Vibration Therapeutic VT027 System manual
Dear Customer,
Thank you for choosing our vibration plate model VT027.
We sincerely wish this vibration machine to bring you
with great health and fitness benefits.
If there is any negative experience using the machine or
any product quality issue, please don’t hesitate to
contact us. We will do our best to make it right for you.
At Vibration Therapeutic®, we are dedicated in designing
and manufacturing high quality home-use vibration
machines, delivered with exceptional customer services.
Thousands of people have enjoyed and benefited from
using our vibration machines, many life changing stories.
However, just like it can produce positive health results,
vibration can adversely impact you if not used properly.
Vibration therapy has not been well studied for its
applications and efficacy. Each person responds
differently to vibration frequency, amplitude, and
movement pattern. Vibration therapy may not work for
everyone.
We are passionate about promoting vibration therapy,
however any health benefit that we suggest or imply has
not been evaluated by any government authority or
medical institute.
For new users, please start with low frequency and low
amplitude. You can gradually increase the intensity as
you feel comfortable and begin to enjoy the benefits.
In order to take the full advantage of this VT027 machine,
and to have many years of pleasure enjoying it, please
read this user manual carefully.
For more information about our products, applications
and conditions, and to download the latest user manual,
please visit our website www.VibrationTherapeutic.com.
We also encourage you to join our vibration therapy
forum at www.vibration.health.
Thank you!!!
User Manual & Tech Specs
Model VT027
Pivotal Oscillation Vibration Plate
www.VibrationTherapeutic.com
©SpecsPro LLC, All Right Reserved.
Disclaimer
The health benefits and efficacy suggested or implied in
this user manual and our other product literatures
including our websites are not certified or endorsed by
any regulatory authority or medical institute. The use of
this vibration machine is entirely on user’s discretion.
We are not medical professionals. Although we share our
understanding and learnings about vibration therapy, its
applications, benefits, limitation and risks, we never
intend to provide health and therapeutic advice to any
specific person for any specific use. Please do your
research and consult medical experts about the use of
vibration machine, before you actually use this machine.
Please read all instructions carefully before using this
machine. We assume no responsibility for personal
injury or property damage sustained by or through using
this machine.
Health Hazard Warning
Just like it can positively affect the user, vibration
machine can adversely impact the user if not used
properly or used under a wrong condition.
This machine is not for children or pregnant women to
use.
If you have medical conditions, please discuss with your
doctor to decide if vibration therapy is a good fit for you.
If you have implant, joint bone or cartilage damage, or
serious motion sickness, vibration therapy may not be for
you.
Do not use vibration immediately after physical injury and
surgery.
For users that lack of physical strength, please hold on
to a stable chair for better balance while using this
machine.
Always keep your knees bent to avoid impact on joint
bone and cartilage, and to control the amount of vibration
transmitted to the upper body.
If you are new to vibration machine, please start with low
frequency and low amplitude. You can gradually increase
the frequency after you get used to the vibration and start
to enjoy the benefits. Be patient and persistent to achieve
your goal.
Excessive exposure to intensive vibration can pose a
health hazard.
Please contact your physician if you experience
sustained discomfort after using this machine.
Safety Instructions
The machine is designed to use indoor in dry
environment without flammable gas or dust. It must be
connected to a properly grounded electricity outlet.
Always use VT027 on a carpeted floor. Carpet effectively
prevents the machine from drifting with the vibration.
On a carpeted wood frame floor, if needed, put extra
cushion pads beneath the machine to absorb the
residual downward vibration transmitted to the floor.
Do not put any object or reach into between the upper
plate and the lower plate. That can hinder the machine
movement and cause injury.
Do not let the machine running unattended.
Product Warranty & Return Policy
Product warranty, return and replacement policy and all
other sales conditions and policies are issued and
implemented by the actual seller of this product.
If you purchased the product from our company through
our own retail channels including our retail stores, our
ecommerce websites and other ecommerce platform,
the general sales terms and conditions are stipulated in
our website or other ecommerce platform. For return,
replacement and warranty services, Please contact us
sales conditions and terms override our general sales
condition and terms.
If you purchased the product through a third party retailer
or distributor, please contact the actual seller for return,
replacement and warranty services.
Packing List
The following items are included in the box of VT027.
Item name Quantity
VT027 machine 1
This user manual 1
Handles 2
Resistance bands 2
Remote control 1
Power cord 1
Tech Specifications
Manufacturer’s Model# VT027
Vibration Pattern Pivotal oscillation
Vibration Frequency
Range
5Hz – 14Hz
In 20 speed level
Max Vibration Amplitude 10 mm
Max G-force 2.97
Power Supply* AC 110V 60Hz for US
AC 220V 50Hz for Europe
Electric Motor 200 W PMDC motor
Product Dimension 630 x 400 x 115 mm
24.8 x 15.7 x 4.5. Inches
Product Weight 12.5 KG / 27.5 LB
Packaging Dimension 720 x 460 x 155 mm
28.3 x 18.1 x 6.1 inches
Package Weight 14.5 KG / 31.9 LB
User’s Max Body
Weight 120 / 264 LB
*The 110V version machine cannot be used with 220V
electricity supply, and vice versa.
Machine Setup
VT027 machine comes as plug-and-play right out of the
box. No assembly needed, except for attaching a pair of
handles or a pair of resistance bands that are designed
for arm and upper body exercises. There is no
maintenance needed over the lifetime of the machine.
Place the machine on a flat carpeted floor. Using the
power cord to securely connect the machine to your
household electricity supply, which must be properly
grounded. Switch on the main power switch at the
backside of the machine. You are ready to take the ride.
VT027 has a default running session time of 10 minutes.
Running session time can be set between 1 and 20
minutes. Motion speed can be adjusted in 20 levels,
covering a vibration frequency range from 5 Hz to 14 Hz.
The machine can be controlled from either control panel
or remote control. Using remote control is recommended.
Remote control is IR (infrared) type. It needs to point to
the remote control signal receiving window to work.
Session time, programs, and frequency can be
controlled using either control panel or remote control.
The parameters are displayed in two LED digit display
windows on the control panel.
Handles
If desired, you can attach to the machine the two handles
that are designed for upper body exercises. The two
handles are stored in two compartments at the back side
of the machine. See the picture below. They can be
easily installed and conveniently stored. Below are the
steps to install the handles.
Step 1: Slide out the two handles from each of their
compartments at the back side of the machine
Step 2: Insert the handles to the desired position. There
are 10 holes with pop-down caps to accommodate four
handle hpositions.
Four handle positions designed for different muscle
group workout.
Resistance Bands
If desired, you can attach the pair of resistance bands
designed for arm exercises.
Below illustration shows how to attach the resistance
bands to the machine.
1. Turn-slide out the metal latch at the bottom of the
machine.
2. Attach the spring hook of the resistance band onto
the latch.
3. Repeat to attach both resistance bands.
Battery
The remote control uses a lithium cell battery, CR2032
3V, which is included in a new machine. A battery can
last for a couple of years of regular use.
A new remote comes with a thin plastic sheet at the
right side of the remote to insulate the battery. Remove
the plastic sheet to use the remote control.
When the battery needs to be replaced, follow the
illustrations below to replace the battery. You can use a
coin to unscrew the battery compartment cover.
Control Panel Display Windows
TIME / PROGRAM Window
This window displays session time or play modes.
Play modes include manual control (P0) or
programmed control (P1, P2 or P3)
When the machine is powered on and idle, this
window displays a number 10, indicating the default
session time of 10 minutes. The following functions
can be performed:
Set up session time by pressing the TIME button,
to adjust the session time between 1 minute and
20 minutes.
Set up program by pressing the Program button
(P) to select either manual control P0, or,
programmed control P1, P2 or P3.
When the machine is running, this window displays
the remaining session time and the running program
(P0, P1, P2 or P3), in a 5-second alternating
sequence.
SPEED Window
This window displays the motion speed level.
The speed can be adjusted in 20 levels, cover a
vibration frequency from 5 Hz to 14 Hz.
The speed can only be adjusted when the machine
is running. The default speed level is 1 (5Hz).
In program modes, this window displays the
programmed speed level.
Middle Window – Remote Control Receiver
This window receives remote control signal.
The remote control uses infrared light signal to
transfer orders, therefore it needs to point to this
remote control receiver window to work.
Control Buttons
Buttons Functions
Button Function
Standby - put the machine to standby, or
wake up the machine from standby.
Functional when power is switched on.
The button is only on remote control.
START/STOP - start or stop the vibration,
PROGRAM - select manual mode P0, or
a program mode, P1, P2 or P3.
Time
TIME (remote control) - set up vibration
session time, from 1 to 20 minutes, when
the machine is powered on but in idle
status.
These two buttons are disabled when the
machine is running.
TIME (control panel) - set up vibration
session time, from 1 to 20 minutes, when
the machine is powered on but in idle
status.
This button is only on the control panel
Speed
SPEED - adjust vibration speed level
from 1 to 20 levels, when the machine is
running on manual control mode.
These buttons are disabled when the
machine is running on program mode.
The remote control
needs to point to the
remote receiver window
on the control panel to
work.
Operation Instruction
1. Power on the machine pressing the main power
switch at the backside. The control panel will light up.
Each time the machine is powered on, the default
mode is manual control Po, and the default session
time is 10 minutes.
2. Use P button on the control panel or the remote
control to select manual mode P0 or program mode
P1, P2 or P3.
3. Use Time button on the control panel or Time+ or
Time- buttons on the remote control to set up session
time. Session time can be set up between 1 minute
and 20 minutes, only in manual mode.
In program mode P1, P2 or P3, session time is preset
at 10 minutes, and cannot be changed. Session time
can only be change in manual control mode P0.
4. Once the program and time are set up, press Play /
Stop button on either control panel or remote control
to start the vibration session.
5. When the machine is running on manual mode (P0),
you can adjust the speed level from 1 to 20.
It is highly recommended for new users to start with low
speed level. You can gradually increase the speed as
you feel comfortable and enjoy the benefits.
After each use, user can press the Standby button on the
remote control to turn off the machine. No need to turn
off the power using the power switch on the back. If there
will be a long time not using the machine, turn off the
power switch.
Manual Control Mode
At manual control mode (displayed as P0), user can
manually set up session time and adjust speed. Each
time the machine is powered on, the default session time
is 10 minutes, and default speed level is 1.
Session time can be set up only when the machine is
idle. The session time can be set up between 1 minutes
and 20 minutes.
Speed level can only be adjusted when the machine is
running on manual mode. The speed level range is from
1 to 20. The table below shows the relationship between
speed level and vibration frequency (Hz).
Speed 1 2 3 4 5 6 7
Hz 5 5.5 5.9 6.4 6.9 7.4 7.8
Speed 8 9 10 11 12 13 14
Hz 8.3 8.8 9.3 9.7 10.2 10.7 11.2
Speed 15 16 17 18 19 20
Hz 11.6 12.1 12.6 13.1 13.5 14.0
Program Mode
Programs are designed to provide different movement
patterns of speed change, which create a spectrum of
stimulation to your muscles, bones, tendons, ligaments
and nerves.
Three programs are built in. Each program runs a set of
speed levels that change every minute, for a total 10
minutes session.
P1: Low intensity spectrum
P2: High intensity spectrum
P3: Mixed intensity specturm
Speed Level
P1 16 18 12 8 18 10 15 6 12 8
P2 20 20 15 18 20 16 20 10 20 15
P3 10 4 20 12 20 10 20 6 20 14
P0 Manual control speed level
Time buttons and Speed buttons are disable when the
machine is running on program mode.
Avoid One Sided Weight
VT027 is designed for user to evenly distribute the body
weight on both sides of the platform.
If user puts the entire body weight on a single side of the
platform, the load on the motor is doubled.
A protection program is built in to prevent motor from
overloading. If a user’s entire weight is on one side of
platform, the motor will run faster to generate more
power to adapt to the increased load. This is called
speed compensation, which protects the motor and
extents the life of the machine.
We don’t recommend user to constantly put the entire
body weight on only side of the machine.
The designed maximum load of VT027 is 120 KB / 264LB.
Overload can damage the machine.
G-force of VT027
G-force is an acceleration rate expressed in units of G
(the acceleration of gravity). G-force is determined by the
vibration frequency and amplitude, it is an important
vibration intensity indicator. The maximum empty load G-
force calculated for VT027 is 2.97.
For more information about our formula and conditions
about vibration G-force calculation, please visit our
website www.VibrationTherapeutic.com.
Troubleshooting
Remote control does not work
Remote control needs to point at the remote signal
receiving window on the control panel to work.
The distance from the remote control to the control
panel should not exceed 4 ft.
Remote control can run out of battery in a couple of
years.
The control panel display windows do not light up
Check if the power switch at the back of the machine
is turned on.
Or, check if the fuse is broken. Fuse box is located
between the power switch and the power cord socket.
Use a flat-headed screwdriver to remove the
fuse box cap and remove the fuse and check.
If fuse is broken, replace it with a 5A /125V
fuse.
If the replaced fuse breaks again, it is
possible the control box is defective. Please
contact the seller for warranty service.
The power is off, but the display LED light up when
step on the machine
This is normal. The motor rotation generates induction
electricity that light up the display LED light.
After power off, the display LED is still on for a while
This is normal. It is the discharge of electricity stored
in the circuit.
VIBRATION THERAPEUTIC® represents high
quality vibration plate machines that SpecsPro LLC
develops and delivers to the global market.
SpecsPro LLC
Minneapolis – Shanghai
www.VibrationTherapeutic.com
Table of contents
Other Vibration Therapeutic Power Tools manuals
