Viewpro Z25K User manual

25x 4K UHD Video Gimbal Camera
Images are for reference only, please subject to the actual product.
User manual
Z25K
Compatible with DJI M200/M210/M210RTK and V2

Contents
Z25K High-precision Camera
Camera introduction.......................................................................................1
Camera description..........................................................................................1
Mechanics@Electronic characteristics........................................................2
Application description..................................................................................2
1. Menu instruction................................................................................................................2
2. Payload Settings................................................................................................................3
2.1 Gimbal Speed.............................................................................................................3
2.2 OSD Display Options..................................................................................................4
2.3 OSD Type Options......................................................................................................4
2.4 Gimbal Angles Setting.................................................................................................5
3. Main functions instruction...............................................................................................5
3.1 Camera Settings.............................................................................................................5
3.1.1 Camera Options....................................................................................................5
3.1.2 Video Record Modes.............................................................................................7
3.2 Video storage..................................................................................................................8
3.3 OIS(Optical Image Stabilization) function.......................................................................9
Specification..................................................................................................10

Gimbal Introduction
Camera Introduction
Camera Description
!Please make sure that the motor is not stopped by any object during
the rotation, if the gimbal is blocked during rotation, please remove
the obstruction immediately.
[1] DJI Skyport
[2] Pan motor
[4] Tilt motor
[3] Roll motor
[5] 4K camera
1
Z25K is a high-precision professional 3-axis gimbal which features high stability,
small size, light weight and low power consumption. The 3-axis gimbal based on FOC
motor control technology, adopts high-precision encoder in each motor. With
advanced OIS function, Z25K can compensate the subtle movements of the UAV to
keep the camera stable even under 25 times optical zoom. It can be used on DJI
drones M200 / M210 / M210RTK and V2, and controlled directly by APP DJI PILOT.
Powered by Panasonic 1/2.3inch CMOS 25.9MP 4K camera, Z25K is engineered for
inspection especially power and utility industry. The speed of Z25K gimbal is
adjustable, LOW speed mode for tele end, the control will be more accurate; Fast
mode for wide end, which makes the gimbal control sensitive and quick. The one-key
to center function will allow the gimbal return to initial position automatically and
rapidly. You can input a degree in APP Payload Setting and get the gimbal attitude
angles exactly
[6] SD card

Mechanics@Electronic Chara cteristics
Input voltage
Dynamic current
Size
3S~ 4S
450mA@12V
162*95*153mm
Idle current
Working
environment temp
Weight
330mA@12V
－40℃~ ＋60℃
550g
Pitch/Tilt: Pitch angle range of action : ±90
Roll: Roll angle range of action : ±85°
Yaw/Pan: Yaw angle range of action : ±360°*N
Vibration angle: Pitch/Roll: ±0.02°, Yaw: ±0.03°
Application Description
After mounting Z25K on DJI drone and connecting with remote control, you can operate the gimbal
camera via APP DJI Pilot. The gimbal attitude angles (tilt and pan) can be controlled by DJI remote
control. Control method please refer to DJI related user manual.
DJI Pilot
1. Menu instruction
Payload
Settings
Camera
Settings
Return to
1.0x zoom
Picture and
record switch
Auto / Manual focus
Zoom times
Shutter button
2
Photo or video status
Time OSD
Definition
Gimbal and camrea
real time data

2. Payload Settings
3
2.1 Gimbal Speed:
Gimbal speed is adjustable. When it’s 0%, the speed will adjust automatically, quick speed for
wide end, slow speed for tele end. When you adjust it to 1% manually, the speed will be low even
in wide end. The high the percentage is, the quicker the speed will be.

4
2.2 Camera Options:
Youcanchoose Definition and Time OSD off to get a clear screen.
Options Picture 16:9 and 4:3 will definit the recorded picture ratio.
You can choose Definition and Time OSD off to get a clear screen.

2.4 OIS (Optical Image Stabilization).
5
2.3 Gimbal Angles Setting:
Input the pitch / yaw angle degrees to get exact attitude angles directly.
Turn on the OIS function, it could effectively keep the image stable during flying.

3. Video Storage
6
3.1 SD card: resolution 3840*2160 pure video without OSD. Support up to 128G.
Note: SD card format requirement
＜2G Format: FAT
2～32G Format: SDHC FAT32
32～128G Format: SDXC EXFAT
Not support NTFS
3.2 Camera Options: Picture modes
Picture 16:9: total pixel is 25.9MP
Picture 4:3: total pixel is 20.4MP

10
12V
3S ~ 4S
450mA @ 12V
330mA @ 12V
≤5.4W
-25 ~ +60
Skyport
SD card (Up to 128G, class 10, FAT32 or ex FAT format)
DJI Pilot
±90°
±85°
±360°*N
Pitch/Roll: ±0.02°, Yaw ±0.03°
√
F1.8~F3.6(f=4.08~81.6mm)
Optical zoom:20x, iA zoom:25x(4k)
5 axis Optical Image Stabilization
MPEG-4
4k:3840*2160/30p
1/30 ~ 1/8000
JPEG
1/2 ~ 1/2000
65dB
1.5M
Horizontal: 53.2°(Wide end) ~ 5.65°(Tele end)
Vertical: 39.8°(wide end) ~ 4.2°(tele end)
Focus: 66.6°(wide end) ~ 7.2°(tele end
Hardware Parameter
Gimbal Spec
Camera Spec
Working voltage
Input voltage
Dynamic current
Idle current
Power consumption
Output
Local-storage
Control method
Pitch/Tilt
Roll
Yaw/Pan
Vibration angle
One-key to center
Imager Sensor Panasonic 1/2.3inch CMOS
Lens
Zoom
Optical Image Stabilization (OIS)
Record format
Record pixel
Record shutter speed(Manual)
Picture format
Picture pixel 20.4M
Picture shutter speed(Manual)
Dynamic range
Min object distance
Viewing angle
Sync system
Local video
FHD output
S/N ratio
Min illumination
Backlight compensation
)
Progressive scanning
1080P 30fps local TF card
1080P/720/480P 60fps HDMI1.4
38dB
Color 0[email protected]
Backlight compensation/strong light inhibition
Working environment temp. ℃ ℃
：

Gain
White balance
Control system
Communication protocol
Focus
Focus speed
Lens initialization
User presetting bit
Image rotation
Facial recognition
Auto
Auto/Manual
UART/IR/PWM
PELCO-D, Hitachi protocol or VISCA
Auto/Manual/One-time automatic focus
2s
Built-in
20 sets
180°, Horizontal/Vertical mirror image
√
550g
162*95*153mm
1pc gimbal camera device / Hight quality plastic box with foam
cushion
Packing Information
N.W.
Product meas.
Accessories
