Condensate lifting system
V AH-300
Safety instructions
Please follow these safety instructions closely to prevent accidents
and material losses.
Safety instructions explained
Danger
This symbol warns against the
risk of injury.
!Please note
This symbol warns against the
risk of material losses and envi-
ronmental pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These instructions are exclusively
intended for qualified contractors.
■ Work on electrical equipment may
only be carried out by a qualified
electrician.
Regulations to be observed
■ National installation regulations
■ Statutory regulations for the preven-
tion of accidents
■ Statutory regulations for environmen-
tal protection
■ Codes of practice of the relevant
trade associations
■ Relevant country-specific safety reg-
ulations

2
Working on the system
■ Isolate the system from the power
supply, e.g. by removing the separate
fuse or by means of a mains isolator,
and check that it is no longer live.
■ Safeguard the system against recon-
nection.
■ Wear suitable personal protective
equipment when carrying out any
work.
Danger
Hot surfaces and fluids can lead
to burns or scalding.
■ Before maintenance and serv-
ice work, switch off the appli-
ance and let it cool down.
■ Do not touch hot surfaces on
the appliance, fittings or pipe-
work.
!Please note
Electronic assemblies can be
damaged by electrostatic dis-
charge.
Prior to commencing work,
touch earthed objects such as
heating or water pipes to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil
a safety function can compro-
mise the safe operation of the
system.
Replace faulty components only
with genuine Viessmann spare
parts.
Disposal of packaging
Please dispose of packaging waste in
line with statutory regulations.
Safety instructions (cont.)
5601325

3
Condensate removal pump V AH-300
Suitable for pumping neutralised con-
densate from condensing boilers, con-
densate from gas condensing boilers
with a pH value >3, clear water and
slightly contaminated DHW.
The condensate removal pump is also
suitable for constant operation.
The condensate removal pump is not
suitable for pumping the following liq-
uids:
■ Non-neutralised condensate from oil
condensing boilers
■ Salt water
■ Water containing chlorine
■ Condensate with textile or paper par-
ticles
■ Aggressive liquids/chemicals
■ Corrosive, flammable, explosive and
gas emitting liquids
Spare parts lists
Information about spare parts can be
found at www.viessmann.com/etapp
or in the Viessmann spare part app.
Product information
5601325

4
Dimensions
440
400 150
300
268
50
Siting
Requirements of the installation room
■ Frost protection
■ Protection against chemicals, dyes,
solvents and dust
■ Protection against high radiation tem-
peratures and direct sunlight
■ Sufficiently large, horizontal, level
and load-bearing installation surface
■ Easy accessibility for maintenance
work
■ Available socket 230 V/50 Hz (per-
manent voltage) in the immediate
vicinity. The length of the power cable
is 2 m.
■ Existing sewer connection (min. DN
40). This must allow drainage of min.
18 l/min without obstruction
Note
Choose an installation location that
means the supply and drain hoses are
as short as possible.
Preparing for installation
5601325

5
AB
0°
ANeutralising system BCondensate lifting system
1. Remove the cover from the con-
tainer and take out the small parts
supplied.
2. Fit supply hose connection (either
DN 20 or DN 25) with a gasket and
nuts.
3. Install the condensate lifting system
in the required location.
4. Route the supply hose to the con-
densate lifting system with a fall.
Secure the hose with hose clips.
Note
Never step on the hose. Protect the
hose against mechanical damage.
5. Route the drain hose into the drain-
age system. Secure the hose with
hose clips.
Note
■ Secure the free end of the drain
hose, because water flows out
under pressure
■ If the drain hose is extended
and/or constricted by hose con-
nectors, this leads to a reduction
in the pump rate/delivery head
6. Close the condensate lifting system
cover.
Positioning and connecting
5601325

6
Note
The level switch and overflow alarm
switch must be fully inserted into the
locking ring fitting, so that they rest
against the locking ring fitting.
Positioning and connecting (cont.)
5601325

7
Note
If there is no bottom drain, a suitable
alarm facility must be connected to the
potential-free overflow alarm switch.
Terminal assignment of the electrical
terminal box
PE
M 1A
PE PE PE NN
123456 7 89
1
3
M
1~
BU
BN
GNYE
A
B
L N
APower supply 230 V/50 Hz
BFeed pump 230 V/50 Hz
Colour coding to DIN IEC 60757
BN brown
BU blue
GNYE green/yellow
Terminal assignment of the overflow
alarm switch
Note
If required, connect the overflow alarm
switch with the sockets supplied in the
cap.
1
2
3
Breaking capacity: 250 V/6 A (resistive
load)
Electrical connection: Flat pin sockets
6.3 x 0.8 mm
Electrical connection
5601325

8
Note
During commissioning, instruct the sys-
tem user in the operation of the appli-
ance.
1. Insert the power plug.
2. Fill the system with water.
3. Test the function. Visually check for
leaks.
4. Record commissioning on
page 13.
Inspection and maintenance intervals
■Regular inspection can be carried
out by the user or any authorised,
qualified person. Inspection should
initially be carried out at short inter-
vals, then as required, but at least
every 6 months
■Maintenance work must be carried
out regularly subject to the volume
and contamination of the condensate,
but at least once a year. It must be
carried out by an approved heating
contractor or personnel trained by
this approved heating contractor
Inspection
1. Open the condensate lifting system
cover.
2. Check filter basket for contamina-
tion and clean if required.
3. Check that the hoses are secure.
4. Check that the level switch and
overflow alarm switch are posi-
tioned correctly. Both must be fully
inserted into the locking ring fitting,
so that they rest against the locking
ring fitting.
5. Carry out a visual inspection of all
components for damage and leaks.
6. Close the condensate lifting system
cover again.
Commissioning and adjustment
5601325

9
7. Record inspection on page 13.
Maintenance
01. Disconnect the power plug.
02. Open the condensate lifting system
cover.
03. Flush the feed pump with clean
water to remove any loose sludge.
04. Carry out a visual inspection of the
feed pump and check for damage.
05. Carry out a function check of the
feed pump and check the pump
rate by means of volumetric meas-
uring.
06. In the event of a pump fault or
obstruction of the pump flow, pos-
sibly caused by contamination
inside the pump:
Open pump cover and clean pump.
Then carefully clean the sealing
faces, refit the pump cover cor-
rectly (pressure chamber above
the pressure joint) and secure with
screws.
Note
First screw in the two fixing screws
next to the pressure joint and
tighten, then the ones opposite.
Then screw in and tighten all other
fixing screws.
!Please note
Leaks in the pump cover
lead to reduced output and
may result in damage to the
pump motor.
The cover must be airtight.
The formation of droplets is
permissible.
07. Clean the non-return valve and fil-
ter basket, replace if required.
08. Clean the supply hose, replace if
required.
Inspection (cont.)
5601325

10
09. Check that the level switch and
overflow alarm switch are posi-
tioned correctly. Both must be fully
inserted into the locking ring fitting,
so that they rest against the lock-
ing ring fitting.
10. Carry out a visual inspection of all
components for damage and leaks.
11. Close the condensate lifting sys-
tem cover again.
12. Restart the condensate lifting sys-
tem.
13. Record service on page 13.
Maintenance (cont.)
5601325

11
System characteristics Cause Measure
Container overflowing or fault
message triggered by overflow
alarm switch (if installed)
■ No voltage at power
supply
■ Check power sup-
ply
■ Filter basket contami-
nated
■ Non-return valve con-
taminated
■ Clean component,
replace if required
■ Fuse in the control unit
blown
■ Level switch faulty.
■ Pump faulty
Replace component
■ The switching point of
the level switch or
overflow alarm switch
is too high (air pocket
in pressure tube may
have escaped).
■ Remove switch
briefly to vent the
pressure tube
■ Condensate supply
volume exceeds the
system output
■ Check the pump
rate by means of
volumetric measur-
ing, if required in-
stall a larger or ad-
ditional condensate
lifting system
■ Delivery head at drain
too large
■ Check pump rate or
delivery head
Feed pump starts repeatedly
even though no condensate is
flowing
■ Non-return valve is
contaminated or dam-
aged (causing conden-
sate return)
■ Drain and undo the
drain hose. Remove
non-return valve
with a pair of poin-
ted pliers and clean,
replace if required
!Please note
The feed pump is equipped with an automatically resetting temperature lim-
iter. The feed pump motor is switched off in the event of overheating and
starts again automatically when it has cooled down sufficiently.
The cause for overheating must be remedied. Further operation without
remedying the cause leads to the destruction of the temperature limiter and
pump motor damage.
Troubleshooting
5601325

12
The condensate flows into the collector
tank of the condensate lifting system
and is pumped from there to the drain-
age system by the level-controlled
pump.
The pump starts when the condensate
level is approx. 80 mm, and stops again
when it is approx. 55 mm. The integral
filter basket protects the pump against
coarser contamination. The non-return
valve prevents return flow into the col-
lector tank while the pump is off.
A second level switch (overflow alarm
switch) with potential-free changeover
contact can be used for an external
fault message or to switch off the heat
generator. It switches when the con-
densate level is approx. 150 mm, and is
reset when the level is approx. 135
mm. The alarm delay available as an
accessory for connection to the over-
flow alarm switch enables the heat gen-
erator to be switched off in parallel to a
fault message, or after a time delay. A
delayed heat generator shutdown can
only be carried out if condensate flow-
ing back cannot cause any damage or
if there is a bottom drain.
Warranty
For wearing parts (parts subject to a
certain level of wear or ageing), the
manufacturer provides a limited 6-
month warranty for the condensate lift-
ing system. The same applies to electri-
cal components.
Wearing parts are:
■ Immersion centrifugal pump with
hose clip
■ Non-return valve
■ Filter basket
Function description
5601325

13
Commissioning Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Report
5601325

14
Condensate removal pump V AH-300
Power supply 230 V/50 Hz
Power consumption VA 70
IP rating/protection class IP 54/I
Max. delivery head m 5.5
Pump rate
■ With 4 m delivery head l/h 300
■ Max. l/h 660
Condensate temperature ºC 5 - 60
Ambient temperature ºC 5 - 40
Weight
In the delivered condition kg 8
Curve of the feed pump with a hose length of 6 m
4
0
1
2
3
0 100 200 300 400 500
5
6
600 700
Flow rate [l/h]
Delivery head [m]
Specification
5601325

15
All components must be disposed of
correctly.
Dispose of the components at
suitable collection points. Do
not dispose of the components
in domestic waste.
Note
Information about collection points for
this product can be obtained from the
local council, the public waste disposal
authority, an authorised body for the
disposal of electrical and electronic
products or the rubbish collection serv-
ice.
Final decommissioning and disposal
5601325

16
Declaration of Conformity
5601325

17
5601325

18
5601325

19
5601325

20
Viessmann Limited
Hortonwood 30, Telford
Shropshire, TF1 7YP, GB
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Viessmann Werke GmbH & Co. KG
D-35107 Allendorf
Telephone: [phone]
Fax: [phone]
www.viessmann.com
5601325 Subject to technical modifications.
