Vibration Therapeutic VT007 User manual

Dear Customer,
Thank you for choosing our model VT007 vibration plate.
We sincerely wish this high frequency vibration machine
to bring you great health and fitness benefits.
At Vibration Therapeutic®, we are dedicated to the
design and manufacture of high-quality home use
vibration machines that come with exceptional customer
services.
Thousands of users have enjoyed using our popular
linear vibration model VT003F, many life changing
stories. This newly designed VT007 adopts the same
movement pattern and parameters as VT003F. Great
efforts are made to optimize the structure and refine the
material and components, in order to achieve high
durability, reliability and performance. VT007 is made to
deliver perfect vibration.
Please note that just like it can produce positive
stimulation for better health, vibration can also adversely
impact you. Vibration therapy has not been well studied
for its applications and efficacy. Each person responds
differently to the frequency, amplitude, and movement
pattern. Please discuss with your doctor about using this
high frequency linear vibration machine.
For new users, please begin with a low frequency and
low amplitude setting. You can gradually increase the
intensity as you feel comfortable and begin to enjoy the
benefits.
In order to take the full advantage of this VT007 machine,
and to have many years of pleasure enjoying it, please
read this user manual carefully.
We are passionate about vibration therapy. We love to
share our learning and understanding with you, and hope
to learn from your experience.
For more information about our products and the
applications, please visit our website.
Thank you!!!
User Manual & Tech Specs
High Frequency Linear Vibration Plate
Model VT007
Solid ♦ Reliable ♦ Reasonably Simple
www.VibrationTherapeutic.com
©SpecsPro LLC, All Rights Reserved.

Disclaimer
The health benefits and efficacy suggested or implied in
this user manual and our other product literatures
including our websites are not certified or endorsed by
any regulatory authority or medical institute.
We are not medical professionals. We never intend to
provide medical advice to any specific person for any
specific use. We do share our understanding and
learnings about vibration therapy, its applications,
benefits, limitation and risks, Please do your own
research and consult a medical expert about the use of
a high frequency linear vibration machine like the VT007.
The use of this vibration machine is entirely on the user’s
discretion.
Please read all instructions carefully before using this
machine. We assume no responsibility for personal
injury or property damage sustained by or through using
this machine.
Hazard & Warnings
Excessive exposure to intensive vibration can pose a
health hazard.
In the US, there is not a set of regulated safety standard
for vibration exposure. US Labor Department and
National Institute for Occupational Safety and Health
published advisory information on profession related
vibration exposure, which is for prolonged continuous
use of vibrational equipment and machineries.
Regular use of vibration plated, for example, 10 minutes
a session, a few sessions a day would not be considered
to be hazardous.
If you have implant, serious motion sickness, or certain
medical conditions, vibration therapy may not be for you.
Do not use vibration immediately after physical injury or
surgery.
Do not use vibration immediately after eating.
Keeping your knees bent to avoid impact on joint
cartilage, and to control the amount of vibration
transmitted to the upper body and head.
High frequency vibration transmitted to the upper body
and head can cause nausea and dizziness.
For new users, please start with a low frequency and low
amplitude setting. You can gradually increase the
frequency and switch to the high amplitude setting after
you get used to the vibration and start to enjoy the
benefits. Please be patient and persistent to achieve
your goal.
Please discuss with your doctor to decide if using high
frequency linear vibration is suitable for your situation.
Safety Instructions
The machine is designed to be used indoor in a dry
environment without flammable gas or dust. Vibration
can produce statics
The machine must be connected to a properly grounded
electricity outlet.
The machine is designed to use on a solid floor.
The suction feet of VT003 can effectively attach on to a
smooth cement floor. If the floor surface is not smooth
and the suction feet could not securely attach to the floor,
and there is no body weight on the machine, it may drift
with vibration. Placing the machine on a carpeted floor
can create a friction that deters the drifting.
The machine will not drift with vibration if there is body
weight on it. So please always keep your body weight on
the machine when it is vibrating. Do not let the machine
running unattended.
Do not put any object or reach into the area between the
upper plate and the lower plate, even though the motor
and eccentric wheel assembly is securely enclosed and
insulated.
For users that lack physical strength, please hold on to a
stable chair for better balance.

Vibration Noises
Vibration plate generates mechanical and soundwave
noises. When the frequency is above 20Hz, the
soundwave becomes audible. The higher the vibration
frequency, the higher the noise level.
Visit our website for detail noise level measurement
results and comparisons with other regular household
electric appliances.
EMF Exposure
Like all other household electric appliances, VT007
produces electric and magnetic fields (EMF). The
maximum magnetic field strength measured at one foot
above the footplate is 1.3 milligauss at the highest
intensity setting. Visit our website for detailed EMF
measurement results and comparisons with other
regular household electric appliances.
According to EPA, there is no clear scientific evidence
that EMF affects health. EPA does not define a safe or
hazardous level of EMF exposure.
VT007 Open Box
Inside the box of VT007 are the following components:
1) VT007 Vibrating Unit (the main machine)
2) VT007 Control Box
3) Power cord
4) Remote Control
5) Inelastic Balance Straps (a pair)
6) This User Manual
7) Warranty Certificate
Set up VT007
Place the machine (the vibrating unit) on a flat solid floor.
If using the machine on a wood frame structure floor, the
machine may vibrate the floor. Placing a 1” thick EVA
material exercise mat beneath the machine can
effectively reduce the vibration transmitted to the floor.
Your electricity outlet must be properly grounded.
Connecting the Control Box
VT007 comes with a separated vibrating unit and a
control box. They need to be connected so the power
and control signals can be sent to the vibrating unit.
The connector is a couple of 3-pin plug and socket.
Below are the steps to make the connection:
1) Observe the 3-pin plug on the cable from the control
box, and the 3-pin socket mounted at the back of
the vibrating unit. Locate the position guiding slot
blow the metal pins.
2) Align the slot on the plug and the slot on the socket,
and then push the plug into the socket.
3) Once the plug is pushed all into the socket, turn up
the plug cap onto the socket. Then the connection is
done.
Once the control box is connected to the vibrating unit,
you can now plug in the power cord to your home A/C
supply. Your VT007 is ready to use.

You may want to attach the pair of balance straps to the
vibrating unit for balance and arm vibration.
For physically weak people, it is suggested to hold onto
a heavy chair for better balance.
The machine can be controlled from either control panel
or remote control.
Always keep your body weight on the machine when it is
vibrating.
Potential Negative Impact
Some users experience dizziness or nausea using
HIGH frequency vibration. That is because the
vibration is transmitted to the head and stomach. Keep
your knees bent to reduce the vibration transmitted to
the upper body and head.
We suggest new users to start with low frequency and
low amplitude settings. You can gradually increase the
frequency and switch to high amplitude after you get
used to the vibration and start to enjoy the benefits.
Keep Your Knees Bent
The knee-bent posture helps achieve better balance
and allows you to adjust the intensity of vibration to be
transmitted to your upper body. This posture helps
enhance muscles, tendons, ligaments, bones and
nerves without big stress on your knee joints.
Start with the Lowest Intensity
If you are a new user for high frequency linear
vibration, you should start with short session time and
the lowest intensity setting, which is 15Hz and low
amplitude.
When you feel comfortable with the intensity, you can
gradually increase the frequency, switch to high
amplitude and/or increase the session time. Please be
patient and persistent.
Control Panel
Control Panel Digit Displays and Indicators
Hz / Program
Window
When the machine is idle, this window
displays operation mode, either
manual (P0) or a programmed play
mood (P1, P2 or P3).
When the machine is running, this
window displays the vibration
frequency in Hz.
Session
Time
Window
When the machine is powered on but
in the idle mode, this window displays
the session time in minutes.
When the machine is running, this
window displays the remaining
minutes of the running session.
Lo Amplitude
Green light indicates the machine is on
low amplitude setting.
Hi Amplitude
Red light indicates the machine is on
high amplitude setting.
Remote
Receiver
IR signal receiving window for the
remote control.

Control Panel Buttons
Button
Function
Time/Hz
When the machine is idle, press this
button to increase vibration session time,
maxium 20 minutes.
When the machine is vibrating on
manual mode, press this button to
increase vibration frequency, 15 – 40Hz.
This button is disabled when the
machine is vibrating on a program mode.
Time/Hz
When the machine is idle, press this
button to decrease vibration sesssion
time, minumum 1 miunute.
When the machine is vibrating on
manual mode, press this button to
decrease vibration frequency.
This button is disabled when the
machine is vibrating on any program
mode.
Start / Stop vibration, after the power
switch is turned on (powered on)
Select manual mode P0, or a program
mode, P1, P2 or P3.
Toggle vibration amplitide between Hi
and Lo. The button is disabled when the
machine is vibrating on any program
mode.
Low Amplitude vs Hi Amplitude
VT007 is low amplitude linear vibration machine.
Without load, at Lo setting, the amplitude is 1.5mm,
and Hi setting 3mm. Your body weight will reduce the
amplitude. Some users do not feel much difference
between Hi and Lo, but if you tiptoe on the vibration
plate, you will feel the intensity difference between Hi
and Lo amplitude settings.
Please note that the remote control is an
infra-red type. It needs to point to the
remote receiver window on the control
box to work.
Battery size: CR2025 or CR2032.
Battery included in a new machine
.
Remote Control Buttons
Button
Function
Set desired session time when the machine
is idle. Defualt session time is 10 minutes,
maximum 20 minutes, mininum 1 minute.
These buttons are disabled when the
machine is vibrating.
Increase and decrease frequency when the
machine is running on manual mode.
These buttons are disabled when the
machine is vibrating on any program mode.
Start / Stop vibration, after the power switch
is turned on.
Select manual mode P0 or preset program
play modes P1, P2 and P3.
Toggle vibration amplitide between Hi and
Lo. This button is disable when the machine
is vibrating on any program play mode.
In the following situations, certain control buttons are
DISABLED for logical reasons:
1. Session time buttons and program buttons are
disabled when the vibration is on.
2. All buttons except for the Stop button are disabled
when the vibration is on and is in a program mode.
3. Frequency buttons are disable unless the vibration is
on and on manual control mode.

Setting the Parameters
1. The power switch is located at the backside of the
control box. When the machine is powered on, the
default parameters are as below:
- Program Mode: P0 – manual control
- Vibration Frequency: 15Hz
- Amplitude: Lo (Low)
- Session Time: 10 minutes
2. When the machine is powered on and idle, you can
use P button on the control panel or the remote
control to select manual mode P0 (default) or
program mode P1, P2 or P3.
3. In manual control mode – P0
- While the machine is vibrating, you can change
vibration frequecny from 15 Hz to 40 Hz, and
amplitude 1.5mm or 3mm.
- While he machine is NOT vibratiing, you can set
session timer from 1 to 20 minutes.
4. In program mode, P1, P2 or P3, the frequency and
amplitude are programmed to run with a certain
pattern in a 10 minutes session. All buttoms, except
for the Play/Stop button are disabled.
5. Press Play / Stop button on either control panel or
remote control to start the vibration session.
If you are a new user of vibration exercise, we highly
recommended you to begin with low intensity settings,
which is low frequency and low amplititue. After a few
days’s of use, if you don’t have any negative impact,
you can gradually increase the intensity.
Upper Body Vibration
To achieve effective vibration on your upper body and
head, you can sit on the vibration plate with the spinal
column straightened.
Please be aware that sitting posture more likely
causes dizziness and nausea.
Program Modes
In program modes (P1, P2 and P3), the vibration runs
a series of spectrums of frequencies, changing every 5
seconds. Each program runs a 10-minute session time.
In P3 mode, amplitude switching is added to frequency
change.
The charts below exhibit the frequency change and
amplitude switch of each program.
Each dot represents a 5 second period vibration at a
certain frequency. Green dots mean low amplitude
setting. Red dots mean high amplitude setting.
10
15
20
25
30
35
40
0
100
200
300
400
500
600
F
re
qu
e
n
c
y (Hz)
T
i
m
e (second)
Program 1 Frequency Pattern
Low Amplitude
Program 2 Frequency Pattern
10
15
20
25
30
35
40
0
100
200
300
400
500
600
F
re
qu
e
n
c
y (Hz)
T
i
m
e (second)
High Amplitude
Program 3 Frequency Pattern
10
15
20
25
30
35
40
0
100
200
300
400
500
600
T
i
m
e (second)
Mixed Amplitude

The purpose of program modes is to create a spectrum
of patterns and magnitudes of stimulation to human body,
through the change of frequency combined with
amplitude switch.
If you have not adapted to a full session high intensity
vibration, you can use a program mode to ease in. It can
help you gradually progress to high intensity vibration.
No Solid Scientific Conclusion
There is no solid scientific conclusion on medical
treatment efficacy in terms of different frequencies and
amplitudes.
Presumably, VT007 is designed to offer these program
modes for the following purpose.
Mode
Amplitude
Suggested Applications
P0
Manual
Custom
P1
Lo
Relax exercise
P2
Hi
Cardio exercise
P3
Lo / Hi
Mixed exercise
Tissue Resonance Frequency
Human skeletal muscles have natural
frequency ranging from 10Hz to 50Hz.
When the vibration frequency is at the
same level of skeletal muscle’s natural
frequency, resonance occurs. The
skeletal muscle vibration amplitude tends to
maximize at resonance but the skeletal
muscles contract forcefully to damp the vibration
amplitude. Such active and counteractive reaction
intensifies the stimulation on the muscles, tendons,
ligaments, nerves and bones.
VT003F provides a wide range of vibration frequency
(15-40Hz), and two amplitude setting to accommodate
different fitness and therapeutic applications.
G-force of VT003F
G-force is an acceleration rate expressed in the unit of
G (the acceleration of gravity). G-force is determined by
the vibration frequency and amplitude. It is an important
vibration intensity indicator. The maximum empty load G-
force calculated for VT003F is 3.86.
Visit www.vibrationtherapeutic.com for vibration G-force
explanation and calculation.
Tech Specifications
Vibration Pattern
Linear Vibration
Vibration Frequency
Range
15Hz –40Hz
1 Hz Incremental
Max Vibration
Amplitude on Hi
3 mm without load
Max Vibration
Amplitude on Lo
1.5 mm without load
Power Supply
AC 120V 60Hz for US
AC 220V 50Hz for Europe
Electric Motor
120V 80W PMDC motor
Machine Net
Dimension
560 x 420 x 14.5 mm
22 x 16.5 x 5.7 Inches
Machine Net Weight
10.4 KG / 23 LB
User’s Max Body
Weight
140 KG / 308 LB
Product Registration & Support
Product registration is optional but recommended.
Registration will make warranty process easy in case
you lose your order information. Registration will also
allow us to reach you for potential product recall, safety
warning and upgrade.
Register your machine online at
www.VibrationTherapeutic.com/support/

Troubleshooting
Issue
Possible Causes
Solution / Action
After powered on, the control
panel lights are not on.
Electricity supply NOT available.
Check the circuit break at your
house.
Power cord NOT properly plugged in the
control box or the electricity supply socket.
Properly plug in the power
cord.
Machine fuse burned (5 Amp fuse tube,
Diameter 2mm / Length 20mm)
Replace the fuse. For new
machine, contact the seller
After powered on, the machine
does not vibrate when the Play
button is pressed. Control
panel lights are on.
Control box not properly connected with the
vibrating unit.
Properly connect the control
box with the vibrating unit.
Remote control does not work.
Remote control not pointed to the remote signal
receiving window on the control box.
Point the remote control to the
Remote Receiving window.
Remote control runs out of battery.
Replace the battery (CR2025)
Defective remote control.
Contact the seller for a
replacement
After power-off, the control
panel lights stay on for a few
seconds.
The remaining electricity stored in the control
circuit needs a few seconds to be completely
discharged, after powered off.
No action needed. It is not an
issue.
Before power-on, the control
panel lights blink once when
stepping on to the machine.
Your movement causes the eccentric wheel to
turn the motor slightly. Electricity thus
generated and makes the lights blink.
No action needed. It is not an
issue.
Excessive noise.
The power cord touches the vibrating unit.
Re-arranged the power cord
Accessories or other stuff left between the
upper board and the lower board
Remove the accessary or
other stuff.
Your body weight is not balanced on the
vibrating plate*.
Find the right standing spot
that cause the least noise.
Assembly quality issue cause high pitch
excessive noise.
Contact the seller.
Clunk sound heard when
switching amplitude and in P3
mode
When the motor reverses the direction to
change amplitude, the eccentric wheels strike
the stop block and produce this sound. It is not
a defect. It does not hurt the machine.
This is not a defect. No worry!
* Due to the two amplitude design, the vibration intensity is not evenly distributed on the platform. If you stand facing
the control box, at high amplitude setting, the intensity center is towards your toes; at low amplitude setting, the
intensity center is towards your heels.
