1 | PIR Ready VT7200 Series-Installation Guide
CONTENTS
Installation 2
Location 2
Installation 2
Configurable BI/UI inputs overview 3
Model Chart 5
Network ready 6
Terminal, Identification and Function 6
Wiring 7
Main outputs wiring 7
Typical applications 8
Remote sensor accessories 12
Configuring and Status Display Instructions 13
Status display 13
User Interface 15
Local keypad interface 15
Occupied setpoints adjustments 16
Unoccupied and stand-by setpoints adjustments 16
Mode button menu sequence 16
System mode function 16
Installer Configuration Parameter Menu 16
Configuration interface 17
Specifications 28
Drawing & Dimensions 29
PIR Ready VT7200 Series 24 VAC Low Voltage
Zoning Terminal Equipment Controller
Installation Guide
For Commercial HVAC Applications
May 3rd, 2012 / 028-0190-R8

2 | PIR Ready VT7200 Series-Installation Guide
INSTALLATION
Remove the security screw on the bottom of
Terminal Equipment Controller cover.
Open unit by pulling on the bottom side
of Terminal Equipment Controller (fig.
1).
Remove wiring terminals from sticker.
Please read the FCC ID and IC label
installed in the cover upon removal of
cover for the wireless products.
Location
1. Should not be installed on an outside
wall.
2. Must be installed away from any direct
heat source.
3. Should not be installed near an air
discharge grill.
4. Should not be affected by direct sun
radiation.
5. Nothing should restrict vertical air
circulation to the Terminal
Equipment Controller.
Installation
1. Swing open the Terminal Equipment
Controller PCB to the left by
pressing the PCB locking tabs (fig.
2).
2. Pull out cables 6” out from the wall.
3. Wall surface must be flat and clean.
4. Insert cable in the central hole of the
base.
5. Align the base and mark the location
of the two mounting holes on the
wall. Install proper side of base up.
6. Install anchors in the wall.
7. Insert screws in mounting holes on
each side of the base (fig. 2).
8. Gently swing back the circuit board
on the base and push on it until the
tabs lock it.
9. Strip each wire 1/4 inch from end.
10. Insert each wire according to wiring
diagram.
11. Gently push excess wiring back into
hole (fig. 3).
12. Re-Install wiring terminals in their
correct locations (fig. 3).

3 | PIR Ready VT7200 Series-Installation Guide
13. Re-install the cover (top side first) and gently push extra wire length back into the
hole in the wall.
14. Install security screw.
CONFIGURABLE BI/UI INPUTS OVERVIEW
Binary input #1 can be configured for the following functions:
1. (None): No function will be associated with the input
2. (Rem NSB): remote NSB timer clock input. The scheduling will now be set as
per the binary input. It provides low cost setback operation via a dry contact
Contact opened = Occupied
Contact closed = Unoccupied
3. (Motion NO) and (Motion NC): Advanced PIR occupancy functions using a
Normally Open (NO) or Normally Closed (NC) remote PIR motion sensor.
Occupancy mode is now set as per applied PIR function and configuration.
Application information and examples are available on document: APP-PIR-
Guide-Exx. This document will provide the installers and system designers with
detailed examples on applications, parameter configuration information,
sequence of operation, troubleshooting and diagnostic help required for the
proper usage of the PIR accessory covers
4. (Window) EMS: Forces the system to disable any current heating or cooling
action by the Terminal Equipment Controller. The mode stays the same and the
current setpoints are the same occupied setpoints. Only the outputs are disabled.
There is a Door/Window alarm displayed on the Terminal Equipment Controller
to indicate to the local tenant that the door/window needs to be closed for
cooling or heating to resume. Use NC contact.
Contact opened = System disabled with local Window alarm
Contact closed = System enabled
If replacing an existing Terminal Equipment Controller, label the wires
before removal of the Terminal Equipment Controller.
Electronic controls are static sensitive devices. Discharge yourself
properly before manipulating and installing the Terminal Equipment
Controller.
A short circuit or wrong wiring may permanently damage the Terminal
Equipment Controller or the equipment.
All VT7000 series Terminal Equipment Controllers are designed for use
as operating controls only and are not safety devices. These instruments
have undergone rigorous tests and verification prior to shipping to ensure
proper and reliable operation in the field. Whenever a control failure
could lead to personal injury and/or loss of property, it becomes the
responsibility of the user / installer / electrical system designer to
incorporate safety devices (such as relays, flow switch, thermal
protections, etc…) and/or an alarm system to protect the entire system
against such catastrophic failures. Tampering with the devices or
unintended application of the devices will result in a void of warranty.

4 | PIR Ready VT7200 Series-Installation Guide
Binary input #2 can be configured for the following functions:
1. (None): No function will be associated with the input
2. (Door Dry) Door contact & Motion detector: This configuration is only
functional if binary input #1 is set to Motion NO or Motion NC or a PIR
accessory cover is used. With this sequence enabled, the occupancy is now
dictated through those 2 inputs. Any motion detected will set the zone to
occupied status. The zone will remain permanently in occupied mode until the
door contact switch opens momentarily. The Terminal Equipment Controller will
then go in stand-by mode. If more movements are detected, the occupied mode
will resume. While the door is opened, any movements detected by the remote
PIR sensor or the PIR accessory cover will be ignored. Use a Normally Closed
contact switching device.
Contact opened = Door opened
Contact closed = Door closed
3. (RemOVR): temporary occupancy remote override contact. This function
disables the central button override function on the Terminal Equipment
Controller. The override function is now controlled by a manual remote
momentarily closed contact. When configured in this mode, the input operates in
a toggle mode. It is now possible to toggle between unoccupied & occupied
setpoints for the amount of time set by parameter (TOccTime) temporary
occupancy time.
4. (Filter): a backlit flashing Filter alarm will be displayed on the Terminal
Equipment Controller LCD screen when the input is energized. It can be tied to a
differential pressure switch that monitor filters
Contact opened = No alarm
Contact closed = Alarm displayed
5. (Service): a backlit flashing Service alarm will be displayed on the Terminal
Equipment Controller LCD screen when the input is energized. It can be tied in
to the AC unit control card, which provides an alarm in case of malfunction.
Contact opened = No alarm
Contact closed = Alarm displayed
Universal input #3 can be configured for the following functions:
1. (None): No function will be associated with the input
2. (COC/NH) Change over dry contact. Normally Heat: Used for hot / cold air /
water change over switching in 2 pipe systems.
Contact closed = Cold air / water present
Contact opened = Hot air / water present
Only used and valid if system is setup as 2.0. Parameter ( Out1Conf ) set as 2.0.
3. (COC/NC) Change over dry contact. Normally Cool: Used for hot /cold air /
water change over switching in 2 pipe systems.
Contact closed = Hot air / water present
Contact opened = Cold air / water present
Only used and valid if system is setup as 2.0. Parameter ( Out1Conf ) set as 2.0.

5 | PIR Ready VT7200 Series-Installation Guide
4. (COS) Change over analog sensor: Used for hot / cold air / water change over
switching in 2 pipe systems.
Only used and valid if system is setup as 2.0. Parameter ( Out1Conf ) set as 2.0.
If temperature is > 77 °F = Hot air / water present
If temperature is < 75 °F = Cold air / water present
5. (SS) Supply air sensor monitoring: Used for supply air temperature
monitoring.
Only used for network reporting of the supply air temperature. Has no internal
function in the Terminal Equipment Controller.
MODEL CHART

6 | PIR Ready VT7200 Series-Installation Guide
Network ready
All Viconics VT7200 series Terminal Equipment Controllers are designed for
stand-alone (Network Ready) operation.
They can be fully integrated into your choice of automation systems using the
available communication adapter options.
If required, stand-alone (Network Ready) Terminal Equipment Controllers can be
field retrofitted with the following communication adapters:
oVCM7300V5000B, Terminal Equipment Controller BACnet™ MS-TP
communication adapter
oVCM7300V5000E, Terminal Equipment Controller Echelon™ Lontalk™
communication adapter
oVCM7000V5000W Terminal Equipment Controller wireless
communication adapter
TERMINAL,IDENTIFICATION AND FUNCTION
Viconics Part Numbers VT7200C5x00(x) Viconics number VT7200F5x00(x)
Description / Application 1 or 2 Floating outputs Description / application 1 or 2 Analog outputs
1 or 2 On/Off outputs
4- 24 V~ Hot 24 V~ Hot 4- 24 V~ Hot 24 V~ Hot
5- 0 V~ Com 24 V~ Com 5- 0 V~ Com 24 V~ Com
6- Aux BO 5 BO 5-Aux 6- Aux BO 5 BO 5-Aux
7- Aux BO 5 BO 5-Aux 7- Aux BO 5 BO 5-Aux
8- BO 3 Open Heat BO 3
9- BO 4 Close Heat BO 4 9- AO 2 Heat AO 2
10- BO 1 Open Cool BO 1 10- AO 1 Cool AO 1
11- BO 2 Close Cool BO 2 Not used Blank Blank
12- BI 1 BI 1 12- BI 1 BI 1
13- RS RS 13- RS RS
14- Scom Scom 14- Scom Scom
15- BI 2 BI 2 15- BI 2 BI 2
16- UI 3 COS / COC /SS UI 3 16- UI 3 COS / COC /SS UI 3

7 | PIR Ready VT7200 Series-Installation Guide
Wiring
Main outputs wiring
Single output applications
Dual output applications
On-Off control VT7200C5x00(x)
Floating control VT7200C5x00(x)
Remote inputs ( All models )
BI 1
RS
Scom
BI 2
UI 3
OR
Contact
- Rem NSB
- Motion
- Window
Contact
- Door
- Remote Override
- Filter alarm
- service alarm
Remote wall sensor
- S3010W1000
- S3020W1000
SS ( supply sensor )
- S1010E1000
- S2000D1000
COS ( changeover sensor )
- S1010E1000
COC/NH
- Normally heat
- Closed contact = cold water
COC/NC
- Normally cool
- Closed contact = heat water
#4 24 V~ Hot
#5 24 V~ Com
#6
#7
#4 24 V~ Hot
#5 24 V~ Com
#6
#7
Auxiliary output
( All models )
- Dry contact to end device 24 V~ maximum
- 24 VAC power to relay
R
R
Heating / Cooling valve
24 VAC
Com
OR
24 V~ Hot
24 V~ Com
BO1
if N.O.
BO2
if N.C.
24 V~ Hot
24 V~ Com
BO3
if N.O.
BO4
if N.C.
BO1
if N.O.
BO2
if N.C.
24 Vac
Com
Heating valve
Cooling valve
24 Vac
Com
OR
OR
24 VAC
Com
Heating valve
Cooling valve
24 VAC
Com
OR
OR
Open
Com
Close
Heating / Cooling valve
24 V~ Hot
24 V~ Com
BO1
BO2
Open
Com
Close
Heating valve
Open
Com
Close
Cooling valve
24 V~ Hot
24 V~ Com
BO3
BO4
BO1
BO2

8 | PIR Ready VT7200 Series-Installation Guide
Analog control VT7200F5x00(x)
Typical applications
Schematic
Wiring
Settings
Pressure dependent VAV cooling only:VT7200C5x00(x) Floating actuator
Mandatory
Out1Conf = 2.0
CntrltTyp = Floating
FL time = as per
actuator
SeqOpera = 0
Cooling only
Pressure dependent VAV cooling only: VT7200F5x00(x) Analog actuator
Mandatory
Out1Conf = 2.0
RA/DA = as per
actuator
SeqOpera = 0
Cooling only
Heating / Cooling valve
Com
24 VAC
0-10 VDC
24 V~ Hot
24 V~ Com
AO 1
24 V~ Hot
24 V~ Com
AO 2
AO 1
Com
24 VAC
0-10 VDC
Heating valve
Cooling valve
Com
24 VAC
0-10 VDC
UI3 COS
0 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
& Maximum
Position
the actuator
Modulating Floating
VAV Actuator
Analog VAV Actuator
& Maximum
Position
the actuator
0 to 10
VDC
UI3 COS
0 V~ Com
24 V~ Hot
AO1
Minimum
Minimum
Adjusted on
Room Temperature Control
Adjusted on
Room Temperature Control

9 | PIR Ready VT7200 Series-Installation Guide
Pressure dependent VAV cooling / heating with changeover: VT7200C5x00(x)
Floating actuator
Mandatory
Out1Conf = 2.0
CntrltTyp = Floating
FL time = as per
actuator
If heat / cool auto-
changeover with a local
discharge air
temperature sensor set:
SeqOpera = 0
Cooling only
UI3 = COS
Pressure dependent VAV cooling / heating with changeover: VT7200F5x00(x)
Analog actuator
Mandatory
Out1Conf = 2.0
RA/DA = as per
actuator
If heat / cool auto-
changeover with a local
discharge air
temperature sensor set:
SeqOpera = 0
Cooling only
UI3 = COS
Supply air
temperature sensor
UI3 COS
0 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
Changeover
Sensor
Room Temperature Control
& Maximum
Position
the actuator
Modulating Floating
VAV Actuator
0 to 10 VDC
Analog Actuator
Changeover
Sensor
Room Temperature Control
Minimum
& Maximum
Adjusted on
the actuator
Position
Supply air
temperature sensor
0 to 10
VDC
UI3 COS
0 V~ Com
24 V~ Hot
AO1
Minimum
Adjusted on

10 | PIR Ready VT7200 Series-Installation Guide
Pressure dependent VAV cooling / heating with changeover and reheat:
VT7200C5x00(x) Floating actuator
Mandatory
Out1Conf = 2.0
CntrltTyp = Floating
FL time = as per
actuator
If heat / cool auto-
changeover with a local
discharge air
temperature sensor set:
SeqOpera = 2
Cooling with Reheat
UI3 = COS
Pressure dependent VAV cooling / heating with changeover and reheat:
VT7200F5x00(x) Analog actuator
Mandatory
Out1Conf = 2.0
RA/DA = as per
actuator
If heat / cool auto-
changeover with a local
discharge air
temperature sensor set:
SeqOpera = 2
Cooling with Reheat
UI3 = COS
Supply air
temperature sensor
1
C
UI3 COS
0 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
BO5-Aux
BO5-Aux
Sensor
Room Temperature Control
& Maximum
Position
Adjusted on
the actuator
Modulating Floating
VAV Actuator
Heating and/or Cooling
& On/Off Duct Heater
Minimum
Sensor
Analog
VAV Actuator
Heating and/or Cooling
& On/Off Duct Heater
& Maximum
Position
the actuator
Minimum
Adjusted on
Room Temperature Control
Supply air
temperature sensor
1
C
0 to 10
VDC
UI3 COS
0 V~ Com
24 V~ Hot
AO1
BO5-Aux
BO5-Aux
AO2
Changeover
Changeover

11 | PIR Ready VT7200 Series-Installation Guide
Schematic
Wiring
Settings
Heating or cooling hydronic valve control: VT7200C5x00(x) Floating actuator
Mandatory
Out1Conf = 2.0
CntrltTyp = Floating
FL time = as per
actuator
If cooling only set::
SeqOpera = 0
Cooling only
If heating only set::
SeqOpera = 1
Heating only
Heating or cooling hydronic valve control: VT7200F5x00(x) Analog actuator
Mandatory
Out1Conf = 2.0
RA/DA = as per
actuator
If cooling only set::
SeqOpera = 0
Cooling only
If heating only set::
SeqOpera = 1
Heating only
Cooling / heating with changeover hydronic valve control: VT7200C5x00(x)
Floating actuator
Mandatory
Out1Conf = 2.0
CntrltTyp = Floating
FL time = as per
actuator
If heat / cool auto-
changeover with a local
water temperature
sensor set:
SeqOpera = 0
Cooling only
UI3 = COS
UI3 COS
0 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
Supply water
temperature sensor
UI3 COS
0 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
Modulating Floating
Valve Cooling or Heating
Room Temperature
Control Thermostat
Analog Valve
Cooling or Heating
Room Temperature
Control Thermostat
0 to 10
VDC
UI3 COS
0 V~ Com
24 V~ Hot
AO1
Modulating Floating Valve
Heating and/or Cooling
Optional Water
Supply Sensor
Room Temperature
Control Thermostat

12 | PIR Ready VT7200 Series-Installation Guide
Cooling / heating with changeover hydronic valve control: VT7200F5x00(x)
Analog actuator
Mandatory
Out1Conf = 2.0
RA/DA = as per
actuator
If heat / cool auto-
changeover with a local
water temperature
sensor set:
SeqOpera = 0
Cooling only
UI3 = COS
Remote sensor accessories
Model no.
Description
S3010W1000
Wall mounted temperature sensor
S3020W1000
Wall mounted temperature sensor with override key and occupancy
status LED
S2060A1000
Averaging temperature sensor
S2000D1000
Duct mounted temperature sensor
Remote mount temperature sensors use 10K NTC thermistor.
This sensor can be used for:
Each sensor can be configured for various averaging combinations
Optional occupancy led
Optional override key
S3020W1000
Wall mounted sensor
Wiring example of single remote room sensor:
Dip switch
setting for:
1 sensor
S2-1 = ON
S2-2 = ON
S3020W1000
Remote wiring 1 sensor
S2=On,
S3=On
VT7200 Series
BO 5
BI 2
RS
Scom
Scom
RS
Scom
RS
C
DI
Aux
Scom
RS
Scom
RS
OR
S3010W1000
Remote wiring 1 sensor
S2=On,
S3=On
24 Vac
Com
12
ON
Dip switch
setting for:
1 sensor
S2-1 = ON
S2-2 = ON
Analog Valve
Heating and/or Cooling
Optional Water
Supply Sensor
Room Temperature
Control Thermostat
Supply water
temperature sensor
0 to 10
VDC
UI3 COS
0 V~ Com
24 V~ Hot
AO1

13 | PIR Ready VT7200 Series-Installation Guide
Wiring examples of 2 remote room sensors for averaging applications:
Wiring examples of 3 remote room sensors for averaging applications:
Temperature vs. resistance chart for 10 Kohm NTC thermistor (R25°C =
10K±3%, B25/85°C = 3975K±1.5%)
ºC
ºF
Kohm
ºC
ºF
Kohm
ºC
ºF
Kohm
ºC
ºF
Kohm
ºC
ºF
Kohm
-40
-40
324.3197
-20
-4
94.5149
0
32
32.1910
20
68
12.4601
40
104
5.3467
-35
-31
234.4009
-15
5
71.2430
5
41
25.1119
25
77
10.0000
45
113
4.3881
-30
-22
171.3474
-10
14
54.1988
10
50
19.7390
30
86
8.0694
50
122
3.6202
-25
-13
126.6109
-5
23
41.5956
15
59
15.6286
35
95
6.5499
55
131
3.0016
CONFIGURING AND STATUS DISPLAY INSTRUCTIONS
Status display
The Terminal Equipment Controller features a two-line, eight-character display. There is a
low level backlight level that is always active and can only be seen at night.
When left unattended, the Terminal Equipment Controller has an auto scrolling display
that shows the actual status of the system. There is an option in the configuration menu to
lockout the scrolling display and to only present the room temperature and conditional
outdoor temperature to the user. With this option enabled, no local status is given of mode,
occupancy and relative humidity.
Each item is scrolled one by one with the back lighting in low level mode. Pressing any
key will cause the back light to come on to high level. When left unattended for 10
Notes for averaging applications:
S3010W1000 and S3020W1000 can
be mixed matched.
S3010W1000 and S3020W1000 are
to be wired in parallel.
Respect the dip switch setting in
each remote sensor.
Dip switch
setting for:
2 sensors
S2-1 = OFF
S2-2 = ON
Dip switch
setting for:
3 sensors
S2-1 = OFF
S2-2 = OFF
1 x S3010W1000 and 1 x
S3020W1000
Remote wiring 2 sensors
S1=On,
S2=Off
Scom
RS
Scom
RS
VT7200 Series
BO 5
BI 2
RS
Scom
24 Vac
Com
Scom
RS
Scom
RS
C
DI
Aux
2 x
S3020W1000
Remote wiring 2 sensors
S2=On,
S3=Off
Scom
RS
Scom
RS
C
DI
Aux
VT7200 Series
BO 5
BI 2
RS
Scom
24 Vac
Com
Scom
RS
Scom
RS
C
DI
Aux
2 x S3010W1000
Remote wiring 2 sensors
S2=On,
S3=Off
Scom
RS
Scom
RS
VT7200 Series
RS
Scom
Scom
RS
Scom
RS
2x S3010W1000 and 1 x
S3020W1000
Remote wiring 3 sensors
S2=Off,
S3=Off
Scom
RS
Scom
RS
Scom
RS
Scom
RS
VT7200 Series
BO 5
BI 2
RS
Scom
24 Vac
Com
Scom
RS
Scom
RS
C
DI
Aux
3x S3010W1000
Remote wiring 3 sensors
S2=Off,
S3=Off
Scom
RS
Scom
RS
Scom
RS
Scom
RS
VT7200 Series
RS
Scom
Scom
RS
Scom
RS
12
ON
Dip switch
setting for:
2 sensors
S2-1 = OFF
S2-2 = ON
12
ON
Dip switch
setting for:
3 sensors
S2-1 = OFF
S2-2 = OFF

14 | PIR Ready VT7200 Series-Installation Guide
seconds after changes are made, the display will resume automatic status display
scrolling.
To turn on the back light to high level, press any key on the front panel. The back lit
display will return to low level when the Terminal Equipment Controller is left unattended
for 45 seconds
Sequence of auto-scroll status display:
ROOM &
HUMIDITY
SYSTEM MODE
SCHEDULE
STATUS
OUTDOOR
TEMPERATURE
ALARMS
x.x °C or °F
XX % RH
Sys mode
Occupied
Outdoor
Service
Auto
x.x °C or°F
Filter
Sys mode
Cool
Stand-By
Window
Sys mode
heat
Unoccup
Outdoor air temperature
Display is only enabled when outdoor air temperature network variable is received.
Occupancy Status
Occupied, Stand-By, Unoccupied and Override status are displayed on the scrolling
display.
Alarms
If alarms are detected, they will automatically be displayed at the end of the status
display scroll.
During an alarm message display, the back lit screen will light up at the same time as
the message and shut off during the rest of the status display.
Two alarms maximum can appear at any given time. The priority for the alarms is as
follows:
Two status LED’s on the Terminal Equipment Control cover are used to indicate a call for
heat or a call for cooling.
Service
Indicates that there is a service alarm as per one of the configured binary
inputs ( BI2 )
Filter
Indicates that the filters are dirty as per one of the configured binary
inputs ( BI2 )
Window
Indicates that the outside window or door is opened and that the Terminal
Equipment Controller has cancelled any cooling or heating action ( BI1 )

15 | PIR Ready VT7200 Series-Installation Guide
Zoning Models
When heating & reheat is ON, the HEAT LED will illuminate
When cooling is ON, the COOL LED will illuminate
USER INTERFACE
Unoccupied mode override
An Override can be made during an unoccupied period. If the Override option is enabled
in the lockout configuration pressing the Override button will resume occupied setpoints
for a time specified by parameter ToccTime
Local keypad interface
Any setpoint change can be permanent or temporary based on configuration
parameter (Setpoint Type)
Any setpoint written through the network, will be permanent and cancel any
active temporary setpoints
Lockouts of access to certain functions is made with configuration parameter
(lockout)
An Override can be made during an unoccupied period. If the Override
option is enabled in the lockout configuration pressing the override key
will resume occupied setpoints for a time specified by parameter
ToccTime
In cooling mode only the cooling setpoint is displayed,
In heating mode only the heating setpoint is displayed
In auto mode, (See below)
In cooling mode only the cooling setpoint is displayed,
In heating mode only the heating setpoint is displayed
In auto mode, (See below)

16 | PIR Ready VT7200 Series-Installation Guide
Occupied setpoints adjustments
Unoccupied and stand-by setpoints adjustments
Setting of the stand-by and unoccupied setpoints is done through the network or through
configuration setup only.
Mode button menu sequence
Modes presented to the user are dependent on the sequence of operation selected.
Default mode is shown in bold when sequence of operation parameter is changed.
System mode function
PLEASE NOTE THAT: Default system mode of operation is dependent on sequence of
operation selected
Default mode is in bold when sequence of operation parameter is changed
The available mode can only be changed through the network since there is no local
mode access
SEQUENCE SELECTED
MODE MENU
0 = Cooling Only
Off - Cool
1 = Heating Only
Off - Heat
2 = Cooling With Electric Reheat
Off –Auto –Heat –Cool
3 = Heating With Electric Reheat
Off - Heat
4 = Cooling and Heating ( 2 modulating outputs )
Off –Auto –Heat –Cool
5 = Cooling / Heating ( 2 modulating outputs) with
reheat
Off –Auto –Heat –Cool
INSTALLER CONFIGURATION PARAMETER MENU
Configuration can be done through the network or locally at the Terminal Equipment
Controller.
To enter configuration, press and hold the middle button (°C/°F or Override) for
8 seconds.
If a password lockout is active, “Password” is prompted. Enter password value
using the “up” and “down” arrows and press the middle button again to gain
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE
Setpoint presented to user is the setpoint from
the last action taken by the Terminal
Equipment Controller or the one currently in
use.
Both heating and cooling setpoints are
changed simultaneously while respecting the
minimum configured deadband
Cool XX.X
°F or °C
Heat
XX.X
°F or °C
No access
to setpoint
Cool XX.X °F or °C and Heat XX.X °F or °C
Both heating & cooling setpoints change
simultaneously

17 | PIR Ready VT7200 Series-Installation Guide
access to all configuration properties of the Terminal Equipment Controller.
Entering a wrong password will prevent local access to the configuration menu.
Press the same middle button repetitively to scroll between all the available
parameters.
Use the up and down key to change the parameter to the desired value.
To acknowledge and save the new value, press the middle button again.
The next parameter will now be displayed.
Configuration interface
CONFIGURATION
PARAMETERS
DEFAULT VALUE
SIGNIFICANCE AND ADJUSTMENTS
PswrdSet
Configuration parameters
menu access password
Default value = 0
Range is: 0 to 1000
This parameter sets a password access to prevent
unauthorized access to the configuration menu
parameters. A default value of “0” will not prompt a
password or lock the access to the configuration
menu.
Range is: 0 to 1000
Com Addr
Terminal Equipment
Terminal Equipment Controller
networking address
Default value = 254
Range is: 0 to 254
Conditional parameter to BACnet™ MS-TP models
VT7200X5x00B
Conditional parameter to Wireless models
VT7200X5x00W
For BACnet™ MS-TP models, the valid range is
from 1 to 127. Default value of 254 disables
BACnet™ communication for the Terminal
Equipment Controller.
For wireless models, the valid range is 0 to 254
with a maximum of 30 Terminal Equipment
Controller per VWG
Pressing repetitively will individually scroll all the available parameters
Adjust / rotate parameter value down
Adjust / rotate parameter value up

18 | PIR Ready VT7200 Series-Installation Guide
PAN ID
Personal Area Network
Identification
Default value = 0
Range is: 0 to 500
Conditional parameter to Wireless models
VT7200X5x00W
This parameter will only appear when a wireless
network adapter is present. If the Terminal Equipment
Controller is installed as a stand-alone (Network
Ready) unit or with a BACnet™ or Echelon™ adapter,
this parameter will not be used or displayed.
This parameter (Personal Area Network Identification)
is used to link specific Terminal Equipment
Controllers to a single specific Viconics wireless
gateway ( VWG ). For every Terminal Equipment
Controller reporting to a gateway ( maximum of 30
Terminal Equipment Controllers per gateway ), be
sure you set the SAME PAN ID value both on the
gateway and the Terminal Equipment Controller(s).
The default value of 0 is NOT a valid PAN ID.
The valid range of available PAN ID is from 1 to 500.
Range 1 to 250 for centralized networked applications
using a VWG or a Jace with the wireless stat driver
Range 251 to 500 is for stand-alone (Network Ready)
applications where no VWG or Jace with the wireless
stat driver is used.
Channel
Channel selection
Default value = 10
Range is: 10 to 26
Conditional parameter to Wireless models
VT7200X5x00W
This parameter will only appear when a wireless
network adapter is present. If the Terminal Equipment
Controller is installed as a stand-alone (Network
Ready) unit or with a BACnet™ or Echelon™ adapter,
this parameter will not be used or displayed.
This parameter (Channel) is used to link specific
Terminal Equipment Controllers to specific Viconics
wireless gateway(s) (VWG). For every Terminal
Equipment Controller reporting to a gateway
(maximum of 30 Terminal Equipment Controllers per
gateway ), be sure you set the SAME channel value
both on the gateway and the Terminal Equipment
Controller(s).
Viconics recommends using only the usage of
channels 15 and 25 only.
The default value of 10 is NOT a valid channel. The
valid range of available channel is from 11 to 26

19 | PIR Ready VT7200 Series-Installation Guide
Get From
Terminal Equipment
Controller Get From
another device
configuration utility
Default value = 0
Range is: 0 to 254
Conditional parameter to Wireless models
(VT7200X5x00W)
Entering a MAC address enables an automatic routine that
automatically fetches all the required configuration properties
of the current device from another already configured device
and copies the same required configured property values.
If a value other than the default value of 255 is entered, user
will then be prompted to exit the Configuration Menu thus
leaving all other parameter configuration to be copied from the
referenced Terminal Equipment Controller MAC address.
Ex.: If you are currently configuring MAC12 and the settings
matches exactly the settings of ZN MAC5, then enter 5 as the
current parameter value.
If the process is successful and all required configuration
properties have been copied, the value will revert back to
255
If the process is NOT successful and all required
configuration properties have NOT been copied ( either
the reference device is NOT the same model number or is
offline or does not exists ) the value will revert back to 254
to indicate the failure of the process
Leaving the Get From parameter to 255 means that every
configuration parameters will be set manually.

20 | PIR Ready VT7200 Series-Installation Guide
BI 1
Binary input no.1
configuration
Default value = None
(None): No function will be associated with the input. Input can
be used for remote network monitoring.
(Rem NSB): remote NSB timer clock input. The scheduling will
now be set as per the binary input. It provides low cost setback
operation via a dry contact
Contact opened = Occupied
Contact closed = Unoccupied
(Motion NO) or (Motion NC): Advanced PIR occupancy
functions using a Normally Open (NO) or Normally Closed
(NC) remote PIR motion sensor. Occupancy mode is now set
as per applied PIR function and configuration. Application
information and examples are available in document: APP-
PIR-Guide-Exx. This document will provide the installers and
system designers with detailed examples on applications,
parameter configuration information, sequence of operation,
troubleshooting and diagnostic help required for the proper
usage of the PIR accessory covers
(Window) EMS: Forces the system to disable any current
heating or cooling action by the Terminal Equipment
Controller. The mode stays the same and the current setpoints
are the same Occupied setpoints. Only the outputs are
disabled. There is a Door/Window alarm displayed on the
Terminal Equipment Controller to indicate to the local tenant
that the door/window needs to be closed for cooling or heating
to resume.
* These settings will disable the local override function on the
Terminal Equipment Controller.
BI 2
Binary input no.2
configuration
Default value = None
(None): No function will be associated with the input
(Door Dry) Door contact & Motion detector: This configuration
is only functional if binary input #1 is set to Motion NO or
Motion NC or a PIR accessory cover is used.
With this sequence enabled, the occupancy is now dictated
through those 2 inputs. Any motion detected will set the zone
to occupied status. The zone will remain permanently in
occupied mode until the door contact switch opens
momentarily. The Terminal Equipment Controller will then go
in stand-by mode. If more movements are detected, the
occupied mode will resume. While the door is opened, any
movements detected by the remote PIR sensor or the PIR
accessory cover will be ignored. Use a Normally Closed
contact switching device.
Contact opened = Door opened
Contact closed = Door closed
(RemOVR): temporary occupancy remote override contact.
This function disables the central button override function on
the Terminal Equipment Controller. The override function is
now controlled by a manual remote momentarily closed
contact. When configured in this mode, the input operates in
a toggle mode.
It is now possible to toggle between unoccupied & occupied
setpoints for the amount of time set by parameter (TOccTime)
temporary occupancy time.
