Vicon SURVEYOR 2000 S2000-CC22-EX User manual

XX031-01-00
Camera Dome
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not be
used for this purpose.
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com
Vicon part number 8009-8031-01-00 Section 1 Rev 803

Contents
Introduction .........................................................................................................................1
How to Use this Manual.................................................................................................................................3
For Experienced Installers: .......................................................................................................................3
For Novice Installers: ................................................................................................................................3
Accessory Kits................................................................................................................................................4
Unpacking and Inspection.............................................................................................................................4
Surveyor2000 Components...........................................................................................................................5
Enclosure ..................................................................................................................................................5
Camera Drive ............................................................................................................................................5
Shroud.......................................................................................................................................................5
Lower Dome ..............................................................................................................................................5
Housing .....................................................................................................................................................5
Sunshield/Housing Assembly....................................................................................................................5
Installation ...........................................................................................................................7
Quick Installation – In-Ceiling Model, Ceiling Access................................................................................7
Quick Installation – In-Ceiling Model, No Ceiling Access..........................................................................8
Quick Installation – Indoor Pendant ............................................................................................................9
Quick Installation – Outdoor Pendant........................................................................................................10
Detailed Installation .....................................................................................................................................11
Use of the Provided Scribe .....................................................................................................................11
In-Ceiling Mount Model ............................................................................................................11
Indoor Pendant Model .................................................................................................................20
Outdoor Pendant Model ..........................................................................................................23
Wiring .................................................................................................................................27
Typical Relay and Alarm Connections .......................................................................................................28
XX031-01 Rev 803 Surveyor2000 Camera Dome System •i

Installing the Cables .................................................................................................................................... 29
For an In-Ceiling Installation................................................................................................................... 29
For an Indoor or Outdoor Pendant Model Installation ............................................................................ 30
Using the Accessory Kit’s Termination Box and RJ-45 Cable for Wiring............................................... 32
Using the Optional Alarm Kit (S2000-ACL) ............................................................................................ 34
Installing the Flash Upgrade and PC Direct Control ................................................................................ 36
Standalone Configuration........................................................................................................................... 36
Star Configuration ...................................................................................................................................... 37
Configuration .................................................................................................................... 39
Setting the DIP Switches............................................................................................................................. 39
For RS-422/485 Mode: ........................................................................................................................... 39
For Vicoax Mode:.................................................................................................................................... 39
Setting the End-of-Line Jumpers JP1, JP2 & JP3 for RS-485 Protocol Operation ................................ 41
Uninstalling the Surveyor2000 ........................................................................................ 43
For an In-Ceiling Installation................................................................................................................... 43
For a Pendant Installation....................................................................................................................... 43
Operation........................................................................................................................... 45
Initial Power-Up ...................................................................................................................................... 45
Verifying Proper Operation ......................................................................................................................... 46
Use of the Auto-Baud Detect Feature........................................................................................................ 46
Troubleshooting........................................................................................................................................... 47
Maintenance...................................................................................................................... 49
Care and Cleaning of Metallized Domes.................................................................................................... 49
Care and Cleaning of Smoked and Clear Acrylic Domes ........................................................................ 49
Fuse Replacement ....................................................................................................................................... 49
Battery Replacement ................................................................................................................................... 50
Shipping Instructions....................................................................................................... 51
Reference .......................................................................................................................... 53
Coaxial Cable RecommendationS................................................................................... 53
Twisted-Pair Cable....................................................................................................................................... 54
1.0-inch Pipe Designation ........................................................................................................................... 54
Technical Information ...................................................................................................... 55
ii •Contents XX031-01 Rev 803 Surveyor2000 Camera Dome System

Introduction
The information in this manual covers the installation, configuration and operation of the Surveyor2000
Camera Dome. This system should only be installed by a qualified technician using common hand tools and
approved materials in accordance with national, state and local wiring codes.
NOTE: Read all instructions before beginning any installation.
The Surveyor2000 is a compact, lightweight intelligent security device comprised of a camera, pan/tilt drive,
receiver and CPU-based electronics all in an attractive and covert enclosure. Surveyor2000 can be
programmed and operated using any V1300X/V1400X/1500 series of NOVA communication devices and
enhanced Vicoax II protocol. Surveyor2000 is sold in a variety of prepackaged configurations with choices in
environment, mounting configuration, camera type, and lower dome finish. Models are also available for
coaxial cable or twisted pair (UTP) video transmission. A UTP receiver is required for UTP transmission.
Refer to Tables below for specific model numbers and options available. All versions use the same firmware
for programming and operation. For programming, refer to the Surveyor2000 Programming Manual XX034.
Surveyor2000 complies with UL standard 2044, CSA safety standard C22.2, No. 1, meets requirements for
an FCC Class A computing device. Surveyor2000 complies with the fire code of certain local municipalities.
The fire code for any given municipality should be verified for Surveyor2000’s compliance at the installation
site. Vicon strongly recommends the use of line conditioners, voltage regulators and uninterruptible power
supply (UPS) systems in the electrical pow
e odels
Model Number t t/ /
m
er service.
Surv
Environmen
yor2000 M
Camera MountProduc
Code Cable Type Type/Format Type
Optical Zoom
Total Zoo
Lower
Dome Type
S2000-CC22-EX 8211-00 Indoor/Coax Color/NTSC Ceiling 22x/264x Not Included
S2K-CC22NVT 8285-00 Indoor/UTP Color/NTSC Ceiling 22x/264x Not Included
S2000-CC22C-EX 8211-01 Indoor/Coax Color/PAL Ceiling 22x/264x Not Included
S2000-MC22-EX 8212-00 Indoor/Coax Mono/EIA Ceiling 22x/264x Not Included
S2000-MC22C-EX 8212-01 Indoor/Coax Mono/CCIR Ceiling 22x/264x Not Included
S2000-CP22-EX 8213-00 Indoor/Coax Color/NTSC Pendant 22x/264x Not Included
S2K-CP22NVT 8286-00 Indoor/UTP Color/NTSC Pendant 22x/264x Not Included
S2000-CP22C-EX 8213-01 Indoor/Coax Color/PAL Pendant 22x/264x Not Included
S2000-MP22-EX 8214-00 Indoor/Coax Mono/EIA Pendant 22x/264x Not Included
S2000-MP22C-EX luded8214-01 Indoor/Coax Mono/CCIR Pendant 22x/264x Not Inc
S2000-CW22-EX 8215-00 Outdoor/Coax Color/NTSC Pendant 22x/264x Clear
S2K-CW22NVT 8287-00 Outdoor/UTP Color/NTSCL Pendant 22x/264x Clear
S2000-CW22C-EX 8215-01 Outdoor/Coax Color/PAL Pendant 22x/264x Clear
S2000-MW22-EX 8216-00 Outdoor/Coax Mono/EIA Pendant 22x/264x Clear
S2000-MW22C
EX
-x8216-01 Outdoor/Coa Mono/CCIR Pendant 22x/264x Clear
S2000-RC23 7003-00 Indoor/coax Color/NTSC
(day/night)
Ceiling 23x/184x Not Included
S2000-RC23C 7003-01 Indoor/Coax Color/PAL Ceiling 23x/184x Not Included
S2000-RP23 7004-00 Indoor/Coax Mono/EIA Pendant 23x/184x Not Included
S2000-RP23C 7004-01 Indoor/Coax Mono/CCIR Pendant 23x/184x Not Inc
Color/NTSC
(day/night)
Color/NTSC
(day/night)
Color/PAL
luded
S2000-RW23 7005-00 Outdoor/Coax Pendant 23x/184x Clear
S2K-RW23NVT 8288-00 Outdoor/UTP Pendant 23x/184x Clear
S2000-RW23C 7005-01 Outdoor/Coax
(day/night)
Pendant 23x/184x Clear
XX031-01 Rev 803 Surveyor2000 Camera Dome System Introduction •1

UTP Receiver Options
Model Number Product Code Description
V212-NVT 7631 Receiver, converts UTP video to composite up to 500 ft from
transmitter
V213-NVT 6518 Receiver, converts UTP video to composite up to 1000 ft from
transmitter
V652R-NVT 7453 Receiver, converts UTP video to composite up to 3000 ft from
transmitter
V1613-NVT 7648 16-Channel Hub Receiver, converts UTP video to composite up to
1000 ft from each transmitter
V1662-NVT 6519 16-Channel Hub Receiver, converts UTP video to composite up to
3000 ft from each transmitter
Surveyor2000 Lower Domes
Model Number Product Code Description
S2000-SMK-LD 7006 Ceiling/Pendant, indoor, smoked (gray) tint
S2000-CHR-LD 7007 Ceiling/Pendant, indoor, chrome
2000-GLD-LD 7008 Ceiling/Pendant, indoor, goldS
Surveyor2000 Mounting Options
ber ct Code escriptionModel Num Produ D
S2000-UWM 7032 Wall mount, indoor/outdoor
S2000-UCM 7033 Ceiling mount, indoor/outdoor
S2000-1PC-UPM or7428 Parapet mount, outdo
S2000-URM 7035 Roof mount, outdoor
S2000-UCP 7031 Ceiling panel, indoor
SUR-WM 8001 Wall mount, short, indoor/outdoor
S2000-MKT 7036 In-ceiling mount kit, indoor
Surveyor2000 Power Supplies
umber ct Code Model N Produ Description
S28PS 7029 28 VAC output, 2.5 amps, for indoor Surveyor2000 Camera Domes
S28WPS 0 Camera Domes7030 28 VAC output, 4 amps, for outdoor Surveyor200
S24PS 7027 For Surveyor2000 fixed outdoor camera domes
Heavy-duty single-channel for S
impact-resistant camera domes
V284-175PS 6421 Four channel, 120 VAC input, 28 VAC output, 7.25 amps (total)
288-3605PS 6422 Eight channel, 120 VAC input, 28 VAC output, 13 amps (total)
S28PS-HD 7862 urveyor2000 pressurized and outdoor
V
V2816-720PS 6423 Sixteen channel, 120 VAC input, 28 VAC output, 26 amps (total)
2 •Introduction XX031-01 Rev 803 Surveyor2000 Camera Dome System

How to Use this Manual
This manual was designed to provide the best overall instructions for the installation and operation of the
Surveyor2000 Camera Dome. The graphics and terminology used in this manual have been carefully
selected to enable a clear and distinct understanding of the Surveyor2000 and its components. This manual
has been formatted to present distinct methods of installation for experienced and novice installers.
For Experienced Installers:
Start at the Quick Installation sub-section of the Installation section and choose the appropriate method (In-
Ceiling Mount Model, Indoor Pendant Model or Outdoor Pendant Model) to begin. Follow the references
provided in the text for items such as wiring tables, DIP switch settings and lower dome care. Refer to the
subsequent sections of Installation, Wiring, Configuration and Operation for detailed descriptions of any
method.
For Novice Installers:
Complete the remainder of this section (Introduction) and proceed to the Detailed Installation sub-section of
the Installation section and choose the appropriate method (In-Ceiling Mount Model, Indoor Pendant Model or
Outdoor Pendant Model) to begin. When complete, proceed to the Wiring, Configuration and Operation
sections to verify your work. In addition, these sections detail information on use of such optional features as
he Alarm Inputs and Relay Output.t
The Operation section of this manual was written using the available features in the latest revision of the
Surveyor2000 software. The actual version of software may vary in any particular camera dome and support
different features than actually described here.
XX031-01 Rev 803 Surveyor2000 Camera Dome System Introduction •3

Accessory Kits
There are 3 different Accessory Kits included with the 3 basic configurations of Surveyor2000; ceiling, indoor
pendant and outdoor pendant. These kits provide the necessary items for installation as follows:
Ceiling Mount Version
DESCRIPTION QUANTITY
Termination Box with RJ-45 female connector 1
Cable, RJ-45 male to RJ-45 male, 10 ft (2.5 m) 1
RS-485 Termination Jumpers 3
Scribe for Ceiling Tile 1
Fitting, 0.5 in (12.7 mm) Romex with locknut 1
Indoor/Outdoor Pendant Mount Version
DESCRIPTION QUANTITY
Termination Box with RJ-45 female connector 1
Cable, RJ-45 male to RJ-45 male, 10 ft (2.5 m) 1
RS-485 Termination Jumpers 3
Outdoor Pendant Mount Version (only):
DESCRIPTION QUANTITY
Pipe Sealant, 1/4 oz stick 1
NOTE: Pipe sealant is included in the outdoor housing accessory kit only.
The termination box and RJ-45 cable assembly is included to be used for control and relay connections in
connector J3 or alarm connections in connector J2. Refer to the Wiring section of this manual for details on
using this supplied termination box and cable assembly. The supplied strain relief fitting is used as an
alternate means of providing support for cables on the In-Ceiling Mount model when flexible conduit pipe is
not used. Refer to the In-Ceiling Mount model sub-section of the Installation section for details on installing
this fitting. The RS-485 jumpers are provided to configure the RS-485 protocol and enable daisy-chaining of
Surveyor2000. The sealant is used for sealing the end of the 1.0-inch NPT pipe on the Outdoor Pendant
model. Refer to the Outdoor Pendant model sub-section of the Installation section for details on applying the
sealant.
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to
rovide suitable delivery.
s on the carrier’s bill. Then,
btain the carrier agent’s signature and file a damage claim as soon as possible.
ipment must be returned for
pair, follow the instructions in the Shipping Information section of this manual.
p
Inspect the cartons upon delivery and, if damage is present, make detailed note
o
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage
is present, contact the carrier and file a damage claim immediately. If the equ
re
4 •Introduction XX031-01 Rev 803 Surveyor2000 Camera Dome System

Surveyor2000 Components
All Surveyor2000 units are comprised of an Enclosure, a removable
Camera Drive, a Shroud and a Lower Dome. This assembly is the heart of
every prepackaged Surveyor2000. Figure 1 shows an In-Ceiling model,
Figure 2 an Indoor Pendant model and Figure 3 an Outdoor Pendant
model.
Figure 1
Surveyor2000 In-Ceiling
Enclosure
The Enclosure is a metal shell that houses the camera drive on 3 standoffs.
A safety cord and clip are provided to connect to the camera drive latch
during installation. In addition, a small hole is provided on the Enclosure’s
lip for connection of the lower dome’s plug. A top cover, a standard 0.5-
inch (13 mm) conduit fitting and a pair of flippers are provided for the In-
Ceiling Mount model. The top cover is attached with 3 screws. For In-
Ceiling installations that do not use conduit pipe, a standard 0.5-inch (13
mm) strain relief fitting provides solid cable anchoring at the Enclosure.
Two rotating flippers are used to give a convenient and sturdy connection
of the Enclosure into the ceiling. The pendant models do not use flippers.
Camera Drive
The Camera Drive is comprised of an integral camera, pan-and-tilt drive
and CPU. The camera drive quickly and accurately positions the camera in
360°of pan angle and 90°of tilt angle. All wiring is made directly to the top
of the Camera Drive. There are variations in camera type for format,
magnification and day/night usage.
Shroud
The Shroud is a 5.4 in. (137 mm) textured black ABS plastic shell. It has a
1.2 in. (30.5 mm) slotted opening for the camera. This Shroud conceals the
position of the camera and snaps onto the camera drive.
Lower Dome
The Lower Dome is an assembly comprised of a 5.9 inch (150 mm)
diameter acrylic plastic shell, a trim ring and a safety cord. Lower domes
for indoor versions come in a choice of Smoked, Chrome or Gold finishes.
Outdoor Lower Domes are clear and use 4 screws for additional support.
All Lower Domes are anchored to the enclosure by the safety cord. Refer
to the Maintenance section for care.
Housing
The Housing is a molded plastic protective cover for the enclosure in the
Surveyor2000 Indoor Pendant configuration. The Housing contains two
spring clips that snap into the enclosure and a 1.0-inch NPT pipe flange
mount. In addition, the Housing is equipped with a safety cord and clip that
is used to suspend the enclosure during installation.
Sunshield/Housing Assembly
The Sunshield is pre-installed over the housing used on the Outdoor
Pendant version for environmental sealing from water, dust and debris. It
incorporates an O-ring seal and a foam barrier. In addition, a
thermostatically-controlled heater is provided for temperature control.
CAUTION: For any environment subject to moisture, use the Outdoor
Pendant model.
XX031-01 Rev 803 Surveyor2000 Camera Dome System Introduction •5

Figure 3
Surveyor2000 Outdoor Pendant
Figure 2
Surve
y
or2000 Indoor Pendant
6 •Introduction XX031-01 Rev 803 Surveyor2000 Camera Dome System

Installation
Choose the installation type based on the specific unit purchased (In-Ceiling, Indoor or Outdoor Pendant).
Quick Installation – In-Ceiling Model, Ceiling Access
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
XX031-01 Rev 803 Surveyor2000 Camera Dome System Installation •7

Quick Installation – In-Ceiling Model, No Ceiling Access
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
8 •Installation XX031-01 Rev 803 Surveyor2000 Camera Dome System

Quick Installation – Indoor Pendant
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
XX031-01 Rev 803 Surveyor2000 Camera Dome System Installation •9

Quick Installation – Outdoor Pendant Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
Q
U
I
C
K
I
N
S
T
A
L
L
A
T
I
O
N
10 •Installation XX031-01 Rev 803 Surveyor2000 Camera Dome System

Detailed Installation
For novice or first-time installers, these steps provide the most thorough and accurate instructions.
Use of the Provided Scribe
A small metal scribe is provided to assist in marking an accurate hole size in a ceiling tile. Use as follows:
1. Place a ceiling tile on a large flat surface, face up.
Figure 4
Use of the Scribe
2. Measure and make a small mark at position A
from corner (11.9 in./302 mm). Refer to Figure 4.
3. Measure and make a small mark at position B
(8.2 in./208 mm), placing the Scribe as
perpendicular to the A-edge as possible.
4. Place the Scribe across positions Band C.
Rotate the Scribe around center Cfor a full turn.
5. Cut out the circle, using a sharp tool, on the
scribed line.
In-Ceiling Mount Model
Figure 5
Ceiling Mount Model, No Ceiling Access Provided
This version of Surveyor2000 mounts in the ceiling
and rests on the ceiling material occupying the space
between the lower ceiling and upper building frame.
There are 2 methods of installation. The first method
is for ceilings with no access to the space above, as
in a typical hard material ceiling. The second method
is used for a ceiling with access, as a dropped ceiling
(metal grid type). All mounting hardware is provided.
From Below the Ceiling (no access to the
space above)
The camera drive is removed from the enclosure. The
ceiling hole is cut using the scribe and the enclosure
is prepared with flexible conduit or cabling below the
ceiling. The enclosure is then lifted up through ceiling
hole and the flipper screws are turned and tightened
against the ceiling. Then the camera drive is hung
from the enclosure’s safety cord, wired, configured
and screwed back into the enclosure. The indoor
lower dome is then snapped on. The Surveyor2000 is
secured with the flippers. The Surveyor2000’s
horizontal position is determined by the hole
placement. Refer to Figure 5 for installation details.
XX031-01 Rev 803 Surveyor2000 Camera Dome System Installation •11

The accessory kit containing the RJ-45 to RJ-45
10 foot (2.5 m) cable and RJ-45 termination box
can be used in this installation for the 4 alarms
or relay. Since there is no access to above
ceiling space and the supplied cable is limited to
10 feet (2.5 m), the termination box must be
mounted in an area with access. In addition, the
10 foot (2.5 m) cable must be routed discretely
with the other cables or through the flexible
conduit pipe. Refer to Figure 6 for an example
of using the supplied cable and termination box
in this situation.
Figure 6
Typical use of Accessory Kit
The ceiling material must provide a surface of suitable strength for the Surveyor2000 weight of 4.5 lb (2.0 kg)
on the area of the two flippers. Refer to the Optional Independent Support sub-section for installations
requiring additional support.
1. Mark, with the scribe, and cut a 7-3/8-inch (187 mm) diameter hole in ceiling at the desired location. Feed
all flexible conduit pipe or cables down through the hole.
2. Remove the camera drive from the enclosure by loosening the 3 captive screws.
3 . If cables are used without the use of flexible conduit:
a) Remove the enclosure’s top cover by loosening the 3 screws and lifting it off. Then remove the
conduit fitting by loosening the nut and sliding it out. Install the supplied strain relief fitting in its place
and re-attach the top cover.
Hold the enclosure near the hole in the ceiling and route approximately 9 inches (229 mm) of cables
through the strain relief fitting. Tighten the 2 strain relief fitting screws to compress the cables. Do not
b)
over-tighten the screws and crush the cables.
NOTE: Connectors that do not fit through the strain relief fitting must be cut off and re-terminated after
passing the cable through. It is recommended to pass any RJ-45 connectors through the fitting first.
BNC type connectors do not fit through the fitting and must be terminated later.
3. If cables are channeled through flexible conduit:
a) n the ceiling and route approximately 9 inches (229 mm) of conduit
cables through the conduit fitting.
b) Insert the end of the flexible conduit pipe into the conduit fitting and tighten the clamp screw.
NOTE:
Hold the enclosure near the hole i
Connectors that do not fit through the conduit fitting must be cut off and re-terminated after passing
the cable through. It is recommended to pass any RJ-45 connectors through the fitting first. BNC type
connectors do not fit through the fitting and must be terminated later.
4. Lift enclosure up through ceiling hole, turn and tighten flipper screws.
5. Connect the latch of the camera drive to the enclosure’s safety cord clip.
12 •Installation XX031-01 Rev 803 Surveyor2000 Camera Dome System

6. With the camera drive hanging from the enclosure, terminate all the cables as follows:
a) Remove terminal blocks TB1 and/or TB3. Since the control signals exist in both TB3 and J3, do not
remove TB3 if J3 will be used for control signal wiring.
b) Strip approximately 1 inch (25 mm) of insulation off all wires to be terminated in terminal blocks. Then
strip approximately 0.25 inches (6 mm) of insulation off of each individual wire.
c) Make all connections to terminal blocks TB1 and TB3 with reference to Table 2. On TB3, the
COMMAND IN + (CI+) and COMMAND IN - (CI-) connections must be used for Simplex operation.
For Half Duplex operation, the additional signals RESPONSE OUT + (RO+) and RESPONSE OUT -
(RO-) must also be used. Insert each wire into its proper terminal block location and tighten each
screw.
) Terminate the video (coaxial) cable with a BNC type male connector.d
Terminate the 8-conductor alarm
connectors J2 and J3 will be used.
e) cable or control/relay cable with an RJ-45 male connector, if
WARNING: with control signals, as this will causeIf Vicoax mode is being used, DO NOT wire TB3 or J3
the camera dome program to lock up upon power-up.
Reinstall the te7. rminal blocks TB1 and TB3 into the Communication Power Supply Board at the proper
block frames.
8.
(for coax installations) or connect twisted-pair video wires to screw terminal TB4
(for UTP installations).
9. les should
be just long enough to reach their respective connectors or approximately 8 inches (203 mm).
Install the video BNC cable connector to the Communication Power Supply Board’s mating BNC
connector at location J1
Plug in all RJ-45 cable connectors to their corresponding mating connectors J2 and J3. All cab
WARNING:g connectors can cause damageFailure to insert the RJ-45 connectors into the correct matin
to the Communication Power Supply Board upon power-up.
10. Configure the Surveyor2000 communication and address DIP switches as follows:
a)
. le 3. All
or NTSC/ON).
5. Set switch 4 on DIP switch 2 (S2) to the appropriate communication protocol (RS-422 or RS-
485).
If RS-422 mode will be used:
Set switches 1 - 8 on DIP switch 1 (S1) to Surveyor2000’s address as specified in Tab1
addresses between 0 and 255 are valid (address 0 is the same as camera number 256).
2. Set switch 1 on DIP switch 2 (S2) to the appropriate video mode (PAL/OFF
3. Set switch 2 on DIP switch 2 (S2) to the OFF position (VPS/NOVA mode).
4. Set switch 3 on DIP switch 2 (S2) to the OFF position (SIMPLEX/DUPLEX mode).
XX031-01 Rev 803 Surveyor2000 Camera Dome System Installation •13

If Vicoax Mode will be used:
1. Set switch 1 on DIP switch 2 (S2) to the appropriate video mode (PAL or NTSC).
2. Set switch 2 on DIP switch 2 (S2) to the ON position (Vicoax mode).
3. Set switch 3 on DIP switch 2 (S2) to either position, as it does not affect Vicoax protocol
operation.
4. Set switch 4 on DIP switch 2 (S2) to either position, as it does not affect Vicoax protocol
operation.
NOTE: DIP switches labeled ON or CLOSED and OFF or OPEN have the same meaning.
11. Carefully align the 3 camera drive Captive screws with their mating standoffs and insert the camera drive
into the enclosure. When seated, tighten the 3 captive screws.
12. Lift the lower dome up to the
Surveyor2000 and line up the 2
molded tabs on the lower dome with
the 2 recesses on the inner
enclosure. Refer to Figure 7. There
are only 2 ways to align it.
Figure 7
Final Assembly, Ceiling Mount Version
13. Insert the plug on the safety cord into
the hole on the Surveyor2000. Push
the lower dome up into the Surveyor
2000. Verify that it snaps into place
on both sides. The upper edge of the
lower dome should be flush with
ceiling plane.
14. Proceed to the Operation section of
this manual.
14 •Installation XX031-01 Rev 803 Surveyor2000 Camera Dome System

Figure 8
Ceiling Mount Model, Access Provided
From Above the Ceiling (access
to the space above)
The ceiling hole is marked with the scribe
and cut. The enclosure is then lifted up
through ceiling hole and the flipper screws
are turned and tightened against the
ceiling. The enclosure’s top cover is
removed and the Surveyor2000 is wired
and configured from above the ceiling.
The top cover is replaced and the indoor
lower dome is then snapped on. The
Surveyor2000 is secured with the flippers.
Refer to Figure 8 for installation details.
The accessory kit containing the RJ-45 to
RJ-45 8 foot (2.4 m) cable and RJ-45
termination box can be used in this
installation for the 4 alarms or relay. Since
there is access above the ceiling and the
supplied cable is limited to 8 feet (2.4 m),
the termination box must be mounted
while wiring and configuring the
Surveyor2000. Refer to Figure 6 for an
example of using the supplied cable and
termination box in this situation. Detailed
installation instructions will follow.
The ceiling material must provide a
surface of suitable strength for the
Surveyor2000 weight of 4.5 lb (2.0 kg) on
the area of the two flippers. Refer to the
Optional Independent Support sub-
section for installations requiring
additional support.
1. Mark, with the scribe, and cut a 7-3/8-
inch (187 mm) diameter hole in ceiling
at the desired Surveyor2000 location. Feed the necessary flexible conduit pipe or cables down through
the hole.
2. Lift enclosure up through ceiling hole, turn and tighten flipper screws.
3. Working above the ceiling, remove the enclosure top cover by loosening the 3 screws and lifting it off.
4. If cables are used without the use of flexible conduit:
a) Remove the conduit fitting by loosening the nut and sliding it out. Install the supplied strain relief
fitting in its place.
b) Route approximately 9 inches (229 mm) of cables through the strain relief fitting. Tighten the 2 strain
relief fitting screws to compress the cables. Over-tightening the screws could crush cables.
XX031-01 Rev 803 Surveyor2000 Camera Dome System Installation •15

NOTE: Connectors that do not fit through the strain relief fitting must be cut off and re-terminated after
passing the cable through. It is recommended to pass any RJ-45 connectors through the fitting first.
BNC type connectors do not fit through the fitting and must be terminated later.
4. If cables are channeled through flexible conduit:
a) Route approximately 9 inches (229 mm) of conduit cables through the conduit fitting.
b) Insert the end of the flexible conduit pipe into the conduit fitting and tighten the clamp screw.
NOTE: Connectors that do not fit through the conduit fitting must be cut off and re-terminated after passing
the cable through. It is recommended to pass any RJ-45 connectors through the fitting first. BNC type
connectors do not fit through the fitting and must be terminated later.
. Terminate all the cables as follows (refer to Figure 9):5
a) Remove terminal blocks TB1 and/or TB3. Since the control signals exist in both TB3 and J3, do not
remove TB3 if J3 will be used for control signal wiring.
b) terminal blocks. Then
strip approximately 0.25 inches (6 mm) of insulation off of each individual wire.
c)
ust also be used. Insert each wire into its proper terminal block location and tighten each
screw.
) Terminate the video (coaxial) cable with a BNC type male connector.
e) le or communication/relay cable with an RJ-45 male connector,
if connectors J2 and J3 will be used.
Strip approximately 1 inch (25 mm) of insulation off all wires to be terminated in
Make all connections to terminal blocks TB1 and TB3 with reference to Table 2. On TB3, the
COMMAND IN + (CI+) and COMMAND IN - (CI-) connections must be used for Simplex operation.
For Half Duplex operation, the additional signals RESPONSE OUT + (RO+) and RESPONSE OUT -
(RO-) m
d
Terminate the 8-conductor alarm cab
WARNING: with control signals, as this will causeIf Vicoax mode is being used, DO NOT wire TB3 or J3
the camera dome program to lock up upon power-up.
Reinstall the te6. rminal blocks TB1 and TB3 into the Communication Power Supply Board at the proper
7.
(for coax installations) or connect twisted-pair video wires to screw terminal TB4
Plug in all RJ-45 cable connectors to their corresponding mating connectors J2 and J3. All cables should
block frames.
Install the video BNC cable connector to the Communication/Power Supply Board’s mating BNC
connector at location J1
(for UTP installations).
8.
be carefully looped around to prevent the excess cable from bending sharply and breaking later.
WARNING: Failure to insert the RJ-45 connectors into the correct mating connectors can cause damage
to the Communication Power Supply Board upon power-up.
NOTE: Failure to loop the cables can prevent later removal of the camera drive from the enclosure.
16 •Installation XX031-01 Rev 803 Surveyor2000 Camera Dome System
