VEVOR RC-9001 User manual

Support and E-Warranty Certificate
www.vevor.com/support
50/75/100 FOOT
Electric Drain Cleaner
Model: RC-9001
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and doses not necessarily mean to
cover all categories of tools offered by us. You are kindly reminded to verify
carefully when you are placing an order with us if you are actually saving half
in comparison with the top major brands.

- 1 -
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Model: RC-9001
50/75/100 FOOT
Electric Drain Cleaner

- 2 -
Save This Manual
Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the
product’s serial number in the back of the manual near the assembly
diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference.
General Power Tool Safety Warnings
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
The term ″power tool″in the warnings refers to your mains-operated
(corded) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not
avoided,could result in death or serious injury.
Indicates a hazardous situation which, if not
avoided,could result in minor or moderate injury.
Addresses practices not related to personal injury.

- 3 -
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
2. Avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is grounded.
3. Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling
or unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
5. When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
Personal safety
1. Stay alert, watch what you are doing and use common sense
when operating a power tool.Do not use a power tool while you are
tired or under the influence of drugs,alcohol or medication.
A moment of inattention while operating power tools may result in
serious personal injury.
2. Use personal protective equipment.Always wear eye protection.
Safety equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source, picking up or carrying

- 4 -
the tool.
Carrying power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning the power
tool on.
A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in moving parts.
7. Only use safety equipment that has been approved by an
appropriate standards agency.
Unapproved safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved and breathing
protection must be NIOSH approved for the specific hazards in
the work area.
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application.
The correct power tool will do the job better and safer at the rate
for which it was designed.
2. Do not use the power tool if the switch does not turn
it on and off.
Any power tool that cannot be control led with the switch
is dangerous an d must be repaired.
3. Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools.
Suc h pr eventive safety measur es reduce the risk of
starting the power tool ac cidentally.
4. Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these

- 5 -
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7 . Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair person using
only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
Drain Cleaner Safety Warnings
1. Maintain labels and nameplates on the tool. These carry important
safety information. If unreadable or missing, contact Harbor Freight Tools
for a replacement.
2. Wear ANSI-approved safety impact eye goggles and heavy duty
LEATHER work gloves when using the Drain Cleaner. Never grasp a
rotating cable with a rag or cloth glove. Using personal safety devices
reduce the risk for injury. Safety impact eye goggles and heavy work
gloves are available from Harbor Freight Tools.
3. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
4. Do not force the Drain Cleaner. This tool will do the work better and
safer at the speed and capacity for which it was designed.
5. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Always keep the
work area free of obstructions, grease, oil, trash, and other debris. Do not
use a power tool in areas near flammable chemicals, dusts, and vapors

- 6 -
6. Unplug the Drain Cleaner from its electrical outlet before
performing any inspection, maintenance, or cleaning procedures.
7. Do not leave the Drain Cleaner unattended while running. Turn
power off if you have to leave the Drain Cleaner.
8. Do not allow the cutter to stop turning while the machine is
running. This can over stress the cable and may cause twisting, kinking or
breaking of the cable. Twisting, kinking or breaking cable may cause
striking or crushing injuries.
9. Keep gloved hand on the cable whenever the machine is running.
This provides better control of the cable and helps prevent twisting, kinking
and breaking of the cable. Twisting, kinking or breaking cable may cause
striking or crushing injuries
10. Before each use, check all nuts, bolts, and screws for tightness.
Vibration during operation may cause these to loosen.
11. Avoid electrical shock. Do not operate the Drain Cleaner if sitting in
standing water, and if the operator is in standing water. Keep extension
cord off the ground and away from water. Water increases the risk of
electric shock.
12. Install this product on a proper surface. Locate on a flat, level, and
solid surface that is capable of supporting the weight of the Drain Cleaner.
13. Do not operate the Drain Cleaner with the belt guard removed.
Fingers can get caught between the drive belt and pulley.
14. Do not put too much stress on cable. Keep gloved hand on the
cable for control when machine is running. In the course of drain cleaning,
if the cable encounters an obstruction, it may stress the cable and cause
the cable to twist, kink, or break. This may result in serious injury, and
damage the equipment or pipes.
15. Position Drain Cleaner within two feet of drain opening. Greater
distances can result in the cable twisting or kinking.
16. One person must control both the cable and the Foot Switch. If
the cutter stops rotating, the operator must be able to turn the machine
motor off to prevent twisting, kinking and breaking of the cable. Twisting,
kinking or breaking cable may cause striking or crushing injuries.
17. Reverse Motor direction only when pulling the Cable off an
obstruction. Trying to push the Cable down the pipe or pull it out of a pipe
while in reverse operation can result in Cable damage. Make sure Drum
has stopped turning before changing the Rotation Switch.
18. Keep hands away from the rotating Drum and Distributor Tube.
Do not reach into Drum unless the Drain Clean power cord is unplugged.
19. Use appropriate personal protective equipment while handling
and using drain cleaning equipment. Drains may contain chemicals,
bacteria and other substances that may be toxic, infectious, cause burns

- 7 -
or other issues. Appropriate personal protective equipment always
includes ANSI approved safety glasses and heavy-duty work gloves, and
may include equipment such as latex or rubber gloves, face shields,
goggles, protective clothing, respirators and steel toed footwear.
20. Wash hands after use. Use hot, soapy water to wash hands and
other exposed body parts exposed to drain contents after handling or
using drain cleaning equipment. Do not eat or smoke while operating or
handling drain cleaning equipment. This will help prevent contamination
with toxic or infectious material.
Drain Cleaner Safety Warnings (cont.)
Do not operate this machine if operator or machine is standing in
water. Operating machine while in water increases the risk of
electrical shock.
Only use drain cleaning machine to clean drains of recommended
sizes according to these instructions. Other uses or modifying the
drain cleaning machine for other applications may increase the risk of
injury.
Be aware of possible damage to drain lines that may result from the
discovery of roots and other obstacles.
WARNING! People with pacemakers should consult their
physician(s) before using this product. Electromagnetic fields in
close proximity to a heart pacemaker could cause interference to or
failure of the pacemaker. In addition, people with pacemakers
should adhere to the following:
• Avoid operating power tools alone.
• Properly maintain and inspect all tools before use to avoid electrical
shock.
WARNING! Handling the cord on this product will expose you to lead,
a chemical known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
(California Health & Safety Code § 25249.5, et seq.)
The warnings, precautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be
supplied by the operator.

- 8 -
Vibration Safety
This tool vibrates during use.
Repeated or long- term exposure to vibration may cause temporary
or permanent physical injury, particularly to the hands, arms and
shoulders.To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an extended period should
first be examined by a doctor and then have regular medical check-ups to
ensure medical problems are not being caused or worsened from use.
Pregnant women or people who have impaired blood circulation to the
hand, past hand injuries, nervous system disorders, diabetes, or
Raynaud’s Disease should not use this tool. If you feel any symptoms
related to vibration (such as tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces the blood supply to the
hands and fingers, increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the vibration effects on the user.
4. Use tools with the lowest vibration when there is a choice.
5. Include vibration-free periods each day of work.
6. Grip tool as lightly as possible (while still keeping safe control of it). Let
the tool do the work.
7. To reduce vibration, maintain the tool as explained in this manual. If
any abnormal vibration occurs, stop use immediately.
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM
INCORRECT GROUNDING
Check with a qualified electrician if you are in doubt as to whether the
outlet is properly grounded. Do not modify the power cord plug provided
with the tool. Never remove the grounding prong from the plug. Do not
use the tool if the power cord or plug is damaged. If damaged, have it
repaired by a service facility before use. If the plug will not fit the outlet,

- 9 -
have a proper outlet installed by a qualified electrician.
Grounded Tools: Tools with Three Prong Plugs
1. Tools marked with “Grounding Required” have a three wire cord and
three prong grounding plug. The plug must be connected to a properly
grounded outlet. If the tool should electrically malfunction or break down,
grounding provides a low resistance path to carry electricity away from the
user, reducing the risk of electric shock. (See 3-Prong Plug and Outlet.)
2. The grounding prong in the plug is connected through the green wire
inside the cord to the grounding system in the tool. The green wire in the
cord must be the only wire connected to the tool’s grounding system and
must never be attached to an electrically “live” terminal. (See 3-Prong
Plug and Outlet.)
3. The tool must be plugged into an appropriate outlet, properly installed
and grounded in accordance with all codes and ordinances. The plug and
outlet should look like those in the preceding illustration. (See 3-Prong
Plug and Outlet.)
3-Prong Plug and Outlet
Ground Fault Circuit Interrupter (GFCI)
Your machine is equipped with a ground fault circuit interrupter (GFCI),
which protects you against shock if a short circuit should occur. Check that
the receptacle is properly grounded and test the GFCI before each use.
1. Plug the GFCI Power Plug into a grounded, 120 VAC electrical
outlet.

- 10 -
2. Press the TEST button. The GFCI indicator light will go out and power
to the machine should cut off.
3. WARNING! If the light does not go out when test button is pushed,
equipment should not be used until proper repairs can be made.
4. To restore power after test, push the reset button. WARNING! If the
machine doesn’t start, stops while running, or if you experience a mild
shock, do not use the machine. Have it repaired or replaced by a licensed
electrician.
Note: The Power Cord is not GFCI protected from the GFCI unit to the 3-
prong plug in the electrical outlet.
Extension Cords
1. Grounded tools require a three wire extension cord. Double
Insulated tools can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a
heavier gauge extension cord. Using extension cords with
inadequately sized wire causes a serious drop in voltage, resulting
in loss of power and possible tool damage. (See Table A on page 7.)
3. The smaller the gauge number of the wire, the greater the capacity
of the cord. For example, a 14 gauge cord can carry a higher
current than a 16 gauge cord. (See Table A.)
4. When using more than one extension cord to make up the total
length, make sure each cord contains at least the minimum wire
size required. (See Table A.)
5. If you are using one extension cord for more than one tool,
add the nameplate amperes and use the sum to determine
the required minimum cord size. (See Table A.)
6. If you are using an extension cord outdoors, make sure it is
marked with the suffix “W-A”(“W”in Canada) to indicate it is
acceptable for outdoor use.
7. Make sure the extension cord is properly wired and in good
electrical condition. Always replace a damaged extension cord or
have it repaired by a qualified electrician before using it.
8. Protect the extension cords from sharp objects, excessive heat,
and damp or wet areas.

- 11 -
TABLE A: RECOMMENDED MINIMUM WIRE GAUGE FOR
EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE
AMPERES (at full
load)
EXTENSION CORD LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop to five volts at
150% of the rated amperes.
Symbology
European Standards Association
Compliance is a North n security certification.
V~ Volts Alternating Current
AAmperes
n0xxxx / min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk of Eye Injury.
Wear ANSI-approved safety goggles with side shields.
Read the manual before set-up and/or use.

WARNING marking concerning Risk of Fire. Do not cover
ventilation ducts. Keep flammable objects away
WARNING marking concerning. Risk of Electric Shock.
Properly connect power cord to appropriate outlet.
Specifications
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
120V~, 60Hz, (North）220-230V~ 50Hz（Europe）
1800 RPM (North） 1500RPM（Europe）
1.3 Meters
1/2 Inch Dia. x 50/75/100FT Long
3/8 Inch Dia. x 50/75/100FT Long
3/4 Inch Dia. x 100FT Long
up to 50-100MM and 100-200MM of 1/2 Inch Cable & 3/8 Inch Cable
up to 100-200MM of 3/4 Inch Cable
329x160MM/329x216MM/455x216MM
up to 100FT of 1/2 Inch Cable (Not included)
up to 100FT of 3/8 Inch Cable (Not included)
up to 100FT of 3/4 Inch Cable (Not included)
Electrical Rating
Motor Speed
Power Cord
Cable Type
Drain Pipe Capacity
Drum Dimensions
Drum Capacity

- 13 -
Functions
Cutting Tool Accessories
There are four Cutting Tools included with each Drain Cleaner. Select the
appropriate tool for the cleaning job and attach to Cable. Each is
described in the table below.

- 14 -
Arrow Cutter Boring Bulb Cutter C-Cutter Spade Cutter
Cutter Tool
Applications
Arrow Cutter (2 pieces)
Starting tool; ideal for cutting and scraping
Boring Bulb Cutter
Starting tool; ideal for removing loose objects
C-Cutter
Finishing tool; ideal for grease stoppages and cleaning
pipe walls.
Spade Cutter
Finishing tool; used for scraping the inside edges of
pipes.
NOTICE: If the cause of the obstruction is unknown, use the Boring Bulb
Cutter to explore the obstruction and, if possible, retrieve a piece to
inspect. Once you can see the cause of the obstruction, select the
appropriate tool for the job. Run the smallest available tool through the
blockage to allow the backed up water to flow and carry away the debris
as the drain is cleaned.
Once the drain is flowing, more appropriate tools can be used on the rest
of the blockage.
Keep in mind that the largest tool used should be no bigger than the
drain’s inside diameter, minus an inch.
If properly used, the Drain Cleaners and assorted Drain Cleaner
Accessories will not damage a drain that is in good condition and properly
designed, constructed, and maintained.
However, if the drain is in poor condition or has not been properly
designed, the drain cleaning work may damage the drain. If possible,
visually inspect the drain’s quality before operation.

- 15 -
Assembly
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Rotation Switch of the tool to its “OFF”position and unplug the
tool from its electrical outlet before assembling or making any adjustments
to the tool.
Note: For additional information regarding the parts listed in the following
pages, refer to the Assembly Diagram near the end of this manual.

- 16 -
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Rotation Switch of the tool to its “OFF”position and unplug the
tool from its electrical outlet before assembling or making any adjustments
to the tool.
TO PREVENT SERIOUS INJURY:
DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR
REMOVED.
Wear ANSI-approved safety goggles, heavy-duty LEATHER work
gloves, and other appropriate protective equipment when setting up
your Drain Cleaner. For extra protection from chemicals and bacteria
on the machine and in the work area, we recommend wearing latex,
rubber or other liquid barrier gloves under the heavy-duty work gloves.
Before use, inspect gloves to be sure they are free of defects or loose
sections that could be caught in the Drain Cleaner. Rubber soled, non-slip
shoes can help prevent slipping and electric shock, especially on wet
surfaces.
TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK,
TWISTED/BROKEN CABLES, CHEMICAL BURNS, INFECTIONS AND
OTHER CAUSES AND PREVENT DRAIN CLEANER DAMAGE:
Before each use, inspect Drain Cleaner and correct any problems.
1. Once the Drain Cleaner is assembled, check the device and cutters for
any signs of wear and damage. If necessary, replace worn or damaged
parts prior to using the drain cleaning machine. Dull or damaged cutting
tools can lead to binding, cable breakage, and slow the drain cleaning.
2. Verify Drain Cleaner is unplugged and inspect the power cord, Ground
Fault Circuit Interrupter (GFCI) and plug for damage. If the plug has

- 17 -
been modified, is missing the grounding prong or if the cord is damaged,
to avoid electrical shock, do not use the machine until the cord has been
replaced by a qualified electrician.
3. Clean any oil, grease or dirt from all equipment handles and controls.
This helps prevent the machine or control from slipping during use.
4. Verify Foot Switch is attached to Drain Cleaner.
5. Verify Drain Cleaner is properly assembled. Inspect the machine for
broken, worn, missing, misaligned or binding parts or any other condition
which may prevent safe and normal operation.
6. Make sure that switches and handles move smoothly between
positions and lock in place, and that the bumpers at the bottom of the
handle are present and firmly attached.
7. Rotate the drum and make sure that it turns freely without binding.
8. Check that all warning labels are present, firmly attached and readable.
9. Make sure Belt Guard is securely fastened to the Drain Cleaner.
10. Check the cable for any wear and damage. If any section of the cable
is worn or flattened, replace cable before use.
11. Verify cable does not have multiple or excessive kinks (greater than
15°). Kinks weaken the cable and can cause cable failure. Replace any
cables that have multiple or excessively large kinks.
12. Look for spaces between the cable coils.
Kinking, stretching (pulling cable by hand) or running the cable in reverse
can deform the cable. Cables with spaces between the coils should be
replaced.
13. Check for signs of excessive corrosion. Corrosion weakens the cable,
making it brittle. This can be caused by storing the cable wet or using the
cable with corrosive chemicals (often found in chemical clog removers).
Excessively corroded cable should be replaced.
14. Before use, fully retract the cable with no more than 2″ of cable outside
of the machine. This will the keep the cable from “whipping” when the
machine is turned on.
15. Set the Rotation Switch to the OFF position.
16. With dry hands, plug cord into properly grounded outlet and move the
Rotation Switch into the Forward position.

- 18 -
17. Move Feed Lever to exactly between F and R settings, otherwise cable
will start moving in or out during this test.
18. Press the Foot Switch and note the direction of rotation of the drum. If
the Foot Switch does not control the Drain Cleaner’s operation, do not
use the machine until the Foot Switch has been repaired.
19. The drum should rotate clockwise when seen from the front of the
drum. It will match the drum direction shown on the warning label and the
arrow on the drum. If the rotation is not correct, do not use the machine
until it has been repaired.
20. After inspection, set the Rotation Switch to OFF, dry off your hands,
and unplug the Drain Cleaner.
21. Once you’ve verified that the Drain Cleaner is in good working order,
inspect the work area where you will be using the machine.
Work Area Set-Up
1. Verify that work area has adequate lighting for the job.
2. Make sure work area is free of flammable liquids, vapors or dust that
may ignite. Sparks can be generated during Drain Cleaner operation. Do
not work in area until these sources of ignition have been identified and
corrected.
3. Choose a firm, stable location for the machine and operator that will
remain relatively dry. Do not use the machine while standing in water. If
needed, remove the water from the work area.
4. Verify the electrical outlet is properly grounded. A three-prong or GFCI
outlet may not be properly grounded. If in doubt, have outlet inspected by
a licensed electrician.
5. Make sure there is a clear, unobstructed path from the Drain Cleaner to
the electrical outlet.
6. Inspect the drain to be cleaned. If possible, determine the best access
point (s) to the drain, the size(s) and length(s) of the drain, distance to
tanks or mainlines, the nature of the blockage, presence of drain cleaning
chemicals or other chemicals, etc.
7. If there are chemicals present in the drain, read and adhere to the
specific safety measures required to work around those chemicals.
Contact the chemical manufacturer for required

safety instructions and information.
8. If necessary, remove fixture (toilet, sink, etc.) to allow access to the
drain. Do not feed the cable through a fixture. This could damage the
Drain Cleaner and the fixture.
9. Determine the correct drain cleaning cable size for the drain cleaning
job. See Cable/Pipe Size chart below.
10. If needed, place protective covers over the work area floor. Cleaning
the clogged drain can be a messy operation.
11. Make sure that the Drain Cleaner handle is locked into the upright
position for transport. If the Drain Cleaner needs to be lifted, use proper
lifting techniques or seek assistance if needed. Use caution when moving
equipment up and down stairs. Wear appropriate footwear to help prevent
slipping on floor.
12. Set the Drain Cleaner so that the drum opening is within 2 feet of the
drain access. The greater the distance from the drain access, the higher
the risk of the cable twisting or kinking.
13. If the machine cannot be placed with the drum opening within 2′of
the drain access, use appropriate-sized pipes and fittings to extend the
drain access back to within 2′of the drum opening. Improper cable
support can allow the cable to kink and twist and can damage the cable or
injure the operator.
14. If needed, set up barriers to keep bystanders away from the Drain
Cleaner and work area during operation.
15. Select proper cutting tool. (See Cutting Tool Accessories ).
16. Install the tool to the end of the cable. Slide the base of the Cutter
Tool into the slot at the end of the cable. Fasten together using a
screwdriver.
17. Position the Foot Switch for easy accessibility. You must be able to
hold and control the cable, control the Foot Switch, and reach the Rotation
Switch.
Cable Size Pipe Size Typical Applications
1/2 Inch 50-100MM to 200MM Roof stacks and small floor drains (no roots)
3/8 Inch 50-100MM to 200MM Roof stacks and small floor drains (no roots)
3/4 Inch 100MM to 200MM Roof stacks and small floor drains (no roots)
