Viconics VTR8300 Series User manual

VTR8300 Series Installation Guide
Room Controller with Optional PIR sensor
Commercial and Hotel/Lodging HVAC Fan Coil Applications

2
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
DISCLAIMERS
• The VTR8300 series Room Controller is only to be used in conjunction with the VC3000 line voltage switching relay pack.
Together they are used as operating controls for high voltage fan coil units.
• If replacing an existing Line Voltage FCU Controller, label the wires before removal of the Room Controller.
• Electronic controls are static sensitive devices. Discharge yourself correctly before manipulating and installing the Room Controller.
A short circuit or wrong wiring may permanently damage the Room Controller or equipment.
• All VTR8300 series Room Controllers are designed for use as operating controls only and are not safety devices. These
instruments have undergone rigorous tests and verification prior to shipping to ensure proper and reliable operation in the field.
Whenever a control failure could lead to personal injury and/or loss of property, it becomes the responsibility of the user/installer/
electrical system designer to incorporate safety devices such as relays, flow switches, thermal protections, and/or an alarm
system to protect the entire system against any catastrophic failures. Tampering with the devices or unintended application of the
devices results in a void of warranty.
• If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
• These devices are not serviceable and must be returned to the supplier for any repair.
• A switch or circuit breaker must be installed. It must be suitably located, easily reached, and marked as the disconnecting device
• This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
VTR8300 Room Controller VC3000 Relay Pack
IMPORTANT SYMBOLS
Products marked with this symbol state that the manuals must be consulted in all cases to any hazards.
This product has been tested to the requirements of CAN/CAS-C22.2 No. 61010-1, second edition, including Amendment
1, or a later version of the same standard incorporating the same level of testing requirements.
Alternating Current
Direct Current
Equipment protected throughout by DOUBLE INSULATION or REINFORCED INSULATION

3
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
• If replacing an existing VTR8300 Room Controller, label wires before removal of Controller.
• Electronic controls are static sensitive devices. Discharge yourself correctly before manipulating and installing
Controller.
• A short circuit or wrong wiring may permanently damage Room Controller or equipment.
• All VTR8300 series Room Controllers are designed for use as operating controls only and are not safety devices.
Tampering with the devices or unintended application of the devices will result in a void of warranty.
• This transmitter must be installed to provide a separation distance of at least 4in (10cm) from all persons and
must not be collocated or operating in conjunction with any other antenna or transmitter.
CLEANING THE ROOM CONTROLLER
• Use a soft, pre-moistened lint-free cloth for cleaning.
• Avoid getting moisture in openings.
• Do not spray anything directly on the Room Controller or use compressed air.
• Do not use caustic/corrosive products, ammonia, solvents or any cleaning product containing alcohol or grit.
• Never use tools directly on the touchscreen.
• Never use paint on the Room Controller.
• Do not drop or crush the Room Controller, or allow it to come into contact with liquids.
• Do not use a damaged device (such as one with a cracked screen).
• Performance can be affected if the glass on the screen is broken.
• Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s warranty.
LOCATION
• Do not install on outside wall
• Do not install behind a door
• Do not install in areas with direct heat source.
• Do not install near any air discharge grill.
• Do not install in areas exposed to direct sunlight.
• Ensure Room Controller has sufficient natural air circulation
• Ensure wall surface is flat and clean.
• Ensure external thermal sensor wirings are away from noisy electrical sources
• Install 1.3 to 1.5 meter (52 to 60 inches) above the floor

4
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
INSTALLATION
1. Open the unit by pulling on the bottom of the Room Controller (Figure 1).
2. Read the FCC ID and IC label installed in the cover before installing any
wireless product.
3. Ensure the correct side of the base faces up.
4. Pull the cables 6 in (15 cm) out from the wall.
5. Align the base and mark location of the two mounting holes on the
wall(Figure2).
6. Install the anchors in the wall.
7. Insert the cable in the central hole of the base.
8. Insert the screws in the mounting holes on each side of the base.
9. Strip each wire 1/4 in (0.6 cm) from the end.
10. Insert each wire according to the wiring chart (see next page).
11. Gently push excess wiring back into the hole.
12. Gently align the cover with the top of the base and snap into place from the
bottom (Figure 3).
13. Install the security screw.
Figure 1 Open the cover
Figure 2 Install the base
Figure 3 Reinstall cover

5
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
To other
VC3xxxE
Relay
Pack
Terminal Controller
Relay Pack
VTR83xxA VC3504E
4 - Tx / Rx
5 - 7 Vdc Power Hot
6 - Power Common
1 - Tx / Rx
2 - 7 Vdc Power Hot
3 - Power Common
Relay Pack
VC3300E
1 - Tx / Rx
2 - 7 Vdc Power Hot
3 - Power Common
Terminal Controller
Terminal Controller
To others
To others
13 - COM +
14 - COM -
VTR83xxA VTR83xxA
13 - COM +
14 - COM -
Terminal Identification All VTR83xxA
Terminal Equipment Controller
Terminal 4 Tx – Rx Communication
Terminal 5 Power Hot 7.0 VDC
Terminal 6 Power Common
Terminal 12 ECM 0-10 VDC output
Terminal 13 BACnet +
Terminal 14 BACnet -
Terminal 15 BACnet REF
Terminal 16 BI 1 ( Configurable )
Terminal 17 BI 2 ( Configurable )
Terminal 18 Scom
TERMINAL, IDENTIFICATION AND FUNCTION
Only ONE VC3xxxE Relay Pack with remote
monitoring inputs can be used under a single
VTR83xxA Controller. All other slave units must be
VC3xxxE Relay Pack(s) WITHOUT remote inputs. A
maximum of 10 VC3xxxE Relay Packs can be used
for a single VTR83xxA Room Controller.
From VTR83xxA to first VC3xxxE Relay Pack
• Uses existing or new field wires
• A minimum of 3 wires are required
• Solid or Stranded, Shield is not necessary
• Distance between the two units must not exceed
15 m (49 ft)
• Wire gauge depends on available distance:
<= 10 m (33 ft): AWG 16-18 (1.31 - 0.823 mm²)
> 10 m (33 ft): AWG 16 (1.31 mm²)
From first VC3xxxE to all other slave
VC3xxxE Relay Pack(s)
• Uses existing or new field wires
• 2 required wires AWG 16-18 (1.31 - 0.823 mm²):
Tx/Rx (1)
Power Common (3)
• Solid or Stranded, Shield is not necessary
Daisy Chained Topology
Star Topology Mixed Daisy Chained & Star Topology
COMMUNICATION WIRING TO VC3XXXE RELAY PACK
Network Wiring Topology
BACnet®Communication Shielded Wiring (if required)
• NOTE: See VTR8300 BACnet®integration manual for more details
• NOTE: never use any terminal not mentioned in above table.

6
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
HOME SCREEN DISPLAY
NOTE:User HMI is configurable and allows display functions such as Date, Time, Humidity, Outdoor Temperature, Setpoint, and
others to be enabled or disabled by setting various parameters.
Time
System Status
Fan Status
Up Arrow
Increase Temperature Setpoint
Actual Setpoint
Down Arrow
Decrease Temperature
Setpoint
Help
Language Selection
Temperature Units
Fan Mode
Date
Occupancy Status
Indoor Temperature
Indoor Humidity
Outdoor Temperature
System Mode
Short Network
Message
Hospitality User Interface Shown

7
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0414-07 April 2019
HOW TO ENTER SETUP SCREEN
SETUP SCREEN DISPLAY
Return to
home screen
General Note:
1/2 Setup
Network
Configuration
Setpoints - Display
Service View
Test Outputs
Language Selection
Adjustable parameter
Nonadjustable parameter
Touch and hold this point
for 3 seconds to enter setup mode
NOTE: If a configuration / installer
password is activated to prevent
unauthorised access to the
configuration menu parameters, a
password entry prompt will appear
to prevent access to the device
configuration components.
Enter BACnet®& ZigBee®network settings
Enter parameter configuration menu
Enter setpoint & display settings
Enter output testing mode
Enter status and service view
Enter setpoint & display settings
Enter language selection settings
