4/12/2017
SWA-48, MANUAL
Copyright 2017 Vestil Manufacturing Corp.; All rights reserved Page 2 of 16
Signal Words
This manual uses SIGNAL WORDS to draw the reader’s attention to safety-related information. Signal words
indicate the likelihood of personal injuries as well as the probable seriousness of those injuries, if the product is
misused in the ways described. Other signal words call attention to uses of the product likely cause property damage.
Signal words used in this manual appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS
INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE
injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
Hazards of Improper Use
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is
responsible for exercising sound judgment at all times.
If this product is used improperly or carelessly, personal injuries might result.
DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil. Unauthorized
modifications automatically void the Limited Warranty and might make the product unsafe to use.
Read the manual whenever necessary to refresh your understanding of proper use and maintenance procedures.
DO NOT exceed the capacity of the unit (see Label 287 in “Labeling diagram” on p. 17).
DO NOT stand, or sit, on the turntable or the load at any time.
Install the machine ONLY on even, level surfaces where it will not be exposed to the outdoor environment.
Keep hands, clothing, etc. out of contact with all moving parts of the machine during operation.
During operation, stand with the mast between yourself and the turntable.
DO NOT activate the turntable UNLESS the load is centered on it and stable. Be prepared to stop the turntable,
because rotation can cause the load become unstable. An unstable load might topple during the wrapping process.
EVERY person in the area should remain far enough away from the machine to avoid contact with the load if it falls.
Higher rotation speed might cause an unstable load to slide off of the turntable.
DO NOT continue to use the machine if you observe abnormal motion or noise. Immediately tag the unit “Out of
service” and report the problem to maintenance personnel.
If you notice a malfunction during operation, DO NOT attempt to resolve it unless you are both authorized to do so
and certain that it will be safe to use afterwards. The unit must be in normal operating condition whenever it is used.
(See “Inspections & Maintenance” on p. 13).
Inspect the product before each use as directed on page 13. DO NOT use the machine unless it is in normal
operating condition.
DO NOT use this machine UNLESS all labels are in place, readable, and undamaged. (See “Labeling Diagrams”
on p. 12).
Proper use, maintenance, and storage are essential for this product to function properly.
oAlways use this product in accordance with the instructions in this manual and consistent with any training
relevant to machines, devices, etc. used in conjunction with this product.
oPeriodically lubricate the chain.
oKeep the product clean & dry.
oVestil uses only quality parts to make the equipment we manufacture. Vestil bears no responsibility for problems
that result as a consequence of using unapproved replacement parts. To order replacement or spare parts for this
equipment, contact the factory.
