Viconics VT8300 Series User manual

VT8300 Series Installation Guide
24 Vac Low Voltage
Commercial and Hotel/Lodging HVAC Fan Coil Applications for 1, 2, 3-speed or ECM motors

• If replacing an existing Room Controller, label wires before removal of Controller.
• Electronic controls are static sensitive devices. Discharge yourself correctly before manipulating and
installing Room Controller.
• A short circuit or wrong wiring may permanently damage Room Controller or equipment.
• All Room Controllers are designed for use as operating controls only and are not safety devices. Tampering
with the devices or unintended application of the devices will result in a void of warranty.
• This device must be installed to provide a separation distance of at least 8in (20cm) from all persons and
must not be located or operating in conjunction with any other antenna or transmitter.
CLEANING THE ROOM CONTROLLER
• Use a soft, pre-moistened lint-free cloth for cleaning.
• Avoid getting moisture in openings.
• Do not spray anything directly on the Room Controller or use compressed air.
• Do not use caustic/corrosive products, ammonia, solvents or any cleaning product containing alcohol or grit.
• Never use tools directly on the touchscreen.
• Never use paint on the Room Controller.
• Do not drop or crush the Room Controller, or allow it to come into contact with liquids.
• Do not use a damaged device (such as one with a cracked screen).
• Performance can be affected if the glass on the screen is broken.
Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s
warranty.
LOCATION
• Do not install on outside wall.
• Do not install behind a door.
• Do not install in areas with direct heat source.
• Do not install near any air discharge grill.
• Do not install in areas exposed to direct sunlight.
• Ensure Room Controller has sufficient natural air circulation.
• Ensure wall surface is flat and clean.
• Ensure external thermal sensor wirings are away from noisy electrical sources.
• Install 1.3 to 1.5 meter (52 to 60 inches) above the floor.

3
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Figure 1 Open the cover
Figure 2 Install the base
Figure 3 Reinstall cover
INSTALLATION
Installation
1. Remove security screw (if any) on bottom of Room Controller cover.
2. Open unit by pulling on bottom side of Room Controller (Figure 1).
3. Read FCC ID and IC label installed in cover before installing any
wireless product.
4. Ensure correct side of base faces up.
5. Pull cables 6in (15cm) out from wall.
6. Align base and mark location of two mounting holes on wall (Figure 2).
7. Install anchors in wall.
8. Insert cable in central hole of base.
9. Insert screws in mounting holes on each side of base.
10. Strip each wire 1/4in (0.6cm) from end.
11. Insert each wire and screw according to wiring chart (see following
pages).
12. Gently push excess wiring back into hole.
13. Gently align cover to top of base and snap in place from bottom
(Figure 3).
14. Install security screw.

4
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Fan Type - 3-Speed
Control Type On/Off Floating Analog
1- BO1 Not used Not used Not used
2- BO2 Fan-L Fan-L Fan-L
3- BO3 Fan-M Fan-M Fan-M
4- BO4 Fan-H Fan-H Fan-H
5- RC / 24 V~ Hot 24 V~ Hot 24 V~ Hot 24 V~ Hot
6- C / 24 V~ Com 24 V~ Com 24 V~ Com 24 V~ Com
7- RH Aux Heat Aux Heat Aux Heat
8- BO8 Aux Heat Aux Heat Aux Heat
9- UO9 Normally Close Cool Valve Close Cool Valve Not used
10- UO10 Normally Close Heat Valve Close Heat Valve Not used
11- UO11 Normally Open Cool Valve Open Cool Valve Analog Heat Valve
12- UO12 Normally Open Heat Valve Open Heat Valve Analog Cool Valve
13- RS485 + RS485 +
14- RS485 - RS485 -
15- RS485 Ref RS485 Ref
16- UI16 UI16 Function
17- UI17 UI17 Function
18- Scom Common
19- UI19 UI19 Function
20- UI20 Remote Room Sensor
21- Scom Common
22- UI22 Remote Supply Sensor
23- UI23 Not used
24- UI24 Not used
TERMINAL IDENTIFICATION AND FUNCTION
Terminal identification for 3-Speed Fan System

5
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Terminal identification for ECM Fan System
Fan Type - ECM
Control Type On/Off Floating Analog
1- BO1 Normally Close Heat Valve Close Heat valve Not used
2- BO2 Not used Not used Not used
3- BO3 Not used Not used Not used
4- BO4 ECM Fan Start ECM Fan Start ECM Fan Start
5- RC / 24 V~ Hot 24 V~ Hot 24 V~ Hot 24 V~ Hot
6- C / 24 V~ Com 24 V~ Com 24 V~ Com 24 V~ Com
7- RH Aux Heat Aux Heat Aux Heat
8- BO8 Aux Heat Aux Heat Aux Heat
9- UO9 Normally Close Cool Valve Close Cool Valve Not used
10- UO10 Analog ECM Fan Analog ECM Fan Analog ECM Fan
11- UO11 Normally Open Cool Valve Open Cool Valve Analog Heat valve
12- UO12 Normally Open Heat Valve Open Heat Valve Analog Cool Valve
13- RS485 + RS485 +
14- RS485 - RS485 -
15- RS485 Ref RS485 Ref
16- UI16 UI16 Function
17- UI17 UI17 Function
18- Scom Common
19- UI19 UI19 Function
20- UI20 Remote Room Sensor
21- Scom Common
22- UI22 Remote Supply Sensor
23- UI23 Not used
24- UI24 Not used

6
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Wiring - Single or Multispeed Motor
Power and Fan
HIGH HIGH
MED
LOW LOW
HIGHHIGH HIGH
MED
LOW LOW
HIGH
3 Speed 2 Speed Single Speed
24 Vac
Transformer
RC (24 Vac)
C (Common)
RH
BO8 - Aux Heat
R
RC (24 Vac)
C (Common)
RH
BO8 - Aux Heat R
BO8 Auxiliary Output Wiring
Dry contact to end device 24 V~ maximum 24 Vac power to relay
Power and Fan
Relay Coil
Wiring ECM Motor
BO4 - Fan H
RC (24 Vac)
C (Common)
UO10 ECM Fan
Transformer
24Vac
0 - 10Vdc signal
24Vac signal to start fan (optional)
4
+
-

7
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Main Outputs Wiring
2 Pipe Applications 4 Pipe Applications
Control type = On-Off
2 Pipe Applications
OR
Heating / Cooling valve
Com
24Vac
UO9
UO11
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
4 Pipe Applications
Heating valve
Cooling valve
OR
OR
UO10 NC
UO12 NO
UO09 NC
UO11 NO
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Floating control
2 Pipe Applications 4 Pipe Applications
Heating / Cooling valve
UO11
UO9
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Heating valve
Cooling valve
UO12
UO10
UO11
UO9
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Analog control
Heating / Cooling valve
UO12
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close
Heating valve
Cooling valve
UO11
UO12
Com
Open
Close
Com
24Vac
0-10Vdc
Com
24 Vac
0-10 Vdc
Com
24 Vac
0-10 Vdc
Com
24Vac
Com
24Vac
Com
Open
Close
Com
Open
Close

Date
Occupancy Status
Indoor Temperature
Indoor Humidity
Outdoor Temperature
System Mode
Short Network
Message
8
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
REMOTE SENSOR ACCESSORIES
Model no. Description
S3010W1031 Wall mounted temperature sensor
S3020W1031 Wall mounted temperature sensor with override button and occupancy status LED
The VT8300 Room Controller is compatible with remote mount temperature sensors using 10K type 2 NTC thermistors.
Note: If one or multiple sensor(s) is/are connected into the RS terminal, the internal temperature sensor is automatically disabled.
Disconnecting the sensor(s) in the RS terminal will re-activate the internal sensor.
Features:
• Each sensor can be configured for various averaging combinations
• Optional occupancy led
• Optional override key
Wiring example of single remote room sensor
Common
UI 20
BO8
24 Vac Com
UI17
VT8300
Series Controller
S3020W1031
Remote wiring 1 sensor
S2-1= On, S2-2=On
S3010W1031
Remote wiring 1 sensor
S2-1= On, S2-2=On
SCom
RS
Aux
C
DI
SCom
RS
OR
Temperature vs. resistance chart for 10 Kohm NTC thermistor (R25°C = 10KΩ±3%, B25/85°C = 3975K±1.5%)
ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm
-40 -40 324.3197 -20 -4 94.5149 032 32.1910 20 68 12.4601 40 104 5.3467
-35 -31 234.4009 -15 571.2430 541 25.1119 25 77 10.0000 45 113 4.3881
-30 -22 171.3474 -10 14 54.1988 10 50 19.7390 30 86 8.0694 50 122 3.6202
-25 -13 126.6109 -5 23 41.5956 15 59 15.6286 35 95 6.5499 55 131 3.0016
Dip switch
setting for:
1 sensor
S2-1 = ON
S2-2 = ON
ON
1 2

Time
System Status
Fan Status
Up Arrow
Increase Temperature Setpoint
Actual Setpoint
Down Arrow
Decrease Temperature
Setpoint
Help
Language Selection
Temperature Units
Fan Mode
Date
Occupancy Status
Indoor Temperature
Indoor Humidity
Outdoor Temperature
System Mode
Short Network
Message
9
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
HOME SCREEN DISPLAY
Hospitality User Interface Shown
Note: User HMI is configurable and allows display functions such as Date, Time,
Humidity, Outdoor Temperature, Setpoint, and others to be enabled or disabled by
setting various parameters.

10
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
Return to
home screen
1/2 Setup
Network
Configuration
Setpoints - Display
Service View
Test Outputs
Language Selection
HOW TO ENTER SET-UP SCREEN
Touch and hold this point
for 3 seconds to enter set-up mode
SET-UP SCREEN DISPLAY
General Note:
Adjustable parameter
Nonadjustable parameter
Note: If a configuration/installer
password is activated to prevent
unauthorised access to the
configuration menu parameters,
a password entry prompt shows
to prevent access to device
configuration components.
Enter BACnet®& ZigBee®network settings
Enter parameter configuration menu
Enter setpoint & display settings
Enter output testing mode
Enter status and service view
For more information on using and
configuring the functions of the HMI,
refer to the VT8300 User Interface
Guide
Enter language selection

11
Viconics Technologies Inc. www.viconics.com [e-mail]
028-0429-05 November 2018
APPENDIX A TERMINAL CORRESPONDENCE
The terminals of a VT8300 are identified differently and have a wider range of possible functions compared to those of any of the
VT7300 series Room Controllers. Nonetheless, there is a direct correspondence of functions between the terminals of the VT7300
series and the VT8300 series. Consult the table below to verify the appropriate terminal when replacing a VT7300 Room
Controller with a VT8300 Room Controller.
VT7300 VT8300
Terminal name Terminal ID Terminal name Terminal ID
Binary Input 1 BI1 Universal Input 16 UI16
Binary Input 2 BI2 Universal Input 17 UI17
Universal Input 3 UI3 Universal Input 19 UI19
Sensor Common Scom Terminal 18 Common COM
Remote Sensor RS Universal Input 20 UI20 - RS
Sensor Common Scom Terminal 21 Common COM
Mix/Supply Sensor MS Universal Input 22 UI22 - SS
APPENDIX B POWER OUTAGE CLOCK RESET
In the event of a power outage, VT8300 Room Controllers retain the correct time as long as the duration of the power outage is
not prolonged. Depending on the duration of the power outage, the Room Controllers internal clock may need to be updated or
reset completely. The following table gives an indication of the expected clock performance after a power outage.
Outage duration Room Controller behaviour
0 - 24 hours Clock functions are normal
24 - 36 hours Clock accuracy not guaranteed, time may need to be adjusted
36 - 72 hours Clock no longer increments and must adjusted when power is
restored
72+ hours Clock functions are fully reset, and must be reinitialized as per a new
installation
