame member could result in serious personal injuries. DO NOT use your ladder
stand if any of the hardware (bolts, nuts, etc.) is damaged. Contact Vestil to order replacement parts.
•DO NOT assemble the ladder by yourself. At least 2 people are needed for assembly.
•Read the entire instruction manual before assembling this ladder.
•DO NOT use the ladder if a wheel is damaged because the ladder might wobble or tip during use.
•Apply lifting techniques to minimize back strain if you must pick up ladder parts or move the ladder.
The following tools are necessary to assemble the ladder:
1. 2 crescent wrenches (adjustable to 1/2in.)
2. Rubber mallet
3. Pliers, preferably needle nose, to bend arms of cotter pins
4. Proper work clothing, eye protection, gloves
5. Sturdy wall no shorter than 8 feet high
6. At least 30ft by 10ft of floor space is required to raise or collapse the ladder
7. (If indoors) ceiling at least 16ft high.
NOTE: Numbers in the diagrams and in parentheses () correspond to part numbers in the Exploded Views on
pages 4-8.
Step 1: Fasten the back leg weldment to the stair frame weldment with 5/16 in. hardware. Be sure to orient the
back leg weldment as shown below (support tabs should face inwards).
Step 2: Fasten base supports to support brackets and wheel brackets with
5
/
16
in. – 18 hardware as shown below.
11060
Back leg
weldment
Stair frame
weldment
+
37021
Ladder
assembly
Support
tab
Wheel
bracket
Support
bracket
+
Base
support
37021
11055 & 33006
37021
33006 11055

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 10 of 14
Step 3: Install the plugs, caps, and wheels.
a) Install the plastic plugs and square caps in the leg tubes. First, press the 1in. plastic plug into the leg
tubes. Then, press the square caps over the plugs and onto the ends of the legs. If necessary, use a
rubber mallet to gently tap the plugs and caps into place.
b) Press a plug into each end of the cross brace.
c) Then, insert the wheels into the wheel brackets and install 3/8”-16 x 21/2” bolts (11113). Secure the bolts
with axle. Periodically lubricate the bolts to allow the wheels to rotate freely.
Step 4 (LAD-MM-11 & LAD-MM-12 only): Install the outriggers. Unfasten the bolt (11055), flat washer
(33006), and lock nut (37021). Then, reinstall the hardware the outrigger, support bracket, and base
support as shown.
1in. black
plastic plug
44-514-311
Left outrigger
33006
Ladder
assembly
1in. x 1in.
square cap
37024
11113
16-132-009
Insert
plug
Cross
brace
11055
44-514-310
Right outrigger
37021
Support
bracket
Base
support

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 11 of 14
RECORD OF SATISFACTORY CONDITION (THE “RECORD”)
After assembling the ladder and before putting it into service, visually inspect the ladder. Record the
condition and appearance of each of the frame members (step weldment, back leg weldment, base
support frame members), the handrails, outriggers, wheels and/or casters, (leg) caps, back platform frame
and chain, and all fasteners (bolts, nuts, etc.). Thoroughly photograph the ladder from multiple angles.
Include close range photographs of the rubber leg caps, casters and wheels, all labeling, and all handrail
connections. Add the photographs to the record. Collate all photographs and writings into a single file. This
file is a record of the ladder in satisfactory condition. Compare the results of all inspections to this Record to
determine whether the ladder is in satisfactory condition. Do not use the ladder unless it is in satisfactory
condition. Purely cosmetic changes, like damaged paint or powdercoat, are not changes from satisfactory
condition. However, touchup paint should be applied as soon as damage occurs.
Step 5: Attach the handrails.
Step 6: Install the platform chain. Attach the snap hooks to the hook brackets.
Handrail
11060
37021
Hook
bracket
Chain
Side rail
Snap
hook

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 12 of 14
NATIONAL STANDARDS
This product is a “mobile ladder stand” (MLS). ANSI standard A14.7 (the “Standard”) applies to MLS’s. You
should acquire a copy of the latest version of the standard. Follow all use and maintenance/care
instructions provided in the Standard as well as all other provisions for MLS owners and users. If any content
in this manual conflicts with any mandatory provision(s) in the Standard, apply the provision(s) from the
Standard.
USING THE LADDER
Review the SAFETY INSTRUCTIONS on p. 3 before using the ladder.
Inspect the ladder before each use for damage, such as unusual wear, deterioration, or corrosion.
Tighten loose nuts. If a lock nut has been partially or completely unfastened, replace it with a new lock nut.
Make sure there are no children in the area where the ladder is used or stored.
Climbing the ladder:
ONLY use this ladder on solid, level ground. Never use the ladder on angled surfaces. The ladder must
not wobble or lean while in use. Only climb the ladder when the steps and handrails are clean and dry.
The rubber caps on the front legs must solidly contact the ground. The caps are provided to help the
ladder resist movement during use. Confirm solid contact between the entire bottom surface of each cap
and the floor before climbing the ladder. Do not use the ladder if either or both of the rubber caps are
damaged (worn, cracked, torn, or cut through by the front legs (see STEP 3 on p. 10). Remove the ladder
from service until new caps are installed.
Face the ladder and grasp the handrails while ascending or descending the steps. Do not lean against
the handrails, the guardrails (around the top of the ladder), or the cross bar or chain. Do not lean over the
handrails, guardrails, or cross bar.
To move the ladder, grasp either the handrails or the side rails. Carefully lift the front of the ladder off of
the ground. Ladders with more steps are heavier and therefore require more effort to move. Only attempt
to lift and move the ladder if you are able to comfortably lift it and can easily control it.
INSPECTIONS & MAINTENANCE
Inspections and repairs should only be performed by qualified persons. Compare the results of each
inspection to the RECORD OF SATISFACTORY CONDITION (the “RECORD”). Do not use the ladder unless all
parts are in satisfactory condition. Replace parts that are not in satisfactory condition before using the
ladder again. DON’T GUESS! If you have any questions about the condition of your ladder, speak with
TECHNICAL SERVICE personnel.The phone number is provided on the cover page of this manual. Never
make temporary repairs of damaged or missing parts. Only use manufacturer-approved replacement
parts. DO NOT continue to use the ladder if damage cannot be repaired.
Before each use inspect the ladder for any sustained damage such as impact/collision damage, unusual
wear, deterioration, or corrosion. Look for loose connections. Tighten all loose connections. If any lock nut is
removed from its bolt, it must be replaced with a new lock nut.
Regular inspections —at least once per month inspect the following items. Replace all parts not in
satisfactory condition before returning the ladder to service. DO NOT use the ladder if damage cannot be
repaired.
•Handrails, guardrails, cross bar, snap hooks, and platform chain: Inspect both handrails. Confirm that they
are solidly fastened to the step weldment and to the platform. Each handrail should be straight, rigid, and
undamaged. Examine the guardrails around the platform for damage, bends, and cracks. Examine the
cross bar and the chain and snap hooks (if included with your ladder model). Confirm that the cross bar
and chain are undamaged and securely fastened to the guard railing. Snap hooks should close
automatically.
•Back leg weldment and wheels: Make sure that the back leg weldment is undamaged, e.g. not bent,
cracked, or warped. Check the wheels. They must not be cracked or significantly worn. Wheels should be
vertical (not angled towards or away from the ladder) and should roll smoothly. Make sure that the wheel
fasteners are undamaged. If any lock nut is loose, replace it with a new lock nut.
•All frame members (step weldment, back leg weldment, base supports, handrails) and all fasteners (bolts,
nuts, pins): Inspect each frame member weekly for damage like excessive wear, warps, cracks, and other
types of damage. All frame pieces should be square, rigid, and free of rust and corrosion. Remove rust
with steel wool or a metal bristle brush and apply touch-up paint to the affected area. Check the areas
where frame members are bolted together. Check the areas around bolt holes for warps, cracks, etc.
Replace all parts that are damaged before using the ladder again.

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 13 of 14
•Square rubber foot caps: Check the caps for cracks, tears, wear, or for the bottoms of the front legs
cutting through the caps. Install replacement caps before returning the ladder to service. Even a
moderate amount of wear can affect the ability of a cap to resist sliding movement. The entire bottom
surface of each cap must contact the floor.
•Outriggers (11 and 12 step models): Examine the outriggers and confirm that they are securely fastened
to the step weldment. Both outriggers should make solid contact with the ground, i.e. the ladder should
not be able to wobble. Confirm that the caps on the outrigger legs are in satisfactory condition.
Maintenance: in addition to correcting issues discovered during inspections, maintain the ladder
as described below.
•Clean the ladder to remove dirt and grime, especially from step surfaces.
•Lubricate the axle as necessary for the wheels to rotate freely.
•Apply touchup paint wherever the finish is chipped.
LABELING DIAGRAM
Each unit should be labeled as shown in the diagram. Label content and location are subject to
change so your product might not be labeled exactly as shown. Compare the diagram below to your
RECORD OF SATISFACTORY CONDITION. If there are any differences between actual labeling and this
diagram, contact TECHNICAL SERVICE.
Replace all labels that are damaged, missing, or not easily readable (e.g. faded). To order
replacement labels or to inquire whether your unit is properly labeled, contact the technical service
and parts department online at https://www.vestil.com/page-parts-request.php or by calling (260)
665-7586 and asking for the Parts Department.
C: Label 1153 (on nosing of a step)
B: Label 729A (on
nosing of a step)
A: Label 740 (on nosing of a step or platform)
D: Label 821 (on nosing of a step)
A
B
C
D
NOTE: To provide access to this manual for all persons who use this ladder, a protected copy of the
manual should be attached to the ladder. For example, a copy of the manual can be placed
inside a transparent plastic pouch or folder that is tied to the ladder frame. An appropriate place
to tie the folder to the frame is on the side rail next to the step where label 821 is applied.

Table of Contents Rev. 10.5.2022 LAD-MM, MANUAL
Table of Contents Copyright 2022 Vestil Manufacturing Co. Page 14 of 14
LIMITED WARRANTY
Vestil Manufacturing Corporation (“Vestil”) warrants this product to be free of defects in material and
workmanship during the warranty period. Our warranty obligation is to provide a replacement for a
defective, original part covered by the warranty after we receive a proper request from the Warrantee
(you) for warranty service.
Who may request service?
Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil
or from an authorized distributor AND Vestil has been fully paid.
Definition of “original part”?
An original part is a part used to make the product as shipped to the Warrantee.
What is a “proper request”?
A request for warranty service is proper if Vestil receives: 1) a photocopy of the Customer Invoice that
displays the shipping date; AND 2) a written request for warranty service including your name and
phone number. Send requests by one of the following methods:
US Mail Fax Email
Vestil Manufacturing Corporation [phone] [email protected]
2999 North Wayne Street, PO Box 507 Phone Enter “Warranty service
Angola, IN 46703 [phone] request” in subject field.
In the written request, list the parts believed to be defective and include the address where
replacements should be delivered. After Vestil receives your request for warranty service, an authorized
representative will contact you to determine whether your claim is covered by the warranty. Before
providing warranty service, Vestil will require you to send the entire product, or just the defective part (or
parts), to its facility in Angola, IN.
What is covered under the warranty?
The warranty covers defects in the following original, dynamic parts: motors, hydraulic pumps, motor
controllers, and cylinders. It also covers defects in original parts that wear under normal usage
conditions (“wearing parts”), such as bearings, hoses, wheels, seals, brushes, and batteries.
How long is the warranty period?
The warranty period for original dynamic components is 1 year. For wearing parts, the warranty
period is 90 days. Both warranty periods begin on the date Vestil ships the product to the Warrantee. If
the product was purchased from an authorized distributor, the periods begin when the distributor ships
the product. Vestil may, at its sole discretion, extend a warranty period for products shipped from
authorized distributors by up to 30 days to account for shipping time.
If a defective part is covered by the warranty, what will Vestil do to correct the problem?
Vestil will provide an appropriate replacement for any covered part. An authorized representative of
Vestil will contact you to discuss your claim.
What is not covered by the warranty?
The Warrantee (you) is responsible for paying labor costs and freight costs to return the product to
Vestil for warranty service.
Events that automatically void this Limited Warranty.
•Misuse;
•Negligent assembly, installation, operation or repair;
•Installation/use in corrosive environments;
•Inadequate or improper maintenance;
•Damage sustained during shipping;
•Collisions or other accidents that damage the product;
•Unauthorized modifications: Do not modify the product IN ANY WAY without first receiving written
authorization from Vestil.
Do any other warranties apply to the product?
Vestil Manufacturing Corp. makes no other express warranties. All implied warranties are disclaimed
to the extent allowed by law. Any implied warranty not disclaimed is limited in scope to the terms of this
Limited Warranty. Vestil makes no warranty or representation that this product complies with any state
or local design, performance, or safety code or standard. Noncompliance with any such code or
standard is not a defect in material or workmanship.
