Vestil PM2-3344-SLP User manual

rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 1 of 6








PM2‐3344‐SLPSuperLowProfilePalletTrucks
InstructionManual












Afterdelivery,immediatelyremovethepackagingfromtheproductinamannerthatpreservesthepackagingand
maintainstheorientationoftheproductinthepackaging;theninspecttheproductcloselytodeterminewhetherit
sustaineddamageduringtransport.Ifdamageisdiscoveredduringtheinspection,immediatelyrecordacomplete
descriptionofthedamageonthebilloflading.Iftheproductisundamaged,discardthepackaging.

NOTES:
1)Compliancewithlaws,regulations,codes,andnon‐voluntarystandardsenforcedinthelocationwheretheproduct
isusedisexclusivelytheresponsibilityoftheowner/end‐user.
2)Vestilisnotliableforanyinjuryorpropertydamagethatoccursasaconsequenceoffailingtoapplyeither:a)the
instructionsinthismanual;orb)informationprovidedonlabelsaffixedtotheproduct.NeitherisVestilresponsible
foranyconsequentialdamagessustainedasaresultoffailingtoexercisesoundjudgmentwhileassembling,installing,
usingormaintainingthisproduct.













Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: [phone] -or- Toll Free [phone]
Fax: [phone]
www.vestilmfg.com e-mail: [email protected]m
Table of Contents
Product specifications………………………………………..…………………………………………………………….. 2
Signal words….……………………………………………………………………………………………………………… 3
Safe use recommendations………………………………………………………………………..……………………….. 3
FIG. 1A: PLC-P-FM exploded parts diagram and bill of materials……………………………………………………… 4
FIG. 1B: Adjust pail stops……………………………………….................................................................................. 4
Height adjustment……………………………………………………………………………………………………………. 5
FIG. 2: Height adjustment diagram………………………………………………………………………………………… 5
Use instructions……………………………………………………………………………………………………………… 5
FIG. 3: Center pail beneath platen………………………………………………………………………………………… 5
FIG. 4: Adjust burper plunger assembly……………………………………………………………………………………5
Inspections & Maintenance………………………………………………………………………………………………… 6
Label placement diagram……...………………………………………………………………………………………….. 6
Limited warranty…...……………………………………………………………………………………………………….. 7

rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 2 of 6

Signalwords:
ThismanualusesSIGNALWORDStoindicatethelikelihoodofpersonalinjuries,aswellastheprobableseriousnessofthose
injuries,iftheproductismisusedinthewaysdescribed.Othersignalwordscallattentiontousesoftheproductlikelycause
propertydamage.Thesignalwordsusedappearbelowalongwiththemeaningofeachword:


Identifiesahazardoussituationwhich,ifnotavoided,WILLresultinDEATHorSERIOUSINJURY.
Useofthissignalwordislimitedtothemostextremesituations.


Identifiesahazardoussituationwhich,ifnotavoided,COULDresultinDEATHorSERIOUS
INJURY.

Indicatesahazardoussituationwhich,ifnotavoided,COULDresultinMINORorMODERATE
injury.

 Identifiespracticeslikelytoresultinproduct/propertydamage,suchasoperationthatmight
damagetheproduct.

Eachpersonwhoassembles,installs,uses,ormaintainsthisproductshouldreadtheentiremanualandfullyunderstand
thedirectionsinadvance.Ifafterreadingthemanualyoudonotunderstandaninstruction,askyoursupervisororemployerfor
clarification,becausefailuretoadheretothedirectionsinthismanualmightresultinseriouspersonalinjury.

Productspecifications: 

Dimensionsandotherpertinentspecificationsappearinthetablebelow.
ModelUniform
capacityOverallforkdimensionsForkservicerangeNetweight
PM2‐2044‐SLP2,200lb.
1,000kg
20in.(W)x44in.(L)
51cmx112cm
1
1
/
2
in.to3
3
/
8
in.
3.8cmto8.6cm
313lb.
142.3kg
PM2‐2744‐SLP2,200lb.
1,000kg
20in.(W)x44in.(L)
51cmx112cm
1
1
/
2
in.to3
3
/
8
in.
3.8cmto8.6cm
323lb.
146.8kg
PM2‐3344‐SLP2,200lb.
1,000kg
20in.(W)x44in.(L)
51cmx112cm
1
1
/
2
in.to3
3
/
8
in.
3.8cmto8.6cm
333lb.
151.4kg

Safeuserecommendations: 

Vestilstrivestoidentifyforeseeablehazardsassociatedwiththeuseofitsproducts.However,materialhandlingis
dangerousandnomanualcanaddresseveryconceivablerisk.Theend‐userultimatelymustexercisesoundjudgmentatall
timestominimizetherisksassociatedwiththeuseofthisproduct.


Failuretoreadandunderstandtheentiremanualbeforeassembling,installing,usingandservicingthe
productisamisuseoftheproduct.Ifthisproductisusedimproperlyorcarelessly,theoperatorand/orbystandersmight
sustainseriouspersonalinjuries.Toreducethelikelihoodofinjury:
DONOTmodifytheproductinanywayUNLESSyoufirstobtainwrittenapprovalfromVestil.Unauthorizedmodifications
automaticallyvoidtheLimitedWarrantyandmightmaketheproductunsafetouse.
Readthemanualwheneverthehandlemustbeinstalledordisconnected.
Readthemanualwheneverthereleasemechanismrequiresadjustment.
DONOTexceedthe2,200poundcapacity(alsoseeLabel287in“Labelplacementdiagram”onp.6).
Keepclearofthewheelsandforkswhileusingthepallettruck.
DONOTcontinuetousethepallettruckifyouobserveabnormalmotionorhearunusualnoiseswhileraising/loweringthe
forksormovingthetruck.Immediatelytagtheunit“Outofservice”.Restoretheunittonormaloperatingconditionbefore
returningittoservice.
DONOTattempttoresolveanyproblem(s)withtheproductunlessyouarebothauthorizedtodosoandcertainthatitwill
besafetouseafterwards.
DONOTusethisdeviceUNLESSallproductlabels(see“LabelPlacementDiagram”onp.5)arereadableandundamaged.
Properuse,maintenance,andstorageareessentialforthisproducttofunctionproperly.
oKeeptheproductclean&dry.
oVestilbearsnoresponsibilityforproblemsthatresultasaconsequenceofusingunapprovedreplacementparts.Contact
Vestiltoorderauthorizedreplacementsandsparepartsforthisequipment.


rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 3 of 6
Assemblyinstructions:
Thefollowinginstructionsexplainhowtoattachtheoperatorhandletothemainbodyofthetruck.


Frontview Sideview
NOTE: Photosthatappearintheassembly
instructionsareofthehandleandreceiver
connectionwhichappearsinsidethedashed
boxes inthefrontandsideviews.
Step2. Pullthechainoutofthehandleandlayitoverthepivot
pin.
Step1.Insertthebottomofthehandleinto
thereceiver.
Receiver
Step3.Useahammertoinserttheaxlepin through theholes
inthereceiver;thenhammerspringpinsthroughtheendsof
theaxlepin(groovesareprovidedinthereceiverholesforthe
springpins.]Removetheshippingpin.Theshippingpinisnot
partofthefinishedassembly.
Pivot
pin
Chain
Axlepin
Springpin
Shipping
p
in
Axlepin
Groovefor
springpin
Spring
p
in
Step 4. Feedthechainbehindthepivotand
through the axlepin holeandintotherelease
levercavity(alsoseestep1).Thethreaded
shaftandlocknutat
theendofthechainshouldfit in the release
lever asshownbelow.
Release
lever
Release
lever
cavity
Threaded
shaft
Locknut
Release
lever
Pump
p
iston

rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 4 of 6













Releaseleveroperation:
Acontrolleverispartofthehandleassembly.Thecontrolleverhas3positions,eachofwhichcorrespondstoadifferent
functionasindicatedinthediagrambelow.Toraisetheforks,pushthecontrolleverdowntotheRAISEposition;thenmovethe
handleup‐and‐down.Tolowertheforks,pullthecontrolleverup.ThecontrolleverreturnstotheDRIVEpositionautomatically
onceitisreleasedfromtheLOWERposition.
































Step5.Liftthereleaseleveruntilthethreadedshaftcanslideintotheslotintheendofthelever.



Threaded
shaft
Locknut
Release
lever





 


Troubleshooting:
1. ControllevelintheDRIVEposition:
a. Iftheforkselevatewhilepumpingthehandleup‐and‐down,thelocknut(seestep5above;fastenedtotheendofthe
threadedshaft)requiresadjustment.Turnthenutclockwise;thenpumpthehandleagaintodetermineiftheforksstill
rise.Continuetoturnthenutclockwiseuntiltheforksnolongerrise.
b. Ifpumpingthehandlecausestheforkstolower,turnthelocknutcounterclockwise.Turnthenutcounterclockwise
untiltheforksnolongerdescend.
2. ControlleverintheLOWERposition:
a. Iftheforksdonotlower,turnthelocknutclockwise.Turnthenutclockwiseuntiltheforkslower.
3. ControlleverintheRAISEposition:
a. Iftheforksdonotrisewhilepumpingthehandle,turnthenutcounterclockwise.Continuetoturnthenutuntilthe
forksriseproperly.
RAISE
p
osition
LOWER
position
DRIVE position
Release
lever

rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 5 of 6
Labelplacementdiagram:

























































BA
C
A:Label371

B:Label465

C:Label463


rev. 3/3/2015 PM2-3344-SLP, MANUAL.doc
Copyright 2015 Vestil Manufacturing Corp. 6 of 6
LIMITEDWARRANTY

VestilManufacturingCorporation(“Vestil”)warrantsthisSemi‐AutomaticStrappingMachine,modelS‐2001tobefreeof
defectsinmaterialandworkmanshipduringthewarrantyperiod.Ourwarrantyobligationistoprovideareplacementfora
defectiveoriginalpartifthepartiscoveredbythewarranty,afterwereceiveaproperrequestfromthewarrantee(you)for
warrantyservice.

Whomayrequestservice?
Onlyawarranteemayrequestservice.YouareawarranteeifyoupurchasedtheproductfromVestilorfromanauthorized
distributorANDVestilhasbeenfullypaid.

Whatisan“originalpart”?
Anoriginalpartisapartusedtomaketheproductasshippedtothewarrantee.

Whatisa“properrequest”?
ArequestforwarrantyserviceisproperifVestilreceives:1)aphotocopyoftheCustomerInvoicethatdisplaystheshipping
date;AND2)awrittenrequestforwarrantyserviceincludingyournameandphonenumber.Sendrequestsbyanyofthe
followingmethods:

 Mail   FaxEmail
VestilManufacturingCorporation  (260)665‐1339  [email protected]
2999NorthWayneStreet,POBox507 Phone
Angola,IN46703    (260)665‐7586

Inthewrittenrequest,listthepartsbelievedtobedefectiveandincludetheaddresswherereplacementsshouldbedelivered.

Whatiscoveredunderthewarranty?
AfterVestilreceivesyourrequestforwarrantyservice,anauthorizedrepresentativewillcontactyoutodeterminewhetheryour
claimiscoveredbythewarranty.Beforeprovidingwarrantyservice,Vestilmayrequireyoutosendtheentireproduct,orjust
thedefectivepartorparts,toitsfacilityinAngola,IN.Thewarrantycoversdefectsinthefollowingoriginaldynamic
components:motors,hydraulicpumps,electroniccontrollers,switchesandcylinders.Italsocoversdefectsinoriginalpartsthat
wearundernormalusageconditions(“wearingparts”),suchasbearings,hoses,wheels,seals,brushes,andbatteries.

Howlongisthewarrantyperiod?
Thewarrantyperiodfororiginaldynamiccomponentsis90days.Forwearingparts,thewarrantyperiodis90days.The
warrantyperiodsbeginonthedatewhenVestilshipstheproducttothewarrantee.Iftheproductwaspurchasedfroman
authorizeddistributor,theperiodsbeginwhenthedistributorshipstheproduct.Vestilmay,atitssolediscretion,extendthe
warrantyperiodsforproductsshippedfromauthorizeddistributorsbyupto30daystoaccountforshippingtime.

Ifadefectivepartiscoveredbythewarranty,whatwillVestildotocorrecttheproblem?
Vestilwillprovideanappropriatereplacementforanycoveredpart.AnauthorizedrepresentativeofVestilwillcontactyouto
discussyourclaim.

Whatisnotcoveredbythewarranty?
1. Labor;
2. Freight;
3. Occurrenceofanyofthefollowing,whichautomaticallyvoidsthewarranty:
Productmisuse;
Negligentoperationorrepair;
Corrosionoruseincorrosiveconditions;
Inadequateorimpropermaintenance;
Damagesustainedduringshipping;
Accidentsinvolvingtheproduct;
Unauthorizedmodifications:DONOTmodifytheproductINANYWAYwithoutfirstreceivingwrittenauthorization
fromVestil.Modification(s)mightmaketheproductunsafetouseormightcauseexcessiveand/orabnormalwear.

Doanyotherwarrantiesapplytotheproduct?
VestilManufacturingCorp.makesnootherexpresswarranties.Allimpliedwarrantiesaredisclaimedtotheextentallowedby
law.AnyimpliedwarrantynotdisclaimedislimitedinscopetothetermsofthisLimitedWarranty.

