Viatom pulox Checkme Lite User manual

Checkme Lite Health Monitor
User’s Manual………………….…….English 1-19
Manuel de l'utilisateur ......... Français 20-35
Benutzerhandbuch …………...Deutsch 36-51
Manuale d’uso……………………Italiano 52-66

2
Checkme Lite Health Monitor User’s Manual
Warnings and Cautionary Advices
We recommend not to use this device if you have a pacemaker or other
implanted devices. Follow the advice given by your doctor, if applicable.
Do not use this device with a defibrillator.
Do not use this device during MRI examination.
Never submerge the device in water or other liquids. Do not clean the device with
acetone or other volatile solutions.
Do not drop this device or subject it to strong impact.
Do not place this device in pressure vessels or gas sterilization device.
Do not dismantle the device, as this could cause damage or malfunctions or
impede the operation of the device.
This device is not intended for use by people (including children) with restricted
physical, sensory or mental skills or a lack of experience and/or a lack of
knowledge, unless they are supervised by a person who has responsibility for
their safety or they receive instructions from this person on how to use the
device.
This device displays changes in the heart rhythm and blood oxygenation etc.
which may have various different causes. These may be harmless, but may also be
triggered by illnesses or diseases of differing degree of severity. Please consult a
medical specialist if you believe you may have an illness or disease.
Do not self-diagnose or self-medicate on the basis of this device without
consulting your doctor. In particular, do not start taking any new medication or
change the type and/or dosage of any existing medication without prior approval.
The device has no alarms and will not sound if the measurement reading is too
low or too high.
1. About Checkme
1.1 Intended Use
The Checkme Lite health monitor is intended to be used for measuring, displaying,
storing and reviewing of multiple physiological parameters including ECG, pulse oxygen
saturation (SpO2) and systolic blood pressure (SBP) in home or healthcare facilities
environment.
ECG and SBP are intended for use with adult.
The data and results provided by this device are for pre-check screening purpose only
and cannot be directly used for diagnostic or treatment.

3
1.2 Outline
1 2
3
4
5
1. Touch Screen
2. Internal SpO2 sensor
3. Micro-D connector - It connects with mirco-D cable for charging.
4. Home button
When the monitor is off, press this button to power it on.
When the monitor is on, press and hold it for 2 seconds to turn it off.
During operation, press this button will switch to Main Screen or return to upper
menu.
5. ECG right electrode (Put right thumb onit.)
6
9 7
8
6. Speaker
7. ECG left electrode
8. (Put it to your left palm, left abdomen or left knee.)
9. Neck stripe hole
10. ECG back electrode
11. (Put right forefinger or middle finger on it.)
1.3 Main Screen
The Main Screen is shown as below.

4
Press an icon in the Main Screen will start a measurement, activate a function, or open
corresponding menu.
The device will enter Main Screen when:
No operation is detected for 60 seconds in result screen, the device will
automatically switch to Main Screen.
Pressing the Home button in other screen interface.
You can change the sound volume by taping the button on the left of the screen,
then tap the <Volume> area. Or you can also go to the Setting menu to change it.
1.4 Symbols
Symbol
Meaning
Application part type BF
Manufacturer
CE0197
In conformity with Directive 93/42/EEC
European Representative
Symbol for “ENVIRONMENT PROTECTION – Waste electrical
products should
not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or retailer for
recycling advice”.
IP22
Against ingress of solid foreign objects ≥12.5mm diameter;
Against dripping
(15° tilted)
Follow operating instructions
No alarm system.

5
2. Getting Started
2.1 Power On/Off
Press the Home button to power on the device. Press and hold Home button for 2
seconds to power off the device.
2.2 Initial Settings
The first time when the Checkme is powered on, you can set up your Checkme step by
step. You can also change the settings in the <Settings> menu.
3. Using Checkme
3.1 Prior to Use
Before using ECG
Before using Daily Check or ECG Recorder function, pay attention to the following points
in order to obtain precise measurements.
If your skin or hands are dry, moisten them before taking the measurement.
During the measurement, do not touch your body with the hand with which you
are taking the measurement.
Please note that there must be no skin contact between your right and left hand.
Otherwise, the measurement cannot be taken correctly.
Stay still during the measurement, do not speak and move.
If possible, take the measurement when sitting instead of standing.
Before using Oximeter
Before using Daily Check and Oximeter function, pay attention to the following points in
order to obtain precise measurements.
The finger inserted in SpO2 sensor must be clean.
Any of the following conditions may cause inaccurate measurements, including
but not limited to:
-Flickering or very bright light;
-Poor blood circulation;
-Low hemoglobin;
-Hypotension, severe vasoconstriction, severe anemia or hypothermia;
-Nail polish, artificial nails;
-Any tests recently performed on you that required an injection of
intravascular dyes.
The Oximeter may not work if you have poor circulation. Rub your finger to
increase circulation, or place the SpO2 sensor on another finger.
The Oximeter measures oxygen saturation of functional hemoglobin. High levels
of dysfunctional hemoglobin (caused by sickle cell anemia, carbon monoxide,
etc.) could affect the accuracy of the measurements.
The pleth waveform displayed on the device is normalized.
Warnings and Cautionary Advices
Limit finger movement as much as possible when using the Daily Check or
Oximeter, which might result in incorrect reading or analysis.
3.2 Daily Check

6
About Daily Check
Warnings and Cautionary Advices
To ensure better tracking of your health status, it is strongly suggested that every
Daily Check measurement is made at the same time period when your body is in
the relative same situation. E.g., every morning when get up, or every night
before go to bed.
Daily Check measurement is a function that combines the measuring of ECG
(Electrocardiograph) waveform, HR (heart rate), SpO2 (blood oxygenation), PI (Pulse
Index), systolic Blood Pressure. It takes only 20 seconds to collect your vital signs before
giving results.
Using Daily Check
To start a Daily Check, follow the steps as below.
1. Tap the <Daily Check> icon in the middle
of the Main screen.
2. Hold the device according to the
instruction, keep the device at the same
level as your heart, and keep stable
posture and stay calm. Don’t exert too much pressure on the ECG electrode,
which may result in EMG (electromyograph) interference. Just hold gently and
ensure good contact with the ECG electrode. Do not exert pressure on the finger
that put in the SpO2 sensor. Just fit it inside but gently to ensure good blood
perfusion.
(1)
Put the right forefinger into the built-in SpO2sensor. Use the finger nail to
(1)
(4)
(1)
(2)
squeeze the edge of the SpO2sensor cover, then move in upward to the left
to raise it up as shown below.
(2)
Press the right thumb on the rightelectrode.
(3)
Press the right middle finger on the back
electrode.
(4)
Press the left electrode to the left palm.
3. Once the device detects stable waveform, it will
automatically start the measurement. The countdown
bar moves from left to right.

7
4. When the bar is fully filled, the device will analysis your data, and then show the
measurement result.
3.3 ECG Recorder
Different methods of taking the ECG measurement are available on Checkme. The ECG
recorder offers two different methods to measuring ECG:
Lead I: right hand to left hand
Lead II: right hand to left abdomen or left knee
Please keep stable posture and stay calm during the measurement. Movements may
result in interference and incorrect readings or analysis result.
Measuring without cable
To start an ECG Recorder measurement without cable,
1.
If the device is power off, press the Home button.
2.
In the Main Screen, tap the <ECG Recorder> icon.
3.
Choose the method A or B.
4.
Follow the instruction according to the mode you
selected.
Press the right thumb on the right electrode;
Press the right forefinger on the back electrode;
For Lead I, press the left electrode to the left palm;
For Lead II, press the left electrode to the left lower
abdomen;
Do not press the device too firmly against your skin, which may result in EMG
(electromyography) interference. After you finish the above steps, hold the device stably
and stay calm.
1. Once the device detects stable waveform, it will automatically start the
measurement. The countdown bar moves from left to right.
2. When the bar if fully filled, the device will analysis your data, and then show the
measurement result.
Measuring with Cable
To start an ECG Recorder measurement with cable,

8
1.
If the device is power off, press the Home button.
2.
In the Main Screen, tap the <ECG Recorder> icon.
3.
Choose the method C or D.
4.
Follow the instructions to connect the ECG cable and place the ECG electrodes.
Sit down or stand, stay calm;
Palms facing up, place an electrode in the middle of right wrist;
For method C, place another electrode in the middle of left wrist;
For method D, place another electrode in the left lower abdomen;
5.
The display will then show your ECG waveform.
The device will monitor your ECG continuously, however no data will be saved
until you press the button.
6.
Press the button to start collecting your ECG data. The countdown bar
movesfrom left to right.
7.
When the bar is fully filled, the device will analysis your data, and then show the
measurement result.
3.4 Oximeter
The Checkme Health Monitor measures the amount of oxygen in your blood (SpO2),
your pulse rate (PR) and pulse index (PI). The oxygen saturation (SpO2) is measured and
displayed as a percentage of full capacity.
Measuring without cable
To start a Oximeter measurement without cable,
1.
If the device is power off, press the home button.
2.
In the Main Screen, tap the “Pulse Oximeter” icon.
3.
Insert the forefinger into the built-in SpO2 sensor as shown below.
Relax your forefinger and do exertpressure.

9
4.
When the device detects stable waveform, it will automatically start the
measurement. The countdown bar moves from left to right.
5.
When the bar is fully filled, the device will analysis your data, and then show the
measurement result.
Measuring with Cable (Optional)
1.
Connect the external SpO2 sensor to the multi-functional connector.
2.
Put your index finger or middle finger into the external SpO2 sensor. Make sure
the cable is positioned along the top of the hand, and the finger nail is in the
position as shown below.
Finger nail position
3.
If the device is power off, press the Home button. Tap the <Pulse Oximeter> icon.
4.
The display will then show your PLETH waveform, SpO2 and pulse rate.
The device will monitor continuously, however no data will be saved until you
press the button.
5.
Press the button to start collecting your SpO2 data. The countdown bar moves
from left to right.
6.
When the bar is fully filled, the device will analysis your data, and then show the
measurement result.

10
4. Settings
4.1 Opening Settings Menu
To open the Settings menu, tap the <Settings> icon to open the menu as below.
4.2 Changing Sound Volume
In the Settings menu, tap the <Volume> area to change the volume directly. Or use the
quick setting by tapping the area on the left side of the screen.
4.3 Changing Brightness
In the Settings menu, tap the <Brightness> area to change the Brightness directly or use
the quick setting by tapping the area on the left side of the screen.
4.4 Setting Date &Time
1.
Choose <Date &Time>.
2.
Tap “+” or “-” button to change the date and time.
4.5 Turning on/off Voice Guide
In the Settings menu, tap the <Voice Guide> area to turn on/off voice guide directly. Or
use the quick setting by tapping the area on the left side of thescreen.
4.6 Choosing Language
1.
In the Settings menu, choose <Language>.
2.
Choose the language from the list.
3.
Press the Home Button to return to the Settingsmenu.
4.7 Erasing Data
In the Setting menu, tap <Erase All Data>, and then <Yes>. Please be noted that all
measurements saved in the device will be deleted.
4.8 Factory Reset
In the Setting menu, choose <Factory Reset>, then tap<Yes>.
All measurements, user information and other settings saved in the device will be
deleted, and the device will be restored to the factory default settings.

11
4.9 Bluetooth connection
Install the latest APP on your smartphone (support BLE Bluetooth) from App Store (iOS)
or Google Play (Android).
Switch on the device bluetooth in Setting-Bluetooth and run the APP, then the data will
be downloaded automatically.
5. Review
To open the <Data Review> menu, tap the <Data
Review> icon in Main screen.
5.1 Reviewing Daily Check
To review Daily Check records,
1.
In the <Data Review> menu, select <DailyCheck>.
2.
Select one record to review more information as
below.
In this menu, you can:
Select to delete this measurement
Select to replay the ECG waveform as
shown below.
Select to return to the Daily Check list.
5.2 Reviewing ECG Recorder
To review ECG Recorder records, in the <Data Review> menu, select <ECG Recorder>.
The operations you can perform is almost the same with Daily Check.
5.3 Reviewing Oximeter
To review Oximeter records, in the <Data Review> menu, select <Oximeter>. The
operations you can perform is almost the same with Daily Check.
6. Maintenance
6.1 Battery
This monitor is designed to operate on rechargeable Lithium-ion battery. The battery is
charged automatically when the monitor is connected to a powered USB port.
On-screen battery symbols indicate the battery status as follow:
The battery is fully charged.
The solid portion represents the remained battery energy. If the solid portion
moves from left to right, then it means that the battery is being charged.
Indicates that the battery is almost depleted and need to be charged
immediately. Otherwise the device will shut down automatically.

12
Tocharge the battery, connect the USB charging
cable as shown.
The device cannot be used for any measuremen
during charging.
Use USB charging devices comply with electrica
safety standard, for example IEC 60950.
6.2 Care and Cleaning
Clean the device by carefully swabbing the device surface with a soft cloth swab with
water or alcohol.
6.3 Trouble Shooting
Problem
Possible Cause
Solution
The device does
not turn on.
1. The battery may below.
2. The device might be
damaged
1. Charge the battery
and try again.
2. Please contact with
your local distributor.
The ECG waveform
amplitude is small
The lead you choose is not
suitable for you.
Change another lead
and try again.
ECG waveform drifts
1. The pressure exerted on the
electrode is not stable or too
much.
2. Hand or body may be moving.
1. Hold the device stably
and gently.
2. Try to keep perfectly
still and test again.
SpO2or pulse rate
shows no value, or
the number
fluctuates
1. Finger may not be inserted
correctly.
2. Finger or hand may be moving
1. Remove finger and
reinsert, as directed.
2. Try to keep perfectly
still and test again
“Error XX”
occurred.
Software or hardware failure.
Restart the device. If the
error persists, contact
with authorized service
center.
SpO2value is too low
when measured
using integrated
sensor.
1. Finger pressed too hard.
2. Finger may not be inserted
correctly.
1. Reinsert your finger
gently and stably.
2. Make sure your finger
is in right position.
Have the device repaired by authorized service centers only, otherwise its warranty is
invalid.
7. Accessories
Warnings and Cautionary Advices
Use accessories specified in this chapter. Using other accessories may cause
damage to the device or not meet the claimed specifications.
Part Number
Description
540-00192-00
ECG cable with 2 leadwires, snap
540-00194-00
USB charging cable, micro D

13
560-00198-00
ECG electrode, 10 pcs
8. Specifications
Environmental
Item
Operating
Storage
Temperature
5 to 45°C
-25 to 70°C
Relative humidity (noncondensing)
10% to 95%
10% to 95%
Barometric
700 to 1060 hPa
700 to 1060 hPa
Degree of dust & water resistance
IP22
Physical
Size
88×56×13 mm
Weight
64 g (main unit)
Display
2.4” touch screen, color, backlit
Connector
Micro-USB connector
Power Supply
Battery type
Rechargeable lithium-polymer battery
Battery run time
Daily check: > 200 times
Charge time
Less than 2 hours to 90%
ECG
Lead type
Integrated ECG electrodes
Lead set
Lead I, lead II
Record length
30s
Sampling
500 Hz / 16 bit
Display Gain
1.25 mm/mV, 2.5 mm/mV, 5 mm/mV
10 mm/mV, 20 mm/mV
Sweep speed
25 mm/s
Bandwidth
0.67 to 40Hz
Electrode offset potential
tolerance
±300 mV
HR measurement range
30 to 250 bpm
Accuracy
±2 bpm or ±2%, whichever is greater
Heart rate is calculated based on average of every 5
to 30 QRS complex.
Measurement summary
Heart rate, QRS duration, Rhythm analysis (Regular
ECG Rhythm, High Heart Rate, Low Heart Rate, High
QRS Value,. Irregular ECG Rhythm, Unable to analyze)
Standards
Meet standards of ISO 80601-2-61

14
Measurement accuracy verification: The SpO2 accuracy has been verified in human
experiments by comparing with arterial blood sample reference measured with a
CO-oximeter. Pulse oximeter measurement are statistically distributed and about
two-thirds of the measurements are expected to come within the specified
accuracy range compared to CO-oximeter measurements.
SpO2 range
70% to 100%
SpO2 Accuracy (Arms)
80-100%:±2%, 70-79%:±3%
PR range
30 to 250 bpm
PR accuracy
±2 bpm or ±2%，whichever is greater
PI range
0.5-15
Measurement summary
SpO2, PR, PI, Summary (Normal Blood Oxygen, Low
Blood Oxygen, Unable to analyze)
Blood Pressure Variation
Measurement method
Cuff-free non-invasive technology
Measurement summary
systolic pressure
Review
Waveform review
Full disclosure waveform
Storage
100 pcs of records

15
9. Electromagnetic Compatibility
The device meets the requirements of EN 60601-1-2. All the accessories also meet the requirements
of EN 60601-1-2 when in use with this device.
Warnings and Cautionary Advices
Using accessories other than those specified in this manual may result in increased
electromagnetic emission or decreased electromagnetic immunity of the equipment.
The device or its components should not be used adjacent to or stacked with other equipment.
The device needs special precautions regarding EMC and needs to be installed and put into
service according to the EMC information provided below.
Other devices may interfere with this device even though they meet the requirements of
CISPR.
When the inputted signal is below the minimum amplitude provided in technical
specifications, erroneous measurements could result.
Portable and mobile communication equipment may affect the performance of this device.
Other devices that have RF transmitter or source may affect this device (e.g. cell phones, PDAs,
and PCs with wireless function).
Guidance and Declaration - Electromagnetic Emissions
The Health Monitor is intended for use in the electromagnetic environment specified below. The
customer or the user of the device should assure that it is used in such an environment.
Emission tests
Compliance
Electromagnetic environment - guidance
RF emissions CISPR 11
Group 1
The device uses RF energy only for its internal
function. Therefore, its RF emissions are very low
and are not likely to cause any interference in
nearby electronic equipment.
RF emissions CISPR 11
Class B
The device is suitable for use in all establishments,
including domestic establishments and those
directly connected to the public low-voltage power
supply network that supplies buildings used for
domestic purposes.
Harmonic emissions
IEC61000-3-2
Class A
Voltage Fluctuations /
Flicker Emissions IEC
61000-3-3
Complies
Guidance and Declaration - Electromagnetic Immunity
The Health Monitor is intended for use in the electromagnetic environment specified below. The
customer or the user of the Health Monitor should assure that it is used in such an environment.
Immunity test
IEC60601 test level
Compliance level
Electromagnetic
environment - guidance

16
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are
covered with synthetic
material,
the relative humidity
should be at
least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for
input/output lines
± 2 kV for power
supply lines
± 1 kV for
input/output
lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
Voltage dips, short
Interruptions and
Voltage variations
on power supply
input lines IEC
61000-4-11
<5 % UT (>95 % dip
in UT) for 0.5 cycle
40 % UT (60 % dip in
UT) for 5 cycles 70
% UT (30 % dip in
UT) for 25 cycles <5
% UT (>95 % dip in
UT) for 5 s
<5 % UT (>95 % dip
in UT) for 0.5 cycle
40 % UT (60 % dip
in UT) for 5 cycles
70 % UT (30 % dip
in UT) for 25 cycles
<5 % UT (>95 % dip
in UT) for 5 s
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
our product requires
continued operation during
power mains interruptions, it
is recommended that our
product be powered from an
uninterruptible power supply
or a battery.
Power frequency
(50/60 HZ)
magnetic field IEC
61000-4-8
3 A/m
3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note: UTis the AC mains voltage prior to application of the test level.
Guidance and Declaration - Electromagnetic Immunity
The Health Monitor is intended for use in the specified electromagnetic environment. The
customer or the user of the Health Monitor should assure that it is used in such an environment
as described below.
Immu
nity
test
IEC60601
test level
Compliance
level
Electromagnetic environment -guidance

17
Conduced
RF
IEC61000-
4-6
3 Vrms 150
kHz to
80 MHz
outside ISM
bands
3 Vrms 150 kHz
to
80 MHz
Outside ISM
bands
Portable and mobile RF communications
equipment should be used no closer to any
part of the system, including cables, than
the recommended separation distance
calculated from the equation appropriate
for the frequency of the
transmitter. Recommended separation
distances:
Radiated
RF
IEC61000-
4-3
3 V/m 80
MHz to
2.5 GHz
3 V/m 80 MHz
to
2.5 GHz
Recommended separation distances: 80
Where, P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter
manufacturer and d is the recommended
separation distance in meters (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the
compliance level in each frequency range
b.
Interference may occur in the vicinity of
equipment marked with the following
symbol:
Note 1: At 80 MHz to 800 MHz, the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered.
If the measured field strength in the location in which the device is used exceeds the applicable
RF compliance level above, the device should be observed to verify normal operation. If
abnormal performance is observed, additional measures may be necessary, such as re-orienting
or relocating the device.
b Over frequency range 150kHz to 80MHz. For Resp field strength should be less than 1V/m.

18
Recommended separation distances between portable and mobile RF communications
equipment and the device
The Health Monitor is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the Health Monitor can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile
RF communications equipment (transmitters) and the monitor as recommended below,
according to the maximum output power of the communications equipment.
Rated max.
output power of
transmitter (W)
Separation distance according to frequency of the transmitter (m)
150 kHz - 80 MHz
80 MHz - 800
800 MHz - 2.5
GHz
0.01
0.12
0.12
0.23
0.1
0.38
0.38
0.73
1
1.20
1.20
2.30
10
3.80
3.80
7.30
100
12.00
12.00
23.00
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in metres (m) can be estimated using the equation applicable to the
frequency of the transmitter, where P is the maximum output power rating of the transmitter in
watts (W) according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.

19
Mode d'emploi du moniteur de santé Checkme Lite
Avertissements et mises en garde
Nous vous recommandons de ne pas utiliser cet appareil si vous avez un
stimulateur cardiaque ou un autre dispositif implanté. Demandez alors conseil
à votre médecin.
N'utilisez pas cet appareil en complément d'un défibrillateur.
N'utilisez pas cet appareil si vous passez une IRM.
Ne plongez jamais l'appareil dans l'eau ou tout autre liquide. Ne nettoyez pas
l'appareil avec de l'acétone, ni toute autre solution volatile.
Ne faites pas tomber cet appareil et ne lui faites pas subir de choc important.
Ne placez pas cet appareil dans un récipient sous tension, ni dans un appareil
de stérilisation par gaz.
Ne démontez pas l'appareil : cela pourrait causer des dommages ou des
défaillances, ou encore empêcher son fonctionnement.
Cet appareil ne convient pas à une utilisation par des personnes (y compris des
enfants) aux capacités physiques, sensorielles ou mentales réduites, ou
manquant d’expérience ou de connaissances, à moins qu'elles ne soient
surveillées par une personne responsable de leur sécurité, ou que cette
dernière leur donne des instructions sur l'utilisation de l'appareil.
Cet appareil affiche notamment les variations du rythme cardiaque et de
l'oxygénation du sang, dont les causes sont très variables. Ces variations
peuvent être inoffensives, mais elles peuvent également être symptomatiques
de pathologies ou de troubles plus ou moins graves. Si vous pensez être atteint
d'une quelconque pathologie, veuillez consulter un médecin.
N'établissez pas vous-même de diagnostic et n'ayez pas recours à l'auto-
médication à partir des résultats fournis par cet appareil sans consulter un
médecin. En particulier, ne prenez pas de nouveaux médicaments et ne
remplacez pas ceux que vous prenez actuellement, ni leur dosage, sans
autorisation préalable.
Cet appareil ne comporte pas d'alarme ; il ne sonnera pas si les valeurs relevées
sont trop faibles ou trop élevées.
1. À propos de Checkme
1.1 Usage prévu
Le moniteur de santé Checkme Lite est conçu pour mesurer, afficher, stocker et
consulter plusieurs paramètres physiologiques - ECG, saturation pulsée en oxygène
(SpO2) et pression artérielle systolique (PAS) - à domicile ou dans un environnement
médical.
L'ECG et la mesure de la PAS sont réservés aux adultes.
Les données et les résultats fournis par cet appareil servent à des fins de dépistage
avant bilan médical et ne peuvent être utilisés directement pour établir un diagnostic
ou un traitement.

20
1.2 Schéma
1 2
3
4
5
1.
Écran tactile
2.
Capteur interne SpO2
3.
Connexion micro-D: Rechargeable à l'aide d'un câble D.
4.
Bouton Accueil
Quand l'écran est éteint, appuyez sur ce bouton pour l'allumer.
Quand l'écran est allumé, appuyez sur ce bouton pendant deux secondes pour
l'éteindre.
Lorsque l'appareil est en marche, appuyez sur ce bouton pour passer sur l'écran
principal ou revenir au menu supérieur.
5.
Électrode droite de l'ECG (Placez le pouce droitdessus.)
6
9 7
8
6.
Haut-parleur
7.
Électrode gauche de l'ECG (placez-la dans la paume de votre main gauche, sur
la partie gauche de votre abdomen ou sur votre genou gauche.)
8.
Point d'attache pour le cordon de cou
9.
Électrode arrière de l'ECG (Placez l’index ou le majeur de la main droite dessus.)
1.3 Écran principal
Voici à quoi ressemble l'écran principal.
