ViewSonic VNB102 User manual

- User Guide
- Guía del usuario
-Οδηγόςχρηστών
- 使用手冊 (簡中)
VNB102
NetBook
ViewSonic®
Model No. : VS12867

ViewSonic VNB102 i
Compliance Information
For U.S.A.
This device complies with part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved by the
party responsible for compliance could void your authority to operate the equipment.
For Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as unsorted
municipal waste, but use the return and collection systems according to local
law.
If the batteries, accumulators and button cells included with this equipment, display
the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy
metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or
more than 0.004% Lead.
•
•
•
•

ViewSonic VNB102 ii
FCC Radiation Exposure Statement
This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
End-users must be provided with specic operating instructions for satisfying RF exposure
compliance.
The highest reported SAR level is: Body: 0.019 W/kg.
Industry Canada Notice
This wireless module device complies with Canadian RSS-210.To prevent radio
interference to the licensed service, this device is intended to be operated indoors and
away from windows to provide maximum shielding. Equipment (or its transmitting antenna)
that is installed outdoors is subject to licensing. The installer of this radio equipment must
ensure that the antenna is located or pointed such that it does not emit RF eld in excess
of Health Canada limits for the general population; consult Safety Code 6, obtainable from
Health Canada’s web site www.hc-sc.gc.ca/rpb.
R&TTE Compliance Statement
This wireless module device complies with the Essential Requirements of the R&TTE
Directive of the European Union (1999/5/EC). This equipment meets the following
conformance standards:
ETSI EN 300 328V1.7.1
EN 301 489-01 V1.6.1
EN 301 489-17 V1.2.1
EN 62311
Notied Countries: Germany, UK, Netherlands, Belgium, Sweden, Denmark, Finland,
France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg, Estonia, Latvia,
Lithuania, Czech Republic, Slovakia, Slovenia, Hungary, Poland and Malta.
ENERGY STAR®information
The computer complies with the ENERGY STAR® requirements of less than 15 min of user
inactivity for the display and less than 30 min of inactivity for the computer.
Move the mouse or click any button on the keyboard to wake the computer from Sleep
mode.

ViewSonic VNB102 iii
Important Safety Instructions
1. DO NOT press or touch the LCD Screen. DO NOT place the Notebook PC with small
items, they may scratch LCD Screen or enter the Notebook PC.
2. DO NOT expose the Notebook PC to dirty or dusty environment. Keep the environment
clean and dry.
3. DO NOT place the Notebook PC on uneven or unstable work surface.
4. DO NOT place or drop objects on the top of the Notebook PC. DO NOT shove any
foreign objects into the Notebook PC. DO NOT cover the LCD Screen strongly.
5. DO NOT expose the Notebook PC to strong magnetic or electrical elds; DO NOT
place the oppy disk near or on the Notebook PC, that may loss the data of the oppy
disk.
6. DO NOT leave the Notebook PC facing the sun as it can damage the LCD Screen,
especially in the car.
7. SAFE TEMP: This Notebook PC should only be used in environments with ambient
temperatures between 5°C (41°F) and 35°C(95°F).
8. DO NOT expose the Notebook PC to or use near liquids, rain, or moisture.
9. Caution: risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
10. DO NOT throw the Notebook PC in municipal waste. Check local regulations for
disposal of electronic products. Please recycle the Battery Pack, and check with your
Local Authority or retailer for recycling advice.
11. The Notebook PC and the Adapter may occur some heat during operating or charging.
DO NOT leave the Notebook PC on your lap or any part of the body in order to prevent
discomfort or injury from heat exposure.
12. INPUT RATING: Refer to the rating label on the Notebook PC and be sure that the
Power Adapter complies with the rating. Only use attachments or accessories specied
by the manufacturer.
13. Checking the connections between the main unit and attachments before turning on
the Notebook PC.
14. DO NOT use the Notebook PC during eating food avoid dirtying the Notebook PC.
15. DO NOT insert anything into the Notebook PC that may result in short circuit or
damage the circuit.
16. Powering off the Notebook PC, if you want install or remove some external devices,
which are not support hot-plug.

ViewSonic VNB102 iv
17. Disconnect the Notebook PC from the electrical outlet and remove any installed
batteries before cleaning. And Keep it away from children.
18. DO NOT disassemble the Notebook PC, only a certied service technician
should perform repairs on your computer. Otherwise, problem may result and the
manufacturer should not hold responsibility for the damage.
19. Only use Battery Packs approved by the manufacturer or else damage may occur.
20. The Notebook PC has some little metal ake to disperse heat. DO NOT place the
Notebook PC on soft objects (e.g.: bed, sofa, your lap), or else the Notebook PC may
become hot and halt the system operating.

ViewSonic VNB102 v
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/
EC of the European Parliament and the Council on restriction of the use of certain
hazardous substances in electrical and electronic equipment (RoHS Directive) and is
deemed to comply with the maximum concentration values issued by the European
Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum Concentration
Actual Concentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers (PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the Annex of the
RoHS Directives as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps
not specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and
electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight
or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium
containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead
by weight.

ViewSonic VNB102 vi
Copyright Information
Copyright © ViewSonic®Corporation, 2009. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows®logo are registered trademarks of
Microsoft®Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter®are registered
trademarks of ViewSonic®Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency
(EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product
meets the ENERGY STAR® guidelines for energy efciency.
Disclaimer: ViewSonic®Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic®Corporation reserves the
right to change product specications without notice. Information in this document may
change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic®Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The
ViewSonic®Wizard CD-ROM also provides an opportunity for you to print the registration
form, which you may mail or fax to ViewSonic®.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VNB102
ViewSonic 10" NetBook
VS12867
VNB102-1_UG_ENG Rev. 1B 10-27-09
Product disposal at end of product life
ViewSonic®is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. For the recycling information, please refer to
our website:
1. USA: www.viewsonic.com/company/green/recycle-program/
2. Europe: www.viewsoniceurope.com/uk/support/recycling-information/
3. Taiwan: recycle.epa.gov.tw

ViewSonic VNB102 vii
Directions
Meanings of icons:
Forbidding: forbid improper operations to avoid damaging the Notebook PC.
Caution: cautions for operators to avoid potential damages. Please note and
remember.
Importance: important information, common notes, denitions, general knowledge
and references, etc.

Content
External Appearance..........................................................................................................1
1-1 Top View......................................................................................................................1
1-2 Rear View....................................................................................................................2
1-3 Bottom View ................................................................................................................3
1-4 Left View......................................................................................................................4
1-5 Right View ...................................................................................................................4
Setting Up Your Computer.................................................................................................5
2-1 Installing/Removing the Battery...................................................................................5
2-2 Connecting the Power Supply.....................................................................................7
2-3 Startup.........................................................................................................................7
2-4 Emergency Shutdown .................................................................................................8
Using the Touchpad ...........................................................................................................9
3-1 Introduction to the Touchpad .......................................................................................9
3-2 Single Tap/ Single Click...............................................................................................9
3-3 Double Tap/ Double Click ............................................................................................9
3-4 Drag.............................................................................................................................9
Special Function Keys .................................................................................................... 10
Viewsonic System Recovery DVD/HDD Partition..........................................................11
4-1 Running the Recovery DVD ......................................................................................11
4-2 System Recovery HDD Partition .............................................................................. 12
Netbook FAQ.................................................................................................................... 13
Specications .................................................................................................................. 15
Customer Support........................................................................................................... 16
Limited Warranty ............................................................................................................. 17

ViewSonic VNB102 1
External Appearance
The Netbook is a compact and easy to use portable computer. It is equipped with an intuitive
graphical interface and full wireless connectivity so you can use the Netbook and access
the Internet at any time and in any place. Provided below is an introduction to each product
function.
1-1 Top View
9
8
7
6
5
4
3
2
1
Your Netbook keyboard may vary depending on the country/region of purchase.
CAUTION
!

ViewSonic VNB102 2
No. Purpose Description
1 CCD Camera Records videos or take photos.
2 Color LCD Display Netbook's screen.
3 Power Button Button for turning the computer's power on/off.
4 Keyboard Input device used for controlling the Netbook's various functions.
5 Touchpad Works the same way as a mouse and is used for controlling the computer
cursor.
6 Right Touchpad Button Works the same way as the right mouse button.
7 Left Touchpad Button Works the same way as the left mouse button.
8 Computer Status Light From left to right:
Power icon
Num Lock icon
Caps Lock icon
Wireless Network icon
9 Microphone Netbook's built-in microphone.
1-2 Rear View
No. Purpose Description
1 Battery Replaceable battery that serves as Netbook's power supply.
1

ViewSonic VNB102 3
1-3 Bottom View
No. Purpose Description
1 Battery Lock Slide inwards to lock the battery in place. Slide outwards to unlock battery.
2 Battery Replaceable battery. Serves as the Netbook's power supply.
3 Battery Latch Push outwards to release battery for removal.
4 Hard Disk Cover The Hard Disk Cover protects the internal hardware. Open to exchange
device.
5 Memory Cover The cover is to protect the memory from damage.
1
4
3
5
2
When the computer is running or charging, heat is produced inside the Netbook and transferred
to the back of the chassis by the heat dissipation system for cooling. The transformer may also
produce a lot of heat during normal use as well. The Netbook and its transformer should therefore
not be placed in the lap or on any other body part for prolonged periods during use. Also avoid
placing the Netbook on a soft surface (e.g. sofa) as it might block the heat vents and interfere
with cooling.
CAUTION
!

ViewSonic VNB102 4
1-4 Left View
654321
No. Purpose Description
1 Vent Netbook's cooling vent
2 Power Port Connects to the external power supply transformer
3 External Display Port Connects to an externally display
4 USB Port Connects to USB 2.0 device
5 Microphone Connects to external microphone
6 Headphone Connects to external headphone
1-5 Right View
No. Purpose Description
1 Multi-Function Card
Reader
Supports MMC/SD/MS memory cards
2 USB Port Connects to USB 2.0 device
3 USB Port Connects to USB 2.0 device
4 Network Port Standard RJ-45 network port
5 Anti-Theft Lock Slot Connects to anti-theft lock
1 5432

ViewSonic VNB102 5
Setting Up Your Computer
2-1 Installing/Removing the Battery
Please install the battery before using the Netbook and connect the external power supply
transformer. The Netbook can be powered by the battery or the external transformer. If you are
in an ofce environment, we recommend using the external transformer as much as possible.
If you are away from the ofce and no power socket is available, use the battery instead.
Installing the Battery
Step 1: Turn the Netbook over and have the back of the battery facing upwards as well. Now
push the end of the battery with the metal contacts into the Netbook's battery slot
evenly and slowly along the battery rails.
Step 2: Push the end of the Netbook battery with the metal contacts completely into the
battery slot. When there is a "click", this means the battery latch has engaged and
the battery is now secured to the Netbook.
Step 3: Push the Battery Lock inwards lightly to lock the battery in place.
1

ViewSonic VNB102 6
3
2
Removing the Battery
Step 1: Shut down the Netbook. Disconnect all cables and devices.
Step 2: Turn the Netbook over and unlock the battery by pushing the Battery Lock
outwards.
Step 3: Push the Battery Latch outwards and hold it in place with your nger. Now use the
other hand to pull the battery out.
3
2
1
Do not remove the battery while the Netbook is still running. This may damage the data on the
hard disk.
CAUTION
!

ViewSonic VNB102 7
2-2 Connecting the Power Supply
Step 1: Insert the round end of the power supply transformer into the charging port on the
left side of the Netbook.
Step 2: Insert the other end of the power supply transformer into a power socket.
2-3 Startup
Step 1: Open the screen of your Netbook.
The power connector for the power socket may vary depending on the local national standards.
The appropriate connector will be bundled with your Netbook. Please always use the adapter when
connecting the power supply. The connector shown here may not match the type included in the
box and is provided for reference purposes only.
CAUTION
!

ViewSonic VNB102 8
Step 2: Turn on the machine by pressing the Power Button.
Power Button
2-4 Emergency Shutdown
When the Netbook cannot be shut down through normal means, please press and hold the
Power Button until the Netbook powers off.

ViewSonic VNB102 9
Using the Touchpad
3-1 Introduction to the Touchpad
The touchpad is like a computer mouse. It senses the pressure from the user's nger and
generates a voltage that is used to control the cursor's movements and issue commands.
The touchpad senses nger movements. Simply move one nger across the touchpad to
control the movement of the cursor on screen. Below the touchpad is two buttons. The left
button is like the left mouse button and is used for selecting options or launching programs
on screen. The right button works the same way as the right mouse button.
Touchpad
Left Button Right Button
3-2 Single Tap/ Single Click
To select a window function or press a button icon, move your nger across the touchpad to
move the cursor to the window or button to select. Now tap the touchpad with your nger to
perform the action. This action is equivalent to pressing the left mouse button. You can also
press the left touchpad button for the same effect.
3-3 Double Tap/ Double Click
To open a le or document, move your nger across the touchpad to move the cursor to the
le you wish to open. Now quickly tap the touchpad twice with your nger to perform the
action. This action is equivalent to pressing the left mouse button twice. You can also press
the left touchpad button twice for the same effect.
3-4 Drag
Move your nger across the touchpad to move the cursor to the object you wish to drag.
Now hold down the left touchpad button with one hand and move the cursor to the desired
location. Release the button and complete the drag operation. You can also double tap the
object you wish to drag and keep the nger on the touchpad after the second tap to perform
the drag operation with one hand.

ViewSonic VNB102 10
Special Function Keys
The following denes some special function keys on the netbook.
Function Keys Description
Fn + F1 WWAN on or off
Fn + F2 Wireless LAN on or off
Fn + F3 Touchpad on or off
Fn + F4 Switches to the external display
Fn + F5 Audio on or off
Fn + F9 To terminate some applications
Fn + F10 Toggles the "Print Screen" key to initiate screen capture utility to capture, save or
print the contents of desktop
Fn + F11 F12 / Enters into the dialog box of "Save As" in Windows Ofce applications
Fn + Page Up Presses to move the cursor to the beginning of the line
Fn + Page Down Presses to move the cursor to the end of the line
Fn + Ins "Number Lock" on or off
Fn + Del "Scroll Lock" on or off
Fn + Esc Enter S3 mode
Fn + (up arrow) Increases the display brightness
Fn + (down arrow) Decreases the display brightness
Fn + (left arrow) Decreases the system volume
Fn + (right arrow) Increases the system volume

ViewSonic VNB102 11
Viewsonic System Recovery DVD/HDD Partition
Your computer supports system recovery to allow you to restore the system to its default
factory settings.
You can run the Recovery DVD, or recover the system from the hard disk partition, if you:
1. Have a system or hardware failure.
2. Need to restore the system to factory settings.
3. Have forgotten the system password.
4-1 Running the Recovery DVD
You will need to attach a DVD drive to the computer in order to access the Recovery DVD.
Make sure an external USB DVD drive is attached to the computer.
Start-up your notebook computer and press <del> to enter the BIOS.
Use the arrow keys to go to the Boot menu.
Set the CD/DVD-ROM Drive (make sure the Recovery DVD is inserted) as the rst device
in the boot order from the Boot menu (use the up/down arrow keys to select 1st Boot
Device, and then use the “+” or “-” keys to move the device up and down the order).
Select Save and Exit Setup from the Exit menu (or press F10) and press Enter to exit
the BIOS and reboot the computer.
Make sure the Recovery DVD is inserted into the external USB DVD drive.
As the computer boots up press a key when you see the message “Press any key to
boot from CD or DVD”.
Click RECOVERY TO FACTORY DEFAULT (button) when the Recovery System message
appears.
You will then receive a FinalConrmation warning to make sure you are aware that all
the partitions and data will be removed (if you need to back up data/partitions then click
No to exit and back up any data before running the Recovery DVD again).
If you are sure you want to delete all data and partitions then click Yes.
The tools will load and the recovery process will then begin (note that the keyboard and
mouse will be temporarily locked during the recovery process).
When the recovery process is complete the computer will restart.
Disconnect the external DVD drive and start up the computer.
You will then need to input your country and region preferences, passwords etc.
A short introductory video will appear before the system personalizes your settings.
When the system recovery is complete you can then restore any backed up data.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Other manuals for VNB102
1
This manual suits for next models
1
Table of contents
Other ViewSonic Laptop manuals

ViewSonic
ViewSonic ViewBook VS13550 User manual

ViewSonic
ViewSonic ViewBook VS13058 User manual

ViewSonic
ViewSonic VNB104 User manual

ViewSonic
ViewSonic NETBOOK VS12914 User manual

ViewSonic
ViewSonic ViewBook 109 User manual

ViewSonic
ViewSonic VNB131 User manual

ViewSonic
ViewSonic VS13329 User manual

ViewSonic
ViewSonic VB1200 User manual

ViewSonic
ViewSonic VNB102 User manual

ViewSonic
ViewSonic VNB108 ViewBook Quick start guide
