ViewSonic VNB131 User manual

- User Guide
- Guide de l’utilisateur
- Bedienungsanleitung
- Guía del usuario
-Pyководствопользователя
-Οδηγόςχρηστών
- 使用手冊(繁中)
ViewBook Pro
ViewSonic®
Model No. : VS13060

ViewSonic VNB131 i
Compliance Information
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low
Voltage Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical
and Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as
unsorted municipal waste, but use the return and collection systems
according to local law.
If the batteries, accumulators and button cells included with this
equipment, display the chemical symbol Hg, Cd, or Pb, then it means
that the battery has a heavy metal content of more than 0.0005%
Mercury, or more than 0.002% Cadmium, or more than 0.004% Lead.
R&TTE Compliance Statement
This wireless module device complies with the Essential Requirements of the
R&TTE Directive of the European Union (1999/5/EC). This equipment meets
the following conformance standards:
ETSI EN 300 328
EN 301 489-01
EN 301 489-17
NotiedCountries:Germany, UK, Netherlands, Belgium, Sweden, Denmark,
Finland, France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg,
Estonia, Latvia, Lithuania, Czech Republic, Slovakia, Slovenia, Hungary,
Poland and Malta.

ViewSonic VNB131 ii
Important Safety Instructions
1. DO NOT press or touch the LCD Screen. DO NOT place the notebook PC
with small items, they may scratch LCD Screen or enter the notebook PC.
2. DO NOT expose the notebook PC to dirty or dusty environments. Keep
the environment clean and dry.
3. DO NOT place the notebook PC on uneven or unstable work surface.
4. DO NOT place or drop objects on the top of the notebook PC. DO NOT
shove any foreign objects into the notebook PC. DO NOT cover the LCD
Screen strongly.
5. DONOTexposethenotebookPCtostrongmagneticorelectricalelds;
DONOTplacetheoppydisknearoronthenotebookPC,thatmay
causealossofdataontheoppydisk.
6. DO NOT leave the notebook PC facing the sun as it can damage the LCD
Screen, especially when in the car.
7. SAFE TEMPERATURE: This notebook PC should only be used in
environments with ambient temperatures between 5°C (41°F) and
35°C(95°F).
8. DO NOT expose the notebook PC to or use near liquids, rain, or moisture.
9. Caution: risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
10. DO NOT throw the notebook PC in municipal waste. Check local
regulations for disposal of electronic products. Please recycle the Battery
Pack, and check with your Local Authority or retailer for recycling advice.
11. The notebook PC and the Adapter may produce some heat during
operation or charging. DO NOT leave the notebook PC on your lap or
any part of your body in order to prevent discomfort or injury from heat
exposure.
12. INPUT RATING: Refer to the rating label on the notebook PC and be sure
that the Power Adapter complies with the rating. Only use accessories
speciedbythemanufacturer.
13. Check the connections between the main unit and attachments before
turning on the notebook PC.
14. DO NOT use the notebook PC while eating food, avoid dirtying the
notebook PC.

ViewSonic VNB131 iii
15. DO NOT insert anything into the notebook PC that may result in short
circuit or damage the circuit.
16. Power off the notebook PC, if you want to install or remove some external
devices, which do not support hot-plug.
17. Disconnect the notebook PC from the electrical outlet and remove any
installed batteries before cleaning the notebook PC. Keep the notebook
PC and its accessories away from children.
18. DONOTdisassemblethenotebookPC,onlyacertiedservicetechnician
should perform repairs on your computer.
19. Only use Battery Packs approved by the manufacturer or else damage
may occur.
20. The notebook PC has apertures to disperse heat. DO NOT place the
notebook PC on soft objects (e.g.: bed, sofa, your lap), or else the
notebook PC may become hot and the system may halt.

ViewSonic VNB131 iv
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive
2002/95/EC of the European Parliament and the Council on restriction of the
use of certain hazardous substances in electrical and electronic equipment
(RoHS Directive) and is deemed to comply with the maximum concentration
values issued by the European Technical Adaptation Committee (TAC) as
shown below:
Substance
Proposed Maximum
Concentration
Actual
Concentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers (PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the
Annex of the RoHS Directives as noted below:
Examples of exempted components are:
1.Mercuryincompactuorescentlampsnotexceeding5mgperlampandin
otherlampsnotspecicallymentionedintheAnnexofRoHSDirective.
2.Leadinglassofcathoderaytubes,electroniccomponents,uorescenttubes,
and electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85%
by weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight,
aluminium containing up to 0.4% lead by weight and as a cooper alloy
containing up to 4% lead by weight.

ViewSonic VNB131 v
Copyright Information
Copyright © ViewSonic®Corporation, 2009. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows®logo are registered
trademarks of Microsoft®Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter®are
registered trademarks of ViewSonic®Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
Disclaimer: ViewSonic®Corporation shall not be liable for technical or editorial
errorsoromissionscontainedherein;norforincidentalorconsequential
damages resulting from furnishing this material, or the performance or use of
this product.
In the interest of continuing product improvement, ViewSonic®Corporation
reservestherighttochangeproductspecicationswithoutnotice.Informationin
this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any
means, for any purpose without prior written permission from ViewSonic®
Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as
it becomes available, please register your product on the Internet at:
www.viewsonic.com. The ViewSonic®Wizard CD-ROM also provides an
opportunity for you to print the registration form, which you may mail or fax to
ViewSonic®.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VNB131
ViewSonic NoteBook
VS13060
VNB131-1_UG_ENG Rev. 1B 12-14-09
Product disposal at end of product life
ViewSonic®is concerned about the preservation of our environment. Please
dispose of this product properly at the end of its useful life. For the recycling
information, please refer to our website:
1. USA: www.viewsonic.com/company/green/recycle-program/
2. Europe: www.viewsoniceurope.com/uk/support/recycling-information/
3. Taiwan: recycle.epa.gov.tw

ViewSonic VNB131
Table of Contents
Chapter 1 Introduction.......................................................................... 1
1.1 Package Checklist................................................................................................1
1.2 Specications ......................................................................................................2
1.3 Knowing the Parts ...............................................................................................3
Top view..........................................................................................................3
Base view........................................................................................................5
Left view .........................................................................................................7
Right view .......................................................................................................7
1.4 Notebook usage ..................................................................................................8
Battery usage ..................................................................................................8
Installing the battery........................................................................................8
Removing the battery.......................................................................................9
Connecting to the AC power supply ...................................................................9
Startup .........................................................................................................10
Shutdown......................................................................................................10
Indicators......................................................................................................11
Touchpad ......................................................................................................12
Touchpad basics.............................................................................................12
Multi-Finger Touchpad ....................................................................................13
Using the keyboard ........................................................................................15
Lock keys and embedded numeric keypad .......................................................15
Windows keys................................................................................................16
Hotkeys.........................................................................................................16
Chapter 2 BIOS Setup Utility...............................................................17
2.1 When to Use BIOS Setup ...................................................................................17
2.2 How to Run BIOS Setup.....................................................................................17
2.3 Control Keys......................................................................................................17
2.4 Boot Device Priority ...........................................................................................18
2.5 BIOS Menu .......................................................................................................18
2.5.1 Main Menu ...........................................................................................18
2.5.2 Advanced Settings.................................................................................19
2.5.3 Security Settings ...................................................................................19
2.5.4 Boot Settings ........................................................................................20
2.5.5 Exit Settings..........................................................................................21
Chapter 3 System Recovery ................................................................22
How to restore the previously backed up system in Windows .....................................22
Restore the backed up system under DOS mode .......................................................25
Rescue the data under DOS mode............................................................................28
Troubleshooting ..................................................................................31

ViewSonic VNB131 1
Chapter 1 Introduction
1.1 Package Checklist
Thank you for choosing ViewSonic ViewBook Pro.
Please check if the packaging or any of the below listed accessories are damaged or
missing, in which case please contact with ViewSonic local representative ofce.
• ViewBook Pro notebook computer
• Power Cord
• Power Adapter
• Quick Start Guide
• ViewSonic User Guide CD Wizard
• System Recovery Disc or Driver disc (recovery disc comes with models bundled with
an operating system only)
• Lithium-lon Battery
• Screen Wiping Cloth
* The items listedabove are for reference only, and are subject tochange without notice.
* Depending on the model you purchased, the actual appearance of your notebook mayvary from that
shown inthis manual.

ViewSonic VNB131 2
1.2 Specications
CPU - INTEL®CoreTM 2 Duo Processor ULV SU7300
Chipset - Intel® GS45/40+ICH9M
LCD Screen - 34cm/13.3” WXGA color TFT-LCD with LED Backlight
- Resolution: 1280*800 pixels
Power Management - ACPI V3.0
- S0, S3, S4, S5 support
System Memory - DDR2 667/800MHz (Single Channel)
- DDR2 SO-DIMM slot supports up to 2GB (one slot)
Mass Storage - Support SATA HDD
- 6.35cm/2.5” 9.5mm HDD
User Interface
- 7 in 1 Card Reader (supports MS/MS Pro/MS Duo/SD/miniSD/
MMC/RSMMC)
Note: MS Duo, miniSD, RSMMC, MS Pro require an adapter
- 2 x 4-pin USB2.0 Ports
- 1 x VGA Port
- 1 x HDMI Port
- 1 x CD-ROM/Second battery/Module (Optional)
- 1 x Express card Slot
- 1 x MIC
- 1 x Line Out
- 1 x RJ45 Port
- 1 x DC-In Port
Audio - Azalia Codec supports 2.1 channel output
- Built-in audio connector and mic connector
Digital Camera - Build-in 1.3 megapixels camera
Ethernet LAN - 10/100Mbps Fast Ethernet Support
Wireless LAN - Mini PCI-E interface, supports 802.11b/g/n
Bluetooth - Bluetooth™ v2.1+EDR
Battery - 6 cells Li-Ion battery pack, 10.8V/47.52Wh, supports an
additional 3-cell Li Ion Battery Pack (Optional)
Dimensions - 322 x 239 x 17~25 mm
- 12.68 x 9.41 x 0.67~1 inch
Weight - Less than 1.5 kg/3.30 lbs (including 3 cell Li-Ion battery pack)

ViewSonic VNB131 3
1.3 Knowing the Parts
After having checked the package and installed your ViewBook Pro, let’s get familiar
with its parts.
Top view
1
1
1
4
5
87
6
3
2
9

ViewSonic VNB131 4
NO. Item Description
1Built-in Camera The built-in camera allows you to snap a photo or create a video chat or
video conference with just a click.
2Display screen Also called Liquid-Crystal Display (LCD), displays computer output.
3
Power and
hard disk
locking button
Pressing power button turns your notebook on and off. Pressing the anti-
theft lock button activates the ViewSensor; if anyone attempts moving your
ViewBook Pro, the notebook will sound an alarm; to unlock your notebook
or deactivate the alarm you must input your password or use the ngerprint
scanner.
4Keyboard A full-size keyboard with dedicated Windows® keys.
5Touchpad Touch-sensitive pointing device which functions like a computer mouse.
6Fingerprint sensor Collects and recognizes ngerprint information. (Optional)
7Click buttons (left
and right) The left and right buttons function like the left and right mouse buttons.
8Status indicators Light-Emitting Diodes (LEDs) that light up to show the status of the
computer’s functions and components.
9Palmrest Comfortable support area for your hands when you use the computer.

ViewSonic VNB131 5
Base view

ViewSonic VNB131 6
NO. Item Description
1Battery Pack
The battery pack is automatically charged when your ViewBook Pro is
connected to an AC power source. It maintains power to your ViewBook Pro
when AC power is not connected. This allows for use of ViewBook Pro when
AC power outlet is not available. Battery time varies with the way you use
your ViewBook Pro. The battery pack cannot be disassembled and must be
purchased as a single unit.
2Battery Lock -
Manual
The manual battery lock is used to keep the battery pack secured. Move the
manual lock to the unlocked position to insert or remove the battery pack.
Move the manual lock to the locked position after inserting the battery pack.
3Fan Outlets
These are vents for the fan to dissipate heat from the computer’s internal
components. Do not block or place the computer in such a position that you
inadvertently allow the outlets to become blocked.
4Speakers Left and right speakers deliver stereo audio output.
5CD-ROM locking
knob
Place your ViewBook Pro up side down, use a at tool like a screwdriver or a
coin to whirl the knob clockwise, the knob will unlock the bay. Now you can
pull out the Super Multi Drive and install the Secondary Battery Pack or an
expansion module.
6Battery Lock -
Spring
The spring battery lock keeps the battery pack secured. When the battery pack
is inserted, the spring battery lock will automatically lock. When removing the
battery pack, this spring lock must be retained in the unlocked position.

ViewSonic VNB131 7
Left view
NO. Item Description
1DC-in jack Connects an AC adapter to ViewBook Pro.
2Ethernet (RJ-45) port Connects to an Ethernet 10/100-based network.
3Fan Outlets These are vents for the fan to dissipate heat from the computer’s internal
components. Do not block or place the computer in such a position that you
inadvertently allow the outlets to become blocked.
4VGA port Connects to a display device. (e.g., external monitor, LCD projector).
5HDMI port Connects to multimedia devices of HDMI protocol.
6PCI Express slot Here PCI Express expansion cards can be inserted.
7Memory Card
Reader
The memory card reader offers the fastest and most convenient method to
transfer pictures, music and data between your netbook and devices using
ash memory cards such as digital cameras, MP3 players, mobile phones,
and PDAs. (Optional).
Right view
NO. Item Description
1Tray release
Use a sharp tool like a paper clip to push the button inside the tray
release hole to open Super Multi Drive tray when ViewBook Pro can-
not be turned on due to unavailability of electricity or in case a Super
Multi Drive is not responding for a long time to pressing the open-
tray button.
2Open- tray button Press this button to open the Super Multi Drive tray.
3Super Multi Drive Plays and records CD or DVD discs. (Optional).
4USB 2.0 ports Connects to USB 2.0 devices. (e.g., USB mouse, USB camera).
5Microphone-in jack Accepts input from external microphones.
6Headphones / speaker /
line-out jack Connects to audio line-out devices. (e.g., speakers, headphones).

ViewSonic VNB131 8
1.4 Notebook usage
Battery usage
ViewBook Pro has two sources of power supply – the battery and the power adapter.
Before turning on your ViewBook Pro, please install the battery or connect the power
adapter.
Installing the battery
1. Turn ViewBook Pro up side down and place it on a at surface;
2. Gently push the battery lock into unlocked position;
3. Slide the battery into its slot. When doing so make sure the battery goes exactly
along its slides. The battery should be able to get on its place smoothly, don’t force
it into its position if you have difculties installing it, or you may damage your View-
Book Pro or the battery.
4. Having pushed the battery to the end you will hear a click sound. Then push the
battery lockers into the locked position.
When using your ViewBook Pro for the rst time, we suggest connecting the power adapter
and allowing for the battery to charge for at least 8 hours. Please note that the battery will
reach its best condition only after several charge/discharge cycles.
The battery charging normally starts once the battery charge drops below 98%. First the
master battery is charged. Once it is full, the secondary (optional) battery is charged. The
discharge process is opposite – the secondary battery is used rst and once it is empty the
master battery takes over.

ViewSonic VNB131 9
Removing the battery
1. Shut down your ViewBook Pro and disconnect external devices and the power
adapter;
2. Turn ViewBook Pro up side down and place it on a at surface;
3. Push the battery locks into the unlocked position.
4. Pulling the spring battery lock into the unlock position, remove the battery.
5. The battery should be able to get out of its placement smoothly, don’t force it out of
its position if you have difculties removing it, or you may damage your ViewBook
Pro or the battery.
Please don’t remove the battery when your netbook is undergoing POST (at startup), or it may
destroy the data on your HDD or cause other problems.
Connecting to the AC power supply
1. Connect the power cord to the power adapter;
2. Connect the power cord to the AC power outlet;
3. Push the DC power connector of the power adapter into the power jack in your
ViewBook Pro.
ViewBook Pro is supplied with DC power of +19V @ 65W and the power adapter can accept
AC 110~240V, 50~60HZ outputting +19V, 3.42A.

ViewSonic VNB131 10
Startup
1. Open the lid of your ViewBook Pro.
Please don’t force the lid to open beyond its extreme position, or it may damage the lid hinge.
Please don’t carry the open ViewBook Pro by holding it by its lid.
2. Press power button to start.
1
Shutdown
1. When using Microsoft Windows, click on “Shutdown” item in “Start” menu to shut
down the operating system.
2. You can also short-press the Power button to shutdown your ViewBook Pro.
3. If your OS is not responding, so you cannot shutdown or restart your computer the
normal way, do the long-press on the Power button for about 6 seconds until your
ViewBook Pro turns off (cold power off). Please note that this should be used only
when your OS is not responding and there is no other way to shutdown or restart,
as doing the cold power off may result in a data loss.

ViewSonic VNB131 11
Indicators
ViewBook Pro has several easy-to-read status indicators.
Icon Function Description
Power and hard
disk locking
When the system is turned on, the white LED on the Power button glows
continuously.
When ViewBook Pro is off, the white LED on the Power button is off.
White LED hint: Press the hard disk locking button to lock your ViewBook
Pro, the white LED on the Power button will start pulsating. If you move your
ViewBook Pro from its place while it is in the locked mode, a loud alarm will
sound and it will go on until you scan your ngerprint or log into Windows with
your the password.
HDD A blinking HDD LED suggests an HDD activity (data is being read or written).
Wireless LAN Indicates the status of wireless LAN communication.
1
Num Lock Lights up when Num Lock is activated.
DC-IN
When the battery is charging, the DC socket LED is fading in and out in
green color; once the battery has been charged, the DC socket LED glows
continuously in green color. When ViewBook Pro is in Sleep mode the DC socket
LED would be pulsating in white color.
Caps Lock Once Caps Lock is on, the LED on the Caps Lock button would be glowing.

ViewSonic VNB131 12
Touchpad
The built-in touchpad is a pointing device that senses movement on its surface. The
cursor responds as you move your nger across the surface of the touchpad.
Touchpad basics
The following items show you how to use the touchpad:
• Move your nger across the touchpad (1) to move the cursor on the display (2).
• Move your nger up or down across the right edge of the touchpad (5) to scroll.
• Press the left (3) and right (4) buttons located beneath the touchpad to perform
selection and execution functions. These two buttons are similar to the left and right
buttons of a mouse. Tapping on the touchpad is the same as clicking the left button.
Function Left button (3) Right button (4) Main touchpad (1)
Execute Quickly click twice. Tap twice (at the same speed as double
clicking a mouse button).
Select Click once. Tap once.
Drag
Click and hold, then use
nger on the touchpad
to drag the cursor.
Tap twice (at the same speed as double
clicking a mouse button), rest your
nger on the touchpad on the second
tap and drag the cursor.
Access context menu Click once.
When using the touchpad, keep it — and your fingers — dry and clean. The touchpad is
sensitive to nger movement, hence, the lighter the touch, the better the response. Tapping
harder will not increase the touchpad’s responsiveness.

ViewSonic VNB131 13
Multi-Finger Touchpad
Start the whole new experience
Scroll
